21Hybrid4 system
DS5Hy4_en_Chap00c_hybride_ed01-2015
SPORT mode
(Diesel and
electric)
4WD mode
(4 - wheel
drive)
This mode allows more dynamic driving by providing additional performance . By using the capacity of the electric motor to supplement the power of the HDi Diesel engine, the vehicle's full power is used for acceleration and pick-up. This mode manages the response of the accelerator, the electronic gearbox and the use of the electric motor. In SPORT mode: - the electric motor as an addition is available up to 75 mph (120 km/h).
This "4-wheel drive" mode provides additional traction * at low speed by driving all four wheels of the vehicle simultaneously: the HDi Diesel engine (front wheel drive) and the electric motor (rear wheel drive) operate simultaneously and permanently. Their coupling is managed electronically to optimise traction when grip is poor. In 4WD mode: - the HDi Diesel engine operates continuously; if necessary, it supplies energy for the electric motor, - the additional traction from the electric motor is available up to 75 mph (120 km/h).
This mode should be used on snow covered roads or difficult ground (mud, sand, ...), as well as for crossing a ford, at moderate speed. In this mode, in severe conditions and if the circumstances allow, it is recommended that you accelerate strongly to facilitate moving off and making progress and so reduce the risk of getting stuck. The addition of 4WD traction is available whatever: - the state of charge of the 12 V
battery, - t h e a l t i t u d e .
* This mode will be even more effective if the vehicle is fitted with tyres suitable for winter conditions.

DS5Hy4_en_Chap00c_hybride_ed01-2015
ECO OFF function
This function prevents the HDi Diesel engine being switched off and so ensures that a comfortable temperature can be maintained in the passenger compartment (air conditioning running continuously). On pressing the ECO OFF switch, the HDi Diesel engine restarts immediately. To return to normal operation, press this switch again. After switching off the ignition, the vehicle will return to normal operation (lamp in the switch off).
* E x c e p t i n ZEV mode, which gives preference to electric running over maintaining a comfortable temperature.
During electric running and when the engine is stopped, the hybrid system manages restarting automatically to maintain the temperature in the passenger compartment * . However, variations in temperature may still be felt in very hot climates. To avoid any discomfort in these conditions you can operate the ECO OFF s w i t c h .

23Hybrid4 system
DS5Hy4_en_Chap00c_hybride_ed01-2015
A few driving recommendations
Observe the driving regulations at all times and remain vigilant whatever the traffic conditions. Pay close attention to the traffic and keep your hands on the wheel so that you are ready to react at any time to any eventuality. On a long journey, a break every two hours is strongly recommended. In difficult weather, drive smoothly, anticipate the need to brake and increase the distance from other vehicles.
Driving on flooded
roads
We strongly advise against driving on flooded roads, as this could cause serious damage to the internal combustion engine or electric motor, the electronic gearbox, or the electrical systems of your vehicle.
If you are obliged to drive through water:
- check that the depth of water does not exceed 15 cm, taking account of waves that might be generated by other users, - place the mode selector in the 4WDposition, - drive as slowly as possible without stalling. In all cases, do not exceed 6 mph (10 km/h), - do not stop and do not switch off the
engine. On leaving the flooded road, as soon as circumstances allow, make several light brake applications to dry the brake discs and pads. If in doubt on the state of your vehicle, contact a CITROËN dealer or a qualified workshop.
Important!
Never drive with the parking brake applied - Risk of overheating and damage to the braking system! Do not park or run the engine when stationary in areas where inflammable
substances and materials (dry grass, dead leaves...) might come into contact with the hot exhaust system or certain components of the Hybrid4 system which can reach very high temperatures - Risk of fire!
Never leave a vehicle unsupervised with the engine running. If you have to leave your vehicle with the engine running, apply the parking brake and put the electronic gearbox into position N .

DS5Hy4_en_Chap00c_hybride_ed01-2015
Eco-driving
Eco-driving is a range of everyday practices that allow the motorist to optimise their fuel consumption and CO2 emissions.
Adapted to your Hybrid4 vehicle
Use gear selector position A , as this optimises gear changes to suit the circumstances, and the AUTO mode of the Hybrid4 mode selector. When moving off, accelerate normally up to the desired speed ( POWER zone between 20 and 40 %). At steady speeds, drive gently with small movements of the accelerator pedal ( ECO or CHARGE zone), run in electric mode as often as possible when driving at low speed. Anticipate the need to slow down and use engine braking ( CHARGE zone), so as to make use of free energy recovery while keeping light pressure on the accelerator pedal.
For information on other eco-driving practices, refer to the corresponding section of the handbook for the vehicle.

25Hybrid4 system
DS5Hy4_en_Chap00c_hybride_ed01-2015
Special conditions for the operation of ZEV mode
ZEV mode can be selected when all of the conditions for its operation are met, in particular an adequate state of charge of the battery (50% at least). In the situations described below, the HDi Diesel must be running; accordingly, ZEVmode cannot be selected or is deactivated automatically. The mode selector remains at or returns to the AUTO position to allow starting of the HDi Diesel engine, as required.
- Manual gear change when in automatic mode using the steering mounted controls for the electronic gearbox.
Cases of non availability of ZEV mode or automatic return
to AUTO mode
- Selection of manual mode by moving the gear selector for the electronic gearbox to position M .
- Sustained and sharp acceleration.
- Use of demisting / defrosting.
- Intensive use of air conditioning.
Action by the driver:

