Page 23 of 358
21Familiarisation
Monitoring
On switching on, the dial needles go to the extent of their travel then return to 0.
A.With the ignition on, the bars indicate the
fuel remaining.
Instrument panel
1.
With the ignition on, the orange and redwarning lamps come on. 2.With the hybrid system active, these
warning lamps should go off.
If a warning lamp remains on, refer to thecorresponding section.
Warning lamps
55
B.
With the ignition on, the instrument panelscreen should indicate the oil level.
If the levels are not correct, top up the level which is low.
54
Page 62 of 358
With the hybrid system active or when the vehicle is being driven, illumination of one of the following warning lamps indicates a fault which requires action on the par t of the driver.
Any fault resulting in the illumination of a warning lamp must be investigated further by reading the associated message in the instrument panel screen.
If you encounter any problems, contact a CITROËN dealer or a qualified workshop.
Warning / indicator lampStateCauseAction / Observations
STOPfixed, associated with another warning lamp, accompanied by an audible signal and a message in the screen.It is associated with a punctured wheel,
the brakin
g system, the power steering,
the engine oil pressure, the enginecoolant temperature, the hybrid system
or a major electrical fault.Stop as soon as it is safe to do so as the en
gine may cut out.
Park, switch off the ignition and call a CITROËN
dealer or a qualified workshop.
Serviceon temporarily. A minor fault has occurred for which
there is no specific warning lamp. Identify the fault by reading the message shown in the screen, such as, for example:
- the closing of the doors, boot or bonnet,
- the engine oil level,
- the screenwash level,
- the remote control battery,
- the tyre pressures,
- saturation of the par ticle emission filter (Diesel). - ...For any other faults, contact a CITROËN dealer or a
qualified workshop.
fixed. A major fault has occurred for which
there is no specific warning lamp. Identify the fault by reading the message shown on the screen and contact a CITROËN dealer or a yyg g
qualified workshop.
PEF: particle emissions filter,Diesel
fixed, associated
temporarily with a message on the risk of
blockage of the PEF.Thi
s indicates the start of saturation
of the par ticle emissions filter. As soon as traffic conditions allow, regenerate the
filter by driving at a speed of at least 35 mph (60 km/h)
until the ser vice warning lamp goes off.
fixed.This indicates the low level in theDiesel additive reservoir. Have the level topped up by a CITROËN dealer or a
qualified workshop as soon as possible.
Page 69 of 358
Monitoring
Engine oil level
indicator
Oil level incorrect
This is indicated by a message in the instrument panel screen.
If the low oil level is confirmed by a check using
the dipstick, the level must be topped up to avoid damage to the engine.
Oil level indicator fault
This is indicated by a message in the
instrument panel screen. Contact a CITROËN
dealer or a qualified workshop.
Dipstick
Refer to the "Checks" section to locatethe dipstick and the oil filler cap on
your engine.
System which informs the driver whether theengine oil level is correct or not.
This information is indicated for a few secondswhen the ignition is switched on, after theservice information.
The level read will only be correct if the vehicle is on level ground and the engine has been off for more than30 minutes.
There are
2 marks on the dipstick:
- A= max; never exceed this
level,
-
B= min; top up the level via
the oil filler cap, using the grade of oil suited to your engine.
Oil level correct
This is indicated by a message in the instrument panel screen.
Page 238 of 358
The various caps and covers allow access for
checking the levels of the various fluids, for replacing cer tain components and for primingthe fuel system.
Diesel engine
1.
Power steering reservoir.2.
Screenwash and headlamp wash reser voir.3.
Coolant reservoir. 4.
Brake fluid reservoir.5.
Battery / Fuses.
6.Fusebox.
7. Air filter.8.Engine oil dipstick. 9.
Engine oil filler cap.10.Priming pump. 11.
Bleed screw.
