DAEWOO LACETTI 2004 Service User Guide

0B – 4IGENERAL INFORMATION
DAEWOO V–121 BL4
Steering System
Application1.4L DOHC1.6L DOHC1.8L DOHC
Gear TypePower
Rack and Pinion


Overall Gear Ratio
Power Steering16 : 1


Wheel Diameter
W/ Air Bag
W/O Air Bag380 mm (15.0 in.)
370 mm (14.5 in.)






Wheel Alignment :
Front :
Toe–In
Caster
Camber0° ± 10’
4° ± 45’
20’ ± 45’










Rear :
Toe–In
Camber
12’ ± 10’
–1° ± 45’






Oil Capacity1.1L (1.2 qts)


Suspension
Application1.4L DOHC1.6L DOHC1.8L DOHC
Front TypeMacpherson Strut


Rear TypeDual Link


Fuel System
Application1.4L DOHC1.6L DOHC1.8L DOHC
Fuel DeliveryMPI


Fuel Pump TypeElectric Motor Pump


Fuel Filter TypeCartridge


Fuel Capacity60L (15.85 gal)


Lubricating System
Application1.4L DOHC1.6L DOHC1.8L DOHC
Lubricating TypeForced Feed


Oil Pump TypeRotary (Trochoid)


Oil Filter TypeCartridge (Full Flow)


Oil Pan Capacity
Including Oil Filter3.75L (4 qts)
4.0L (4.2 qts)

GENERAL INFORMATION 0B – 5
DAEWOO V–121 BL4
Cooling System
Application1.4L DOHC1.6L DOHC1.8L DOHC
Cooling TypeForced Water
Circulation


Radiator TypeCross–flow


Water Pump TypeCentrifugal


Thermostat TypePellet Type


Coolant Capacity7.0L (7.49 qts)7.2L (7.6 qts)7.4L (7.8 qts)
Electric System
Application1.4L DOHC1.6L DOHC1.8L DOHC
Battery12V–55 AH


610 CCA
(Cold Cranking Amps)


Alternator85 Amps
95 Amps
Starter1.2 KW
1.4 KW
No–Load Test @ 12.2
volts
Drive Pinion Speed at :90 Amps Max
Min. 2,600 rpm


85 Amps Max
Min. 2,550 rpm

0B – 6IGENERAL INFORMATION
DAEWOO V–121 BL4
VEHICLE DIMENSIONS AND WEIGHTS
Vehicle Dimensions
Application1.4L DOHC1.6L DOHC1.8L DOHC
Overall Length
4 Door
5 Door H/B4,500 mm (177.2 in.)
4,295 mm (169.1 in.)






Overhang :
4 Door
Front
Rear
885 mm (34.8 in.)
1,015 mm (40.0 in.)






5 Door H/B
Front
Rear
902 mm (35.5 in.)
793 mm (31.2 in.)






Overall Width1,725 mm (67.9 in.)


Overall Height1,445 mm (56.9 in.)


Minimum Ground Clear-
ance160 mm (6.3 in.)


Wheel Base2,600 mm (102.4 in.)


Tread :
Front
Rear1,480 mm (58.3 in.)
1,480 mm (58.3 in.)






Vehicle Weights
4 Door
Application1.4L DOHC1.6L DOHC1.8L DOHC
Manual :
Curb Weight :
Standard
Optional1,175 kg (2,590 lb)
1,225 kg (2,701 lb)1,180 kg (2,601 lb)
1,230 kg (2,712 lb)1,210 kg (2,668 lb)
1,260 kg (2,778 lb)
Gross Vehicle Weight1,660 kg (3,660 lb)1,665 kg (3,671 lb)1,695 kg (3,737 lb)
Automatic :
Curb Weight :
Standard
Optional–
–1,190 kg (2,624 lb)
1,240 kg (2,734 lb)1,235 kg (2,723 lb)
1,285 kg (2,833 lb)
Gross Vehicle Weight–1,675 (3,693 lb)1,720 kg (3,792 lb)
Passenger Capacity5


