ENGINE CONTROLS 1F–29
DAEWOO M-150 BL2
Engine Cranks But Will Not Run (Cont’d)
StepActionValue(s)YesNo
42
1. Turn the ignition OFF.
2. Connect test light between fuel injector harness
connector 2 and battery positive.
3. Crank the engine.
4. Repeat step 2 and 3 for each of the remaining
fuel injectors.
Does the test light flash for all of the fuel injectors?
–
Go to Step 43Go to Step 46
43
Measure the resistance of each fuel injectors.
Is the resistance within the value specified.
Note: the resistance will increase slightly at higher
temperature.
13.75–15.25
ΩSystem OKGo to Step 44
44
Replace any of the fuel injectors with a resistance
out of specification.
Is the repair complete?
–
Go to Step 2
–
45
1. Inspect the fuse EF19 in engine fuse block.
2. Check for an open between the circuit from
terminal 2 of the three fuel injectors and terminal
87 of main relay.
Is the problem found?
–
Go to Step 48
Go to “Main
Relay Circuit
Check”
46
Measure the resistance between following terminals.

Terminal 1 of injector 1 connector and terminal 30
of ECM connector.

Terminal 1 of injector 2 connector and terminal 58
of ECM connector.

Terminal 1 of injector 3 connector and terminal 89
of ECM connector.
Does the resistance within the specified value?
0 ΩGo to Step 49Go to Step 47
47Repair the open fuel injector harness wire(s).
Is the repair complete?–Go to Step 2–
48Replace the fuse or repair the wiring as needed.
Is the repair complete?–Go to Step 2–
49Replace the ECM.
Is the repair complete?–Go to Step 2–

ENGINE CONTROLS 1F–31
DAEWOO M-150 BL2
No Malfunction Indicator Lamp
StepActionValue(s)YesNo
1
Attempt to start the engine.
Does the engine start?
–
Go to Step 2
Go to “Engine
Cranks But
Will Not Run”
2
1. Turn the ignition OFF.
2. Disconnect the engine control module (ECM)
connector.
3. Turn the ignition ON.
4. Connect a test light between terminal 68 of ECM
connector and ground.
Is the test light on?
–
Go to Step 3Go to Step 6
3Check terminals for damage or poor connection.
Does any problem found?–Go to Step 5Go to Step 4
4
Replace ECM
Is the repair complete?
–
Go to “On
Board
Diagnostic
System Check”
–
5
Repair any damaged terminals or poor connection.
Is the repair complete?
–
Go to “On
Board
Diagnostic
System Check”
–
6Check the fuse F1.
Is the fuse blown?–Go to Step 7Go to Step 8
7
1. Check for a short to ground in the circuit and
repair as needed.
2. Replace the blown fuse.
Is the repair complete?
–
Go to “On
Board
Diagnostic
System Check”
–
8
1. Check for an open circuit between fuse F16 and
terminal 68 of ECM connector and repair as
needed.
2. Check the MIL bulb and replace if blown.
Is the repair complete?
–
Go to “On
Board
Diagnostic
System Check”
–

ENGINE CONTROLS 1F–37
DAEWOO M-150 BL2
Fuel Pump Relay Circuit Check (Cont’d)
StepActionValue(s)YesNo
3
1. Check for an open circuit between fuel pump test
connector and ground G401, and repair as
needed.
2. Check for the fuel cut-off switch and reset or
replace the fuel cut off switch.
Is the repair complete?
–
System OKGo to Step 4
4
1. Turn the ignition OFF.
2. Disconnect the fuel pump relay.
3. Connect a test light between the fuel pump relay
connector terminal 66 and battery positive.
4. Turn the ignition ON.
Is the test light on?
–
Go to Step 6Go to Step 5
5
Check for an open circuit between terminal 66 of fuel
pump relay and battery positive and repair as
needed.
Is the repair complete?
–
System OK
–
6
1. Turn the ignition OFF.
2. Connect a test light between the fuel pump relay
connector terminal 85 and ground.
3. Turn the ignition ON.
Is the test light on?
2 secGo to Step 8Go to Step 7
7
Check for an open circuit between terminal 85 of fuel
pump relay and terminal 10 of ECM, and repair as
needed.
Is the repair complete?
–
System OK
–
8
1. Turn the ignition OFF.
2. Connect a test light between the fuel pump relay
connector terminal 30 and ground.
Is the test light on?
–
Go to Step 10Go to Step 9
9
1. Check the fuse EF19, if blown, repair short circuit
between fuel pump relay 30 terminal.
2. Replace the fuse as needed.
3. Repair an open circuit as needed.
Is the repair complete?
–
System OK
–
10
1. Turn the ignition OFF.
2. Measure the resistance between following
terminals:

