316
F Start the engine of the vehicle with the good battery and leave it running for a
few
m

inutes.
F

O
perate the starter on the broken down
vehicle and let the engine run.
I

f the engine does not start straight
away, switch off the ignition and wait a
few
moments before trying again.
F

W
ait until the engine returns to idle then
disconnect the jump lead cables in the
reverse order.
F

R
efit the plastic cover to the (+) terminal, if
your vehicle has one.
F

A
llow the engine to run for at least
30
minutes, by driving or with the vehicle
stationary, so that the battery reaches an
adequate state of charge.
Starting using another battery
Some functions, including Stop & Start,
are not available if the battery is not
sufficiently charged.
F

R

aise the plastic cover on the (+) terminal,
if your vehicle has one.
F

C

onnect the red cable to the positive
terminal (+) of the flat battery A (at the metal
elbow) then to the positive terminal

(+) of the
slave battery B or the booster.
F

C

onnect one end of the green or black
cable to the negative terminal (-) of the
slave battery B or the booster (or earth
point on the other vehicle).
F

C

onnect the other end of the green or black
cable to the earth point C on the broken
down vehicle.
Never try to start the engine by
connecting a battery charger.
Never use a 24 V or higher battery
b o o s t e r.
First check that the slave battery has a
nominal voltage of 12 V and a capacity
at least equal to that of the discharged
battery.
The two vehicles must not be in contact
with each other.
Switch off the electrical consumers on
both vehicles (audio system, wipers,
lighting,
...

).
Ensure that the jump lead cables do
not pass close to moving parts of the
engine (cooling fan, belts,

...).
Do not disconnect the (+) terminal when
the engine is running.
When your vehicle's battery is discharged, the
engine can be started using a slave battery
(external or on another vehicle) and jump lead
cables or a battery booster.
In the event of a breakdown

332
Accessories ..........................................129, 226
Accessory position ....................................... 12
9
Access to the 3rd row

..................................... 88
A

ctive Safety Brake................... 27, 32, 175, 177
AdBlue
® additive ................ 1 9, 36, 43, 279, 280
Adjusting head restraints ................................ 80
A
djusting the air distribution
.....................9
6, 99
Adjusting the air flow

.................................9
6, 99
Adjusting the date

........................................... 52
A

djusting the height and reach
of the steering wheel

.................................... 93
A

djusting the seat
........................ 7
6, 78, 84, 86
Adjusting the seat belt height

.......................23

3
Adjusting the temperature

........................9
6, 99
Adjusting the time

........................................... 52
A

dvice on care and maintenance
.................2

78
Advice on driving

..............................
....12 2, 123
Airbags
...............

.....................................33, 238
Airbags, curtain
..................................... 2

40, 241
Airbags, front......................................... 239, 241
Airbags, lateral
...................................... 2

40, 241
Air conditioning
...............................

............9, 98
Air conditioning, automatic

.......................9
5, 99
Air conditioning, manual
...........................9

5, 97
Air intake

...............
.......................................... 99
Air vents
..............................

............................94
Alarm
............................................................... 71
A

nti-lock braking system (ABS)
....................23

0
Anti-pinch
...................................................... 2

25
Anti-slip regulation (ASR)

............................. 23

0
Anti-theft
..............................

.........................129
Armrest, front

..........................................8
3, 107
Assistance call
...............................

...............228
Assistance, emergency braking
...........1

78, 230
Automatic headlamps
..................................... 24B

attery
...............................
..... 267, 277, 315 -318
Battery, charging
...............................
............
317
Battery, remote control
.............................5
9, 60
Black panel ...................................................... 48
Black screen .............................. .....................
48
Blanking screen (snow shield) ......................26
3
Blind, panoramic sunroof

..............................2

25
Blind spot monitoring system

..........2
5, 184, 186
Blind spot monitoring system, assisted
................

.................................25, 186
Blind spot sensors

..................................2
5, 184
Blinds, side

............................................ 1
08, 113
BlueHDi
...............................

............43, 282, 321
Bonnet
...............

............................................271
Boot
........