Optional Weight : ABS, Sun Roof, A/C

GENERAL INFORMATION 0B – 7
DAEWOO V–121 BL4
Vehicle Weights
5 Door H/B
Application1.4L DOHC1.6L DOHC1.8L DOHC
Manual :
Curb Weight :
Standard
Optional1,170 kg (2,580 lb)
1,220 kg (2,690 lb)1,175 kg (2,590 lb)
1,225 kg (2,701 lb)1,205 kg (2,657 lb)
1,255 kg (2,767 lb)
Gross Vehicle Weight1,645 kg (3,627 lb)1,650 kg (3,638 lb)1,680 kg (3,704 lb)
Automatic :
Curb Weight :
Standard
Optional–
–1,185 kg (2,612 lb)
1,235 kg (2,723 lb)1,230 kg (2,712 lb)
1,280 kg (2,822 lb)
Gross Vehicle Weight–1,660 kg (3,660 lb)1,705 kg (3,759 lb)
Passenger Capacity5


Optional Weight : ABS, Sun Roof, A/C

0B – 8IGENERAL INFORMATION
DAEWOO V–121 BL4
STANDARD BOLT SPECIFICATIONS
Bolt*4T – Low Carbon Steel7T – High Carbon Steel7T – Alloy Steel
M6 X 1.04.1–8.1 NSm (36–72 lb–in)5.4–9.5 NSm (48–84 lb–in)–
M8 X 1.25 8.1–17.6 NSm (72–156 lb–in)12.2–23.0 NSm (108–204 lb–in)16–30 NSm (12–22 lb–ft)
M10 X 1.25 20–34 NSm (15–25 lb–ft)27–46 NSm (20–34 lb–ft)37–62 NSm (27–46 lb–ft)
M10 X 1.5 19–34 NSm (14–25 lb–ft)27–45 NSm (20–33 lb–ft)37–60 NSm (27–44 lb–ft)
M12 X 1.25 49–73 NSm (36–54 lb–ft)61–91 NSm (45–67 lb–ft)76–114 NSm (56–84 lb–ft)
M12 X 1.75 45–69 NSm (33–51 lb–ft)57–84 NSm (42–62 lb–ft)72–107 NSm (53–79 lb–ft)
M14 X 1.5 76–115 NSm (56–85 lb–ft)94–140 NSm (69–103 lb–ft)114–171 NSm (84–126 lb–ft)
M14 X 2.0 72–107 NSm (53–79 lb–ft)88–132 NSm (65–97 lb–ft)107–160 NSm (79–118 lb–ft)
M16 X 1.5 104–157 NSm (77–116 lb–ft)136–203 NSm (100–150 lb–ft)160–240 NSm (118–177 lb–ft)
M16 X 2.0 100–149 NSm (74–110 lb–ft)129–194 NSm (95–143 lb–ft)153–229 NSm (113–169 lb–ft)
M18 X 1.5 151–225 NSm (111–166 lb–ft)195–293 NSm (144–216 lb–ft)229–346 NSm (169–255 lb–ft)
M20 X 1.5 206–311 NSm (152–229 lb–ft)270–405 NSm (199–299 lb–ft)317–476 NSm (234–351 lb–ft)
M22 X 1.5 251–414 NSm (185–305 lb–ft)363–544 NSm (268–401 lb–ft)424–636 NSm (313–469 lb–ft)
M24 X 2.0 359–540 NSm (265–398 lb–ft)431–710 NSm (318–524 lb–ft)555–831 NSm (409–613 lb–ft)
* Diameter X pitch in millimeters

