•For tough stains, apply MOPARTotal Clean or a mild
soap solution to a clean, damp cloth and remove stain.
Use a fresh, damp towel to remove soap residue.
•For grease stains, apply MOPARMulti-Purpose
Cleaner to a clean, damp cloth and remove stain. Use
a fresh, damp towel to remove soap residue.
•Do not use any solvents or protectants on Yes Essen-
tialsproducts.
Glass Surfaces
All glass surfaces should be cleaned on a regular basis
with MOPARGlass Cleaner or any commercial
household-type glass cleaner. Never use an abrasive type
cleaner. Use caution when cleaning the inside rear win-
dow equipped with electric defrosters or the right rear
quarter window equipped with the radio antenna. Do
not use scrapers or other sharp instruments, which may
scratch the elements.When cleaning the rear view mirror, spray cleaner on the
towel or rag that you are using. Do not spray cleaner
directly on the mirror.
Cleaning Plastic Instrument Cluster Lenses
The lenses in front of the instruments in this vehicle are
molded in clear plastic. When cleaning the lenses, care
must be taken to avoid scratching the plastic.
1. Clean with a wet, soft rag. A mild soap solution may
be used, but do not use high alcohol content or abrasive
cleaners. If soap is used, wipe clean with a clean damp
rag.
2. Dry with a soft tissue.
Seat Belt Maintenance
Do not bleach, dye, or clean the belts with chemical
solvents or abrasive cleaners. This will weaken the fabric.
Sun damage can also weaken the fabric.
MAINTAINING YOUR VEHICLE 399
7
Page 402 of 473
If the belts need cleaning, use a mild soap solution or
lukewarm water. Do not remove the belts from the car to
wash them.
Replace the belts if they appear frayed or worn or if the
buckles do not work properly.
Dry with a soft tissue.
Cleaning Center Console Cupholders
Removal
Grab the rubber portion of the cupholder and lift
upward.
Cleaning
Soak the rubber cupholder liner in a mixture of medium
hot tap water and one teaspoon of mild liquid dish soap.
Let soak for approximately one hour. After one hour pull
the liner from the water and dip it back into the water
about six times. This will loosen any remaining debris.Rinse the liner thoroughly under warm running water.
Shake the excess water from the liner and dry the outer
surfaces with a clean soft cloth.
Installation
Align the liner in the cupholder and press down firmly.
FUSES
Totally Integrated Power Module (TIPM)
The TIPM is located in the engine compartment near the
air cleaner assembly. This center contains cartridge fuses
and mini fuses. A label that identifies each component
may be printed on the inside of the cover. Refer to the
graphic below for FUSES/TIPM location.
400 MAINTAINING YOUR VEHICLE
Page 403 of 473
CavityCartridge
FuseMini Fuse Description
140 Amp
Green—Power Top
Module (If
Equipped)
CavityCartridge
FuseMini Fuse Description
2—20 Amp Yel-
lowAWD Mod-
ule
3 — 10 Amp RedBattery Feed
— Center
High
Mounted
Stop Light
(CHMSL)/
Brake
Switch
4 — 10 Amp RedBattery Feed
— Ignition
Switch
5—20 Amp Yel-
lowTrailer Tow
—If
Equipped
Totally Integrated Power Module (TIPM)
MAINTAINING YOUR VEHICLE 401
7
Page 404 of 473
CavityCartridge
FuseMini Fuse Description
6 — 10 Amp RedIgnition Off
Draw (IOD)
— Power
Mirror
Switch/
Climate
Controls
7—30 Amp
GreenIgnition Off
Draw (IOD)
Sense 1
8—30 Amp
GreenIgnition Off
Draw (IOD)
Sense 2CavityCartridge
FuseMini Fuse Description
940 Amp
GreenBattery Feed
— Power
Seats - if
equipped/
PZEV Air
Pump - if
equipped
10 —20 Amp Yel-
lowBattery Feed
— Cabin
Compart-
ment Node
(CCN)
11 —15 Amp Lt
BlueSelectable
Power Out-
let
12 —20 Amp Yel-
low—
402 MAINTAINING YOUR VEHICLE
Page 405 of 473
CavityCartridge
FuseMini Fuse Description
13 —20 Amp Yel-
low—
14 — 10 Amp RedIgnition Off
Draw (IOD)
— Cabin
Compart-
ment Node
(CCN)/ In-
terior Light-
ing
1540 Amp
Green—Battery Feed
— Radiator
Fan RelayCavityCartridge
FuseMini Fuse Description
16 —15 Amp Lt.
