Citroen NEMO 2009 1.G Owner's Manual
Manufacturer: CITROEN, Model Year: 2009, Model line: NEMO, Model: Citroen NEMO 2009 1.GPages: 153, PDF Size: 3.99 MB
Page 1 of 153
5
FAMILIARISATION
Familiarisation
EXTERIOR
Roof rack and roof bars
Fixing points are provided on each side of the
roof for securing the roof rack or the transverse
roof bars.
109
Opening the hinged rear doors
to 180°
Once the vehicle has been unlocked, the
hinged rear doors can be opened to 180° to
make unloading/loading operations easier.
34
Rear parking assistance
This equipment warns you, by means of an
audible signal, if an obstacle is detected
behind the vehicle when reverse gear is
engaged.
68
"Guide-me-home" lighting
After switching off the ignition, when you leave
y o u r v e h i c l e , t h e f r o n t l a m p s r e m a i n o n b r i e fl y .
39
Page 2 of 153
6
Familiarisation
OPEN
Remote control key
A. Unfolding/Folding of the key.
B. Unlocking of the front doors only (Light
van) or of all of the doors (Combi)
( t w o fl a s h e s o f t h e d i r e c t i o n i n d i c a t o r s ) .
C. Central locking of the vehicle
( o n e p r e s s ; o n e fl a s h o f t h e d i r e c t i o n indicators).
or
Deadlocking of the vehicle
( t w o c o n s e c u t i v e p r e s s e s ; o n e fl a s h o f t h e direction indicators).
D. Unlocking of the load space (Light van) or
of the hinged rear doors or tailgate only
(Combi).
If a door is open or has not been closed
properly, the failed locking is indicated by three
fl a s h e s o f t h e d i r e c t i o n i n d i c a t o r s .
Fuel tank
1. O p e n i n g o f t h e f u e l fi l l e r fl a p .
2. Opening and hooking of the fuel tank cap.
Capacity of the tank: approximately 45 litres.
29
129
Opening to 180°
34
Press the catch while opening the door.
Page 3 of 153
7
FAMILIARISATION
Familiarisation
INTERIOR
Trip computer
By means of the MENU button, this system
permits management or consultation of the
v a r i o u s v e h i c l e c o n fi g u r a t i o n s / i n f o r m a t i o n s u c h
as the disarming of the passenger air bag, the
automatic locking of the doors, the language,
etc.
64
Retractable multifunction passenger
seat
T h i s e q u i p m e n t e n a b l e s y o u t o c o n fi g u r e y o u r
passenger seat in three positions:
- seat for the transportation of a passenger,
- table to accommodate your various
documents,
- retracted for the transportation of long objects.
76
Audio system
T h i s e q u i p m e n t b e n e fi t s f r o m t h e l a t e s t
technology: MP3 compatible audio equipment
and Bluetooth ®
hands-free kit.
69
Cruise control/speed limiter
These two functions control the speed of the
vehicle in relation to the programmed value.
41, 44
Electronic gearbox system
This equipment guarantees perfect driving
by combining a fully automatic mode and a
manual mode.
50
Page 4 of 153
8
Familiarisation INSTRUMENTS AND CONTROLS
1. Steering wheel adjustment control.
2. Lights and direction indicators controls.
3. Instrument panel.
4. Driver’s air bag.
Horn.
5. Cruise control/speed limiter switches.
6. Gear lever.
7. Handbrake.
8. Bonnet release.
9. Exterior mirror controls.
10. Fuse box.
11. Manual headlamp height adjustment.
12. Side adjustable and closing vent.
13. Front side window demisting vent.
14. Windscreen demisting vent.
15. Steering lock and ignition.
16. Wipers/wash-wipe/trip computer controls.
17. Central adjustable and closing vents.
18. Passenger air bag.
19. MENU button.
20. Glove box.
21. Lighter.
22. Ashtray.
23. Heating/air conditioning controls.
24. Audio equipment.
25. Electric window controls.
26. 12 V accessories socket.
Page 5 of 153
9
FAMILIARISATION
Familiarisation
LOAD SPACE (LIGHT VAN)
1. Stowing rings.
2. Storage tray.
3. Torch.
4. Partition.
5. Spare wheel.
82 It is advisable to immobilise the load
b y fi x i n g i t s e c u r e l y u s i n g t h e s t o w i n g
rings
1 o n t h e fl o o r .
Page 6 of 153
10
Familiarisation
REAR LAYOUT (COMBI)
8 9
With hinged rear doors
1. Stowing rings.
2. Luggage retaining net.
3. Tool kit.
4. Rear shelf.
With tailgate
1. Stowing rings.
2. Luggage retaining net.
3. Rear shelf.
4. Retaining straps/Tool kit.
5. Torch/Boot light.
Page 7 of 153
11
FAMILIARISATION
Familiarisation
SIT COMFORTABLY
Driver’s seat adjustment
Forwards-backwards Height Seat back angle (A)
Lumbar support (B)
74
Page 8 of 153
12
Familiarisation Front seat belts
A. Fastening.
94
SIT COMFORTABLY
Steering wheel adjustment
1. Unlocking of the control.
2. Adjustment of the height and depth.
3. Locking of the control.
As a safety precaution, it is imperative
that these operations are carried out
while stationary.
49
Electric exterior mirror adjustment
A. Selection of the driver’s mirror.
B. Selection of the passenger’s mirror.
C. Adjustment of the position of the mirror.
47
Interior mirror adjustment
1. Selection of the "day/night" position of the
mirror.
2. Directing of the mirror.
47
Page 9 of 153
13
FAMILIARISATION
Familiarisation
SEE CLEARLY
Ring
Lamps off.
Side lamps.
Dipped/main beam headlamps.
Fog lamps
Rear fog lamp.
or
Front and rear fog lamps.
38
Direction indicators
"Motorway" function
Press the lighting control up or down once,
without passing the point of resistance; the
c o r r e s p o n d i n g d i r e c t i o n i n d i c a t o r s w i l l fl a s h
three times.
38
Wipers
Ring A: windscreen wipers
40
Ring B: rear wiper
40 Single wipe.
Intermittent wipe.
Wash-wipe.
Wash-wipe.
Park.
Lighting
Park.
Intermittent.
Slow continuous.
Rapid continuous.
Raise or lower the lighting control past the
point of resistance; the corresponding direction
i n d i c a t o r s w i l l fl a s h u n t i l t h e c o n t r o l i s m o v e d
out of this position.
Page 10 of 153
14
Familiarisation
81
VENTILATION
Recommended interior settings
I require...
Heating or Manual Air Conditioning
Air distribution A i r fl o w
Air recirculation/
Intake of outside air
Temperature Manual A/C
HOT
COLD
DEMISTING
DE-ICING
