DODGE DAKOTA 2007 3.G Owners Manual

Center High-Mounted Stoplamp And Cargo Lamp
1. Remove the two (2) screws holding the housing/lens
to the body as shown.2. Remove housing from Cab
Removing Screws
Removing Housing from Cab
MAINTAINING YOUR VEHICLE 341
7

3. Remove connector from housing tab for more clear-
ance.4. Turn desired bulb socket14turn and remove socket
and bulb from housing.
Removing Connector from TabRemoving Socket From Housing
342 MAINTAINING YOUR VEHICLE

5. Pull desired bulb straight from the socket.
•Outside Bulbs: Cargo Lamps
•Inside Bulb: Center High Mount Stop Lamp
6. Reverse procedure for installation of bulbs and hous-
ing.
License Lamps
1. Using a screw driver pry black rubber housing from
the bumper.
Pulling Bulb From Socket
Removing Housing From Bumper
MAINTAINING YOUR VEHICLE 343
7

2. Rotate the socket 1/4 turn counterclockwise. 3. Pull bulb from socket.
4. Reverse procedure for installation.
Rotating SocketPulling Bulb From Socket
344 MAINTAINING YOUR VEHICLE

Fog Lamps
1. Disconnect connector from fog lamp by raising wire
harness lock tab and pulling on wire harness connector.2. Rotate fog lamp bulb 1/4 turn counterclockwise and
pull to remove from fog lamp housing.
3. Reverse Procedure to install.
FLUIDS AND CAPACITIES
U.S. Metric
Fuel
3.7L/4.7L, 87 Octane 22 Gal. 83L
4.7L HO, 91 Octane, Recommended Not Required 22 Gal. 83L
Engine Oil (with filter)
3.7L, SAE 5W-20, API Certified 5 Qt. 4.7L
4.7L, SAE 5W-20, API Certified 6 Qt. 5.7L
4.7L HO, SAE 5W-20, API Certified 6 Qt. 5.7L
Cooling System (includes 2.1 Qts./2L for coolant bottle
3.7L (MoparAntifreeze/Coolant 5 Year/100,000 Mile Formula) 13.3 Qt. 12.5L
4.7L (MoparAntifreeze/Coolant 5 Year/100,000 Mile Formula) 13.3 Qt. 12.5L
4.7L HO (MoparAntifreeze/Coolant 5 Year/100,000 Mile Formula) 13.3 Qt. 12.5L
NOTE:All fluid capacities are approximate capacities.
MAINTAINING YOUR VEHICLE 345
7

FLUIDS, LUBRICANTS AND GENUINE PARTS
Engine
Component Fluids, Lubricants and Genuine Parts
Engine Coolant MoparAntifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Or-
ganic Additive Technology) or equivalent.
Engine Oil Use SAE 5W-20, API Certified, meeting material standard MS-6395.
Engine Oil Filter MoparEngine Oil Filter, P/N 5281090 or equivalent.
Spark Plugs Refer to the Vehicle Emission Control Information label in the engine com-
partment.
Fuel Selection 3.7L/4.7L 87 Octane, (R+M)/2 Method
Fuel Selection 4.7L HO 91 Octane, (R+M)/2 Method (Recommend, Not Required.)
346 MAINTAINING YOUR VEHICLE

Chassis
Component Fluids, Lubricants and Genuine Parts.
Automatic Transmission MoparATF+4, Automatic Transmission Fluid.
Manual Transmission (Getrag 238) MoparATF+4, Automatic Transmission Fluid.
Transfer Case MoparATF+4, Automatic Transmission Fluid.
Front Axle SAE 75W-90 Multipurpose Type, GL-5 Gear Lubricant (MS-9763).
Rear Axle SAE 75W-140 Synthetic Gear Lubricant (MS-8985). Limited-slip rear axles
require Moparlimited-slip additive (MS-10111). Four ounces (118 ml)
should be added to the gear lubricant whenever a fluid change is made.
Brake Master Cylinder MoparDOT 3 and SAE J1703 should be used. If DOT 3 brake fluid is not
available, then DOT 4 is acceptable. Use only recommended brake fluids.
Power Steering Reservoir MoparATF+4, Automatic Transmission Fluid.
MAINTAINING YOUR VEHICLE 347
7

MAINTENANCE SCHEDULES
CONTENTS

Emission Control System Maintenance........350

Maintenance Schedules...................350▫Schedule “B”........................353
▫Schedule “A”........................364
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

EMISSION CONTROL SYSTEM MAINTENANCE
The “Scheduled” maintenance services, listed inbold
typeon the following pages must be done at the times or
mileages specified to assure the continued proper func-
tioning of the emission control system. These, and all
other maintenance services included in this manual,
should be done to provide best vehicle performance and
reliability. More frequent maintenance may be needed for
vehicles in severe operating conditions such as dusty
areas and very short trip driving.
Inspection and service also should be done any time a
malfunction is suspected.
NOTE:Maintenance, replacement, or repair of the emis-
sion control devices and systems on your vehicle may be
performed by any automotive repair establishment or
individual using any automotive part which has been
certified pursuant to U.S. EPA or, in the State of Califor-
nia, California Air Resources Board regulations.
MAINTENANCE SCHEDULES
There are two maintenance schedules that show the
requiredservice for your vehicle.
First is Schedule“B”. It is for vehicles that are operated
under the conditions that are listed below and at the
beginning of the schedule.
•Day or night temperatures are below 32° F (0° C).
•Stop and go driving.
•Extensive engine idling.
•Driving in dusty conditions.
•Short trips of less than 10 miles (16 km).
•More than 50% of your driving is at sustained high
speeds during hot weather, above 90° F (32° C).
•Trailer towing.
•Taxi, police, or delivery service (commercial service).
