tow Citroen DS4 2016 1.G Workshop Manual

273
DS4_en_Chap09_info-pratiques_ed03-2015
Be ready for the weight of the towball
(around 3.5 kg). Risk of injury!
Grasp the towball firmly with one hand; with
the other hand, press and turn the locking
wheel
clockwise as far as it will go.
Extract the towball downward. Refit the protective cover for the ball and the
protective cover for the locking wheel.
Stow the towball in its bag.
Refit the protective blanking plug to the carrier.
Maintenance
Correct operation is only possible if the towball
and its carrier remain clean.
Before cleaning the vehicle with a high pressure
jet wash, the towbar harness socket carrier must
be folded away, the towball removed and the
blanking plug inserted in the carrier.
For any work on the towbar, got to a CITROËN
dealer or a qualified workshop.
Practical information

DS4_en_Chap09_info-pratiques_ed03-2015
AccessoriesA wide range of accessories and genuine parts is available from the CITROËN dealer network.
These accessories and parts are all suitable for your vehicle and benefit from CITROËN's recommendation and warranty.
"Comfort":
door deflectors, side window blinds, rear
screen blind, isotherm module, coat hanger
fixed to head restraint, mobile reading lamp,
mirror for caravan, scented ar freshener and
cartridges, front and/or rear parking sensors...
"Transport systems":
child seats and booster cushions, boot carpet,
boot liner, boot net, boot spacers, transverse
roof bars, bicycle carrier, ski carrier, DS roof
boxes, towbars, wiring harnesses...
"Styling":
gear lever knobs, aluminium foot rest, alloy
wheels, chrome mirror shells...
"Security and safety":
anti-intrusion alarm, anti-tilt unit, stolen
vehicle tracking system, child seats and
booster cushions, breathalyser, first aid kit, fire
extinguisher, dog guard, pet seat belt, warning
triangle, high visibility vest, wheel security
bolts, snow chains, non-slip covers...
If a towbar and wiring harness are fitted
outside the CITROËN dealer network,
the installation must be done following
the manufacturer's recommendations. *

T
o avoid any risk of jamming the pedals:
-

e
nsure that mats are correctly positioned
and secured,
-

n
ever fit one mat on top of another.
"Protection":
mats*, seat covers compatible with lateral
airbags, mud flaps, door protective mouldings,
bumper protection strips, boot sill protectors,
vehicle cover, protective covers for pets...

A dYNAMIC PARTNERSHIP,
dI
RECTE d TOWAR
dS T
HE FUTURE.
For more than 45 years, TOTAL and DS have
shared common values: excellence, creativity and
technological innovation.
It is in this same spirit that TOTAL has developed a
range of TOTAL QUARTZ lubricants adapted to DS
engines,
making them even more fuel efficient and protective of
the environment.
Choose TOTAL QUARTZ lubricants
for servicing your vehicle,
this is your assurance of optimum
durability and per formance from your
engine.

279
DS4_en_Chap10_verifications_ed03-2015
Fuel tankCapacity of the tank: approximately 60 litres.
Low fuel level
When the low fuel level in the
tank is reached, this warning lamp
comes on in the instrument panel,
accompanied by an audible warning
Refuelling
F Press control A until the automatic opening of the fuel flap is heard.
T

his control remains active for a few
minutes after switching off the ignition. If
necessary, switch the ignition on again to
reactivate it.
F

T
ake care to select the pump that delivers
the correct fuel for your vehicle.
With Stop & Start, never refuel with the
system in STOP mode; you must switch
off the ignition with the key, or the
START/STOP button if your vehicle has
Keyless Entry and Starting.
Additions of fuel must be of at least 5 litres to
be registered by the fuel gauge.
Opening the filler cap may result in an inrush of
air. This vacuum is entirely normal and results
from the sealing of the fuel system.
and the display of an alert message. When it
first comes on, around 6 litres of fuel remain
in the tank.
Until sufficient fuel has been added, every
time the ignition is switched on, this warning
lamp appears, accompanied by an audible
signal and an alert message. When driving,
this audible signal and the display of this
alert message are repeated with increasing
frequency, as the level drops towards 0
.
You must refuel as soon as possible to avoid
running out.
If you run out of fuel (Diesel), refer to the
corresponding section.
Checks

293
DS4_en_Chap10_verifications_ed03-2015
Electric parking brake
This system does not require any
routine servicing. However, in the
event of a problem, have the system
checked by a CITROËN dealer or a
qualified workshop.Only use products recommended by
CITROËN or products of equivalent
quality and specification.
In order to optimise the operation of
units as important as those in the
braking system, CITROËN selects and
offers very specific products.
After washing the vehicle, dampness,
or in wintry conditions, ice can form
on the brake discs and pads: braking
efficiency may be reduced. Make light
brake applications to dry and defrost
the brakes.
Brake disc wear
For information on checking brake
disc wear, contact a CITROËN dealer
or a qualified workshop.
Manual parking brake
If a loss of effectiveness of this
system is noticed, the parking brake
must be checked, even between two
services.
Brake pads
Brake wear depends on the style
of driving, particularly in the case
of vehicles used in town, over short
distances. It may be necessary to have
the condition of the brakes checked,
even between vehicle services.
For more information on the electric parking
brake, refer to the corresponding section.
Unless there is a leak in the circuit, a drop in
the brake fluid level indicates that the brake
pads are worn.
Checking this system must be done by a
CITROËN dealer or a qualified workshop.
Checks