.........................................................64
Boot (fittings)

...............................
..................11 6
Boot (opening)

...............................
..................53
Bottle holder

...............................
...................107
Brake discs

....................................................2

78
Brake lamps

...............................
...........305-308
Brakes
...............................................3

0, 35, 278
Braking, automatic emergency
............. 2

7, 32, 175, 177
Braking, dynamic emergency
............... 13

0, 13 5
Bulbs (changing)
........................... 3

01, 305-308Cartridge, fragrance
.....................................
10
5
Central locking
................................... 5
4, 56, 57
Changing a bulb
............................ 3
01, 305-308
Changing a fuse ............................................ 31 0
Changing a wheel ............................... ..
291-294
Changing a wiper blade ........................2 24, 268
Changing the remote control battery

..............59
C

hecking the engine oil level
..........................42
C

hecking the levels
................................2

74-276
Checking tyre pressures (using the kit)

..............................
................284
Checks
...............

................... 272, 273, 277, 278
Child lock

...............................
........................258
Children
...............................

. 249, 252, 253, 255
Children (safety)
...............................

.............258
Child seats

............ 2
37, 242, 243, 247-249, 257
Child seats, conventional

..............................24

8
Child seats, ISOFIX

......................25

1-253, 255
Citroën Connect Box

....................................2

28
Citroën Localised Emergency Call

...............2

28
Closing the boot

...............................
...............64
Closing the doors

............................... 5
4, 56, 57
Collision Risk Alert

.................... 2
7, 32, 175, 176
Configurations, seats
...................................... 91
C

onfiguration, vehicle
............................... 1
1, 13
Control, emergency boot release

...................68
C

ontrol, emergency door
................................63
C

ontrol, heated seats
......................................8

2
Control stalk, lighting

......................2
4, 208, 212
Control stalk, wipers

.....................2
20, 221, 223
Courtesy lamps

.............................................12

0
Cruise control
........................ 1

48, 151, 156, 166
Cruise control, dynamic

................................15

9
Cruise control by speed limit recognition
.................................................. 1

51
Cruise control, dynamic with Stop function

........................16

6
Cup holder

...............................
......................107
AB
Capacity, fuel tank .............................. ..........259
Cap, fuel filler ................................................ 25
9
C
Alphabetical index

334
Identification, vehicle ....................................3 31
Ignition ................ ........................................... 129
Immobiliser, electronic
............................6

0, 129
Indicator, AdBlue
® range ................................. 43
I
ndicator, coolant temperature ........................ 41
I
ndicator, engine oil level
................................ 42
I

ndicator lamps, operation
............ 2
2, 25, 27, 31
Indicator lamps, status

.............................. 2
5, 31
Indicators, direction
...................................... 2

17
Inflating tyres

..............................
.............. 9, 287
Instrument panels
...............................

......18 -20
Intelligent Traction Control
............................ 2

31
ISOFIX
...............

........................................... 252
Isofix mountings
...............................

.............2 51Key
.......

.................................. 53, 55, 56, 59, 60
Key, electronic
........................................... 53
-58
Keyless Entry and Starting
................. 5
5, 57, 60
Key with remote control
................................
12
9
Kit, temporary puncture repair
......................
28
4
Labels, identification
..................................... 3
31
Lamp, boot ............................... .....................
11 9
Lamps, parking ............................................. 2
12
Lane departure warning active
.......3 0, 180, 186
LEDs - light-emitting diodes

.........3
01, 305, 307
Leg rest, electric

..............................
...............81
Level, AdBlue
® additive ................................. 2 79
Level, brake fluid ........................................... 2
75
Level, Diesel additive

.................................... 2

76
Level, engine coolant

.............................. 4
1, 276
Level, engine oil

...............................
....... 42, 274
Level, headlamp wash

.................................. 2

75
Levels and checks

..............................
...272-276 Maintenance, routine
........................................ 9
M
ap reading lamps
.......................................
12
0
Markings, identification
................................. 3
31
Massage function
...............................
............
81
Mat
.......
.........................................................
111
Memorising a speed .....................................
14 8
Mirror, child surveillance ...............................2
07
Mirror, rear view
............................................20
6
Mirrors, door......................... 104, 184, 205, 206
Misfuel prevention
...............................

..........260
Modularity, seats
...............................

..............91
Motorised tailgate
..................................... 6

5 - 67
Mountings, Isofix
...............................

