buttons Citroen DS5 2011 1.G User Guide

1
2
1
2
09
285






AUDIO STREAMING
Streaming allows audio fi les on your telephone to be played via the
vehicle's speakers.
Connect the telephone: see "USING THE TELEPHONE".
Select " Audio" or " All" profi le.
I
f play does not start automatically, it may be necessary to start the audio playback from the telephone.
Control is from the peripheral device or b
y using the audio system buttons.
Once connected in streaming mode, the telephone is considered to bea media source.
It is recommended that
you activate " Repeat" on the Bluetooth
peripheral.

MUSIC MEDIA PLAYERS


iPod/iPhone
Connect the iPod or iPhone to the USB port using a suitable cable (not supplied).
Play starts automatically.
Control is via the audio system.
The classifi cations available are those of the portable device
connected (artists/albums/genres/playlists/audiobooks/podcasts).
The de
fault classifi cation used is by artist. To modify the classifi cationused, return to the fi rst level of the menu then select the desired classifi cation (playlists for example) and confi rm to go down through
the menu to the desired track.
The version o
f software in the audio system may not be compatible
with the generation of your iPodÆor iPhone.
The list of devices compatible with software versions is available from CITROÀN dealers.

04
1
2
3
AUDIO






AUDIO CD


Insert 12 cm diameter circular compact discs only.
Some anti-piratin
g systems, on original discs or CDs copied using apersonal recorder, may cause faults which are no refl ection on thequality of the original player.

Without pressing the EJECT
button, insert a CD in the player, playbegins automatically.

To play a disc which has already beeninserted, press the SOURCEbuttonseveral times in succession and select
" CD".

Pr
ess one of the buttons to select a
track on the CD.
PLAYING A CD

Pr
ess LIST
to display the list of trackson the CD.

Pr
ess and hold one of the buttons for fast forward or backward.

04
1
3
2
4
5












CD, USB
AUDIO


PLAYING A COMPILATION

Insert an MP3 compilation in the
CD player or connect a memory stick to the USB port,
directly or via an extension lead.
The s
ystem creates playlists (temporary memory) the creation time
for which can take from a few seconds to several minutes.
The pla
ylists are updated every time the ignition is switched off or aUSB memory stick is connected.
Pla
y starts automatically after a period which depends on the capacity of the USB memory stick.

At a fi rst connection, the order suggested is by folder.When connecting again, the order previously chosen is retained.

To play a disc or memory stick whichhas already been inserted, press
SOURCE
several times in successionand select " CD" or "USB".
Pr
ess one of the buttons to select the next or previous track.

Pr
ess one of the buttons to select the next or previous folder in the order chosen.

Pr
ess and hold one of the buttons for
fast forwards or backwards.

Press LISTto display the menu of folders in the compilation.

1
2
1
4
2
33
05
317
USING THE TELEPHONE
To display the "TELEPHONE " menu:
-
Make along press on SOURCE.
- Or, press OK
to display thecontextual menu. Select " Call" and confi rm.
-
Or, press MENU
, select
"Telephone" and confi rm. Select
"Call
" and confi rm.


Select "Dial
" to enter a number andconfi rm.
Repeat the previous step 1
to displaythe "TELEPHONE" menu.

Select OKand confi rm to start the call.

Select "Calls list
" and confi rm.


MAKING A CALL - DIALLING

Select numbers one at a time
using the and buttons andconfi rm.

MAKING A CALL - RECENTLY CALLED
NUMBERS *

Select the number and confi rm to start the call.

The calls list includes calls sent and received in the vehicle usin
g the connected telephone.

*
Depending on the compatibility of the telephone.
Correction allows numbers to be deleted one at a time.

It is possible to make a call directl
y from the telephone; park the
vehicle fi rst as a safety measure.

341Visual search

eMyWay controls 247
Head-up display 120 -121
Memorising speeds 12 2Speed limiter 123 -124Cr uise c ontrol 125 -126
Lighting c ontrols 132-13 8 Automatic headlamp dipping 137Direction indicators 138, 16 4
Wiper c ontrols 143 -146 Tr i p c o m p u t e r 4 4 - 4 5
Instrument panels, screens 28, 38-43 - check/ser vice indicator/trip distance recorder - lighting dimmer
Warning lamps 29-37Indicators 38-41Gear shift indicator 107
Colour screen 249, 290 -292 Screen C 302, 325-326

Instruments and controls (cont.)
Electric parking brake 97-104
START/STOP, ignition switch,switching on/off 94-96 Stop & Start 116-118 Accessory position 95 Clock 43

Hazard warning lamps 164

Audio system controls 248, 301

Steering wheel adjustment 77 Horn 165
Switch panels, buttons 12Opening the fuel filler flap 63Opening the boot 56 Alarm 57 Eco OFF (Stop & Start) 11 6 -11 8Headlamp height adjustment 140
