101Driving

Switching off using the
electronic key
)Immobilise the vehicle.


Electronic key left in the reader

If the electronic key is left in the reader, on opening the driver's door a messageappears to warn you.



Stopping with the
"Keyless Entry and
Startin
g" system
)Immobilise the vehicle.
If the vehicle is not immobilised,
the engine will not stop.
Ignition on without starting
the engine
(accessory position)
)
With the electronic key inside
the vehicle, press the "START/
STOP"
button.
The engine stops and thesteering column locks.
)
Press the "START/STOP
" button
The engine stops and thesteering column locks.











Anti-theft protection


Electronic engine immobiliser

The keys contain an electronic chip which has
a secret code. When the ignition is switched on, this code must be recognised in order for starting to be possible.
This electronic engine immobiliser locks theengine management system a few minutes
after the ignition is switched off and preventsstarting of the engine by anyone who does not have the key.
In the event of a malfunction, you are informed
by a message in the instrument panel screen.
In this case, your vehicle does not start; contact
a CITROËN dealer as soon as possible.
With the electronic key in the reader or the
Ke
yless Entry and Starting key inside the
vehicle, pressing the "START/STOP" button,with no action on the pedals, allows the ignition
to be switched on and so activate the ancillaryequipment.
)Remove the electronic key from the reader.
)
Press the "STA R T/STOP" button,
the instrument panel comes on
but the engine does not star t. ) Press the button again to switch
off the ignition and so allow the
vehicle to be locked.

If you use the accessory position for toolong, the system automatically goes intoeconomy mode to avoid the risk of a flatbattery.

Emergency starting with the
Keyless Entry and Starting
system
When the electronic key is in the defined zone and your vehicle does not star t after pressingthe "STA R T/STOP" button: )Inser t the electronic key in the reader. )Press the brake pedal on vehicles withautomatic gearbox or electronic gearbox
system, or fully declutch with a manualgearbox.)Press the "STA R T/STOP" button.The engine starts. In the event o
f an emergency only, the enginecan be switched of without conditions. To dothis, press and hold the "START/STOP" button
for about 3 seconds.
In this case the steering column locks as soon
as the vehicle stops.
I
f the electronic key is no longer in the defined
zone when driving or when you (later) request switching off the engine, a message appears in
the instrument panel.

Emergency switch- off
Electronic key not recognised by
the "Keyless Entry and Starting"
system
)Press and hold the "STA R T/STOP"
button for about 3 seconds if you want to
force switchin
g off the engine (note that restarting will not be possible without
the key).

Visibility





Exterior welcome
lighting
The remote switching on of the lighting makesyour approach to the vehicle easier in poor
light. It is activated according to the level of
light detected by the sunshine sensor.

Switching on

Switchin
g off


The exterior welcome lighting switches off
automatically after a set time, when the ignitionis switched on or on locking the vehicle.
Programming

The lighting duration is selected via
the vehicle configuration menu.
The duration of the welcome lighting isassociated with and identical to that of the automatic guide-me-home lighting.) Press the open padlock on the
remote control or the door handlewith Keyless Entry and Starting.







Door mirror
spotlamps

Switching on
The spotlamps come on:


- when you unlock the vehicle,

- when
you remove the electronic key from
the reader,

- when
you open a door,

- when you use the remote control.



Switching off

They are timed to go off automatically. To m a k e
your approach to the vehicle easier,
these illuminate:


- the zones facing the driver’s andpassenger’s doors,

- the zones forward of the door mirrors and
rearward of the front doors.
The dipped beam headlamps and the sidelamps come on; your vehicle is also unlocked.

Jack............................................................. 192JACK socket..................................86, 292, 317
J
Massage function.........................................78Mat................................................................85Menu, main.................................................308Mirror, rear view............................................83Mirrors, door..................................................r82Misfuel prevention.........................................69Motorway function(direction indicators).................................170Mountings
for ISOFIX seats .......................................164MP3 CD .......................................288,313,314Music media players ...........................287, 313
Navigation...................................................257Number plate lamps....................................206
N
Labels, identification...................................245Lamps, warning and indicator...........r31, 35,36Lane Depar ture Warning System(LDWS).....................................................125LED daytime running lamps........................141Level, brake fluid.........................................230Level, headlamp wash................................231Level, power steering fluid ..........................230Levels and checks...............................225-234
Lighting........................................................154
Lighting, guide-me home ....................142,144Lighting, interior..................................r153, 15 4
Lighting bulbs (replacement)..............199-206Lighting control stalk...........................138,144Lighting dimmer............................................r44Lighting on reminder...................................r141Loading..................................................25,218Load reduction mode ..................................213Localised assistance call............................249Localised emergency call...........................249Locating your vehicle....................................54
Locking from the inside.................................59Locking the doors.........................................59Long objects, transpor ting............................87Low fuel level....................................19, 38,68
L
Ignition on..............................................55, 101Indicator lamps, status.............................31-39Indicators, direction....................................170Inflating accessories (using the kit)............................................191Inflating tyres ........................................25, 245
Inputs for audio system .................84, 292, 317Instrument panel lighting..............................44Instrument panels.........................................30Instrument panel screen...............................30Intelligent Traction Control..........................174Interior fittings...............................................84
Interior mood lighting..................................154
ISOFIX.........................................................165ISOFIX child seats ...............................164-166ISOFIX mountings....................................... 164
Keeping children safe...................... 158 -167, 178, 180Key..........................................................52-58Key, electronic...................................52-54,56Keyless Entry and Starting.....................53,58
K
Main beam............................32,138, 199-201Maintenance..................................................25Map reading lamps.....................................153Markings, identification...............................245
MOil filter........................................................r233Oil level..................................................43, 229Opening the boot..............................52,53,61Opening the doors..................................52,53Operation indicator lamps ........................31-39
O

341Visual search
Exterior

Electronic key / Keyless Entryand Star ting 52- 58, 10 0 -101


- opening / closing

- anti-theft protection

- battery

- startingWelcome lighting 145 Directional lighting 147Cornering lighting 148Headlamp height adjustment 146 Changing bulbs 199 -203- front lamps - foglamps- direction indicator repeaters
Wipers 149-152 Changing a wiper blade 152, 214
Doors 52-60 - Keyless Entry and Starting- opening / closing - central locking - emergency control Alarm 62-63

Fuel tank, misfuel prevention 68 -70

Cockpit glass roof 66-67
Roof bars 218
Accessories 219-220


ESP: ABS, EBA, ASR, DSC 173 -175
Tyre under-inflation detection 172
Tyre pressures 245 Changing a wheel 192-198


- tools

- removing / refitting

Te m p o r a ry puncture repair kit 186 -191


Boot 52, 61


- opening / closing

- emergency release


Changing bulbs 204-206


- rear lamps

- 3rd brake lamp

- number plate lamps

- foglamps

Parking sensors 133 -134 To w i n g 215 Towbar 216 -217

Door mirrors 82Door mirror spotlamps 145
