Input Speed Sensor
S Inspect resistance of each input speed senor be-
tween terminals.
Notice :
S Make sure to inspect resistance again at 20°C
(68°F) when resistance differ from standards ex-
cept 20°C (68°F).
S It might become infinity ohm when inspect resist-
ance at higher temperature.
Action : If the result of inspection is bad, replace ISS.
Transmission Range (TR) Switch
S Remove TR switch connector and inspect continuty
each range according to the conection chart.
Action : If the result of inspection is bad, replace the TR
switch.
Transmission Fluid Temperature Sensor
S Inspect the resistance between the terminals of
TFT sensor at 10°C (50°F) and 110°C (230°F).
Standard Value
10°C (50°F)11 0°C (230°F)
5.80~7.09 kΩ0.23~0.263 kΩ
Action : If the result of inspection is bad, replace the TFT
sensor.

5A2 – 32IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
Shift Solenoid (NO.1,2), Timing Solenoid,
Lock–Up Solenoid
1. Inspect the resistance of each shift solenoid be-
tween the terminal and the body earth.
Action : If the result of inspection is bad, replace each so-
lenoid.
Notice :
S Make sure to inspect resistance again at 20°C
(68°F) when resistance differ from standards ex-
cept 20°C (68°F).
S It might become infinity ohm when inspecting resist-
ance at higher temperature.
2. Inspect the operation of each shift solenoid.
S Solenoid (No.1,2), Lock–up solenoid (Normal
open type)
No battery connection
Leak air
Battery connectionNo leak air
S Timing solenoid (Normal close type)
No battery connection
No leak air
Battery connectionLeak air
Action : If the result of inspection is bad, replace the each
solenoid.
Notice : Do not damage the strainer on the tip of solenoid
while inspecting operation.
Pressure Control Solenoid
S Inspect the resistance of each pressure control so-
lenoid between terminals.
Action : Repalce the valve body assembly. (No replace-
ment of solenoid by itself)
Notice :
S Make sure to inspect resistance again at 20°C
(68°F) when resistance differ from standards ex-
cept 20°C (68°F).
S It might become infinity ohm when inspecting resist-
ance at higher temperature.

AISIN AUTOMATIC TRANSAXLE 5A2 – 33
DAEWOO V–121 BL4

5A2 – 34IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
ON–VEHICLE REPAIR (MATRIX CHART)

AISIN AUTOMATIC TRANSAXLE 5A2 – 35
DAEWOO V–121 BL4

5A2 – 36IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE DIAGNOSIS
DIAGNOSTIC TROUBLE CODE CHART
DTCDESCRIPTIONTYPEIlluminate
MILBlink
Hold
Lamp
P0562System Voltage LowBYe sNo
P0563System Voltage HighBYe sNo
P0601Internal Control Module Memory Checksum ErrorAYe sNo
P0604Internal Transmission Control Module (TCM) Random Access
Memory (RAM) ErrorBYe sNo
P0705Transmission Range (TR) Switch Circuit MalfunctionBYe sNo
P0712Transmission Fluid Temperature Sensor Circuit Low InputAYe sNo
P0713Transmission Fluid Temperature Sensor Circuit High InputAYe sNo
P0717Input Shaft Speed (ISS) Sensor Circuit No SignalAYe sNo
P0722Output Shaft Speed (OSS) sensor Circuit No SignalAYe sNo
P0727Engine Speed Input Circuit No SignalAYe sNo
P0741Torque Converter Clutch (TCC) Circuit Stuck OffBYe sNo
P0742Torque Converter Clutch (TCC) Circuit Stuck OnBYe sNo
P0743Torque Converter Clutch (TCC) ElectricalBYe sNo
P0748Pressure Control Solenoid (PCS) ElectricalAYe sNo
P0751Shift Solenoid 1 (SS1) Stuck OffBYe sNo
P0753Shift Solenoid 1 (SS1) ElectricalAYe sNo
P0756Shift Solenoid 2 (SS2) Stuck OffBYe sNo
P0758Shift Solenoid 2 (SS2) ElectricalAYe sNo
P0785Timing Solenoid (ST) ElectricalAYe sNo
P1781Engine Torque Signal ErrorAYe sNo
P1791Throttle Position Signal ErrorAYe sNo
P1792Engine Coolant Temperature (ECT) Signal ErrorDNoNo
U2105CAN ErrorAYe sNo
* Description of Type
S Type A : TCM will request the illumination of MIL and store DTC when TCM detects a failure on the first ignition
cycle.
S Type B : TCM will request the illumination of MIL and store DTC when TCM detects failures on two consecutive
ignition cycle.
S Type D : TCM will not request the illumination of MIL or hold lamp, but will store DTC when TCM detects a failure
on the first ignition cycle.

