Monitoring
Power steeringfixed. The power steering has a fault. Drive carefully at reduced speed.
Have it checked by a CITROËN dealer or a qualified
workshop.
Under-inflatedtyrefixed. The pressure in one or more wheels
is too low.Check the pressure of the tyres as soon as possible.
This check should preferably be carried out when
the tyres are cold.
Directional headlampsflashing. The directional headlamps system
has a fault.Have it checked by a CITROËN dealer or a qualified workshop.
Warning lampis onCauseAction/Observations
Foot on the brakepedalfixed. The brake pedal is not pressed. With the 6 -speed electronic gearbox system, press
the brake pedal to star t the engine (lever in position N).
If you wish to release the parking brake withoutpressing the brake pedal, this warning lamp willremain on.
flashing. With the 6-speed electronic gearbox
system, if you hold the vehicle on an
incline using the accelerator for too long, the clutch overheats.Use the brake pedal and
/or the electric parking brake.
Airbags
temporarily. This lamp comes on for a fewseconds when you turn on the
ignition, then goes off. This lamp should
go off when the engine is started.
If it does not go off, contact a CITROËN dealer or a qualified workshop.
fix
ed. One of the airbag or seat belt pretensioner systems has a fault. Have it checked by a CITROËN dealer or a qualified
workshop.
Page 52 of 396
Warning lampis onCauseAction/Observations
Left-hand
direction indicator
flashing with buzzer. The lighting stalk is pushed down.
Right-handdirection indicator
flashing with buzzer. The lighting stalk is pushed up.
Sidelamps
fixed. The lighting control is in the"Sidelamps" position.
On vehicle where the daytime running lamps are deactivated,
if the lighting control is in the "AUTO" position, the sidelampscome on as a luminous signature of the vehicle.
Dipped beam headlamps
fixed. The lighting stalk is in the "Dipped beam
headlamps" position or in the "AUTO"
position in conditions of low li
ght.
Main beamheadlamps
fixed. The lighting stalk is pulled towards you. Pull the stalk again to return to dipped beam
headlamps.
Front foglamps
fixed. The front foglamps are switched on. Turn the ring on the stalk rear wards twice to switch off
the front foglamps.
Rear foglamps fixed. The rear foglamps are switched on. Turn the ring on the stalk rear wards to switch off the rear foglamps.
Hazard warninglamps flashing with audible
signal. The hazard warning lamps switch, located on the dashboard, has beenoperated. The le
ft-hand and right-hand direction indicators and
their associated indicator lamps flash simultaneously.
Operation indicator lamps
If one of the following indicator lamps comes on, this confirms that the corresponding system has come into operation.
It may be accompanied by an audible signal and a message on the multifunction screen.
Page 53 of 396
51Monitoring
Warning lampis onCauseAction/Observations
Parking brakefixed. The parking brake is applied or not
properly released. Release the parking brake to switch off the warning lamp, keeping your foot on the brake pedal.Observe the safety recommendations.
For fur ther information on the parking brake, refer to
the "Driving" section.
Electric parkingbrakefixed. The electric parking brake is applied. Release the electric parking brake to switch off the warning lamp: with your foot on the brake pedal,pull the electric brake control. Observe the safety recommendations.
For more information on the electric parking brake,refer to the "Driving" section.
Deactivation of the automaticfunctions of theelectric parking brake
fixed. The "automatic application" (on switching off the engine) and"automatic release" functions are
deactivated or faulty. Activate the
function (according to country) via the
vehicle configuration menu or contact a CITROËN
dealer or a qualified workshop.
Diesel enginepre-heatingfixed. The ignition switch is at the2nd position (ignition on). Wait until the warning lamp goes off before star ting.
The period of illumination of the warning lamp is
determined by the climatic conditions (up to about
thirty seconds in extreme climatic conditions).
If the en
gine does not star t, switch the ignition off and
then on, wait until the warning lamp goes off again,
then star t the engine.
Page 54 of 396
Lighting dimmer fixed. The lighting dimmer is making an
adjustment. You can adjust the level of illumination of the
instruments between 1 and 16.
Passenger's airbag systemfixed in the seat beltand passenger's front airbag warning lamps
display.
The control switch, located in the glove
box, has been placed in the "ON"
position.
The passen
ger's front airbag is activated.
In this case, do not install a "rear facing"child seat.
Move the control switch to the "OFF"
position
to deactivate the passenger's front airbag.
In this case, you can install a "rear facing" child seat.
Automatic wiping
fixed. The wiper control is pushed
downwards. Automatic front wipin
g is activated.
To deactivate automatic wipin
g, operate the control stalk downwards or put the stalk into another position.
Warning lampis onCauseAction/Observations
Stop & Startfixed. When the vehicle stops (red lights,
traffic jams, ...) the Stop & Star t system has put the engine into STOPmode.The warnin
g lamp goes off and the engine restarts
automatically in START mode, as soon as you want
to move off.
fl
ashes for a few seconds, then goesoff. STOP mode is temporaril
y unavailable. or STA R T mode is invokedautomatically. Refer to "Drivin
g - § Stop & Star t" for special cases
with STOP mode and STA R T m o d e .
Parking space sensorsfixed.The parking space sensors function
is selected.To star t measurement, operate the direction indicator
on the side of the space to be measured, and do notexceed 12 mph (20 km/h). A message is displayed
once t
he measurement has been completed.
Page 55 of 396
53Monitoring
Passenger'sairbag systemfixed in the instrument panel and/or seat beltand front passenger'sairbag warning lamps
display.
The control switch, located in theglove box, is set to the OFFposition.
The passenger's front airbag is deactivated.
