DODGE DAKOTA 2007 3.G Owners Manual

CavityCartridge
FuseMini
FuseDescription
54 Spare
55 10 Amp
RedCabin Compartment
Node (CCN) Accessory
(ACC) Feed
56 10 Amp
RedHeated Seats
57 20 Amp
YellowAirbag System # 2
58 20 Amp
YellowHeated Seats
59 10 Amp
RedHVAC Module
60 10 Amp
RedABS Module
61 20 Amp
YellowFront Control Module
(FCM) 3 (Reverse
Lamps)CAUTION!
When replacing a blown fuse, it is important to use
only a fuse having the correct amperage rating. The
use of a fuse with a rating other than indicated may
result in a dangerous electrical system overload. If a
properly rated fuse continues to blow, it suggests a
problem in the circuit that must be corrected.
NOTE:If you are leaving your vehicle dormant for
longer than 21 days you may want to take steps to protect
your battery. You may do this by disconnecting the
battery or by disconnecting the two ignition-off draw
(I.O.D.) fuses located in the Auxiliary Power Distribution
Center (PDC) located in the engine compartment. The
I.O.D. cavities include a snap-in retainer that allows the
fuse to be disconnected, without removing it from the
fuse block. Pressing the I.O.D. fuse back into the cavity
reconnects it.
MAINTAINING YOUR VEHICLE 331
7

VEHICLE STORAGE
If you are storing your vehicle for more than 21 days, we
recommend that you take the following steps to mini-
mize the drain on your vehicle’s battery:
•Disconnect the Ignition-Off Draw fuse (I.O.D.) fuse
located in the Power Distribution Center (PDC). The
I.O.D. cavity includes a snap-in retainer that allows the
fuse to be disconnected, without removing it from the
fuse block.
•The transfer case should be placed in the 4HI mode
and kept in this position to minimize the battery drain.
•As an alternative to the above steps you may discon-
nect the negative cable from the battery.
REPLACEMENT LIGHT BULBS
LIGHT BULBS — Interior Bulb No.
Dome Light........................ WL212–2
Cargo Light............................ 567
Overhead Console Lights................... 192
Reading Light....................... WL212–2
LIGHT BULBS — Outside Bulb No.
Headlight............................. H13
Front Park/Turn/Sidemarker.............3157NA
Back-Up..............................3157
Center High Mounted Stoplight.............. 921
Fog Lamp.............................9145
Rear Sidemarker......................... 168
License Plate Light....................... 168
Rear Tail, Stop, Turn Signal.................3057
332 MAINTAINING YOUR VEHICLE

BULB REPLACEMENT
Headlamps
Removing Attaching Screw
Removing Headlamp Assembly
MAINTAINING YOUR VEHICLE 333
7

1. Open the hood.
2. Remove the 3 screws attaching the headlamp housing
to the inner panel.
3. Grasp the headlamp and pull firmly to disengage the
headlamp housing from the fender panel.4. While firmly holding the headlamp housing in your
hands unlock and disconnect Headlamp bulb connector.
5. Twist 1/4 turn and remove headlamp bulb and socket
from housing and replace.
Removing Headlamp Assembly
Removing Headlamp Bulb
334 MAINTAINING YOUR VEHICLE

Unlocking ConnectorRemoving Headlamp from Assembly
MAINTAINING YOUR VEHICLE 335
7

6. Reverse procedure to install new Headlamp bulb into
the headlamp assembly.
NOTE:These are Halogen bulbs. Take care not to touch
the bulb with your fingers. Body oils from your fingers
could cause excessive heat buildup which reduces bulb
life.
Removing Headlamp BulbDisconnecting Headlamp Bulb Connector
336 MAINTAINING YOUR VEHICLE

Front Park and Turn Signal Lamp.
•
Open the hood.
•Remove the (3 ) screws attaching the headlamp hous-
ing to the inner panel.
•Grasp the headlamp and pull firmly to disengage the
headlamp housing from the fender panel.
NOTE:It is not necessary to disconnect the connector to
replace this bulb. If the bulb socket needs replacement
disconnect the connector.
Removing Turn Signal Bulb
MAINTAINING YOUR VEHICLE 337
7

•Rotate bulb socket 1/4 turn and remove socket from
housing.
•Pull bulb straight from socket.
•Reverse procedure to install new turn signal bulb.
Rear Side Marker, Taillamps/Stoplamp, and Turn
Signal Bulbs — Replacement
1. Remove the two (2) screws that pass through the bed
sheetmetal.
Disconnecting Turn Signal ConnectorRemoving the Two (2) Screws
338 MAINTAINING YOUR VEHICLE

2. Pull the taillamp housing straight out from the body.
3. Rotate the bulb socket counterclockwise to from the
housing.
Pulling Housing From Body
Rotating Bulb Socket From Housing
MAINTAINING YOUR VEHICLE 339
7

4. Pull bulb straight out of socket. 5. Reverse Procedure to install bulb and housing. Place
the two raised blocks passed the body.
Pulling Bulb From Socket
Sliding Raised Blocks Past Body
