•After you enter the name, the UConnect™system will
ask you if you wish to delete the home, work, mobile,
or pager number for this entry.
Delete All Entries in the UConnect™Phonebook
•
Press the’Phone’button to begin.
•After theReadyprompt, sayPhonebook Delete All.
•The UConnect™system will ask you to verify that you
wish to delete all the entries from the phonebook.
•After confirmation, the phonebook entries will be
deleted.
List All Names in the UConnect™Phonebook
•
Press the’Phone’button to begin.
•After theReadyprompt, sayPhonebook List
Names.
•The UConnect™system will play the names of all the
phonebook entries.
•To call one of the names in the list, press the’Voice
Recognition’button during the playing of the desired
name and sayCall.
•The UConnect™system will then prompt you as to
number designation you wish to call.
•The selected number will be dialed.
Phone Call Features
The following feature(s) can be accessed through the
UConnect™system if the feature(s) are available on your
cellular service plan. For example, if your cellular service
plan provides three-way calling, this feature can be
accessed through the UConnect™system.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101
3

Answer or Reject an Incoming Call - No Call
Currently in Progress
When you receive a call on your cellular phone, the
UConnect™system will interrupt the stereo audio and
will ask if you would like to answer the call by pressing
the’Phone’button. Press the’Phone’button to answer
the call. To reject the call, press the’Phone’button until
you hear a single beep indicating that the incoming call
was rejected.
Answer or Reject an Incoming Call - Call
Currently in Progress
If a call is currently in progress and you have another
incoming call, press the’Phone’button to place the
current call on hold and answer the incoming call. To
reject the incoming call, you can disregard the call and
continue with your current conversation.
Making a Second Call while Current Call in
Progress
To make a second call while you are currently in a call,
press the’Voice Recognition’button and sayDialor
Callfollowed by the phone number or phonebook entry
you wish to call. The first call will be on hold while the
second call is in progress.
Putting a Call on Hold and Retrieving a Call from
Hold
To put a call on hold, press the’Phone’button until you
hear a single beep which will indicate that the call has
been placed on hold. To bring the call back from hold,
press the’Phone’button.
Toggling Between Two Calls
If two calls are in progress (one active and one on hold),
press the’Phone’button until you hear a single beep
102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

indicating that the active and hold status of the two calls
have switched. Only one call can be placed on hold at one
time.
Conference Call
When two calls are in progress (one active and one on
hold), press the’Phone’button until you hear a double
beep indicating that the two calls have been joined into
one conference call.
Three-Way Calling
To initiate three-way calling, press the’Voice Recogni-
tion’button while a call is in progress and make a second
phone call. When the second call is established, press the
’Phone’button until you hear a double beep indicating
that the two calls have been joined into one conference
call.
Call Termination
To end a call in progress, press the’Phone’button. All
calls in progress will be terminated.
Phone Redial
•
Press the’Phone’button to begin.
•After theReadyprompt, sayRedial.
•The UConnect™system will call the last number that
was dialed on your cellular phone. This may not be the
last number dialed by your UConnect™system.
Advanced Phone Connectivity
Transferring an Active Call between the
UConnect™System and Your Cellular Phone
The UConnect™system allows ongoing calls to be trans-
ferred to your cellular phone or to the UConnect™
system without terminating the call. To transfer an ongo-
ing call from your cellular phone to the UConnect™
system or vice versa, press the’Voice Recognition’button
and sayTransfer Call.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103
3

Delete Paired Cellular Phones
•
Press the’Phone’button to begin.
•After theReadyprompt, saySetup Phone Pairing.
•At the next prompt, sayDelete.
•You will be asked to say the name of the phone that
you wish to delete. You can either say the name of the
phone that you wish to delete or you can sayAllto
delete all the phones.
Connect or Disconnect the Connection between the
UConnect™System and Your Cellular Phone
Your cellular phone can be paired with many different
electronic devices, but can only be activelyconnected
with one electronic device at a time.If you would like to connect or disconnect the Blue-
tooth™connection between a paired cellular phone and
the UConnect™system, follow the instruction described
in your cellular phone user’s manual.
List Paired Cellular Phone Names
•
Press the’Phone’button to begin.
•After theReadyprompt, saySetup List Phonesand
the UConnect™system will play the phone names of
all paired cellular phones in order from highest prior-
ity to lowest priority.
Select a Lower Priority Paired Cellular Phone
•
Press the’Phone’button to begin.
•After theReadyprompt, saySetup Select Phone.
•When prompted, say the phone name of the cellular
phone you wish to use, or sayList Phonesto hear a
list of all the phones that have been paired to your
104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