DS4_en_Chap11_caracteristiques_ed03-2015
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for
each additional 1 000 metres of altitude.
When towing, the maximum authorised speed is reduced (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.
Petrol weights and towed loads (in kg)
Petrol engineV Ti 120PureTech 130 S&S THP 15 0
Gearbox Manual

(5 - speed) Manual
(6- speed) Automatic
(6- speed)
Model code:
NX... 5FS0

5FS0/1 HNYM/S
HNYM/1S - /2S 5FEA
-

U
nladen weight 1 2051 2551 363
-

K
erb weight* 1 2801 330 1 438
-

G
ross vehicle weight
(GV W) 1 755
1 790 1 835
-

G
ross train weight (GTW)
o

n a 12 % gradient 2 955
2 990 2 635
-

B
raked trailer (within the GTW limit)
o

n a 12 % gradient 1 200
1 200 800
-

B
raked trailer** (with load transfer within the
GTW limit) 1 450
1 4501 000
-

U
nbraked trailer 640675715
-

R
ecommended nose weight 757575
*

T
he kerb weight is equal to the unladen weight + driver (75 kg).
**

T
he weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount. Warning:
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.

309
DS4_en_Chap11_caracteristiques_ed03-2015
Petrol engineTHP 160THP 165 S&S THP 200THP 210 S&S
Gearbox Automatic

(6- speed) EAT6 automatic
(6- speed) Manual

(6- speed) Manual
(6- speed)
Model code:
NX... 5FMA
5GZT/S
5GZ T/1S 5FU8

5FU8/1 5GMM/S
-

U
nladen weight 1 3631 3101 316 1 313
-

K
erb weight* 1 4381 385 1 3911 388
-

G
ross vehicle weight (GV W) 1 8351 850 1 8201 845
-

G
ross train weight (GTW)
o

n a 12 % gradient 2 635
3 2502 8202 845
-

B
raked trailer (within the GTW limit)
o

n a 12 % gradient 800
1 400 1 000 1 000
-

B
raked trailer** (with load transfer within the
GTW limit) 1 000
1 6501 2501 250
-

U
nbraked trailer 715690 695655
-

R
ecommended nose weight 75757575
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for
each additional 1 000 metres of altitude.
When towing, the maximum authorised speed is reduced (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load. * The kerb weight is equal to the unladen weight + driver (75 kg).
**

T
he weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount. Warning:
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
Technical data

DS4_en_Chap11_caracteristiques_ed03-2015
diesel enginee-H d i 115BlueH d i 115 S&S
Gearbox Manual

(6- speed) Manual
(6- speed) EAT6 automatic
(6- speed)
Model code:
NX... 9H
d8

/S
9H
d8

/1SBHXM/S
BHXM/1S -/2S -/3S BHX T/1S
BHX T/2S
-

U
nladen weight 1 2951 290 1 310
-

K
erb weight* 1 3701 365 1 385
-

G
ross vehicle weight (GV W) 1 8101 860 1 890
-

G
ross train weight (GTW)
o

n a 12 % gradient 3 11 0
3 160 3 090
-

B
raked trailer (within GTW limit)
o

n 12 % gradient 1 300
1 300 1 200
-

B
raked trailer** (with load transfer with the
GTW limit) 1 550
1 550 1 450
-

U
nbraked trailer 680680640
-

R
ecommended nose weight 757575
Diesel weights and towed loads (in kg)
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for
each additional 1 000 metres of altitude.
When towing, the maximum authorised speed is reduced (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load. * The kerb weight is equal to the unladen weight + driver (75 kg).
**
T
he weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount. Warning:
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.

313
DS4_en_Chap11_caracteristiques_ed03-2015
diesel engineBlueH d i 120 S&S BlueH d i 150 S&S BlueH d i 180 S&S
Gearbox Manual

(6- speed) EAT6 automatic

(6- speed) Manual
(6- speed) EAT6 automatic
(6- speed)
Model code:
NX... BHZM/S

BHZM/1S -/2S -/3S BHZT/SAHRM/S
AHRM/1S -/2S AHW T/S
AHW T/1S - /2S
-

U
nlade weight 1 2901 3101 4101 410
-

K
erb weight* 1 3651 4151 485 1 495
-

G
ross vehicle weight (GV W) 1 8601 890 1 935 1 975
-

G
ross train weight (GTW)
o

n a 12 % gradient 3 160
3 090 3 235 3 275
-

B
raked trailer (within GTW limit)
o

n 12 % gradient 1 300
1 2001 300 1 300
-

B
raked trailer** (with load transfer with the
GTW limit) 1 550
1 4501 550 1 550
-

U
nbraked trailer 680640 74 074 5
-

R
ecommended nose weight 75757575
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for
each additional 1 000 metres of altitude.
When towing, the maximum authorised speed is reduced (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load. * The kerb weight is equal to the unladen weight + driver (75 kg).
**

T
he weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount. Warning:
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
Technical data

1
7
8
12
9
13
10
14
11
15
2
3
4
5
6
329
DS4_en_Chap12c_SMEGplus_ed03-2015
Level 1Level 2 Level 3 Comments
Navigation
Secondary page
Enter destination Address
Curr. location
Address settings
Points of Interest
Town centre
Save Save the current address.
Add waypoint Add a waypoint to the route.
Navigate to Press to calculate the route.
Contacts Addresses
Select a contact then calculate the route.
View
Navigate to
Search for contact
Call
From map Display the map and zoom to view the roads.
Itinerary Create, add or delete a waypoint or view the
itinerary.
Stop Delete navigation information.
Navigate to Press to calculate the route.
Audio and Telematics
