Page 261 of 656
The system will indicate a detected obstacle by showing
a single arc in one or more regions based on the obstacle’s
distance and location relative to the vehicle.If an obstacle is detected in the center rear region, the
display will show a single solid arc in the center rear
region and will produce a one-half second tone. As the
vehicle moves closer to the obstacle, the display will
show the single arc moving closer to the vehicle and the
sound tone will change from slow, to fast, to continuous.
If an obstacle is detected in the left and/or right rear
region, the display will show a single flashing arc in the
left and/or right rear region and will produce a fast
sound tone. As the vehicle moves closer to the obstacle,
the display will show the single arc moving closer to the
vehicle and the sound tone will change from fast, to
continuous.
Park Assist System Off
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 259
Page 262 of 656
One-Half Second ToneSlow Tone
260 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 263 of 656
Slow ToneFast Tone
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 261
Page 264 of 656
Fast ToneFast Tone
262 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 265 of 656
The vehicle is close to the obstacle when the warning
display shows one flashing arc and sounds a continuous
tone. The following chart shows the warning alert opera-
tion when the system is detecting an obstacle:
Continuous ToneContinuous Tone
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 263
Page 266 of 656
WARNING ALERTS
Rear
Distance (in/cm) Greater
than
79 in
(200 cm)
79-59 in (200-
150 cm)59-47 in (150-
120 cm) 47-39 in
(120-
100 cm) 39-25 in
(100-65 cm) 25-12 in
(65-30 cm) Less than
12 in
(30 cm)
Audible Alert
Chime None Single 1/2-
SecondTone
(for rear centeronly) Slow
(for rear centeronly) Slow
(for rear centeronly) Fast
(for rear centeronly) Fast Continuous
Arc — Left Rear None None None None None 2nd
Flashing1st Flashing
Arc —
Center Rear None 6th Solid 5th Solid 4th Solid
3rd
Flashing2nd
Flashing 1st Flashing
Arc —
Right Rear None None None None None 2nd
Flashing1st Flashing
264 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 267 of 656

Enabling And Disabling ParkSense®
ParkSense® can be enabled and disabled using the
Uconnect® System. The available choices are: Off, Sound
Only, or Sound and Display. Refer to “Uconnect® Set-
tings” in “Understanding Your Instrument Panel” for
further information.
When the ParkSense® button is pushed to disable the
system, the EVIC will display the “PARK ASSIST SYS-
TEM OFF” message for approximately five seconds.
Refer to “Electronic Vehicle Information Center (EVIC)”
in “Understanding Your Instrument Panel” for further
information. When the shift lever is moved to REVERSE
and the system is disabled, the EVIC will display the
“PARK ASSIST SYSTEM OFF” message for as long as the
vehicle is in REVERSE.
Service The ParkSense® Rear Park Assist
System
During vehicle start up, when the ParkSense® Rear Park
Assist system has detected a fault condition, the Elec-
tronic Vehicle Information Center (EVIC) will actuate a
single chime, once per ignition cycle, and it will display
the “WIPE OFF REAR PARK ASSIST SENSORS”, “SER-
VICE PARK ASSIST SENSORS” or “SERVICE PARK
ASSIST SYSTEM” message. Refer to “Electronic Vehicle
Information Center (EVIC)” in “Understanding Your
Instrument Panel” for further information. When the
shift lever is moved to REVERSE and the system has
detected a faulted condition, the EVIC will display the
“WIPE OFF REAR PARK ASSIST SENSORS”, “SERVICE
PARK ASSIST SENSORS” or the “SERVICE PARK AS-
SIST SYSTEM” message for as long as the vehicle is in
REVERSE. Under this condition, ParkSense® will not
operate.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 265
Page 268 of 656
If “WIPE OFF REAR PARK ASSIST SENSORS” appears
in the EVIC make sure the outer surface and the under-
side of the rear fascia/bumper is clean and clear of snow,
ice, mud, dirt or other obstruction and then cycle the
ignition. If the message continues to appear, see an
authorized dealer.If “SERVICE PARK ASSIST SENSORS” or “SERVICE
PARK ASSIST SYSTEM” appears in the EVIC, see an
authorized dealer.
Wipe Off Rear Park Assist Sensors
Service Park Assist Sensors
266 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 269 of 656
The ParkSense® Rear Park Assist system will be auto-
matically disabled when there are faulted conditions
outside of the ParkSense® Rear Park Assist system that
inhibit the feature from functioning properly. The Elec-
tronic Vehicle Information Center (EVIC) will actuate asingle chime, once per ignition cycle, and it will display
the
PARK ASSIST SYSTEM DISABLED message. If
“PARK ASSIST SYSTEM DISABLED” appears in the
EVIC, cycle the ignition. If the message appears again,
see an authorized dealer.
Service Park Assist System
Park Assist System Disabled
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 267
Page 270 of 656

Cleaning The ParkSense® System
Clean the ParkSense® sensors with water, car wash soap
and a soft cloth. Do not use rough or hard cloths. Do not
scratch or poke the sensors. Otherwise, you could dam-
age the sensors.
ParkSense® System Usage Precautions
NOTE:
•
Ensure that the outer surface and the underside of the
rear bumper is clean and clear of snow, ice, mud, dirt or
other obstruction to keep the ParkSense® system operat-
ing properly.
•Jackhammers, large trucks, and other vibrations could
affect the performance of ParkSense®.
• When you turn ParkSense® off, the EVIC will display
“PARK ASSIST SYSTEM OFF.” Furthermore, once you
turn ParkSense® off, it remains off until you turn it on
again, even if you cycle the ignition key. •
When you move the shift lever to the REVERSE
position and ParkSense® is turned off, the EVIC will
display the “PARK ASSIST SYSTEM OFF” message for
as long as the vehicle is in REVERSE.
•
Clean the ParkSense® sensors regularly, taking care not to
scratch or damage them. The sensors must not be covered
with ice, snow, slush, mud, dirt or debris. Failure to do so
can result in the system not working properly. The
ParkSense® system might not detect an obstacle behind
the fascia/bumper, or it could provide a false indication
that an obstacle is behind the fascia/bumper.
• Ensure the ParkSense® system is OFF if objects such as
bicycle carriers, trailer hitches, etc., are placed within
12 in (30 cm) from the rear fascia/ bumper. Failure to
do so can result in the system misinterpreting a close
object as a sensor problem, causing the “SERVICE
PARK ASSIST SYSTEM” message to be displayed in
the EVIC.