HDi 160 PEF 6-SPEED ELECTRONIC GEARBOX
Page 240 of 358
Checking levels Check all of these levels regularly and top them up if necessary, unless other wise indicated.
If a level drops significantly, have the corresponding system checked by a CITROËN dealer or a qualified workshop.
When working under the bonnet, take care, as cer tain areas of the engine may be extremely hot (risk of burns).
Oil level
The reading will only be correct if the
vehicle is on level ground and theengine has been off for more than30 minutes.
The check is carried out either when the ignition
is switched on using the oil level indicator in the
instrument panel, or usin
g the dipstick.
Engine oil change
Refer to the ser vicing booklet for the inter val for
this operation.
In order to maintain the reliability of the engine
and emission control system, the use of
additives in the engine oil is prohibited.
Oil specifi cation
The oil must correspond to your engineand conform to the manufacturer's
recommendations.
It is normal to top up the oil level between two ser vices. CITROËNrecommends that you check the oil level, and top up if necessary,every 3 000 miles (5 000 kilometres).
Before doing anything under the bonnet,switch off the ignition (Readylamp off) to avoid any risk of injury resulting from automatic operation of the engine.
Page 244 of 358
Particle emission filter (Diesel)
The start of saturation of theparticle filter is indicated bythe temporary illumination of
this warning lamp accompanied by a message
in the multi-function screen.
As soon as the traffic conditions permit, regenerate the filter by driving at aspeed of at least 40 mph (60 km/h) until the warning lamp goes off.
If the warning lamp stays on, this indicates a low additive level.
On a new vehicle, the first par ticlefilter regeneration operations may be accompanied by a "burning" smell, which is perfectly normal.
Following prolonged operation of the vehicle at very low speed or at idle, you may, in exceptional circumstances,notice the emission of water vapour at the exhaust on acceleration. This does not affect the behaviour of the vehicle or the environment.
The 100% electric mode is not available during regeneration of the par ticle emissions filter.
Air filter and passenger compartment filter
Oil filter
Replace the oil filter each time the engine oil is changed.
Refer to the ser vicing booklet for
details of the replacement interval for
this component.
Re
fer to the ser vicing booklet for
details of the replacement intervals
for these components.
Dependin
g on the environment (e.g. dustyatmosphere) and the use of the vehicle (e.g. city driving), replace them twice as often if necessary.y A clogged passenger compartment filter mayhave an adverse effect on the performance
of the air conditioning system and generate undesirable odours.
Page 245 of 358
243Checks
6-speed electronic gearbox
The gearbox does not require anymaintenance (no oil change).
Refer to the ser vicing booklet for
details of the checking interval for
this component.
Brake wear depends on the st
yle
of driving, par ticularly in the case
of vehicles used in town, over shor tdistances. It may be necessary tohave the condition of the brakes checked, evenbetween vehicle services.
Unless there is a leak in the circuit, a drop in
the brake fluid level indicates that the brakepads are worn.
Brake pads
For information on checking brake
disc wear, contact a CITROËN dealer or a qualified workshop.
Brake disc wear
Electric parking brake
This system does not require anyroutine servicing. However, in the
event of a problem, have the systemchecked by a CITROËN dealer or aqualified workshop.
Only use products recommended by CITROËN or products of equivalent quality and specification. In order to optimise the operationof units as impor tant as the braking
system, CITROËN selects and offers very specific products.
To avoid damaging the electrical units, the use of a high pressure washer in the engine compar tment is strictly prohibited.
For more information, refer to the "Electric parking brake - Operating faults" section.