UConnect™system. To select a phone from the list,
press the’Voice Recognition’button and saySelect.
•The lower priority phone will only be used for the next
phone call. After that, the UConnect™system will
return to using the highest priority phone in the
vehicle.
UConnect™System Features
Barge In - Touch Tone Phone Inputs
You can use your UConnect™system to access a voice mail
system, an automated service, or any other phone number
that you can dial with any phone. When calling a number
with your UConnect™system that normally requires you to
enter in a touch-tone sequence on your cellular phone
keypad, you can push the’Voice Recognition’button and
say the sequence you wish to enter followed bySend. For
example, if required to enter your pin number, you can press
the’Voice Recognition’button and say3746Send,or
whatever you have made your pin. This method can also beused in instances where you are pressing a number on your
keypad to navigate through a menu structure or to enter a
number for a pager.
Barge In - Overriding Prompts
The’Voice Recognition’button can be used when you
wish to skip part of a prompt and issue your voice
recognition command immediately. For example, if a
prompt is playingWould you like to pair a phone, clear
a, you could press the’Voice Recognition’button and
sayPair A Phoneto select that option without having to
listen to the rest of the voice prompt.
Language Selection
To change the language that the UConnect™system is
using, press the’Phone’button and say the name of the
language you wish to switch to (English, Español, or
Français as equipped). After selecting one of the lan-
guages, all prompts and voice commands will be in the
selected language.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105
3

Turning Confirmation Prompts On/Off
Turning confirmation prompts off will stop the system
from confirming your choices (e.g. the UConnect™sys-
tem will not repeat a phone number before you dial it).
•Press the’Phone’button to begin.
•After theReadyprompt, saySetup Confirmation.
The UConnect™system will play the current confir-
mation prompt status and you will be given the choice
to change it.
Low Signal, Battery Strength, and Roam
Notification
The UConnect™system will provide notification to
inform you if your cellular phone is in roaming status,
has low signal strength, or has a low battery when you
are trying to place a phone call.
Dialing Using the Cellular Phone Keypad
You can dial a phone number with your cellular phone
keypad and still use the UConnect™system. By dialing a
number with your paired Bluetooth™cellular phone, the
audio will be played through your vehicle’s stereo sys-
tem. The UConnect™system will work the same as if
you dialed the number using voice recognition.
Mute/Unmute
When you mute the UConnect™system, you will still be
able to hear the conversation coming from the other
party, but the other party will not be able to hear you. In
order to mute the UConnect™system press the’Voice
Recognition’button and sayMute. In order to unmute
the UConnect™system; press the’Voice Recognition’
button and sayUnmute.
106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Help
If you need assistance at any prompt or if you want to
know what your options are at any prompt, sayHelp.
The UConnect™system will play all the options at any
prompt if you ask for help.
Cancel
At any prompt, you can sayCanceland you will be
returned to the previous menu.
Emergency Assistance
If you are in an emergency, sayDial EmergencyorCall
Emergencyand the UConnect™system will instruct
your cellular phone to call 911.
Towing Assistance
If you need towing assistance, sayDial Towing Assis-
tanceorCall Towing Assistance. Please refer to the
24-Hour Towing Assistance coverage details in the
DaimlerChrysler Motors Company 24-Hour Towing As-
sistance Program Guide.
SEATS
Manual Front & Second Row Seat Adjuster
The adjusting bar is located under the front of the seat.
Pull the bar up and move the seat to the desired position.
Release the bar to lock the seat into position.
Manual Seat Adjuster
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107
3

Using body pressure, move forward and rearward on the
seat to be sure the seat adjusters have latched.
WARNING!
Adjust the seat only while the vehicle is parked.
Adjusting a seat while the vehicle is moving is
dangerous. The sudden movement of the seat could
cause you to lose control. The seat belt might not be
properly adjusted and you could be injured.
8–Way Driver’s Power Seat—If Equipped
The driver’s power seat switches are located on the
outboard side of the seat. The front switch controls
up/down, forward/rearward, and tilt adjustment. The
rear switch controls the seatback recline adjustment.4–Way Passenger’s Power Seat—If Equipped
The passenger’s power seat switches are located on the
outboard side of the seat. The front switch controls
forward and rearward adjustment. The rear switch con-
trols the seatback recline adjustment.
Driver Power Seat Switches
108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

CAUTION!
Do not place any article under a power seat or
impede its ability to move as it may cause damage to
the seat controls. Seat travel may become limited if
movement is stopped by an obstruction in the seat’s
path.
Adjustable Head Restraints—If Equipped
Head restraints can reduce the risk of whiplash injury in
the event of impact from the rear. Pull up or push down
on the head restraint so that the upper edge is as high as
practical. To raise the head restraint, pull up on the head
restraint. To lower the head restraint, depress the release
tab located at the base of the head restraint and push
down on the head restraint.
Adjustable Head Restraints
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109
3

Heated Seats—If Equipped
This feature heats the front driver and passenger seats.
The controls for the heated seats are located on the
instrument panel above the radio. You may choose LOW,
HIGH or No Heat. The switch position as well as an
indicator light will show when the LOW or HIGH heat is
ON.
Manual Reclining Seats—If Equipped
The recliner mechanism control is on the outboard side of
the seat. To recline, lean forward slightly, lift the lever,
then push back to the desired position and release the
lever. Lean forward and lift the lever to return the
Heated Seat Switches
110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
