Deactivate the interior volumetric and anti-tilt
monitoring to avoid unwanted triggering of the alarm in cer tain cases such as: - leaving a pet in the vehicle, - leaving a window par tially open, - washing your vehicle, - changing a wheel, - having your vehicle towed, - transpor t by sea.
Locking the vehicle
with exterior perimeter
monitoring only
Deactivation of the interior volumetric and anti-tilt monitoring
 Switch off the ignition.  Within ten seconds, press the button until the indicator lamp is on continuously.
 Get out of the vehicle.  Press the locking button on the remote control immediately.
The exterior perimeter monitoring alone is activated: the indicator lamp in the button flashes once per second.
To be effective, this deactivation must
be carried out each time the ignition is switched off.
Reactivation of the interior volumetric and anti-tilt monitoring
 Press the unlocking button on the remote control to deactivate the exterior perimeter
monitoring.  Press the locking button on the remote control to activate all the monitoring
functions. The indicator lamp in the button again flashes once per second.

111Access
To lock or unlock the doors manually in the
event of a malfunction of the central locking system or battery failure.
Emergency control
Locking the driver's door
 Inser t the key in the lock, then turn it to the rear.
Unlocking the driver's door
 Inser t the key in the lock, then turn it to the front.
Locking the front and rear passenger doors
 On the rear doors, check that the child lock is not activated.  Remove the black cap, located on the edge of the door, using the key.  Inser t the key in the socket without forcing it, then without turning it, move the latch sideways towards the inside of the door.  Remove the key and refit the cap.
Unlocking the front and rear passenger doors
 Pull the interior door opening control.

Visibility
Model without AUTO lighting
Model with AUTO lighting
Manual controls
The lighting commands are issued directly
by the driver by means of the ring A and the stalk B .
Automatic illumination of headlamps.
B. Stalk for switching headlamps: pull the stalk towards you to switch the lighting between dipped and main beam headlamps. In the lamps off and sidelamps modes, the driver can switch on the main beam headlamps temporarily ("headlamp flash") by maintaining a pull on the stalk.
A. Main lighting mode selection ring: turn it to position the symbol required facing the mark.
Lamps off.
Sidelamps only.
Dipped headlamps or main beam headlamps.
Displays
Illumination of the corresponding indicator
lamp in the instrument panel confirms that the lighting selected is on.

129Visibility
System for selection and control of the various front and rear wiping modes for the elimination of rain and cleaning the screens. The vehicle's front and rear wipers are designed to improve the driver's visibility according to the climatic conditions. The wipers are controlled by means of stalk Afor the front and the ring B for the rear.
Wiper controls
Programming
Model without AUTO wiping
Various automatic wiper control modes are also available depending on whether the following options are fitted: - automatic rain sensitive windscreen wipers, - rear wiping on engaging reverse gear.
Model with AUTO wiping
Windscreen wiper
A. Wiping speed control stalk: raise or lower the stalk to the desired position.
Single wipe (press downwards or pull towards you, then release).
Automatic wiping (press down, then release).
Single wipe (pull the stalk briefly towards you).
Fast wiping (heavy rain).
Normal wiping (moderate rain).
Intermittent wiping (propor tional to the speed of the vehicle).
Park,
or

Visibility
Windscreen and headlamp
wash
 Pull the windscreen wiper stalk towards you. The windscreen wash then the windscreen wipers operate for a fixed period. The headlamp washers only operate when the dipped beam headlamps are on .
Low screenwash/headlamp wash level
The low level of this fluid is indicated by gauge in the reser voir filler neck under the bonnet. Checking and topping up this fluid can only be done when stationary with the engine off.
On vehicles fitted with headlamp washers, the driver should check the level of this fluid regularly, par ticularly during winter.
Refer to "Checks - § Screenwash/headlamp
wash level" for the procedure on checking the level.

Longitudinal adjustment
Front armrest Comfor t and storage device for the driver and front passenger. The length of the armrest cover can be adjusted.
The armrest's compar tment can hold up to 6 CDs.  Raise the cover fully.
Storage
 To move for wards, raise the lever. The armrest slides for wards to its stop.  To stow it, slide it fully back and press down to lock it.

Longitudinal adjustment
Front armrest Comfor t and storage device for the driver and front passenger. The length of the armrest cover can be adjusted.
The armrest's compar tment can hold up to 6 CDs.  Raise the cover fully.
Storage
 To move for wards, raise the lever. The armrest slides for wards to its stop.  To stow it, slide it fully back and press down to lock it.

163Child safety
Your vehicle has been approved in accordance with the new ISOFIX regulation . The seats, represented below, are fitted with regulation ISOFIX mountings:
"ISOFIX" mountings
There are three rings for each seat: - two rings A , located between the vehicle seat back and cushion, indicated by a label,
- a ring B , behind the seat, referred to as the TOP TETHER for fixing the upper strap.
This ISOFIX mounting system provides fast, reliable and safe fitting of the child seat in your vehicle.
The incorrect installation of a child seat
in a vehicle compromises the child's protection in the event of an accident.
For information regarding the ISOFIX child seats which can be installed in your vehicle, refer to the table showing the locations for
installing ISOFIX child seats.
When fitting an ISOFIX child seat to the left hand rear seat, before fitting the seat, first move the centre rear seat belt towards the middle of the vehicle, so as to avoid the seat inter fering with the operation of the seat belt.
The ISOFIX child seats are fitted with two locks which are secured on the two rings A . Some seats also have an upper strap , known as the Top Tether, which is attached to ring B . To attach this strap, raise the vehicle seat's head restraint then pass the hook between its rods. Then fix the hook on ring B and tighten the upper strap.

Direction indicators
 Left: lower the lighting stalk passing the point of resistance.  Right: raise the lighting stalk passing the point of resistance.
"Motorway" function
 Press briefly upwards or downwards, without going beyond the point of resistance; the direction indicators will flash 3 times.
Hazard warning
lamps
A visual warning by means of the direction indicators to aler t other road users to a vehicle breakdown, towing or accident.  Press this button, the direction indicators
flash. They can operate with the ignition off.
If you forget to cancel the direction indicators for more than twenty seconds, the volume of the audible signal will increase if the speed is above 40 mph (60 km/h).

Direction indicators
 Left: lower the lighting stalk passing the point of resistance.  Right: raise the lighting stalk passing the point of resistance.
"Motorway" function
 Press briefly upwards or downwards, without going beyond the point of resistance; the direction indicators will flash 3 times.
Hazard warning
lamps
A visual warning by means of the direction indicators to aler t other road users to a vehicle breakdown, towing or accident.  Press this button, the direction indicators
flash. They can operate with the ignition off.
If you forget to cancel the direction indicators for more than twenty seconds, the volume of the audible signal will increase if the speed is above 40 mph (60 km/h).