Set the control to the "ON"
position to activate
the passenger's front airbag.
In this case, do not fit a child seat in the rear-facingposition.
Warning lampis onCauseAction/Observations
ESP/ASRfixed. The button, located at the bottom left of the dashboard, is pressed. Its
indicator lamp is on.
The ESP/ASR is deactivated.
ESP: electronic stability programme.
ASR: anti-slip regulation.Pr
ess the button to activate the ESP/ASR. Its indicator lamp goes off.
The ESP/ASR system is activated automatically when
the vehicle is started.
If deactivated, the system is reactivated automatically
from around 30 mph (50 km/h).
Deactivation indicator lamps
If one of the following indicator lamps comes on, this confirms that the corresponding system has been switched off intentionally.
This is may be accompanied by an audible signal and a message on the multifunction screen.
Page 56 of 396
This information is displayed for a few seconds
when the ignition is switched on, at the same
time as the service information.
Engine oil level indicator
The vehicle must be on level groundand the engine must have been off for more than 30 minutes for this levelcheck to be accurate.
Oil level correct
Oil level incorrect
This is indicated by the flashing of "OIL"
or the display of a specific message in
the instrument panel, coupled with the ser vice
warning lamp and accompanied by an audible
signal.
If the low oil level is confirmed by a checkusing the dipstick, the level must be topped up
to avoid damage to the engine.
Oil level indicator error
This is indicated by the flashing of "OIL--"
or the display of a specific message in the
instrument panel. Contact a CITROËN or aqualified workshop.
Th
ere are 2 marks on the
dipstick:
-
A= max; never exceed
this level (risk of damage to
the engine), -B= min; top up the level via
the oil filler cap, using the correct grade of oil for your engine.
Dipstick
Refer to the "Checks" section to locate the
dipstick and the oil filler cap on your engine.
Page 57 of 396
55
Monitoring
This information is displayed for a few seconds
after switching on the ignition. It informs the
driver when the next ser vice is due,
in
accordance with the manufacturer'sservicing schedule.
The point at which the ser vice is due is calculated from the last service indicator zero
reset. It is determined by two parameters:
- the distance travelled,
- the time elapsed since the last ser vice.
Service indicator
Between 600 miles (1 000 km)and 1 800 miles (3 000 km) remainbefore the next service is due
For a few seconds after the ignition is switched
on, the spanner symbolising the ser vice
operations comes on. The distance recorder
display line or a specific message in the instrument panel central screen indicates the
distance remaining before the next ser vice is due.
For example:1 700 miles (2 800 km) remainbefore the next service is due.
For a few seconds after the ignition is switched
on, the screen indicates:
Less than 600 miles (1 000 km) remain
before the next service is due
Example:560 miles (900 km) remain before
the next service is due.
For a few seconds after the ignition is switched on, the screen indicates:
A few seconds after the ignition is switched on, the distance recorder resumes its normaloperation. The spanner remains on
toindicate that a service must be carried out
soon.
A
few seconds after the ignition is switched on, the spanner goes off; the distance recorder fresumes its normal operation. The screen thenindicates the total and trip distances.
More than 1 800 miles (3 000 km) remain before the next service is due
When the ignition is switched on, no ser vice information
appears in the instrument panel central screen.
Page 58 of 396
A few seconds after the ignition is switched
on, the distance recorder resumes its normal
operation.
The spanner remains on.
The distance remaining may be weighted by the time factor, depending on the type of driving.
Therefore, the spanner may also comeon if you have exceeded the two year service interval.
Service indicator zero reset
After each ser vice, the ser vice indicator mustbe reset to zero.
The procedure for resetting to zero is as
follows: ) switch off the ignition, )
press and hold the ".../000"
trip distance
recorder zero reset button, ) switch on the ignition; the distance recorder
display begins a countdown,
) when the screen indicates "=/0"and thespanner disappears, release the button.
This operation cannot be carried out while a reminder of the ser vicing information is being displayed.
Following this operation, if you wish todisconnect the battery, lock the vehicleand wait at least five minutes for thezero reset to be registered.
Recalling the service information
You can recall the ser vice information at anytime. )Briefly press the ".../000"
trip distance recorder zero reset button.
The ser vice information is displayed for afew seconds, in the total distance recorder
line or in the type 2 instrument panel central screen.
Service overdue
For a few seconds after the ignition is switched on,
the spanner flashes
to indicate that the servicemust be carried out as soon as possible. Example:
the ser vice is overdue by 180 miles(300 km).
For a few seconds after the ignition is switched on,
the screen indicates:
Page 59 of 396
Monitoring
Manual test in the type 2 instrument panel central screen
This function allows you to check the status of the vehicle systems (reminder of the "activated"/"deactivated" status of the configurable functions) and to
display the aler ts log.
)With the engine running, to star t a manual
test, briefly press the ".../000"button on
the instrument panel. The followin
g information appears successively in the instrument panel central screen:
- engine oil level indicator(see corresponding section),
- ser vice indicator (see correspondingsection),
- under-inflation detection (if your vehicle
is fitted with this system; see the "Safety"section),
- current warnings and aler t messages,
if any (see corresponding section for the
warning lamp or system concerned),
- status of configurable functions(see "Multifunction screens").
This information also appears everytime the ignition is switched on(automatic test).
Page 60 of 396
The total and trip distances are displayed for
thirty seconds when the ignition is switchedoff, when the driver's door is opened and when
the vehicle is locked or unlocked.
Distance recorders
Total distance recorder
Trip distance recorder
Measures a distance travelled since it wasreset to zero by the driver.
)
With the ignition on, press and hold this
button until zeros appear.
Measures the total distance travelled bythe vehicle since its first registration.
