DAEWOO NUBIRA 2004 Service Repair Manual

5A1 – 32IZF 4 HP 16 AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
Drive Range – Third Gear ;
Emergency/Substitute Mode
In Drive 3, transaxle drive is via the input shaft to clutches
B and E. The elements of this transaxle function are as fol-
lows:
S Clutches B and E are engaged to drive the rear sun
gear and rear planetary gear carrier clockwise.
S The clockwise rotation of the rear sun gear and rear
planetary gear carrier will cause the front planetary
gear to rotate in the same direction.Control
Clutch B Engaged
In Park and Neutral solenoid valves 1 and 2 are both ON.
Pressure control solenoids (EDS) 4 and 6 are also turned
ON.
When EDS 6 is ON, the fluid supplied from the reduction
valve flows to the safety valve, clutch valve B and holding
valve B. The oil that is supplied to the inlet port of the clutch
valve presses on the valve spool. Line pressure then flows
to the holding valve and check ball, engaging clutch B.

ZF 4 HP 16 AUTOMATIC TRANSAXLE 5A1 – 33
DAEWOO V–121 BL4
COMPONENT LOCATOR
TRANSAXLE IDENTIFICATION INFORMATION
1. Part Number
2. Serial Number3. Model Code
4. Manufactured Nation and Company

5A1 – 34IZF 4 HP 16 AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
TORQUE CONVERTER
1. Torque Converter Housing
2. Torque Converter
3. Torque Converter Gasket
4. Steel Gasket
5. Oil Baffle Plate
6. Bolt
7. Magnet
8. Oil Filter
9. O–ring10. Screw
11. Pressure Plug
12. Pressure Plug
13. Oil Drain Plug
14. Oil Level Plug
15. Screw
16. Bolt
17. Bolt

ZF 4 HP 16 AUTOMATIC TRANSAXLE 5A1 – 35
DAEWOO V–121 BL4
TRANSAXLE HOUSING
1. Transaxle Housing
2. Bushing
3. Shaft Seal
4. Axle Shaft Seal
5. Sealing Sleeve
6. Breather Pipe
7. Sleeve Protector
8. Type Plate
9. Cable Terminal10. Output Speed Sensor
11. Washer
12. Bolt
13. Shim
14. Shim
15. Park/Neutral Position Switch
16. Bolt
17. Sealing sleeve

5A1 – 36IZF 4 HP 16 AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
OIL PUMP
1. Oil Pump
2. Oil Pump Seal
3. Washer
4. O–ring5. Dowel Pin
6. Bolt
7. Bolt

ZF 4 HP 16 AUTOMATIC TRANSAXLE 5A1 – 37
DAEWOO V–121 BL4
REAR COVER & OIL PAN COVER
1. Rear Cover
2. Piston Ring
3. O–ring
4. Needle Bearing
5. Shim
6. Screw Plug7. Bolt
8. Oil Pan
9. Oil Pan Gasket
10. Oil Pan Bracket
11. Bolt

5A1 – 38IZF 4 HP 16 AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
PARKING LEVER
1. Selector Shaft
2. Stop Bushing
3. Detent Disc
4. Clamping Sleeve
5. Connecting Bar6. Leg Spring
7. Pawl
8. Pin
9. Support Bolt

ZF 4 HP 16 AUTOMATIC TRANSAXLE 5A1 – 39
DAEWOO V–121 BL4
INPUT SHAFT & SHIFT GEAR

5A1 – 40IZF 4 HP 16 AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
1. Inner Disc Carrier F
2. Clutch Plate F
3. Line Clutch Disc F
4. Clutch Outer Disc F
5. Spring Disc
6. Stop Ring
7. Cup Spring
8. O–ring
9. O–ring
10. Piston D
11. Slotted Nut
12. Roller Bearing
13. Adjust Ring
14. Bearing Plate
15. Roller Bearing
16. Spur Gear
17. Piston D
18. Spring Disc
19. Snap Ring
20. Clutch Plate D
21. Cup Spring
22. Line Clutch Disc D
23. Spring Disc
24. Disc Carrier C/D
25. Pitting Key
26. Line Clutch Disc C
27. Clutch Outer Disc C
28. Cup Spring
29. Line Clutch Disc C
30. Snap Ring
31. Piston C
32. Cylinder C
33. Snap Ring
34. Front Ring Gear
35. Oil Tray
36. Front Planetary Gear
37. Front Sun Gear
38. Snap Ring
39. Needle Bearing40. Rear Planetary Gear Set
41. Snap Ring
42. Rear Sun Gear
43. Needle Bearing
44. Snap Ring
45. Piston B
46. Clutch Plate B
47. Clutch Outer Disc B
48. Line Clutch Disc B
49. Spring Disc
50. Piston Ring
51. Inner Disc Carrier E
52. Needle Bearing
53. Snap Ring
54. Clutch Plate Disc E
55. Line Clutch Disc E
56. Clutch Outer Disc E
57. Spring Disc
58. Retainer Ring
59. O–ring
60. Oil Dam
61. Cup Spring
62. O–ring
63. Piston E
64. O–ring
65. Input Shaft
66. O–ring
67. O–ring
68. Piston
69. Oil Dam
70. O–ring
71. Cup Spring
72. Stop Ring
73. Shim
74. Needle Bearing
75. O–ring
76. Piston Ring
77. Rear Cover

ZF 4 HP 16 AUTOMATIC TRANSAXLE 5A1 – 41
DAEWOO V–121 BL4
VALVE BODY
1. Control Valve Body
2. Valve Body Wiring Harness
3. O–ring
4. Plug
5. Cable Terminal
6. Retaining Clip
7. Input Speed Sensor
8. Cap Screw9. Solenoid Valve
10. Cap Screw
11. Fixing Plate
12. Fixing Plate
13. Cap Screw
14. Solenoid Valve
15. Solenoid Valve