GENERAL INFORMATION 0B – 9
DAEWOO V–121 BL4
MAINTENANCE AND REPAIR
MAINTENANCE AND LUBRICATION
NORMAL VEHICLE USE
The maintenance instructions contained in the mainte-
nance schedule are based on the assumption that the ve-
hicle will be used for the following reasons:
S To carry passengers and cargo within the limitation
indicated on the tire placard located on the edge of
the driver’s door.
S To be driven on reasonable road surfaces and with-
in legal operating limits.
EXPLANATION OF SCHEDULED
MAINTENANCE SERVICES
The services listed in the maintenance schedule are fur-
ther explained below. When the following maintenance
services are performed, make sure all the parts are re-
placed and all the necessary repairs are done before driv-
ing the vehicle. Always use the proper fluid and lubricants.
Drive Belt Inspection
When a separate belt drives the power steering pump, the
air conditioning compressor and the generator, inspect it
for cracks, fraying, wear and proper tension. Adjust or re-
place the belt as needed.
Engine Oil and Oil Filter Change
API Classifications of Engine Oil
The International Lubricant Standardization and Approval
Committee (ILSAC) and American Petroleum Institute
classifies engine oils according to their performance quali-
ty. Always use oil rated API–SL (ILSAC GF–III) or better.
Engine Oil Viscosity
Engine oil viscosity (thickness) has an effect on fuel econ-
omy and cold weather operation. Lower viscosity engine
oils can provide better fuel economy and cold weather per-
formance; however, higher temperature weather condi-
tions require higher viscosity engine oils for satisfactory lu-
brication. Using oils of any viscosity other than those
viscosities recommended could result in engine damage.
Cooling System Service
Drain, flush and refill the system with new coolant. Refer
to ”Recommended Fluids And Lubricants” in this section.
Fuel Micro–Filter Replacement
Replace the engine fuel filter every 45,000 km (27,000
miles).
Air Cleaner Element Replacement
Replace the air cleaner element every 45,000 km (27,000
miles).Replace the air cleaner more often under dusty conditions.
Throttle Body Mounting Bolt Torque
Check the torque of the mounting bolts.
Tighten the throttle body mounting bolts to 15 NSm (11 lb–
ft) if necessary.
Spark Plug Replacement
Replace spark plugs with the same type.
Spark Plug Wire Replacement
Clean wires and inspect them for burns, cracks or other
damage. Check the wire boot fit at the DIS module and at
the spark plugs. Replace the wires as needed.
Brake System Service
Check the disc brake pads and the drum brake linings ev-
ery 15,000 km (9,000 miles) or 12 months. Check the pad
and the lining thickness carefully. If the pads or the linings
are not expected to last to the next scheduledmaintenance
service, replace the pads or the linings. Check the breath-
er hole in the brake fluid reservoir cap to be sure it is free
from dirt and the passage is open.
Transaxle Service
The manual transaxle fluid does not require changing. For
automatic transaxles, refer to ”Scheduled Maintenance
Charts” in this section.
Tire and Wheel Inspection and Rotation
Check the tires for abnormal wear or damage. To equalize
wear and obtain maximum tire life, rotate the tires. If irreg-
ular or premature wear exists, check the wheel alignment
and check for damaged wheels. While the tires and
wheels are removed, inspect the brakes. Refer to ”Each
Time The Oil Is Changed” in this section.
Tire Rotation