BlueIGN Run/
ACC — Ci-
gar Lighter/
PWR
Sunroof
Mod
17 — 10 Amp RedIgnition Off
Draw (IOD)
— Wireless
Control
Module
(WCM)/
Clock/
Steering
Control
Module
(SCM)
MAINTAINING YOUR VEHICLE 403
7
Page 406 of 473
CavityCartridge
FuseMini Fuse Description
1840 Amp
Green—Battery Feed
— Auto
Shutdown
(ASD) Relay
19 —20 Amp Yel-
lowIgnition Off
Draw (IOD)
— Power
Amp Feed 2
-if
equipped
20 —15 Amp Lt.
BlueIgnition Off
Draw (IOD)
— Radio
21 — 10 Amp Red —CavityCartridge
FuseMini Fuse Description
22 — 10 Amp RedIgnition
Run — Cli-
mate
Controls/
Hot Cup-
holder - if
equipped
23 —15 Amp Lt.
BlueAuto Shut-
down (ASD)
Relay Feed
3
24 —25 Amp
ClearBattery Feed
— PWR
Sunroof
Feed
404 MAINTAINING YOUR VEHICLE
Page 407 of 473
CavityCartridge
FuseMini Fuse Description
25 — 10 Amp RedIgnition
Run —
Heated Mir-
rors - If
Equipped
26 —15 Amp Lt.
BlueAuto Shut-
down (ASD)
Relay Feed
2CavityCartridge
FuseMini Fuse Description
27 — 10 Amp RedIgnition
Run — Oc-
cupant Clas-
sification
Module
(OCM)/
Occupant
Restraint
Controller
(ORC)
MAINTAINING YOUR VEHICLE 405
7
Page 408 of 473
CavityCartridge
FuseMini Fuse Description
28 — 10 Amp RedIgnition
Run — Oc-
cupant Clas-
sification
Module
(OCM)/
Occupant
Restraint
Controller
(ORC)
29 — —Hot Car
(No Fuse
Required)
30 —20 Amp Yel-
lowIgnition
Run —
Heated
Seats - If
EquippedCavityCartridge
FuseMini Fuse Description
31 — 10 Amp Red —
3230 Amp
Pink—Auto Shut-
down (ASD)
Relay Feed
1
33 — 10 Amp RedBattery Feed
— Switch
Bank/
Diagnostic
Link
Connector/
Powertrain
Control
Module
(PCM)
406 MAINTAINING YOUR VEHICLE
Page 409 of 473
CavityCartridge
FuseMini Fuse Description
3430 Amp
Pink—Battery Feed
— Anti-
Lock Brakes
(ABS) Mod-
ule - if
equipped/
Electronic
Stability
Program
(ESP) Mod-
ule - If
EquippedCavityCartridge
FuseMini Fuse Description
3540 Amp
Green—Battery Feed
— Anti-
Lock Brakes
(ABS) Mod-
ule - If
Equipped/
Electronic
Stability
Program
(ESP) Mod-
ule - If
Equipped
MAINTAINING YOUR VEHICLE 407
7
Page 410 of 473
CavityCartridge
FuseMini Fuse Description
3630 Amp
Pink—Battery Feed
— Passen-
ger Door
Module
(PDM)/
Driver Door
Module
(DDM)
37 —25 Amp
ClearPower Top
Module (If
Equipped)CAUTION!
•When installing the Totally Integrated Power
Module cover, it is important to ensure the cover is
properly positioned and fully latched. Failure to
do so may allow water to get into the Totally
Integrated Power Module, and possibly result in
an electrical system failure.
•When replacing a blown fuse, it is important to
use only a fuse having the correct amperage rating.
The use of a fuse with a rating other than indicated
may result in a dangerous electrical system over-
load. If a properly rated fuse continues to blow, it
indicates a problem in the circuit that must be
corrected.
408 MAINTAINING YOUR VEHICLE
