99
When towing
distribution of loads
F Distribute the load in the trailer so that the heaviest items are as close as possible to
the axle and the nose weight approaches
the maximum permitted without
exceeding
it.
Air density decreases with altitude, thus
reducing engine per formance. Above
1
000 metres, the maximum towed load must
be reduced by 10
% for every 1 000 metres of
altitude.
Side wind
F Take into account the increased sensitivity to side wind.
cooling
Towing a trailer on a slope increases the
temperature of the coolant.
As the fan is electrically controlled, its cooling
capacity is not dependent on the engine speed.
F

T
o lower the engine speed, reduce your
speed.
The maximum towed load on a long incline
depends on the gradient and the ambient
temperature.
In all cases, keep a check on the coolant
temperature.
F

I
f the warning lamp and the
STOP warning lamp come on,
stop the vehicle and switch off
the engine as soon as possible.
Braking
Towing a trailer increases the braking distance.
To avoid overheating of the brakes, the use of
engine braking is recommended.
Ty r e s
F Check the tyre pressures of the towing vehicle and of the trailer, observing the
recommended pressures.
Lighting
F Check the electrical lighting and signalling on the trailer and the hadlamp beam height
of your vehicle.
For more information on adjusting the
headlamp beam height, refer to the
corresponding section.
For more information on weights (and the
towed loads which apply to your vehicle) refer
to the corresponding section.
The rear parking sensors will be
deactivated automatically if a genuine
CITROËN towbar is used.
driving

Starting using another
battery
Never try to start the engine by
connecting a battery charger.
Never use a 24 V or higher battery
b o o s t e r.
First check that the slave battery has a
nominal voltage of 12 V and a capacity
at least equal to that of the discharged
battery.
The two vehicles must not be in contact
with each other.
Switch off the electrical consumers on
both vehicles (audio system, wipers,
lighting, ...).
Ensure that the jump lead cables do
not pass close to moving parts of the
engine (cooling fan, belts, ...).
Do not disconnect the (+) terminal when
the engine is running.F

S
tart the engine of the vehicle with the
good battery and leave it running for a
few
m
inutes.
F O perate the starter on the broken down
vehicle and let the engine run.
I

f the engine does not start straight away,
switch off the ignition and wait a few
moments before trying again.
When your vehicle's battery is discharged, the
engine can be started using a slave battery
(external or on another vehicle) and jump lead
cables or a battery booster.
F
W
ait until the engine returns to idle then
disconnect the jump lead cables in the
reverse order.
F

R
efit the plastic cover to the (+) terminal, if
your vehicle has one.
F

A
llow the engine to run for at least
30
minutes, by driving or with the vehicle
stationary, so that the battery reaches an
adequate state of charge.
F

R
aise the plastic cover on the (+) terminal,
if your vehicle has one.
F

C
onnect the red cable to the positive
terminal (+) of the flat battery A (at the metal
elbow) then to the positive terminal
(+) of the
slave battery B or the booster.
F

C
onnect one end of the green or black
cable to the negative terminal (-) of the
slave battery B or the booster (or earth
point on the other vehicle). Some functions, including Stop & Start,
are not available if the battery is not
sufficiently charged.
F

C
onnect the other end of the green or black
cable to the earth point c on the broken
down vehicle.

259
Never store bottles of AdBlue® in your
vehicle. Before topping-up, ensure that the vehicle is
parked on a flat and level sur face.
In wintry conditions, ensure that the
temperature of the vehicle is above -11°C.
Otherwise the AdBlue
® may be frozen and
so cannot be poured into its tank. Park your
vehicle in a warmer area for a few hours to
allow the top-up to be carried out.
Procedure
F Press the START/STOP button to switch off the engine. F

R
aise the boot floor for access to the
AdBlue
® tank. Use an object, such as a
bag, to keep the left part up.
Recommendations on storage
AdBlue® freezes at about -11°C and
deteriorates above 25°C. It is recommended
that bottles be stored in a cool area and
protected from direct sunlight.
Under these conditions, the additive can be
kept for at least a year.
If the additive has frozen, it can be used once it
has completely thawed out.
checks

A
Accessories ................................................. 234
Accessory position ....................................... 10
1
Additive, AdBlue
.............................. 2

9, 253 -261
Additive, Diesel
...............................