Terminal 87 of fuel pump relay and terminal 1
of the fuel cut-off switch(or terminal 1 of
connector C201).
Does the resistance within the value specified.
0 ΩGo to Step 12Go to Step 11
11Repair an open circuit as needed.
Is the repair complete?–System OK–
12Replace the fuel pump relay.
Is the repair complete?–System OKGo to Step 13
13Replace the ECM.
Is the repair complete?–System OK–

ENGINE CONTROLS 1F–39
DAEWOO M-150 BL2
Main Relay Circuit Check
StepActionValue(s)YesNo
1
1. Turn the ignition OFF.
2. Disconnect the engine fuse block fuse EF26.
3. Turn the ignition ON.
4. With a test light connected to the ground, probe
the fuse terminals nearest the main relay for fuse
EF19.
Is the light on at both terminal?
–
System OKGo to Step 2
2Is the light on at only one terminal?–Go to Step 3Go to Step 4
3
Repair the open in the wiring between the main relay
connector terminal 30 and the fuse EF19 as needed.
Is the repair complete?
–
System OK
–
4
1. Turn the ignition OFF.
2. Remove the main relay.
3. Turn the ignition ON.
4. With a test light connected to the ground, probe
the main relay terminals 85 and 30.
Is the light on at both terminals.
–
Go to Step 8Go to Step 5
5
1. Turn the ignition OFF.
2. Check engine fuse block fuse EF19.
Is one or both fuse blown?
–
Go to Step 6Go to Step 7
6
1. Repair short circuit between terminal 87 of main
relay and heated oxygen sensor
2. Replace fuse EF19.
Is the repair complete?
–
System OK
–
7
Repair open circuit between terminal 30 of main
relay and fuse EF19.
Is the repair complete?
–
System OKGo to Step 8
8
1. Turn the ignition OFF.
2. Measure the resistance between following
terminals.

Terminal 86 of main relay and ground.

Terminal 87 of main relay and ground.
Is the resistance within the specified value
0 ΩGo to Step 10Go to Step 9
9Repair open circuit.
Is the repair complete?–System OK–
10Replace the main relay.
Is the repair complete?–System OK–

ENGINE CONTROLS 1F–47
DAEWOO M-150 BL2
Ignition System Check (Cont’d)
StepActionValue(s)YesNo
21
Measure the voltage between the CKP sensor
connector terminal 2 and ground.
Is the voltage within the value specified?
0.95–1.10 VGo to Step 18Go to Step 22
22
Check the wire between the CKP sensor connector
terminal 2 and the ECM connector terminal 24 for an
open or short.
Is the problem found?
–
Go to Step 23Go to Step 11
23
Repair the wire between the CKP sensor connector
terminal 2 and the ECM connector terminal 24.
Is the repair complete?
–
System OK
–
24
1. Turn the ignition OFF.
2. Connect a test light between the EI system
ignition coil connector terminal 2 and ground.
3. Turn the ignition ON.
Is the test light on?
–
Go to Step 27Go to Step 25
25
Check for an open in the wiring between the EI
system ignition coil connector, terminal 1 and the
main relay connector terminal 87.
Is the problem found?
–
Go to Step 26
Go to “Main
Relay Circuit
Check”
26
Repair the open in the wiring between the EI system
ignition coil connector terminal 1 and the main relay
connector terminal 87.
Is the repair complete?
–
System OK
–
27
Check for a damage in the terminal of the EI system
ignition coil connector and repair as needed.
Is the repair complete?
–
System OK
–

