DODGE DART 2015 PF / 1.G Owners Manual

Chassis
ComponentFluid, Lubricant, or Genuine Part
Automatic Transmission (1.4L
Turbo Engine) – If Equipped
Gear Oil: Use only MOPAR® C Series Manual & Dual Dry Clutch Trans-
mission Fluid or equivalent.
Control system: Use only MOPAR® C Series DDCT SAE 75W Hydraulic
Fluid or equivalent.
Failure to use the correct fluid may affect the function or performance of
your transmission.
Automatic Transmission (2.0L And
2.4L Engine) – If Equipped
Use only MOPAR® SP-IV Automatic Transmission Fluid or equivalent.
Failure to use the correct fluid may affect the function or performance of
your transmission
Manual Transmission – If
Equipped
We recommend you use MOPAR® C Series Manual & Dual Dry Clutch
Transmission Fluid.
Brake Master CylinderWe recommend you use MOPAR® DOT 3, SAE J1703. If DOT 3, SAE
J1703 brake fluid is not available, then DOT 4 is acceptable.
7
MAINTAINING YOUR VEHICLE 619

MAINTENANCE SCHEDULES
CONTENTS
!MAINTENANCE SCHEDULE.............622▫Required Maintenance..................623
8
MAINTENANCE
SCHEDULES

MAINTENANCE SCHEDULE
Your vehicle is equipped with an automatic oil change
indicator system. The oil change indicator system will
remind you that it is time to take your vehicle in for
scheduled maintenance.
Based on engine operation conditions, the oil change
indicator message will illuminate. This means that ser-
vice is required for your vehicle. Operating conditions
such as frequent short-trips, trailer tow, extremely hot or
cold ambient temperatures, and E85 fuel usage will
influence when the “Change Oil” message is displayed.
Severe Operating Conditions can cause the change oil
message to illuminate as early as 3,500 miles (5,600 km)
since last reset. Have your vehicle serviced as soon as
possible, within the next 500 miles (805 km).
Your authorized dealer will reset the oil change indicator
message after completing the scheduled oil change. If a
scheduled oil change is performed by someone other
than your authorized dealer, the message can be reset by
referring to the steps described under “Electronic Vehicle
Information Center (EVIC)/Driver Information Display
(DID)” in “Understanding Your Instrument Panel” for
further information.
NOTE:Under no circumstances should oil change inter-
vals exceed 10,000 miles (16,000 km) or twelve months,
whichever comes first.
Severe Duty All Models
Change Engine Oil at 4000 miles (6,500 km) if the vehicle
is operated in a dusty and off road environment. This
type of vehicle use is considered Severe Duty.
•Once A Month Or Before A Long Trip:
Check engine oil level.
Check windshield washer fluid level.
8
MAINTENANCE
SCHEDULES
622 MAINTENANCE SCHEDULES

Check the tire inflation pressures and look for unusual
wear or damage.
Check the fluid levels of the coolant reservoir, and brake
master cylinder as needed.
Check function of all interior and exterior lights.
Required Maintenance
Refer to the Maintenance Schedules on the following
pages for required maintenance.
At Every Oil Change Interval As Indicated By Oil
Change Indicator System:
•Change engine oil and filter.
•Rotate the tires.Rotate at the first sign of irregu-
lar wear, even if it occurs before the oil indicator
system turns on.
At Every Oil Change Interval As Indicated By Oil
Change Indicator System:
•Inspect battery and clean and tighten terminals as
required.
•Inspect brake pads, shoes, rotors, drums, hoses
and park brake.
•Inspect engine cooling system protection and
hoses.
•Inspect exhaust system.
•Inspect engine air cleaner if using in dusty or
off-road conditions.
8
MAINTENANCE
SCHEDULES
MAINTENANCE SCHEDULES 623

Maintenance Chart
Mileage Or Time Passed (Whichever Comes
First)20,00030,00040,00050,00060,00070,00080,00090,000100,000110,000120,000130,000140,000150,000
Or Years: 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Or Kilometers:
32,00048,00064,00080,00096,000112,000128,000144,000160,000176,000192,000208,000224,000240,000
Additional Inspections
Inspect CV joint boots.XXXXX
Inspect front suspension, tie rod ends and replaceas necessary.XXX X X X X
Inspect brake linings, parking brake function. X X X X X X X
Additional Maintenance
Replace the cabin/air conditioning filter.XXX X X X X
Replace the engine air cleaner filter.XXXXX
Replace the spark plugs (1.4L Turbo Engine).**XXXXX
8
MAINTENANCE
SCHEDULES
624 MAINTENANCE SCHEDULES

Mileage Or Time Passed (Whichever Comes
First)20,00030,00040,00050,00060,00070,00080,00090,000100,000110,000120,000130,000140,000150,000
Or Years: 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Or Kilometers:
32,00048,00064,00080,00096,000112,000128,000144,000160,000176,000192,000208,000224,000240,000
Replace the spark plugs (2.0L and 2.4L Engine).**X
Flush and replace the engine coolant at 10 years or150,000 miles (240,000 km) whichever comes first.XX
Change the transmission fluid (manual, or 1.4Lturbo automatic) if using your vehicle for any of thefollowing: trailer towing, heavy loading, taxi, police,delivery service (commercial service), off-road, des-ert operation or more than 50% of your driving is atsustained speeds during hot weather, above 90°F(32°C).
XX X
8
MAINTENANCE
SCHEDULES
MAINTENANCE SCHEDULES 625

Mileage Or Time Passed (Whichever Comes
First)20,00030,00040,00050,00060,00070,00080,00090,000100,000110,000120,000130,000140,000150,000
Or Years: 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Or Kilometers:
32,00048,00064,00080,00096,000112,000128,000144,000160,000176,000192,000208,000224,000240,000
Change the automatic transmission fluid and filter(2.0L, 2.4L engines only) if you frequently drive: onrough or unpaved roads, on mountain roads, onshort trips, in heavy city traffic during hot weather,or while towing a trailer, or if you use the vehicle forpolice, taxi, or in a commercial fleet.
XX
Inspect and replace PCV valve if necessary.X
Replace the timing belt (1.4L Turbo Engine).X
** The spark plug change interval is mileage based only,
yearly intervals do not apply.
8
MAINTENANCE
SCHEDULES
626 MAINTENANCE SCHEDULES

WARNING!
•You can be badly injured working on or around a
motor vehicle. Do only service work for which you
have the knowledge and the right equipment. If
you have any doubt about your ability to perform a
service job, take your vehicle to a competent me-
chanic.
•Failure to properly inspect and maintain your ve-
hicle could result in a component malfunction and
effect vehicle handling and performance. This
could cause an accident.
8
MAINTENANCE
SCHEDULES
MAINTENANCE SCHEDULES 627
