DODGE CALIBER 2006 1.G Owners Manual

Miles 78,000 81,000 84,000 87,000 90,000
(Kilometers ) (130 000) (135 000) (140 000) (145 000) (150 000)
Change engine oil and engine oil filter, or at 3
months whichever comes first.X X XXX
Rotate tires. X X X
Check spare tire for proper pressure and correct
stowage.XXX
Inspect brake linings.X
Replace engine air cleaner filter.X
Replace make-up air filter.X
Replace spark plugs.X
Inspect PCV valve, replace as necessary.**X
Inspect auto tension drive belt and replace, if re-
quired.X
SCHEDULE ªBº 291
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 93,000 96,000 99,000 102,000
(Kilometers) (155 000) (160 000) (165 000) (170 000)
Change engine oil and engine oil filter, or at 3 months
whichever comes first.XXXX
Rotate tires. X X
Check spare tire for proper pressure and correct stowage. X X
Flush and replace engine coolant, if not done at 60
months.X
292 SCHEDULE ªBº
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 105,000 108,000 111,000 114,000 117,000 120,000
(Kilometers) (175 000) (180 000) (185 000) (190 000) (195 000) (200 000)
Change engine oil and engine oil filter, or at 3 months
whichever comes first.X X XXXX
Change Automatic Transaxle (CVT) Fluid and Filter X
Change Rear Drive Assembly (RDA) fluid.X
Change Power Transfer Unit (PTU) fluid.X
Rotate tires. X X X
Check spare tire for proper pressure and correct stowage. X X X
Inspect brake linings. X
Replace engine air cleaner filter.XX
Inspect and replace make-up air filter, if required.X
Replace make-up air filter.X
Replace spark plugs.X
Inspect PCV valve, replace as necessary.**X
Inspect auto tension drive belt and replace, if required. X X
Flush and replace engine coolant, if not replaced at
102,000 miles (170 000 km).X
** This maintenance is recommended by the manufac-
turer to the owner, but not required to maintain the
emissions warranty.
SCHEDULE ªBº 293
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Schedule ªAº
Miles 6,000 12,000 18,000 24,000 30,000
(Kilometers) (10 000) (20 000) (30 000) (40 000) (50 000)
[Months] [6] [12] [18] [24] [30]
Change engine oil and engine oil filter. X X X X X
Rotate tires. X X X X X
Check spare tire for proper pressure and correct
stowage.X X XXX
Inspect brake linings. X
Replace engine air cleaner filter.X
Replace make-up air filter.X
Replace spark plugs.X
294 SCHEDULE ªAº
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 36,000 42,000 48,000 54000 60,000 66,000
(Kilometers) (60 000) (70 000) (80 000) (90 000) (100 000) (110 000)
[Months] [36] [42] [48] [54] [60] [66]
Change engine oil and engine oil filter. X X X X X X
Change Rear Drive Assembly (RDA) fluid. X
Change Power Transfer Unit (PTU) fluid. X
Rotate tires. X X X X X X
Check spare tire for proper pressure and cor-
rect stowage.X X XXXX
Flush and replace engine coolant at 60
months, if not replaced at 102,000 miles (170
000 km).X
Inspect brake linings. X X
Replace engine air cleaner filter.X
Replace make-up air filter.X
Replace spark plugs.X
Inspect PCV valve, replace as necessary.**X
Inspect auto tension drive belt and replace, if
required.X
SCHEDULE ªAº 295
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 72,000 78,000 84,000 90,000 96,000
(Kilometers) (120 000) (130 000) (140 000) (150 000) (160 000)
[Months] [72] [78] [84] [90] [96]
Change engine oil and engine oil filter. X X X X X
Rotate tires. X X X X X
Check spare tire for proper pressure and correct
stowage.X X XXX
Inspect brake linings. X X
Inspect engine air cleaner filter, replace if neces-
sary.X
Replace engine air cleaner filter.X
Replace make-up air filter.X
Replace spark plugs.X
Inspect PCV valve, replace as necessary.**X
Inspect auto tension drive belt and replace, if re-
quired.X
296 SCHEDULE ªAº
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 102,000 108,000 114,000 120,000
(Kilometers) (170 000) (180 000) (190 000) (200 000)
[Months] [102] [108] [114] [120]
Change engine oil and engine oil filter. X X X X
Change Rear Drive Assembly (RDA) fluid. X
Change Power Transfer Unit (PTU) fluid. X
Rotate tires. X X X X
Check spare tire for proper pressure and correct stowage. X X X X
Flush and replace engine coolant, if not done at 60 months. X
Flush and replace engine coolant, if not done at 102,000 miles
(170 000 km)X
Inspect brake linings. X
Replace engine air cleaner filter.X
Replace make-up air filter.X
Replace spark plugs.X
Inspect PCV valve, replace as necessary.**X
** This maintenance is recommended by the manufac-
turer to the owner, but not required to maintain the
emissions warranty.
Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.
WARNING!
You can be badly injured working on or around a
motor vehicle. Do only that service work for which
you have the knowledge and the right equipment. If
you have any doubt about your ability to perform a
service job, take your vehicle to a competent mechanic.
SCHEDULE ªAº 297
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

IF YOU NEED CONSUMER ASSISTANCE
CONTENTS
mSuggestions For Obtaining Service For Your
Vehicle
..............................300
NPrepare For The Appointment............300
NPrepare A List........................300
NBe Reasonable With Requests.............300
mIf You Need Assistance..................300
mWarranty Information (U.S. Vehicles Only)...302
mMopartParts.........................302
mReporting Safety Defects.................303
NIn Canada..........................303
mPublication Order Forms.................303
mDepartment Of Transportation Uniform Tire
Quality Grades
........................305
NTreadwear..........................305
NTraction Grades......................305
NTemperature Grades...................306
9

SUGGESTIONS FOR OBTAINING SERVICE FOR
YOUR VEHICLE
Prepare For The Appointment
If you're having warranty work done, be sure to have the
right papers with you. Take your warranty folder. All
work to be performed may not be covered by the
warranty, discuss additional charges with the service
manager. Keep a maintenance log of your vehicle's
service history. This can often provide a clue to the
current problem.
Prepare A List
Make a written list of your vehicle's problems or the
specific work you want done. If you've had an accident,
or work done that is not on your maintenance log, let the
service advisor know.
Be Reasonable With Requests
If you list a number of items, and you must have your
vehicle by the end of the day, discuss the situation with
the service advisor and list the items in order of priority.
At many dealers you may obtain a rental vehicle at aminimal daily charge. If you need a rental, it is advisable
to make these arrangements when you call for an ap-
pointment.
IF YOU NEED ASSISTANCE
The manufacturer and its dealers are vitally interested in
your satisfaction. We want you to be happy with our
products and services.
Warranty service must be done by an authorized
Chrysler, Dodge, or Jeep dealer. We strongly recommend
that you take your vehicle to your selling dealer. They
know you and your vehicle best, and are most concerned
that you get prompt and high quality service. The
manufacturer's dealers have the facilities, factory-trained
technicians, special tools, and the latest information to
assure your vehicle is fixed correctly and in a timely
manner.
This is why you should always talk to your dealer's
service manager first. Most matters can be resolved with
this process.
300 IF YOU NEED CONSUMER ASSISTANCE
