10
Familiarisation
SITTING COMFORTABLY
Driver’s seat adjustment
Forwards-backwards Height Seat back angle (A)
Lumbar support (B)

 78

11
FAMILIARISATION
Familiarisation
Front seat belts

A. Fastening.

 101
SITTING COMFORTABLY
Steering wheel adjustment

1. Release the adjustment mechanism.

2. Adjust for the height and reach.

3. Lock the adjustment mechanism.
As a safety precaution, these operations
must be carried out while stationary.

 46 Electric door mirror adjustment

A. Selection of the driver’s mirror.

B. Selection of the passenger’s mirror.

C. Adjustment of the position of the mirror.

 44
Rear view mirror adjustment

1. Selection of the "day/night" position of the
mirror.

2. Adjustment of the position of the mirror.

 44

79
4
EASE OF USE and COMFORT
Seats
Seat cushion height
To adjust the height of the driver's seat
cushion, pull the control upwards as many
times as necessary to raise.
To lower, push the control downwards as
many times as necessary.
Forwards-backwards adjustment
Heated seat control
Press the control.
The temperature is controlled automatically.
Pressing a second time stops operation.
Lift the control bar and slide the seat
forwards or backwards to the required
position.
Lumbar support
Seat back angle
Turn the control to adjust the angle of the
seat back. Turn the control.
Armrest
The driver's seat may be fitted with an
armrest on the centre console side.
Raise or lower completely the armrest to
obtain the most comfortable driving position.