0B – 10IGENERAL INFORMATION
DAEWOO V–121 BL4
SCHEDULED MAINTENANCE CHARTS
Engine
Maintenance ItemMaintenance Interval
Kilometers or time in months, whichever comes first
x 1,000 km1153045607590105120
x 1,000 miles0.6918273645546372
Months–1224364860728496
Drive belts (Alternator, power steering
and A/C belt)IIII
Engine oil & engine oil filter (1) (3)IRRRRRRRR
Cooling system hose & connectionsIIIIIIII
Engine coolant (3)IIIRIIRII
Fuel filterRR
Fuel line and connectionsIIIIIIII
Air cleaner element (2)IIRIIRII
Spark plugs (1.4D/1.6D)IRIRIRIR
Spark plugs (1.8D)IRIR
Spark plug wiresReplace every 90,000 km(54,000 miles)
EVAP canister, vapor lines & solenoid
valve filterII
PCV systemIIII
Timing beltlRlR
Chart Symbols:
I –Inspect, and if necessary correct, clean, replenish or adjust.
R – Replace or change:
(1) Change the engine oil and oil filter every 7,500 km (4,500 miles) or 6months, whichever comes first, if the vehicle is
operated under any of the following conditions:
S Short distance driving.
S Extensive idling.
S Driving on dusty roads.
(2) Inspect the air cleaner element every 7,500 km (4,500 miles) or 6 months if driving under dusty conditions. If necessary,
correct, clean or replace.
(3) Refer to ”Recommended Fluids And Lubricants”
Note : Check the engine oil and radiator coolant levels every week.

GENERAL INFORMATION 0B – 11
DAEWOO V–121 BL4
Chassis and Body
Maintenance ItemMaintenance Interval
Kilometers or time in months, whichever comes first
x 1,000 km1153045607590105120
x 1,000 miles0.6918273645546372
Months–1224364860728496
Interior air filter (A/C)RRRRRRRR
Exhaust pipes & mountingsIIIIIIII
Brake/Clutch fluid (1) (4)IIRIRIRIR
Front brake pads and discs(3)IIIIIIII
Rear brake pads & discs or drums and
linings (3)IIIIIIII
Parking brakeIIIIIIIII
Brake line and connections (Including
booster)IIIIIIII
Manual Transaxle Oil *(1)IIIIIIII
Automatic transaxle fluid *(1) (5)IIIIIIII
Tighten chassis and underbody bolts
and nutsIIIIIIII
Tire condition and inflation pressureIIIIIIIII
Wheel alignment (2)Inspect when abnormal condition is noted
Steering wheel and linkageIIIIIIII
Power steering fluid & lines* (1)IIIIIIIII
Drive shaft bootsIIIIIIII
Seat belts, buckles and anchorsIIIIIIII
Lubricate locks, hinges and hood
latchIIIIIIII
Chart Symbols:
I – Inspect and if necessary correct, clean, replenish, or adjust.
R – Replace or change:
(1) Refer to Recommended Fluids And Lubricants.
(2) And if necessary, rotate and balance wheels.
(3) More frequent if operated under severe conditions: short distance driving, extensive idling, frequent low–speed oper-
aion in stop and go traffic, or driving in dusty conditions.
(4) Change the brake/clutch fluid every 15,000 km (9,000 miles), if the vehicle is mainly driven under the following severe
conditions: driving in hilly or mountainous terrain, or towing a trailer/caravan frequently.
(5) 1.8 DOHC model (ZF 4HP16 Automatic Transaxle): Change automatic transaxle fluid every 60,000 Km (36,000 miles)
if the vehicle is mainly driven under any of the following severe conditions:
S In heavy city traffic where the outside temperature regularly reaches 32°C (90°F) or higher, or
S In hilly or mountainous terrain, or
S When doing frequent trailer towing, or
S Uses such as taxi, police or delivery service.

