DAEWOO NUBIRA 2004  Service Repair Manual ENGINE CONTROLS  1F – 15
DAEWOO V–121 BL4
ECM WIRING DIAGRAM (1.4L/1.6L DOHC – 4 OF 6)

Page 262 of 2643

DAEWOO NUBIRA 2004  Service Repair Manual 1F – 16IENGINE CONTROLS
DAEWOO V–121 BL4
ECM WIRING DIAGRAM (1.4L/1.6L DOHC – 5 OF 6)

Page 263 of 2643

DAEWOO NUBIRA 2004  Service Repair Manual ENGINE CONTROLS  1F – 17
DAEWOO V–121 BL4
ECM WIRING DIAGRAM (1.4L/1.6L DOHC – 6 OF 6)

Page 264 of 2643

DAEWOO NUBIRA 2004  Service Repair Manual 1F – 18IENGINE CONTROLS
DAEWOO V–121 BL4
ECM WIRING DIAGRAM (1.8L DOHC – 1 OF 6)

Page 265 of 2643

DAEWOO NUBIRA 2004  Service Repair Manual ENGINE CONTROLS  1F – 19
DAEWOO V–121 BL4
ECM WIRING DIAGRAM (1.8L DOHC – 2 OF 6)

Page 266 of 2643

DAEWOO NUBIRA 2004  Service Repair Manual 1F – 20IENGINE CONTROLS
DAEWOO V–121 BL4
ECM WIRING DIAGRAM (1.8L DOHC – 3 OF 6)

Page 267 of 2643

DAEWOO NUBIRA 2004  Service Repair Manual ENGINE CONTROLS  1F – 21
DAEWOO V–121 BL4
ECM WIRING DIAGRAM (1.8L DOHC – 4 OF 6)

Page 268 of 2643

DAEWOO NUBIRA 2004  Service Repair Manual 1F – 22IENGINE CONTROLS
DAEWOO V–121 BL4
ECM WIRING DIAGRAM (1.8L DOHC – 5 OF 6)

Page 269 of 2643

DAEWOO NUBIRA 2004  Service Repair Manual ENGINE CONTROLS  1F – 23
DAEWOO V–121 BL4
ECM WIRING DIAGRAM (1.8L DOHC – 6 OF 6)

Page 270 of 2643

DAEWOO NUBIRA 2004  Service Repair Manual 1F – 24IENGINE CONTROLS
DAEWOO V–121 BL4
CONNECTOR END VIEW
Engine Control Module (ECM)
MR140
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 1617 18 19 20 21 22 23 24 25 26 27 28 29 30 31 3233 34 35 36 37 38
