License Lights
1. Remove the two screws securing the lens to the
liftgate.2. Rotate the socket 1/4 turn counterclockwise.
3. Pull bulb from socket.
MAINTAINING YOUR VEHICLE 333
7

Center High-Mounted Stoplight
1. Remove two screws securing stoplight housing assem-
bly to the liftgate.
2. Turn socket 1/4 counterclockwise and free from hous-
ing.3. Pull bulb straight from socket to remove.
334 MAINTAINING YOUR VEHICLE

Fog Lights
1. Rotate bulb and connector 1/4 turn counterclockwise.
2. Pull bulb off of connector.NOTE:For foglights ensure that the takeout push-
fasteners are relocated back in their positions; one in the
foglight molding and the other in the hydroform.
FLUIDS AND CAPACITIES
U.S. Metric
Fuel
3.7L/4.7L, 87 Octane 27 Gal. 102L
5.7L, 89 Octane 27 Gal 102L
Engine Oil (with filter)
3.7L, SAE 5W-30, API Certified 5 Qt. 4.7L
4.7L, SAE 5W-30, API Certified 6 Qt. 5.7L
5.7L, SAE 5W-30, API Certified 7 Qt. 6.6L
Cooling System (includes 2.1 Qts./2L for coolant
bottle
3.7L without Rear Heat (MopartAntifreeze/Coolant 5
Year/100,000 Mile Formula)13.5 Qt. 12.9L
MAINTAINING YOUR VEHICLE 335
7

Center High Mounted Stop Light............ 334
Certification Label....................... 250
Changing A Flat Tire..................... 272
Charging.............................. 280
Chart, Tire Sizing........................ 223
Child Restraint......................50,51,61
Child Restraint Tether Anchors.............54,60
Child Restraint with Automatic Belts........... 35
Child Seat.............................. 55
Circuit Breakers......................... 325
Climate Control......................... 179
Clock................................ 154
Compact Disc Maintenance................. 178
Compact Spare Tire...................... 234
Compass.............................. 124
Compass Calibration..................... 124
Compass Variance....................... 125
Computer, Trip/Travel.................... 120
Console, Floor.......................... 137Console, Overhead....................... 119
Contract, Service........................ 362
Converter, Catalytic...................... 249
Coolant............................... 310
Coolant Pressure Cap..................... 310
Cooling System......................... 306
Adding Coolant (Antifreeze).............. 309
Coolant Capacity...................... 335
Coolant Level......................... 310
Disposal of Used Coolant................ 308
Drain, Flush, and Refill.................. 308
Inspection........................... 306
Points to Remember.................... 311
Radiator Cap......................... 310
Selection of Coolant...............308,335,337
Temperature Gauge..................... 146
Cruise Control.......................... 116
Cup Holder............................ 138
Customer Assistance..................... 360
372 INDEX

Pretensioners.......................... 35
Reminder............................ 147
Seats................................. 86
Adjustment........................... 86
Heated.............................. 90
Lumbar Support........................ 88
Memory............................. 97
Reclining............................. 87
Security Alarm.......................24,149
Selection of Coolant...................... 337
Selection of Oil......................... 295
Sentry Key.............................. 9
Sentry Key Programming................... 11
Service and Maintenance.............292,340,341
Service Assistance....................... 360
Service Contract......................... 362
Service Manuals........................ 366
Setting the Clock........................ 155Shifting
Automatic Transmission................. 203
Transfer Case......................... 208
Transfer Case, Shifting into Transfer
Case Neutral (N)..................... 263
Transfer Case, Shifting out of Transfer
Case Neutral (N)..................... 265
Shoulder Belt Upper Anchorage.............. 34
Shoulder Belts........................... 29
Signals, Turn.....................108,146,329
Snow Chains........................... 239
Snow Plow............................ 261
Snow Tires............................ 240
Spare Tire..........................234,235
Spark Plugs............................ 297
Speed Control.......................... 116
Speedometer........................... 148
Starting............................... 200
Automatic Transmission................. 200
382 INDEX
