DODGE DAKOTA 2007 3.G Owners Manual

Operation Tips Chart
INSTRUMENT PANEL AND CONTROLS 181
4

STARTING AND OPERATING
CONTENTS

Starting Procedures.....................187
▫Manual Transmission..................187
▫Automatic Transmission................187
▫Normal Starting......................188
▫If Engine Fails To Start.................188
▫After Starting........................189

Engine Block Heater — If Equipped.........189

Automatic Transmission..................190
▫Brake/Transmission Interlock System.......191▫Automatic Transmission................191

Manual Transmission....................196
▫Recommended Shift Speeds..............197
▫Downshifting........................198

Four-Wheel Drive Operation...............199
▫NV233/243 GII Transfer Case Operating
Information/Precautions................199
▫Shifting Procedure - NV233/243
Transfer Case........................202
5

▫NV 244 Generation II Transfer Case Operating
Information / Precautions...............205
▫Shifting Procedure - NV 244 Generation II Transfer
Case..............................209

Limited-Slip Rear Axle Differential— If Equipped 210

Driving On Slippery Surfaces..............211

Parking Brake.........................212

Brake System..........................213
▫Rear Wheel Anti-Lock Brake System –
If Equipped.........................213
▫Four-Wheel Anti-Lock Brake System........214

Power Steering........................216

Rocking The Vehicle.....................217

Tire Safety Information...................218▫Tire Markings........................218
▫Tire Identification Number (TIN)..........221
▫Tire Loading And Tire Pressure...........222

Tires — General Information...............226
▫Tire Pressure.........................226
▫Tire Inflation Pressures.................227
▫Radial-Ply Tires......................229
▫Compact Spare Tire — If Equipped.........230
▫Limited Use Spare — If Equipped.........231
▫Tire Spinning........................231
▫Tread Wear Indicators..................232
▫LifeOfTire .........................233
▫Replacement Tires.....................233
184 STARTING AND OPERATING

▫Alignment And Balance.................234

Supplemental Tire Pressure Information – If
Equipped............................235

Tire Chains...........................235

Snow Tires...........................237

Tire Rotation Recommendations............237

Fuel Requirements......................238
▫Reformulated Gasoline.................239
▫Gasoline/Oxygenate Blends..............239
▫MMT In Gasoline.....................240
▫Materials Added To Fuel................241
▫Fuel System Cautions..................241
▫Carbon Monoxide Warnings..............242
Adding Fuel..........................243
▫Fuel Filler Cap (Gas Cap)...............244

Flexible Fuel— If Equipped................245
▫E-85 General Information................245
▫Ethanol Fuel (E-85)....................245
▫Fuel Requirements....................245
▫Selection Of Engine Oil For Flexible Fuel Vehicles
(E-85) And Gasoline Vehicles.............246
▫Starting............................246
▫Cruising Range.......................247
▫Replacement Parts.....................247
▫Maintenance.........................247

Vehicle Loading........................247
STARTING AND OPERATING 185
5

▫Certification Label.....................247
▫Curb Weight.........................249
▫Loading............................249

TrailerTowing .........................251
▫Common Towing Definitions.............251
▫Trailer Hitch Classification...............256
▫Trailer Towing Weights (Maximum Trailer Weight
Ratings)............................257
▫Trailer And Tongue Weight..............257▫Towing Requirements..................258
▫TowingTips .........................262

Snowplow............................264
▫Dodge Dakota Models..................264

Recreational Towing (Behind Motorhome, Etc.) . . 265
▫Recreational Towing 2WD Models.........265
▫Recreational Towing 4WD Models.........265

Equipment Identification Plate.............270
186 STARTING AND OPERATING

STARTING PROCEDURES
The starter should not be operated for more than 15
second intervals. Waiting a few seconds between such
intervals will protect the starter from overheating.
WARNING!
Be sure to turn off the engine if you want to rest or
sleep in your car. Accidents can be caused by inad-
vertently moving the gear selection lever or by
pressing the accelerator pedal. This may cause exces-
sive heat in the exhaust system, resulting in over-
heating and vehicle fire which may cause serious or
fatal injuries.
WARNING!
Do not leave children or animals inside parked
vehicles in hot weather. Interior heat build up may
cause serious injury or death.
Manual Transmission
Apply the parking brake, place the gearshift control lever
in NEUTRAL and depress clutch pedal to the floor before
starting the vehicle. This vehicle is equipped with a
clutch interlocking ignition system. It will not start unless
the clutch is depressed.
Automatic Transmission
Start the engine with the shift lever in NEUTRAL or
PARK position. Apply the brake before shifting to any
driving range.
STARTING AND OPERATING 187
5

Normal Starting
Normal starting of either a warm or cold engine is
obtained without pumping or depressing the accelerator
pedal. Turn the key to the START position and release
when the engine starts. If the engine fails to start within
10 seconds, turn the key to the OFF position, wait 5
seconds, then repeat the starting procedure.
NOTE: This vehicle is equipped with a transmission
shift interlocking system. The brake pedal must be
depressed to shift out of Park (P).
If Engine Fails To Start
If the engine fails to start after you have followed the
normal starting procedure, it may be flooded. Push the
accelerator pedal all the way to the floor and hold it there
while cranking the engine. This should clear any excess
fuel in case the engine is flooded.
CAUTION!
To prevent damage to the starter, do not crank the
engine for more than 15 seconds at a time. Wait 10 to
15 seconds before trying again.
WARNING!
Never pour fuel or other flammable liquids into the
throttle body air inlet opening in an attempt to start
the vehicle. This could result in a flash fire causing
serious personal injury.
188 STARTING AND OPERATING

WARNING!
Do not attempt to push or tow your vehicle to get it
started. Vehicles equipped with an automatic trans-
mission cannot be started this way. Unburned fuel
could enter the catalytic converter and once the
engine has started, ignite and damage the converter
and vehicle. If the vehicle has a discharged battery,
booster cables may be used to obtain a start from a
booster battery or the battery in another vehicle. This
type of start can be dangerous if done improperly.
See section 6 of this manual for the proper jump
starting procedures and follow them carefully.
If the engine has been flooded, it may start to run, but not
have enough power to continue running when the key isreleased. If this occurs, continue cranking with the accel-
erator pedal pushed all the way to the floor. Release the
accelerator pedal and the key once the engine is running
smoothly.
If the engine shows no sign of starting after two 15
second periods of cranking with the accelerator pedal
held to the floor, the normal starting procedure should be
repeated.
After Starting
The idle speed is automatically controlled and will de-
crease as the engine warms up.
Engine Block Heater — If Equipped
The engine block heater warms engine coolant and
permits quicker starts in cold weather. Connect the cord
to a standard 110-115 volt AC electrical outlet with a
grounded, three wire extension cord.
STARTING AND OPERATING 189
5

The engine block heater cord is located at the right front
of the engine compartment for all engine applications.
WARNING!
Remember to disconnect the cord before driving.
Damage to the 110-115 volt electrical cord could
cause electrocution.
AUTOMATIC TRANSMISSION
CAUTION!
Damage to the transmission may occur if the follow-
ing precautions are not observed:
•Shift into PARK only after the vehicle has come to
a complete stop.
•Shift into or out of REVERSE only after the
vehicle has come to a complete stop and the
engine is at idle speed.
•Do not shift from REVERSE, PARK, or NEUTRAL
into any forward gear when the engine is above
idle speed.
•Before shifting into any gear, make sure your foot
is firmly on the brake pedal.
190 STARTING AND OPERATING