...... 250, 251
Adjusting headlamps
.................................... 15

0
Adjusting head restraints

.......................... 7
2, 75
Adjusting seats
.......................................... 7

2, 73
Adjusting the date

..................................... 3
9, 42
Adjusting the height and reach of the steering wheel

.................................... 81
A

djusting the seat belt height
.......................18

7
Adjusting the time

............................... 3
8, 39, 42
Advice on care and maintenance
............................................... 23

3
Advice on driving

..............................
........ 98, 99
Airbags
...............

..................................... 31, 189
Airbags, curtain
..................................... 19

1, 192
Airbags, front......................................... 189, 192
Airbags, lateral
...................................... 19

1, 192
Air conditioning, automatic

....................... 9
0, 91
Air vents
..............................

............................89
Alarm
............................................................... 63
A

nti-lock braking system (ABS)
....................18

2
Anti-pinch
........................................................ 68
A

nti-theft
..............................
.........................101
Armrest, front

............................................ 8
2, 85
Armrest, rear

............................................. 8
2, 86
Ashtray
...............

............................................. 82
Assistance call
...............................

....... 181, 278
Assistance, emergency braking
..................................... 18

2
Audible warning
............................................ 18

1
Audio streaming (Bluetooth)

................. 2
91, 293
Audio system

...............................
............ 39, 281
Automatic headlamps
............................. 2

0, 147Battery ...............................
............. 223 -227, 251
Battery, charging ...............................
............225
Battery, remote control

............................. 5
9, 60
Black panel ...................................................... 38
Blind spot sensors

........................................12

3
BlueHDi
...............................

.......... 246, 253 -261
Bluetooth (hands-free)

..................................2

92
Boot
........

.........................................................62
Boot (opening)

...............................
..................53
Brake discs

....................................................2

52
Brake lamps

...............................
...................216
Brake warning lamp

........................................2

7
Braking assistance system

...........................18

2
Braking, dynamic emergency
............... 10

3, 107
Bulbs (changing)
...............................

.....211-218
Capacity, fuel tank

..............................
..........239
Cap, fuel filler

................................................23

9
CD
..............................

................................... 287
CD, MP3

................................................ 2
88, 289
Central locking

.......................................... 5
3, 55
Changing a bulb
..................................... 21

1-218
Changing a fuse
..................................... 2

19-222
Changing a wheel

...............................
...202-209
Changing a wiper blade

........................ 1
56, 228
Changing the remote control battery

..............59
C

hecking the engine oil level
.................. 3
6, 247
Checking the levels

................................2

47-25 0
Checking tyre pressures (using the kit)

........2

01
Checks
...............

................... 244, 245, 251, 252Date (setting)

...............................
.............. 39, 42
Daytime running lamps

..................1
45, 211, 212
Deactivating ESC

..........................................18

4
Deactivating the passenger airbag
............... 19

0
Deadlocking
...............................

.....................56
Demisting, defrosting
...................................... 95
D

emisting, defrosting the mirrors
...................80
c
B
d
Checks, routine ..................................... 2 51, 252
Child lock ............................... ................ 169, 176
Children
...............................

...160 -176, 188, 190
Child seats

..............................
..............16 2-18 8
Child seats, conventional

......................16

8, 169
Child seats, ISOFIX

...............................17

0 -173
Cigarette lighter............................................... 83
C
ITROËN
L
ocalised Emergency Call........... 278
Cleaning (advice)
.......................................... 23

3
Clock
...............

................................................ 38
Closing the boot

...............................
...............62
Closing the doors

...............................
....... 53, 55
Configuration, vehicle
............................... 3

9, 45
Control, emergency boot release

...................62
C

ontrol, emergency door
................................ 57
C

ontrol, heated seats
...................................... 76
C

ontrol stalk, lighting
............................14

2, 148
Control stalk, wipers

..............................15

3 -155
Courtesy lamps

............................................. 15

7
Cruise control
........................................ 1

28, 133
Cup holder

...............................
........................82

Key .....................................................52- 60, 101
Key, electronic ......................................52-55, 57
Keyless Entry and Starting

....................... 5
4, 60
Kit, hands-free
.............................................. 2

92
Kit, temporary puncture repair

......................19

6
K
n
O
Labels, identification .....................................2 74
Lamps, cleaning ............................................ 23
3
Lamps, parking
............................................. 14

8
Lane Departure Warning System (LDWS)

...............................
...........12 2
Leather (care)
...............................