ENGINE CONTROLS 1F–49
DAEWOO M-150 BL2
Engine Cooling Fan Circuit Check
StepActionValue(s)YesNo
1
Perform an Euro On-Board Diagnostic (EOBD)
System Check.
Was the check performed?
–
Go to Step 2
Go to “Euro
On-Board
Diagnostic
System Check.
2
1. Check the fuses EF3 and EF10 in engine fuse
block.
2. Replace the fuse(s) as needed.
Is the fuse(s) OK?
–
Go to Step 3
Go to
“Diagnostic
Aids”
3
1. Turn the ignition OFF.
2. Turn the A/C switch OFF. If equipped.
3. Connect a scan tool to the Data Link Connector
(DLC).
4. Start the engine.
5. The main cooling fan should run at low speed
when the coolant temperature reaches 96C
(205F).
Does the cooling fan run at low speed?
–
Go to Step 4Go to Step 8
4
The cooling fans should run at high speed when the
coolant temperature reaches 100C (212F).
Do the cooling fans run at high speed?
–
Go to Step 5Go to Step 19
5
1. Turn the ignition OFF.
2. Start the engine.
3. Turn the A/C switch ON.
Does the cooling fan runs at low speed?
–
Go to Step 7Go to Step 6
6
1. Diagnose the A/C compressor clutch circuit.
2. Repair the A/C compressor clutch circuit as
needed.
Is the repair complete?
–
System OK
–
7
1. Turn the ignition OFF.
2. Start the engine.
3. Turn the A/C switch ON and raise the rpm.
4. The cooling fan should run at high speed when
the high side A/C pressure reaches 2068 kPa
(300 psi).
Do the cooling fans run at high speed?
–
System OK
–
8
1. Turn the ignition OFF.
2. Disconnect the cooling fan connector.
3. Turn the ignition ON.
4. Connect a test light between terminal 1 of cooling
fan connector and ground.
Is the test light on?
–
Go to Step 9Go to Step 12
9
Connect a test light between terminal 2 of cooling
fan connector and battery positive.
Is the test light on?
–
Go to Step 11Go to Step 10
10
Repair open circuit between terminal 2 of cooling fan
connector and ground.
Is the repair complete?
–
System OK
–
11
Check for a damaged terminals in main cooling fan
connector and repair it or replace the main cooling
fan.
Is the repair complete?
–
System OK
–

1F–50 ENGINE CONTROLS
DAEWOO M-150 BL2
Engine Cooling Fan Circuit Check (Cont’d)
StepActionValue(s)YesNo
12
1. Turn the ignition ON.
2. Connect a test light between terminals 86 and 30
of low speed cooling fan relay and ground.
Does the test light on for both case?
–
Go to Step 14Go to Step 13
13
Repair power supply circuit.

Fuse EF15 and terminal 30 of low speed cooling
fan relay.
Is the repair complete?
–
System OKGo to Step 14
14
1. Turn the ignition OFF.
2. Disconnect Engine Control Module (ECM)
connectors.
3. Turn the ignition ON.
4. Connect a jump wire between terminal 5 and
ground.
Does the cooling fan run at low speed?
–
Go to Step 15Go to Step 16
15Replace the ECM.
Is the repair complete?–System OK–
16
1. Turn the ignition OFF.
2. Measure the resistance between following
terminals:

Terminal 85 of low speed cooling fan relay and
terminal 39 of ECM connector.
Are the resistance within the value specified?
0 ΩGo to Step 18Go to Step 17
17Repair open circuit.
Is the repair complete?–System OK–
18Replace the low speed cooling fan relay.
Is the repair complete?–System OK–

ENGINE CONTROLS 1F–53
DAEWOO M-150 BL2
Data Link Connector Diagnosis
StepActionValue(s)YesNo
1
Perform an Euro On-Board Diagnostic (EOBD)
System Check.
Was the check performed?
–
Go to Step 2
Go to “Euro
On-Board
Diagnostic
System Check.
2
With a test light connected to the ground, probe the
Data Link Connector (DLC) battery feed terminal 16.
Is the test light on?
–
Go to Step 4Go to Step 3
3
Repair an open or short to ground in the DLC battery
feed circuit .
Is the repair complete?
–
Go to Step 4
–
4
With a test light connected to the battery, probe the
Data Link Connector (DLC) ground terminal 4 and 5.
Is the test light on?
–
Go to Step 6Go to Step 5
5Repair an open circuit .
Is the repair complete?–Go to Step 6–
6
1. Turn the ignition OFF.
2. Connect a scan tool to the Data Link Connector
(DLC).
3. Turn the ignition ON.
Does the scan tool power up?
–
Go to Step 8Go to Step 7
7
Check for damages in the terminal of DLC and scan
tool, and repair as needed.
Is the repair complete?
–
Go to Step 8
–
8
Using a scan tool, request engine data of Engine
Control Module (ECM).
Does the scan tool display any data?
–
Go to Step 12Go to Step 9
9
Install the scan tool on another vehicle and check for
proper operation.
Does the scan tool work properly on a different
vehicle.
–
Go to Step 11Go to Step 10
10
The scan tool is malfunctioning.
Refer to the scan tool’s manual for repair.
Is the repair complete?
–
Go to Step 12
–
11
Repair communication circuit between ECM and
DLC.
Is the repair complete?
–
Go to Step 12
–
12
1. Using a scan tool, clear the Diagnostic Trouble
Codes(DTCs).
2. Attempt to start the engine.
Does the engine and continue to run?
–
Go to Step 13Go to Step 1
13
1. Allow the engine to idle until normal operation
temperature reached.
2. Check if any DTCs are set?
Are any DTCs displayed that have not been
diagnosed?
–
Go to applicable
DTC table
System OK

