79
F Pull the handle toward the rear to unlock the loading area and start the electrically
powered opening of the door. F

P
ull the handle toward the rear to start the
electrically powered opening of the door.
Using the handle
Cab and loading area selectivity
activated. Child lock off (deactivated).
F

P

ull the handle toward the rear to totally

unlock the vehicle and start the electrically
powered opening of the door.
From inside
Cab and loading area selectivity
deactivated.
For more information on the Key,
Remote control or Keyless Entr y
and Starting and in particular total
or selective unlocking, refer to the
corresponding section. Cab
and loading area selectivity
deactivated.
From inside, total
unlocking then
opening
F To unlock the vehicle and start the
electrically powered opening of a door,
press the button for the corresponding
d o o r.
F

P
ressing the button again reverses the
movement of the door.
The button is inoperative and
accompanied by an audible signal, if:
-

t
he vehicle is moving,
-

t
he vehicle has been locked or
deadlocked from outside (using
the key, remote control or Keyless
Entry and Starting, depending on
equipment).
Depending on equipment, the button
for the left hand door is inoperative and
accompanied by an audible signal, if
the fuel filler flap is open.
Using the button(s) at the front
Vehicle locked Vehicle unlocked
2
Access

80
F To unlock the loading area only and start
the electrically powered opening of a door,
press the button for the corresponding
d o o r.
F

P
ressing the button again reverses the
movement of the door. The button is inoperative and
accompanied by an audible signal, if:
-

t
he vehicle is moving,
-
t
he vehicle has been locked or
deadlocked from outside (using
the key, remote control or Keyless
Entry and Starting, depending on
equipment).
Depending on equipment, the button
for the left hand door is inoperative and
accompanied by an audible signal, if
the fuel filler flap is open.
For more information on the Key
,
Remote control or Keyless Entr y
and Starting and in particular total
or selective unlocking, refer to the
corresponding section.
Using the button(s) at the frontFrom inside,
selective unlocking
then opening
Cab and loading area selectivity
activated.
Access

81
F Child lock deactivated, to unlock the vehicle and start the electrically powered
opening of a door, press the button for the
corresponding door.
F

P
ressing the button again reverses the
movement of the door.
The button is not operational and
pressing it results in an audible signal, if:
-

t
he vehicle is moving,
-

t
he vehicle has been locked or
deadlocked from outside (using
the key, remote control or Keyless
Entry and Starting, depending on
equipment),
-

t
he child lock is on (activated).
The button for the left-hand door is not
operational and pressing it results in an
audible signal if the fuel filler flap is open. The button is not operational and
pressing it results in an audible signal, if:
-

t
he vehicle is moving,
-

t
he vehicle has been locked or
deadlocked from outside (using
the key, remote control or Keyless
Entry and Starting, depending on
equipment),
-

t
he child lock is on (activated).
The button for the left-hand door is not
operational and pressing it results in an
audible signal if the fuel filler flap is open.
Using the button(s) at the frontFrom inside,
unlocking then
openingUsing the button(s) on the door
pillar
F Child lock deactivated, to unlock the vehicle and start the electrically powered
opening of a door, press the button for the
corresponding door.
F

P
ressing the button again reverses the
movement of the door.
For more information on the Child lock
,
refer to the corresponding section.
2
Access

82
The remote controls buttons are not
active with the ignition switched on.
Closing
From outside
F To start the electrically powered opening of the door, press the button for the
corresponding door.
F

P
ressing the button again reverses the
movement of the door.
Using the button(s) at the front
The button is not operational and
pressing it results in an audible signal,
if the speed of the vehicle is above
20
mph (30 km/h).
From inside
Using the remote control
F Press and hold this button until the sliding door has closed.
F

P
ress this button again to
reverse the movement of the
d o o r.
Using the handle
F Pull and release the handle to start the electrically powered opening of the door.
F

P
ull the handle again to reverse the
movement of the door.
Access

83
F To start the electrically powered opening of a door, press the button for the
corresponding door.
F

P
ressing the button again reverses the
movement of the door.
Using the button(s) on the door
pillar
The button is not operational and
pressing it results in an audible signal,
if the speed of the vehicle is above
20
mph (30 km/h). If a sliding door is not fully closed:
-

v
ehicle stationary and engine
running, this warning lamp comes
on, accompanied by an alert
message for a few seconds,
-
v
ehicle moving (speed above
6 mph (10 km/h)), this warning
lamp comes on, accompanied
by an audible signal and an alert
message for a few seconds.
2
Access

84
General
recommendations
The doors must only be operated when
the vehicle is stationary.
For your safety and for that of your
passengers, as well as for correct
operation of the doors, you are strongly
advised not to drive with a door open.
Always check that it is safe to operate
the door and in particular, be sure not to
leave children or animals near the door
controls without supervision.
The audible warning, illumination of
the "door open" warning lamp and the
message in the multifunction screen
are there to remind you. Contact
a CITROËN dealer or a qualified
workshop to deactivate these warnings.
Lock your vehicle when using an
automatic car wash.Before any opening or closing and
during any movement of the doors,
ensure that no person, animal or object
is protruding through the window
frame or might prevent the intended
manoeuvre, either inside or outside the
vehicle.
If this advice is not followed, injuries or
damage may occur if a person or an
object is trapped or caught.
Electric closing and opening of the
doors is not possible above 2 mph
(3
km/h):
-