Page 344 of 358
A
ABS...............................................................183Accessories .......................................33, 79, 229Accessory position.....................................33,79Accessory socket, 12V ..........................106, 107Adjusting headlamps.....................................156Adjusting head restraints...........................96,99Adjusting seat belt height.............................. 187Adjusting the steering wheel..........................105Airbags ....................................................63, 191Airbags, curtain......................................191, 192Airbags, front.........................................189, 192Airbags, lateral.......................................191, 192Air conditioning........................................44, 116Air conditioning, digital............................113, 114Air fi lter..........................................................r242Air fl ow............................................................. 44Air vents.........................................................112Alarm ...............................................................85Anti-lock braking system (ABS).....................183Anti-pinch.........................................................89Anti-theft..........................................................33Armrest..........................................................106Armrest, front.................................................108Armrest, rear..................................................r109Ashtray, portable............................................ 106ASR...............................................................183Assistance, emergency braking.....................183Assistance call.......................................181, 255Audible warning.............................................181Audio streaming (Bluetooth)..........297,324, 326Audio system.................................................311Automatic headlamps..............................56, 153Automatic illumination of headlamps ........................................... 149, 152
Automatic operation
of hazard warning lamps.............................180Automatic rain sensitivewindscreen wipers ...............................159,161Auxiliary socket......................108, 297, 298,323
Backup starting ........................................34,221Backup switching off........................................f34
Battery ...............8,28,47-49,103, 220-222,241Battery, charging ............................................221Battery, remote control..............................81, 82Black panel......................................................69Bluetooth (hands-free)...........................280,325Bluetooth (telephone)............................280, 325
Boot.................................................................84Boot (opening) .................................................76Boot fl oor, adjustable.....................................110Brake discs ....................................................243Brake lamps...................................................214
Brake pads ....................................................243Brakes...........................................................243
Central locking...........................................76,78Changing a bulb.....................................209-216Changing a fuse .....................................217-219Changing a wheel...................................202-208Changing a wiper blade .........................162, 224Changing the date .....................................70,71Changing the remote control battery...............81Changing the time.............................70, 71, 301Checking levels......................................238-241Checking the engine oil level...........................67Checking tyre pressures (using the kit).........201Checks....................................................236-243Children ..................................168-177, 188, 190Child lock .......................................................177Child seats .............................................168-176Child seats, conventional....................... 171, 172Cigar lighter...................................................r107Clock................................................................70Closing the boot...............................................84Closing the doors.......................................76,78Connectors, audio .................108, 297, 298, 323Coolant level............................................64, 238Coolant temperature indicator.........................r64Courtesy lamps..............................................163Cruise control........................................ 138, 141Cup holder.....................................................r106
B
Capacity, fuel tank ...........................................91Cables, high voltage........................................49CD .........................................................294,318CD MP3.........................................294, 319,320
C
Date (setting) .............................................70,71Daytime running lamps...........................................209,212, 213
D
Page 345 of 358
343Alphabetical index
Deactivating ESP...........................................185Deactivating the passenger airbag................190Deadlocking ...............................................79,80Defrosting ..............................................104, 118Demisting.......................................................118Diesel...................................................42,43,57Diesel additive level....................................... 240Dimensions....................................................249Dipped beam...........................56, 148,209, 210Dipstick....................................................67, 238Directional lighting.................................157, 158Direction indicators ........154, 180, 209,212, 214
Driving positions (memorising)........................98Dynamic emergency braking..................122-127Dynamic stability control(DSC).......................................59,62,183, 185
EBA (Emergency braking assistance) ...........183EBFD............................................................. 183Eco-driving......................................................44Economical driving .........................................44Economy mode..............................................223Eco off.............................................................f43Electronic brake force distribution (EBFD)....183Electronic engine immobiliser....................r33,82Electronic gearbox.........................131,222, 243Emergency boot release..................................84Emergency call...................................... 181, 255Emergency warning lamps.....................111, 180eMyWay ...................................................69, 257