DS5Hy4_en_Chap00c_hybride_ed01-2015
Unsuitable circumstances:
- If the state of charge of the high voltage battery is lower than 4 bars (equal to 50% charged). In AUTO mode, electric operation is possible with a lower state of charge.
- When the speed of the vehicle exceeds 18 mph (30 km/h), if the internal combustion engine has not already started at least once since the Hybrid4 system was started.
- When the fuel level enters the reserve zone (illumination of the low fuel warning lamp). Where this reserve is is being used up quickly, ZEV may not be possible for some time after refuelling.
- During phases of regeneration of the particle filter (FAP), which is automatically triggered approximately every 300 miles (500 kms) for a period of about 10 minutes. During regeneration of the particle filter, the particles a brought up to a high temperature using the HDi Diesel engine; A message is then displayed: " Electric mode not available: FAP regeneration " .
Maintaining the performance of the system:
- If certain conditions or engine temperature requirements needed by the HDi Diesel engine are not met (for example, in wintry conditions).
- Following a prolonged period with the vehicle parked in the sun.
- When the state of charge of the high voltage battery is close to the maximum level (for example: when going down a long hill using the electric motor for braking), recovery of the vehicle's kinetic energy being no longer possible, the HDI Diesel engine restarts automatically just to provide engine braking.
- On a steep rising slope.
- D r i v i n g a t a l t i t u d e .

27Hybrid4 system
DS5Hy4_en_Chap00c_hybride_ed01-2015
200 V high voltage battery
The 200 V high voltage battery is specially made for partial, rapid and frequent charging and discharging. Of Ni-MH (Nickel Metal Hydride) technology, it is located below the boot floor, close to the electric motor.
Charging
The battery recharges automatically while travelling. The battery is charged when the vehicle decelerates and when going downhill, the electric motor then becomes a generator and converts kinetic energy into electrical energy (except if the speed of the vehicle is above 70 mph (120 km/h)). This recovery allows the use of "free" energy. The battery may also be partially charged up to a level of 4 to 5 bars, using the alternator-starter motor (Stop & Start) of the HDi Diesel engine.
The average state of charge is 4 to 5 bars, so preserving a margin for energy recovery when deceleration of going downhill (free energy).
To preserve the service life of the battery, the level of charge never falls below 20%, even if a level of 0 bars is displayed after ZEV running. Where the battery is close to maximum, vehicle deceleration with your foot off the accelerator pedal will be at a lower l e v e l .
The battery charging time is very short. A discharged battery (following ZEV running or high load, for example) will quickly return to a state of charge sufficient (around 10 minutes) for full operation of the different hybrid modes.
The battery is not recharged from a mains power supply.

DS5Hy4_en_Chap00c_hybride_ed01-2015
The high voltage battery must not in any circumstances be charged from an external source and must only be handled by a qualified technician at a CITROËN dealer or a qualified workshop. There is the risk of serious burns, as well as electric arcs that could cause serious injury or even death. A used Ni-MH (Nickel Metal Hydride) type high voltage battery must be removed in an appropriate manner by a repair workshop, so that its recycling presents no risk to the environment.
High voltage
The voltage used for the operation of the electric motor is in the range 150 to 270 Volts. Be sure to take account of the warning labels fitted to the vehicle. Take great care regarding the high voltage and high temperatures of components carrying the c u r r e n t .
Emergency cut-off
In the event of an accident, a cut-off system blocks the high voltage current and cuts off the fuel pump; your vehicle can no longer be started. To restart the hybrid system, contact a CITROËN dealer.
High voltage cables are routed under the vehicle (sills); take care not to damage them when the vehicle is used for off-road activity (such as covering rough ground).
Before doing any work on the vehicle, switch off the ignition ( RE ADY l a m p o f f ) . RE ADY l a m p o f f ) . RE ADY
Battery precautions High voltage cables
Take care to position lifting equipment ( jack, hoist, ...) at the locations provided to avoid damaging the cables.
Never touch, dismantle, remove or replace the high voltage parts, orange cables or connectors, even in the event of an accident.

29Hybrid4 system
DS5Hy4_en_Chap00c_hybride_ed01-2015
This ventilation system does not operate at the same speed at all times: it is continuously adjusted to suit the cooling requirements of the battery. The noise of its operation can be heard, particularly at the rear, after the Hybrid4 system is switched off (post-ventilation). If the air intake is blocked, the battery may overheat, damaging the battery and causing a loss of per formance of the Hybrid4 system.
Ventilation of the high voltage battery
For the best use of the high voltage battery, please observe the following safety recommendations: - do not obstruct the air intake with loose articles, otherwise, the battery may overheat, which could cause a loss of per formance of the Hybrid4 system, - do not spill fluids, as this may damage the battery (short-circuit).
The high voltage battery has an air cooling system. This comprises an air intake (located on the side of the left hand rear seat) and a fan (located behind the left hand boot trim panel).

DS5Hy4_en_Chap00c_hybride_ed01-2015
Access to the underbonnet
The alternator-starter motor of your hybrid vehicle is also supplied at high voltage. If the vehicle ignition has not been switched off, there is a risk of the engine restarting at any t i m e .
Always ensure that the ignition is switched off ( RE ADY lamp off) RE ADY lamp off) RE ADYbefore opening the bonnet.
Before doing anything under the bonnet, to avoid the risk of serious injury, switch off the ignition and verify that the RE ADY lamp in the instrument RE ADY lamp in the instrument RE ADYpanel is off.
Recommendations