ENGINE CONTROLS 1F–77
DAEWOO M-150 BL2
DTC P0122 – Throttle Position Sensor Low Voltage
StepActionValue(s)YesNo
1
Perform an On-Board Diagnostic (EOBD) System
Check.
Was the check performed?
–
Go to Step 2
Go to
“On-Board
Diagnostic
System Check”
2
1. Install a scan tool to the Data Link Connector
(DLC).
2. Turn the ignition ON.
Is the Throttle Position (TP) sensor voltage below
the specified value?
0.20 VGo to Step 4Go to Step 3
3
1. Turn the ignition ON.
2. Review the Freeze Frame data and note the
parameters.
3. Operate the vehicle within the Freeze Frame
conditions and Conditions for Setting the DTC as
noted.
Is the TP sensor voltage below the specified value?
0.20 VGo to Step 4Go to Step 12
4
1. Turn the ignition OFF.
2. Disconnect the TP sensor connector.
3. Turn the ignition ON.
4. Jump the 5 volt reference circuit terminal B and
the TP signal circuit terminal C at the TP sensor
connector.
Is the TP sensor voltage over the specified value?
4.0 VGo to Step 10Go to Step 5
5
Connect a test light between B+ and the TP sensor
signal circuit terminal C.
Is the TP sensor voltage greater than the specified
value?
4.0 VGo to Step 6Go to Step 8
6
Check the TP sensor 5 volt reference circuit for an
open or short to ground and repair as needed.
Is the repair complete?
–
Go to Step 12Go to Step 7
7
Check the 5 volt reference circuit for a poor
connection at terminal 75 of the Engine Control
Module (ECM) and repair as needed.
Is the repair complete?
–
Go to Step 12Go to Step 11
8
Check the TP sensor signal circuit between terminal
C of the TP sensor and terminal 44 of the ECM for
an open or a short to ground and repair as needed.
Is the repair complete?
–
Go to Step 12Go to Step 9
9
Check the TP sensor signal circuit, terminal 44 of
the ECM for a poor connection and repair as
needed.
Is the repair complete?
–
Go to Step 12Go to Step 11
10Replace the throttle body assembly.
Is the action complete?–Go to Step 12–
11
1. Turn the ignition switch OFF.
2. Replace the ECM.
Is the action complete?
–
Go to Step 12
–

ENGINE CONTROLS 1F–81
DAEWOO M-150 BL2
DTC P0123 – Throttle Position Sensor High Voltage
StepActionValue(s)YesNo
1
Perform an On-Board Diagnostic (EOBD) System
Check.
Was the check performed?
–
Go to Step 2
Go to
“On-Board
Diagnostic
System Check”
2
1. Install a scan tool to the Data Link Connector
(DLC).
2. Turn the ignition ON.
Is the Throttle Position (TP) sensor voltage greater
than the specified value?
1.0 VGo to Step 4Go to Step 3
3
1. Turn the ignition ON.
2. Review the Freeze Frame data and note the
parameters.
3. Operate the vehicle within the Freeze Frame
conditions and Conditions for Setting the DTC as
noted.
Is the TP sensor voltage greater than the specified
value?
3.9 VGo to Step 4Go to Step 12
4
1. Turn the ignition OFF.
2. Disconnect the TP sensor connector.
3. Turn the ignition ON.
Is the TP sensor voltage less than the specified
value?
0.2 VGo to Step 5Go to Step 6
5
Probe the TP sensor ground circuit, terminal A at the
TP sensor connector with a test light connected to
B+.
Does the test light illuminate?
–
Go to Step 7Go to Step 9
6
Check the TP sensor signal circuit for an short to
voltage and repair as needed.
Is the repair complete?
–
Go to Step 12Go to Step 11
7
Check the 5 volt reference circuit for a short to B+
and repair as needed.
Is the repair complete?
–
Go to Step 12Go to Step 8
8
Check the TP sensor electric connector for a poor
connection and repair as needed.
Is the repair complete?
–
Go to Step 12Go to Step 10
9
Check the TP sensor ground circuit for an open and
repair as needed.
Is the repair complete?
–
Go to Step 12Go to Step 11
10Replace the throttle body assembly.
Is the action complete?–Go to Step 12–
11
1. Turn the ignition switch OFF.
2. Replace the Engine Control Module (ECM).
Is the action complete?
–
Go to Step 12
–
12
1. Using the scan tool, clear the Diagnostic Trouble
Codes (DTCs).
2. Start the engine and idle at normal operating
temperature.
3. Operate the vehicle within the Conditions for
setting this DTC as specified in the supporting
text.
Does the scan tool indicate that this diagnostic has
run and passed?
–
Go to Step 13Go to Step 2