AISIN AUTOMATIC TRANSAXLE 5A2 – 37
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE (DTC) P0562
SYSTEM VOLTAGE LOW
Conditions for Setting the DTC
S System voltage is too low.
S TCM detects that voltage is less than 9 volts for 0.5
seconds continuously.
S Engine revolution is 600 rpm or greater.
Action Taken When the DTC Sets
S TCM will request the illumination of MIL and store
DTC when TCM detects failures on two consecu-
tive ignition cycle.
Conditions for Clearing the DTCS The TCM turns off the MIL when no further failures
detected for three consecutive ignition cycles.
S The scan tool can clear the DTC from the TCM his-
tory.
S The TCM clears the DTC from the TCM history
memory after forty consecutive warm up cycles
without fault.
Cause of Failure
S TCM wiring harness and connectors
S Battery
S TCM

5A2 – 38IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DTC P0562 System Voltage Low
StepActionValue(s)YesNo
11. Turn the ignition OFF.
2. Install the Scan tool.
3. Turn the ignition ON, with the engine OFF.
4. Run the engine to 600 rpm or greater.
5. Record then clear DTC(s).
6. Select system voltage on the scan tool.
7. Drive the vehicle and observe the scan tool for
either of the flowing conditions:
Is the voltage within the values shown?9–16vGo to Step 4Go to Step 2
21. Disconnect the battery cable.
2. Measure the battery voltage.
Is the voltage within the values shown?9–16vGo to Step 4Go to Step 3
31. Replace the battery.
Is the replacement completed?–System OK–
41. Turn the headlamp ON.
2. Turn the air conditioner ON.
3. Run the engine to 600 rpm or greater.
4. Observe the scan tool for system voltage.
Is the voltage within the values shown?9–16vGo to Step 6Go to Step 5
51. Turn the ignition LOCK.
2. Repair the alternator circuit if necessary.
Is the action completed?–System OK–
6Inspect the EF1,F2 fuse for an open.
Was a problem found?–Go to Step 7Go to Step 8
7Inspect the EF1,F2 fuse for short. Replace the fuse
if necessary.
Is the replacement complete?–System OK–
81. Turn the ignition ON.
2. Measure the voltage of EF1, F2.
Is the voltage within the values shown?9–16vGo to Step 10Go to Step 9
9Repair the fuse voltage supply lines for open.
Is the action completed?–System OK–
101. Turn the ignition LOCK.
2. Disconnect the TCM wiring connector.
3. Measure the resistance between EF1 fuse and
terminal A24 of the TCM wiring connector.
Is the resistance within the values shown?0ΩGo to Step 12Go to Step 11
11Repair the circuit (between EF1 and terminal A24)
for short to ground and open.
Is the repair completed?–System OK–
121. Disconnect the C105 connector and TCM con-
nector.
2. Turn the ignition ON.
3. Measure the voltage of the terminal A24.
Is the voltage within the values shown?9–16vGo to Step 13Go to Step 14
13Repair the circuit from EF1 to terminal A24 of the
TCM for short to battery.
Is the repair completed?–System OK–

AISIN AUTOMATIC TRANSAXLE 5A2 – 39
DAEWOO V–121 BL4
StepNo Yes Value(s) Action
141. Turn the ignition LOCK.
2. Disconnect the C201 connector.
3. Measure the resistance between F2 fuse and
terminal A6 of the TCM wiring connector.
Is the resistance within the values shown?0ΩGo to Step 17Go to Step 15
15Repair the circuit (between F2 and terminal A6) for
short to ground and open.
Is the repair completed?–System OK–
161. Turn the ignition ON.
2. Measure the voltage of the terminal A6.
Is the voltage within the values shown?9–16vGo to Step 17Go to Step 18
17Repair the circuit (between F2 and terminal A6) for
short to battery.
Is the repair completed?–System OK–
181. Inspect the transaxle wiring for poor electrical
connectors at the transaxle connector.
2. Look for possible bent, backed out, deformed,
or damaged terminals.
3. Check for week terminal tension.
Was a condition found?–Verify repair
and
Go to Step 20–
19Replace the TCM.
Is the replacement complete?–Go to Step 20–
201. After the repair, use a scan tool ”clear info”
function and road test the vehicle.
2. Review the ”DTC info”.
Has the last test failed or is the current DTC dis-
played?–Begin diagno-
sis againRepair verified
Exit DTC chart

5A2 – 40IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE (DTC) P0563
SYSTEM VOLTAGE HIGH
Conditions for Setting the DTC
S System voltage is too high.
S TCM detects that voltage is greater than 18 volts
for 0.5 seconds continuously.
S Engine revolution is 600 rpm or greater.
Action Taken When the DTC Sets
S TCM will request the illumination of MIL and store
DTC when TCM detects failures on two consecu-
tive ignition cycle.
Conditions for Clearing the DTCS The TCM turns off the MIL when no further failures
detected for three consecutive ignition cycles.
S The scan tool can clear the DTC from the TCM his-
tory.
S The TCM clears the DTC from the TCM history
memory after forty consecutive warm up cycles
without fault.
Cause of Failure
S TCM wiring harness and connectors
S Battery
S TCM