.................233
LEDs - light-emitting diodes

................. 1
45, 216
Level, AdBlue
® additive ................................. 25 3
Level, brake fluid ........................................... 24
8
Level, Diesel additive

............................ 2
50, 251
Level, engine coolant

.............................. 3
2, 249
Level, engine oil

...............................
....... 36, 247
Level, headlamp wash

.................................. 24

9
Level, power steering fluid

............................ 24

8
Levels and checks

.................2
44, 245, 247-250
Level, screenwash fluid

................................ 24

9
Light-emitting diodes - LEDs

................ 1
45, 216
Lighting
................

.......................................... 15 8
Lighting, dashboard
........................................ 37
L

ighting dimmer
..............................
................37
Lighting, directional
................................ 15

1, 152
Lighting, guide-me home

...................... 14

6, 148
Lighting, interior
.................................... 15

7, 15 8
Lighting, mood
..............................

................15 8
Lighting, welcome

......................................... 14

9
Loading
..............................

..................... 14, 232
Load reduction mode

.................................... 2

27
Localised Assistance Call

............................. 2

78
Locating your vehicle

...................................... 55
L

ocking from the inside
................................... 61
L

ong objects, transporting
.............................. 86
L

ow fuel level

..............................
............ 28, 239
Lumbar
...............................

............................. 76
LM
Maintenance, routine .............................. 1 4, 233
Map reading lamps ....................................... 15
7
Markings, identification
................................. 2

74
Massage function

...............................
............76
Mat
.......

........................................................... 84
Memorising a speed

..................................... 12

8
Menu, audio system

...................................... 28

4
Mirror, rear view

.............................................. 81
M

irrors, door............................................ 80, 123
Misfuel prevention
...............................

..........242
Mountings, Isofix
...............................

............170
MP3 CD

................
................................. 288, 289
Number plate lamps

...................................... 2

18
Oil change

...............................
......................247
Oil consumption

............................................ 2

47
OIl, engine
...............................

................ 36, 247
Opening the boot

..............................
.. 52-54, 62
Opening the doors

...............................
..... 52, 54
Jack
........

............................................... 202, 203
Jump starting

..............................

.................. 224
J
Instrument panels ............................... ............18
Intelligent Traction Control ............................ 18
3
ISOFIX
...............

.................................... 170 -174
Isofix mountings
...............................

.............170

8Driving
DS5_ Additif_en_Chap04_conduite_ed03-2015
Driving recommendations
Observe the driving regulations and remain vigilant whatever the traffic conditions. Pay close attention to the traffic and keep your hands on the wheel so that you are ready to react at any time to any eventuality. As a safety precaution, the driver must only carry out actions requiring sustained attention when the vehicle is stationary. On a long journey, a break every two hours is strongly recommended. In difficult weather, drive smoothly, anticipate the need to brake and increase the distance from other vehicles.
Driving on flooded roads
We strongly advise against driving on flooded roads, as this could cause serious damage to the engine or gearbox, as well as to the electrical systems of your vehicle.
- check that the depth of water does not exceed 15 cm, taking account of waves that might be generated by other users, - deactivate the Stop & Start system, - drive as slowly as possible without stalling. In all cases, do not exceed 6 mph (10 km/h), - do not stop and do not switch off the engine.
Important!
Never drive with the parking brake applied - Risk of overheating and damage to the braking system! Risk of fire! As the exhaust system of your vehicle is very hot, even several minutes after switching off the engine, never park or leave the engine running where the vehicle is on an inflammable sur face: (grass, dead leaves, paper, etc.): risk of fire.
Never leave a vehicle unsupervised with the engine running. If you have to leave your vehicle with the engine
running, apply the parking brake and put the gearbox into neutral or position N or P , depending on the type P , depending on the type Pof gearbox.
If you are obliged to drive through water:
On leaving the flooded road, as soon as circumstances allow, make several light brake applications to dry the brake discs and pads. If in doubt on the state of your vehicle, contact
a CITROËN dealer or a qualified workshop.