0B – 12IGENERAL INFORMATION
DAEWOO V–121 BL4
OWNER INSPECTIONS AND SERVICES
WHLE OPERATING THE VEHICLE
Horn Operation
Blow the horn occasionally tomake sure it works. Check
all the button locations.
Brake System Operation
Be alert for abnormal sounds, increased brake pedal trav-
el or repeated pulling to one side when braking. Also, if the
brake warning light goes on, or flashes, something may be
wrong with part of the brake system.
Exhaust System Operation
Be alert to any changes in the sound of the system or the
smell of the fumes. These are signs that the system may
be leaking or overheating. Have the system inspected and
repaired immediately.
Tires,Wheels and Alignment Operation
Be alert to any vibration of the steering wheel or the seats
at normal highway speeds. This may mean a wheel needs
to be balanced. Also, a pull right or left on a straight, level
road may show the need for a tire pressure adjustment or
a wheel alignment.
Steering System Operation
Be alert to changes in the steering action. An inspection
is needed when the steering wheel is hard to turn or has
too much free play, or if unusual sounds are noticed when
turning or parking.
Headlight Aim
Take note of the light pattern occasionally. Adjust the
headlights if the beams seem improperly aimed.
AT EACH FUEL FILL
A fluid loss in any (except windshield washer) system may
indicate a problem. Have the system inspected and re-
paired immediately.
Engine Oil Level
Check the oil level and add oil if necessary. The best time
to check the engine oil level is when the oil is warm.
1. After stopping the engine, wait a few minutes for
the oil to drain back to the oil pan.
2. Pull out the oil level indicator (dip stick).
3. Wipe it clean, and push the oil level indicator back
down all the way.
4. Pull out the oil level indicator and look at the oil lev-
el on it.
5. Add oil, if needed, to keep the oil level above the
MIN line and within the area labeled ”Operating
Range.” Avoid overfilling the engine, since this may
cause engine damage.
6. Push the indicator all the way back down into the
engine after taking the reading.If you check the oil level when the oil is cold, do not run the
engine first. The cold oil will not drain back to the pan fast
enough to give a true oil level reading.
Engine Coolant Level and Condition
Check the coolant level in the coolant reservoir tank and
add coolant if necessary. Inspect the coolant. Replace
dirty or rusty coolant.
Windshield Washer Fluid Level
Check the washer fluid level in the reservoir. Add fluid if
necessary.
AT LEAST MONTHLY
Tire And Wheel Inspection and Pressure
Check
Check the tires for abnormal wear or damage. Also check
for damaged wheels. Check the tire pressure when the
tires are cold (check the spare also, unless it is a stow-
away). Maintain the recommended pressures that are on
the tire placard that is in the glove box.
Light Operation
Check the operation of the license plate light, the head-
lights (including the high beams), the parking lights, the
fog lights, the taillight, the brake lights, the turn signals, the
backup lights and the hazard warning flasher.
Fluid Leak Check
Periodically inspect the surface beneath the vehicle for
water, oil, fuel or other fluids, after the vehicle has been
parked for a while. Water dripping from the air conditioning
system after use is normal. If you notice fuel leaks or
fumes, find the cause and correct it at once.
AT LEAST TWICE A YEAR
Power Steering System Reservoir Level
Check the power steering fluid level. Keep the power
steering fluid at the proper level. Refer to Section 6A, Pow-
er Steering System.
Brake Master Cylinder Reservoir Level
Check the fluid and keep it at the proper level. A low fluid
level can indicate worn disc brake pads which may need
to be serviced. Check the breather hole in the reservoir
cover to be free from dirt and check for an open passage.
Clutch Pedal Free Travel
Check clutch pedal free travel and adjust as necessary.
Measure the distance from the center of the clutch pedal
to the outer edge of the steering wheel with the clutch ped-
al not depressed. Then measure the distance from the
center of the clutch pedal to the outer edge of the steering
wheel with the clutch pedal fully depressed. The difference
between the two values must be greater than 130 mm
(5.19 inches).
Weather–Strip Lubrication
Apply a thin film silicone grease using a clean cloth.

