DODGE CHALLENGER SRT 2009 3.G Owners Manual

UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101
3

Voice Commands
Primary Alternate(s)
zero
one
two
three
four
five
six
seven
eight
nine
star (*)
plus (+)
pound (#)
add location
allVoice Commands
Primary Alternate(s)
call
cancel
confirmation prompts
continue
delete
dial
download
edit
emergency
English
erase all
Espanol
Francais
help
home
102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Voice Commands
Primary Alternate(s)
language
list names
list phones
mobile
mute
mute off
new entry
no
pager
pair a phone
phone pairing pairing
phonebook phone book
previous
record again
redialVoice Commands
Primary Alternate(s)
return to main menu return or main menu
select phone select
send
set up phone settings or phone
set up
towing assistance
transfer call
UConnectTutorial
try again
voice training
work
yes
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103
3

General Information
This device complies with Part 15 of the FCC rules and
RSS 210 of Industry Canada. Operation is subject to the
following conditions:
•This device may not cause harmful interference.
•This device must accept any interference received,
including interference that may cause undesired op-
eration.
VOICE RECOGNITION SYSTEM — IF EQUIPPED
Voice Recognition System (VR) Operation
This Voice Recognition System allows you to
control your AM, FM radio, satellite radio, disc
player, and a memo recorder.
NOTE:In a stressful situation, take care to speak into
the Voice Interface System as calmly and normally as
possible. The ability of the Voice Interface System torecognize user voice commands may be negatively af-
fected by rapid speaking or a raised voice level.
WARNING!
Any voice commanded system should be used only
in safe driving conditions and all attention should be
kept on the roadway ahead. Failure to do so may
result in an accident causing serious injury or death.
When you press the VR hard-key, you will hear a beep.
The beep is your signal to give a command.
NOTE:If you do not say a command within a few
seconds, the system will present you with a list of
options.
If you ever wish to interrupt the system while it lists
options, press the VR hard-key, listen for the beep, and
say your command.
104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Pressing the VR hard-key while the system is speaking is
known as “barging in.” The system will be interrupted
and you can add or change commands. This will become
helpful once you start to learn the options.
NOTE:At any time, you can say the words CANCEL,
HELP, or MAIN MENU.
These commands are universal and can be used from any
menu. All other commands can be used depending upon
the active application.
For example, if you are in the disc menu and you are
listening to FM radio, you can speak commands from the
disc menu or from the FM radio menu.
When using this system, you should speak clearly and at
a normal speaking volume.
The system will best recognize your speech if the win-
dows are closed, and the heater/air-conditioning fan is
set to low.At any point, if the system does not recognize one of your
commands, you will be prompted to repeat it.
To hear the first available Menu, press the VR hard-key
and say HELP or MAIN MENU.
Commands
The Voice Recognition System understands two types of
commands. Global commands are available at all times.
Local commands are available if the supported radio
mode is active.
Changing the Volume
1. Start a dialogue by pressing the VR hard-key.
2. Say a command (e.g., HELP).
3. Use the ON/OFF VOLUME rotary knob to adjust the
volume to a comfortable level while the voice recognition
system is speaking. Please note the volume setting for VR
is different then the audio system.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105
3

Main Menu
Start a dialogue by pressing the VR hard-key. You may
say MAIN MENU to switch to the main menu.
In this mode, you can say the following commands:
•RADIO (to switch to the radio mode)
•DISC (to switch to the disc mode)
•MEMO (to switch to the memo recorder)
Radio AM (or Radio Long Wave or Radio Medium
Wave - if equipped)
To switch to the AM band say AM or RADIO AM. In this
mode, you may say the following commands:
•FREQUENCY (to change the frequency)
•NEXT STATION (to select the next station)
•PREVIOUS STATION (to select the previous station)
•RADIO MENU (to switch to the radio menu)
•MAIN MENU (to switch to the main menu)
Radio FM
To switch to the FM band say FM or RADIO FM. In this
mode, you may say the following commands:
•FREQUENCY (to change the frequency)
•NEXT STATION (to select the next station)
•PREVIOUS STATION (to select the previous station)
•RADIO MENU (to switch to the radio menu)
•MAIN MENU (to switch to the main menu)
Satellite Radio
To switch to satellite radio mode say SAT or SATELLITE
RADIO. In this mode, you may say the following com-
mands:
•CHANNEL NUMBER (to change the channel by its
spoken number)
106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

•NEXT CHANNEL (to select the next channel)
•PREVIOUS CHANNEL (to select the previous chan-
nel)
•LIST CHANNEL (to hear a list of available channels)
•SELECT NAME (to say the name of a channel)
•RADIO MENU (to switch to the radio menu)
•MAIN MENU (to switch to the main menu)
Disc
To switch to the disc mode say DISC. In this mode, you
may say the following commands:
•TRACK (#) (to change the track)
•NEXT TRACK (to play the next track)
•PREVIOUS TRACK (to play the previous track)
•MAIN MENU (to switch to the main menu)
Memo
To switch to the voice recorder mode say MEMO. In this
mode, you may say the following commands:
•NEW MEMO (to record a new memo) — During the
recording you may press the VR hard-key to stop
recording. You continue by saying one of the following
commands:
SAVE (to save the memo)
CONTINUE (to continue recording)
DELETE (to delete the recording)
•PLAY MEMOS (to play previously recorded memos)
— During the playback you may press the VR hard-
key to stop playing memos. You continue by saying
one of the following commands:
REPEAT (to repeat a memo)
NEXT (to play the next memo)
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107
3

PREVIOUS (to play the previous memo)
DELETE (to delete a memo)
•DELETE ALL (to delete all memos)
NOTE:Keep in mind that you have to press the VR
hard-key first and wait for the beep, before speaking the
“barge in” commands.
Voice Training
For users experiencing difficulty with the system recog-
nizing their voice commands or numbers, the UConnect
system Voice Training feature may be used.1. Press the VR hard-key, speak “System Setup” and once
you are in that menu then speak “Voice Training.” This
will train your own voice to the system and will improve
recognition.
2. Repeat the words and phrases when prompted by the
UConnectSystem. For best results, the Voice Training
session should be completed when the vehicle is parked,
engine running, all windows closed, and the blower fan
switched OFF. This procedure may be repeated with a
new user. The system will adapt to the last trained voice
only.
108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

SEATS
Easy Entry Seats
Pushing the lever upward (toward the front of the
vehicle) allows the seat back to dump forward and the
seat to slide forward. This allows for easier access to the
rear seat.
Power Seats
The power seat switch is on the outboard side of the seat
near the floor. Use this switch to move the driver’s seat
up or down, forward or rearward, or to tilt the seat.
Easy Entry Seats
Power Seat Switch
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109
3

WARNING!
Adjusting a seat while the vehicle is moving is
dangerous. The sudden movement of the seat could
cause you to lose control. The seat belt might not be
properly adjusted and you could be injured. Adjust
the seat only while the vehicle is parked.
CAUTION!
Do not place any article under a power seat as it may
cause damage to the seat controls.
Front Seat Back Recline
To recline:
1. Lean forward in the seat and lift the handle, then lean
back to the desired position and release the handle.
2. Lift the handle to return the seatback to an upright
position.
Recline Lever
110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