Filling with fuel............................................91-93Fitting a wheel...............................................207Fitting roof bars..............................................228Fittings, boot ..................................................110Flashing indicators.................................154,180Flat bed lorry or trailer.............................r51,226Foglamps, front..............................150, 209,213Foglamps, rear..............................................r150Folding/unfolding the door mirrors .................................................104Front seats..................................................96-98Fuel............................................................44, 93Fuel consumption ......................................44, 46Fuel consumption fi gures ................................ 46Fuel fi ller cap ...................................................91Fuel fi ller fl ap .............................................91, 92Fuel gauge...........................................21, 54, 91Fuel tank ....................................................91, 92Fusebox, dashboard ......................................218Fuses.............................................................217
EFG
G.P.S. ............................................................263Gearbox, electronic............................... 131, 243Gear lever, electronic gearbox system ..........131Guidance.......................................................263Guide-me-home.....................................152, 154
Energy economy mode..................................223Engine, Diesel.........................93, 236, 237,247Engine compartment...............................50,236Engine compartment fusebox ........................219Engine oil level indicator..........................r67,238Engines..................................................246,247Environment...................9,44,81, 113, 118, 241
H
Halogen headlamps.......................................209Hands-free kit ........................................280, 325Hazard warning lamps ............................111, 180Head-up display.............................136, 139, 141Headlamp adjustment....................................156Headlamps, directional..........................157, 209Headlamp wash.....................................160, 240Head restraints, front.................................96,99Head restraints, rear......................................r103Heated seats.................................................100Heating ....................................................44, 11 2Height and reach adjustment,steering wheel.............................................105High voltage...............................47, 49, 222, 235Hill start assist...............................................130History.............................................................46Hybrid.....................................................8, 26-51Hybrid fl ow.......................................................40Hybrid selector.................................................35Hybrid system.........................................8, 26-51
Page 346 of 358
M
Jack ...............................................................202JACK socket..........................108, 297, 298, 323
JL
Labels, identifi cation......................................250Lamps, warning and indicator.....................55-63Lane Departure Warning System (LDWS) ....135LED daytime running lamps..........................151Level, brake fl uid...........................................239Level, headlamp wash...................................240Level, power steering fl uid.............................238Levels and checks ..................................236-242Lighting..........................................................164Lighting, guide-me home.......................152,154Lighting, interior.....................................r163,164Lighting bulbs(replacement) .......................................209-216Lighting control stalk ..............................148,154Lighting dimmer...............................................r68Lighting on reminder......................................r151Loading....................................................44,228Load reduction mode .....................................222Localised assistance call ...............................255Localised emergency call ..............................255Locating your vehicle.......................................83Locking from the inside....................................83Locking the doors............................................83Long objects, transporting.............................109Low fuel level...................................................92
Main beam ........................56, 148,209-211, 213Maintenance....................................................44Markings, identifi cation ..................................250Massage function ......................................... 100Mat................................................................. 107Menu, main....................................................314Mirror, rear view.............................................105Mirrors, door..................................................r104Misfuel prevention...........................................92Motorway function (direction indicators)........180Mountings for ISOFIX seats..........................174MP3 CD.........................................294,319, 320Music media players ...................................... 293
Navigation......................................................263Number plate lamps......................................216
N
Keyless Entry and Starting ........................77, 82Key not recognised..........................................34
Key with remote control...................................33
Identifi cation plates........................................250Ignition.......................................................33,79Ignition on ..................................................33,79Indicator lamps, status................................55-63Indicators, direction.......................180, 212, 214Infl ating accessories (using the kit) ...............201Infl ating tyres ........................................... 44, 250Inputs for audiosystem.................................108, 297, 298, 323Instrument panel lighting.................................68Instrument panels............................................54Instruments and controls.................................16Intelligent Traction Control.............................184Interior fi ttings ................................................106Interior mood lighting.....................................164ISOFIX child seats ..................................174-176ISOFIX mountings.........................................174
I
Keeping children safe.............168-177, 188, 190Key.............................................................76-82Key, electronic ......................................34, 76-80
KOil fi lter..........................................................r242Oil level....................................................67, 238Opening the boot .................................76,77,84Opening the doors .....................................76,77Operation indicator lamps...........................55-63
O