GENERAL INFORMATION 0B – 13
DAEWOO V–121 BL4
EACH TIME THE OIL IS CHANGED
Automatic Transaxle Fluid
Refer to fluid level service procedure of Section 5A, ZF
4HP16 Automatic Transaxle.
Manual Transaxle
Check the fluid level and add fluid as required. Refer to
Section 5B, Five–Speed Manual Transaxle.
Brake System Inspection
This inspection should be done when the wheels are re-
moved for rotation. Inspect the lines and the hoses for
proper hookup, binding, leaks, cracks, chafing, etc. In-
spect the disc brake pads for wear. Inspect the rotors for
surface condition. Also inspect the drum brake linings for
wear and cracks. Inspect other brake parts, including the
drums, the wheels cylinders, the parking brake, etc., at the
same time. Check the parking brake adjustment. Inspect
the brakes more often if habit or conditions result in fre-
quent braking.
Steering, Suspension and Front Drive Axle
Boot And Seal Inspection
Inspect the front and rear suspension and the steering
system for damaged, loose or missing parts, signs of wear
or lack of lubrication. Inspect the power steering lines and
the hoses for proper hookup, binding, leaks, cracks, chaf-
ing, etc. Clean and inspect the drive axle boot and seals
for damage, tears or leakage. Replace the seals if neces-
sary.
Exhaust System Inspection
Inspect the complete system (including the catalytic con-
verter if equipped). Inspect the body near the exhaust sys-
tem. Look for broken, damaged, missing, or out–of–posi-
tion parts as well as open seams, holes, loose
connections, or other conditions which could cause heat
buildup in the floor pan or could let exhaust fumes seep
into the trunk or passenger compartment.
Throttle Linkage Inspection
Inspect the throttle linkage for interference or binding,
damaged, or missing parts. Lubricate all linkage joints and
throttle cable joints, the intermediate throttle shaft bearing,
the return spring at throttle valve assembly, and the accel-
erator pedal sliding face with suitable grease. Check the
throttle cable for free movements.
Engine Drive Belts
Inspect all belts for cracks, fraying, wear and proper ten-
sion. Adjust or replace the belts as needed.
Hood Latch Operation
When opening the hood, note the operation of the secon-
dary latch. It should keep the hood from opening all the
way when the primary latch is released. The hood must
close firmly.
AT LEAST ANNUALLY
Lap and Shoulder Belts Condition and
Operation
Inspect the belt system including: the webbing, the
buckles, the latch plates, the retractor, the guide loops and
the anchors.
Movable Head Restraint Operation
On vehicles with movable head restraints, the restraints
must stay in the desired position.
Spare Tire and Jack Storage
Be alert to rattles in the rear of the vehicle. The spare tire,
all the jacking equipment, and the tools must be securely
stowed at all times. Oil the jack ratchet or the screw mech-
anism after each use.
Key Lock Service
Lubricate the key lock cylinder.
Body Lubrication Service
Lubricate all the body door hinges including the hood, the
fuel door, the rear compartment hinges and the latches,
the glove box and the console doors, and any folding seat
hardware.
Transaxle Neutral Switch Operation on
Automatic Transaxle
CAUTION : Take the following precautions because
the vehicle could move without warning and possibly
cause personal injury or property damage:
S Firmly apply the parking brake and the regular
brakes.
S Do not use the accelerator pedal.
S Be ready to promptly turn off the ignition if the ve-
hicle starts.
On automatic transaxle vehicles, try to start the engine in
each gear. The starter should crank only in P (Park) or N
(Neutral).
Parking Brake and Transaxle P (Park)
Mechanism Operation
CAUTION : In order to reduce the risk of personal in-
jury or property damage, be prepared to apply the reg-
ular brakes promptly if the vehicle begins to move.
Park on a fairly steep hill with enough room for movement
in the downhill direction. To check the parking brake, with
the engine running and the transaxle in N (Neutral), slowly
remove foot pressure from the regular brake pedal (until
only the parking brake is holding the vehicle).
To check the automatic transaxle P (Park) mechanism’s
holding ability, release all brakes after shifting the trans-
axle to P (Park).
Underbody Flushing
Flushing the underbody will remove any corrosive materi-
als used for ice and snow removal and dust control. At
least every spring clean the underbody. First, loosen the
sediment packed in closed areas of the vehicle. Then flush
the underbody with plain water.