............2 51
Level, screenwash fluid

................................
2
75
Light-emitting diodes - LEDs
........3
01, 305, 307
Lighting
................
.................................... 24, 121
Lighting, directional
............................... 21
8, 219
Lighting, guide-me home
..............................
2
12
Lighting, interior
.................................... 12
0, 121
Lighting, mood
..............................
................
121
Lighting, welcome
.........................................
2
16
Loading
..............................
............................... 9
Load reduction mode
....................................
2
67
Localised Assistance Call
.............................
2
28
Locating your vehicle
......................................
54
L
ocking from the inside
...................................
61
L
ocking the doors
..............................
.............
61
Low fuel level
..............................
..................
259
Lumbar
...............................
.............................
81
I
K
LM
Jack ....................................................... 291-294
Jump starting .............................. ..................316
J
Headlamp adjustment ................................... 2 17
Headlamps, automatic dipping .....................2
14
Headlamps,
automatic illumination
......................... 2

09, 213
Headlamps, dipped beam

...... 2
4, 208, 301, 302
Headlamps, directional
......................... 2

19, 301
Headlamps, halogen
..................................... 3

01
Headlamps, main beam ... 24, 208, 301-303, 305
Headlamps, Xenon
....................................... 3
01
Head restraints, front

...................................... 80
H

ead restraints, rear

....................................... 85
H

eating
................

..................................9, 96, 97
Hill start assist

............................................... 13

7
Hooks
...............................

............................. 115
Horn ............................................................... 227
Alphabetical index

94
Audio and Telematics
QUESTIONANSWERSOLUTION
There is a difference in sound quality between the different audio sources.
For optimum sound quality, the audio settings can be adapted to the different sound sources, which may result in audible differences when changing source.
Check that the audio settings are adapted to the sources listened to. Adjust Balance, Treble, Bass to the middle position, select the "None" musical ambience and set the loudness correction to the "Active" position in CD mode or to the "Inactive" position in radio mode.
With the engine off, the system switches off after a few minutes of use.
When the engine is switched off, the system's operating time depends on the state of charge of the battery. The switch-off is normal: the system switches to economy mode and switches off to prevent discharging of the vehicle's battery.
Start the vehicle's engine to increase the battery charge.
The date and time cannot be set. Setting of the date and time is only available if the synchronisation with the satellites is deactivated. Settings menu / Options / Time-Date setting. Select the "Time" tab and deactivate the "GPS synchronisation" (UTC).

146
Audio and Telematics
Transversal-Citroen_en_Chap02_RCC-2-2-0_ed01-2016
QUESTIONANSWERSOLUTION
In changing the setting of treble and bass the equalizer setting is deselected.
The selection of an equalizer setting imposes the settings for treble and bass and vice-versa. Modify the treble and bass or equalizer settings to obtain the desired musical ambience.
In changing the equalizer setting, treble and bass return to zero.
When changing the balance settings, the distribution setting is deselected.
The selection of a distribution setting imposes the balance settings and vice-versa. Modify the balance or distribution settings to obtain the desired musical ambience.
When changing a distribution setting, the balance setting is deselected.
There is a difference in sound quality between the different audio sources.
For optimum sound quality, the audio settings can be adapted to the different sound sources, which may result in audible differences when changing source.
Check that the audio settings are adapted to the sources listened to. Adjust the audio functions to the middle position.
With the engine off, the system switches off after a few minutes of use.
When the engine is switched off, the system's operating time depends on the state of charge of the battery. The switch-off is normal: the system switches to economy mode and switches off to prevent discharging of the vehicle's battery.
Start the vehicle's engine to increase the battery charge.
Settings

166
Audio and Telematics
The table below gives answers to the most frequently asked questions on your audio system.
QUESTIONANSWERSOLUTION
With the engine off, the audio system switches off after a few minutes of use.
When the engine is switched off, the audio system operating time depends on the state of charge of the battery. The switch-off is normal: the audio equipment switches to economy mode and switches off to prevent discharging of the vehicle's battery.
Start the vehicle's engine to increase the battery charge.
The message "the audio system is overheated" appears on the display.
In order to protect the installation if the surrounding temperature is too high, the audio system switches to an automatic thermal protection mode leading to a reduction in volume or CD play stopping.
Switch the audio system off for a few minutes to allow the system to cool.
Frequently asked questions
QUESTIONANSWERSOLUTION
There is a difference in sound quality between the different audio sources (radio, CD...).
For optimum sound quality, the audio settings (Volume, Bass, Treble, Ambience and Loudness) can be adapted to the different sound sources, which may result in audible differences when changing source (radio, CD...).
Check that the audio settings (Volume, Bass, Treble, Ambience and Loudness) are adapted to the sources listened to. It is advisable to set the audio functions (Bass, Treble, Front-Rear Balance and Left-Right Balance) to the middle position, select the musical ambience "None" and set the loudness correction to the "Active" position in CD mode or to the "Inactive" position in radio mode.
Radio