I
f you set off with the door(s) open,
you must slow down to below
20
mph (30 km/h) in order to close
the door(s).
-

A
ny attempt to open a door
electrically using the interior handle
while driving, results in only being
possible to open the door manually.
-

T
his situation is accompanied by
the audible warning, illumination of
the "door open" warning lamp and
the message in the multifunction
screen. To release the door and
be able to operate it again, it is
necessary to stop the vehicle.
Manual or electric sliding side door(s)
The electric controls are inhibited in the
event of an impact. Manual opening and
closing remain possible.
While starting the engine, the
movement of a door is interrupted and
restored once the engine is running.
Depending on the engine, in Stop
mode of Stop & Start, if the door
is closed and you initiate opening
of the door, the door opens
partially and stops. When the
engine changes automatically to
Start mode, the door continues its
movement.
Access

85
When open, a door never projects
beyond the rear bumper.
The doors and the overall
dimensions of the vehicle
When open, a door projects beyond the body.
Be sure to take this into account when you park
alongside a wall, a post or a high kerb...
Safety / Obstacle detection with
electric door(s)Fuel filler flap
The obstacle detection system is triggered
when the moving door encounters an obstacle
with a certain level of physical resistance.
-

I
f an obstacle is detected while the door is
closing, the door stops then opens fully.
-

I
f an obstacle is detected while the door is
opening, the door stops and then closes.
-

I
f an obstacle is detected twice in
succession during a movement of the door,
it will no longer close electrically. Close the
door manually to reinitialise it. If fitted to your vehicle, never open the
left-hand sliding side door when the
fuel filler flap is open. Other wise you
risk damaging the fuel filler flap and the
sliding door and causing injury to the
person filling the vehicle.
If the fuel filler flap is open and your
vehicle has an electric left-hand sliding
side door, the door cannot be opened
using the opening control button. If
required the door can be opened half
way manually. The fuel filler flap must
be closed to allow the door to open
correctly
2
Access

86
In the case of a steep slope, the door
may be driven by its own weight and
as a consequence may open or close
j e r k i l y.
There would not be time for action at
the electric controls to take effect.
There would not be time for the
obstacle detection system to react.
Take care not to leave the vehicle on
a steep slope with the door(s) open
without supervision. If this advice is not
followed, injuries or damage may occur
if a person or an object is trapped or
caught.
On a steep slope
It is possible to open and close the doors
electrically on slopes of up to 20%.
However, if your vehicle is on a slope, with the
front of the vehicle facing up, open the door
with care. The door may open more quickly due
to the incline.
On a steep slope, guide the side door manually
to help it to close. However, if your vehicle is on a slope, with the
front of the vehicle facing down, the door may
not stay open and may close again jerkily with
the risk of injury.
Reinitialising electric doors
Following disconnection of the battery with the
doors open, it may be necessary to close the
doors manually to reinitialise them.
If the doors no longer work electrically,
reinitialise the door(s) as follows:
F

F
ully close the door(s) manually.
F

F
ully open the door(s) manually.
F

C
lose the door(s) manually.
F

F
ully open the door(s) manually.
F

C
lose the door(s) manually.
On completion of this procedure, electric
operation of the doors is restored.
However, if a problem persists following this
procedure, contact a CITROËN dealer or a
qualified workshop.
Access

87
The automatic locking after closing the
door is programmable in the vehicle
configuration menu.
Hands-free sliding side door(s)
By keeping the remote control on your person
and with a movement of your foot, the system
unlocks and opens the sliding side door or
closes and locks it.
The remote control must be located at the rear
of the vehicle, more than about 30 cm and less
than about 2 m from the vehicle.Before making the movement with your
foot, ensure that you are steady and
well positioned, so that you do not lose
your balance (rain, snow, ice, mud, ...).
Take care not to touch the exhaust
tailpipe when making the movement
with your foot - risk of burns.
Make the movement without interruption
and do not repeat it immediately
after wards or several times.
If the door does not open, wait about
2 seconds before trying again.
Do not leave your foot in the air.
F

P
ass your foot below the rear bumper then
remove it, as though kicking (upwards).
The sensor detects your foot approaching and
leaving and triggers opening or closing of the
side door.
2
Ac

88
For more information on the Key,
Remote control or Keyless Entr y
and Starting , and in particular total
or selective locking, refer to the
corresponding section.
Confirmation that the door is going
to open is signalled by the direction
indicators flashing for a few seconds,
accompanied by an audible signal.
The movement of the door is reversed
if you pass your foot under the bumper
during operation of the door.
If fitted to your vehicle, the electric door
mirrors unfold on unlocking the vehicle.
Opening
With "
Hands-free access " activated in the
vehicle configuration menu.
F

W
ith the remote control on your person and
in the recognition zone A , pass your foot
under the outer rear bumper, on the side
you want to open the door. Cab
and loading area selectivity
deactivated.
Cab and loading area selectivity
activated.
If the vehicle is locked, it is unlocked before
opening the door.
If the vehicle is locked, the loading area is
unlocked before opening the door. If the vehicle is locked, it is unlocked before
opening the door.
Access
