DODGE DURANGO 2004 2.G Owners Manual

4. Remove the three screws holding the bulb strip to the
back of the tail light lens.5. Remove the bulb strip from the tail light lens.
MAINTAINING YOUR VEHICLE 331
7

6. Remove bulbs from bulb strip by pulling the bulb
straight out.
332 MAINTAINING YOUR VEHICLE

License Lights
1. Remove the two screws securing the lens to the
liftgate.2. Rotate the socket 1/4 turn counterclockwise.
3. Pull bulb from socket.
MAINTAINING YOUR VEHICLE 333
7

Center High-Mounted Stoplight
1. Remove two screws securing stoplight housing assem-
bly to the liftgate.
2. Turn socket 1/4 counterclockwise and free from hous-
ing.3. Pull bulb straight from socket to remove.
334 MAINTAINING YOUR VEHICLE

Fog Lights
1. Rotate bulb and connector 1/4 turn counterclockwise.
2. Pull bulb off of connector.NOTE:For foglights ensure that the takeout push-
fasteners are relocated back in their positions; one in the
foglight molding and the other in the hydroform.
FLUIDS AND CAPACITIES
U.S. Metric
Fuel
3.7L/4.7L, 87 Octane 27 Gal. 102L
5.7L, 89 Octane 27 Gal 102L
Engine Oil (with filter)
3.7L, SAE 5W-30, API Certified 5 Qt. 4.7L
4.7L, SAE 5W-30, API Certified 6 Qt. 5.7L
5.7L, SAE 5W-30, API Certified 7 Qt. 6.6L
Cooling System (includes 2.1 Qts./2L for coolant
bottle
3.7L without Rear Heat (MopartAntifreeze/Coolant 5
Year/100,000 Mile Formula)13.5 Qt. 12.9L
MAINTAINING YOUR VEHICLE 335
7

U.S. Metric
3.7L with Rear Heat (MopartAntifreeze/Coolant 5
Year/100,000 Mile Formula)14.5 Qt. 13.8L
4.7L without Rear Heat (MopartAntifreeze/Coolant 5
Year/100,000 Mile Formula)13.1 Qt. 12.5L
4.7L with Rear Heat (MopartAntifreeze/Coolant 5
Year/100,000 Mile Formula)14.2 Qt. 13.5L
5.7L without Rear Heat (MopartAntifreeze/Coolant 5
Year/100,000 Mile Formula)NA NA
5.7L with Rear Heat (MopartAntifreeze/Coolant 5
Year/100,000 Mile Formula)16.6 Qt. 15.8L
NOTE:All fluid capacities are approximate capacities.
336 MAINTAINING YOUR VEHICLE

RECOMMENDED FLUIDS, LUBRICANTS AND
GENUINE PARTS
Engine
Component Fluids, Lubricants and Genuine Parts
Engine Coolant MopartAntifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid
Organic Additive Technology) P/N 5011764AB or equivalent.
Engine Oil Use SAE 5W-30, API Certified, meeting material standard MS-6395.
Engine Oil Filter MopartEngine Oil Filter, P/N 5281090 or equivalent.
Spark Plugs Refer to the Vehicle Emission Control Information label in the engine
compartment.
Fuel Selection 3.7L/4.7L 87 Octane, (R+M)/2 Method
Fuel Selection 5.7L 89 Octane, (R+M)/2 Method
MAINTAINING YOUR VEHICLE 337
7

Chassis
Component Fluids, Lubricants and Genuine Parts.
Automatic Transmission MopartATF+4, Automatic Transmission Fluid.
Transfer Case MopartATF+4, Automatic Transmission Fluid.
Front Axle SAE 75W-90 Multipurpose Type, GL-5 Gear Lubricant.
Rear Axle SAE 75W-140 Synthetic Gear Lubricant.
Brake Master Cylinder MopartDOT 3 and SAE J1703 should be used. If DOT 3 brake fluid is not
available, then DOT 4 is acceptable. Use only recommended brake fluids.
Power Steering Reservoir MopartATF+4, Automatic Transmission Fluid.
338 MAINTAINING YOUR VEHICLE

MAINTENANCE SCHEDULES
CONTENTS
mEmission Control System Maintenance........340
mEmissions Testing.......................340
mMaintenance Schedules...................341NSchedule ªBº........................343
NSchedule ªAº........................353
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

EMISSION CONTROL SYSTEM MAINTENANCE
The ªScheduledº maintenance services, listed inbold
typeon the following pages must be done at the times or
mileages specified to assure the continued proper func-
tioning of the emission control system. These, and all
other maintenance services included in this manual,
should be done to provide best vehicle performance and
reliability. More frequent maintenance may be needed for
vehicles in severe operating conditions such as dusty
areas and very short trip driving.
Inspection and service also should be done any time a
malfunction is suspected.
NOTE:Maintenance, replacement, or repair of the emis-
sion control devices and systems on your vehicle may be
performed by any automotive repair establishment or
individual using any automotive part which has been
certified pursuant to U.S. EPA or, in the State of Califor-
nia, California Air Resources Board regulations.
EMISSIONS TESTING
In some localities, it may be or will become a legal
requirement to ensure that all emissions components and
systems are functioning properly as a part of the test
procedure. The test center accomplishes this by checking
the On Board Diagnostic System (OBD) system with an
electronic scan tool. If your vehicle has recently been
serviced, the OBD system may have been reset to a9not
ready9condition because the OBD system has not had
sufficient time since the servicing to reconfirm that
emissions components are operating properly. In most
cases, a reasonable mix and amount of normal city and
highway driving and at least one overnight-off period
will be required to prepare your vehicle for this check;
however your dealer has the equipment and procedures
required to make certain that the OBD system of your
vehicle is ready for the required testing.
340 MAINTENANCE SCHEDULES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
