MAINTAINING YOUR VEHICLE
CONTENTS
mEngine Compartment 3.7L V6..............286
mEngine Compartment 4.7L V-8..............287
mEngine Compartment 5.7L HEMI V-8.........288
mOnboard Diagnostic System Ð OBD II........289
mEmissions Inspection And Maintenance
Programs............................290
mReplacement Parts......................291
mDealer Service.........................291
mMaintenance Procedures..................292NEngine Oil..........................292
NEngine Oil Filter......................297
NDrive Belts Ð Check Condition And Tension . . 297
NSpark Plugs.........................297
NIgnition Cables.......................298
NEngine Air Cleaner Filter................298
NEngine Fuel Filter.....................299
NCatalytic Converter....................299
NMaintenance-Free Battery................300
7

governmental agency for advice on how and where used
oil and oil filters can be safely discarded in your area.
Engine Oil Filter
The engine oil filter should be replaced at every engine
oil change.
Engine Oil Filter Selection
The manufacturer's engines have a full-flow type oil
filter. Use a filter of this type for replacement. The quality
of replacement filters varies considerably. Only high
quality filters should be used to assure most efficient
service. MopartEngine Oil Filters are a high quality oil
filter and are recommended.
Drive Belts Ð Check Condition and Tension
At the mileage indicated in the maintenance schedule, all
belts should be checked for condition and proper tension.
Improper belt tension can cause belt slippage and failure.Belts should be inspected for evidence of cuts, cracks, or
glazing, and replaced if there is indication of damage
which could result in belt failure. If adjustment is re-
quired, see your authorized dealer for service. Low
generator belt tension can cause battery failure. A special
tool is required to properly measure tension and to
restore belt tension to factory specifications.
Also check belt routing to make sure there is no interfer-
ence between the belts and other engine components.
Spark Plugs
Spark plugs must fire properly to assure proper engine
performance and emission control. The plugs installed in
your vehicle should operate satisfactorily in normal
service for the mileage indicated in the Maintenance
Chart. New plugs should be installed at this mileage. The
entire set should be replaced if there is any malfunction
MAINTAINING YOUR VEHICLE 297
7

due to a faulty spark plug. Check the Vehicle Emissions
Control Information label for the proper type of spark
plug for your vehicle.
CAUTION!
When replacing plugs, do not overtighten. You could
damage them and cause them to leak.
Ignition Cables
Replace the ignition cables (5.7L engines only) at the
mileage interval shown in the maintenance charts.
Engine Air Cleaner Filter
Under normal driving conditions, replace the air filter at
the intervals shown on Schedule ªAº. If, however, youdrive the vehicle frequently under dusty or severe con-
ditions, the filter element should be inspected periodi-
cally and replaced if necessary at the intervals shown on
Schedule ªBº.
WARNING!
The air cleaner can provide a measure of protection
in the case of engine backfire. Do not remove the air
cleaner unless such removal is necessary for repair or
maintenance. Make sure that no one is near the
engine compartment before starting the vehicle with
the air cleaner removed. Failure to do so can result in
serious personal injury.
298 MAINTAINING YOUR VEHICLE

Miles 18,000 21,000 24,000 27,000 30,000
(Kilometers) (29 000) (34 000) (38 000) (43 000) (48 000)
Change engine oil and engine oil filter. X X X X X
Rotate tires. X X X
Change rear axle fluid.X
Change front axle fluid (4X4).X
Check transfer case fluid level (4X4).X
Inspect brake linings. X
Inspect engine air cleaner filter, replace if neces-
sary.X
Replace spark plugs.X
Inspect PCV valve, replace as necessary.*X
Drain and refill automatic transmission fluid and
change main sump filter (4.7L/5.7L only).X
SCHEDULE ªBº 345
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 48,000 51,000 54,000 57,000 60,000
(Kilometers) (77 000) (82 000) (86 000) (91 000) (96 000)
Change engine oil and engine oil filter. X X X X X
Rotate tires. X X X
Change rear axle fluid.X
Change front axle fluid (4X4).X
Inspect brake linings. X
Inspect engine air cleaner filter, replace if necessary.X
Replace spark plugs.X
Inspect PCV valve, replace as necessary.*X
Inspect and replace ignition cables if necessary (5.7L only).X
Inspect auto tension drive belt and replace if required. X
Drain and refill automatic transmission fluid, change filter
(3.7L). This applies only if your vehicle is used for police,
taxi, fleet, or trailer towing.X
Drain and refill automatic transmission fluid and change
main sump filter (4.7L/5.7L only).X
Inspect transfer case fluid (4X4).X
SCHEDULE ªBº 347
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 78,000 81,000 84,000 87,000 90,000
(Kilometers ) (125 000) (130 000) (134 000) (139 000) (144 000)
Change engine oil and engine oil filter. X X X X X
Rotate tires. X X X
Change rear axle fluid.X
Change front axle fluid (4X4).X
Check transfer case fluid level (4X4).X
Inspect brake linings.X
Inspect engine air cleaner filter, replace if neces-
sary.X
Replace spark plugs.X
Inspect PCV valve, replace as necessary.*X
Inspect auto tension drive belt and replace if re-
quired.X
Drain and refill automatic transmission fluid and
change main sump and cooler return filter (if
equipped) (4.7L/5.7L only).X
SCHEDULE ªBº 349
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 105,000 108,000 111,000 114,000 117,000 120,000
(Kilometers) (168 000) (173 000) (178 000) (182 000) (187 000) (192 000)
Change engine oil and engine oil filter. X XXXXX
Rotate tires. X X X
Change rear axle fluid. X X
Change front axle fluid (4X4). X X
Inspect brake linings. X
Inspect engine air cleaner filter, replace if
necessary.XX
Replace spark plugs.X
Inspect and replace ignition cables if neces-
sary (5.7L only).X
Inspect PCV valve, replace as necessary.*X
Inspect auto tension drive belt and replace if
required.³XX
Drain and refill transfer case fluid (4X4). X
SCHEDULE ªBº 351
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Schedule ªAº
Miles 6,000 12,000 18,000 24,000 30,000
(Kilometers) (10 000) (19 000) (29 000) (38 000) (48 000)
[Months] [6] [12] [18] [24] [30]
Change engine oil and engine oil filter. X X X X X
Rotate tires. X X X X X
Check transfer case fluid level (4X4).X
Inspect brake linings. X
Replace engine air cleaner filter.X
Replace spark plugs.X
SCHEDULE ªAº 353
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 36,000 42,000 48,000 54000 60,000 66,000
(Kilometers) (58 000) (67 000) (77 000) (84 000) (96 000) (106 000)
[Months] [36] [42] [48] [54] [60] [66]
Change engine oil and engine oil filter. X XXXXX
Rotate tires. X XXXXX
Check transfer case fluid level (4X4). X
Flush and replace engine coolant at 60
months, regardless of mileage.X
Inspect brake linings. X X
Replace engine air cleaner filter.X
Replace spark plugs.X
Inspect PCV valve, replace as necessary. *X
Inspect and replace ignition cables if
necessary (5.7L only).X
Inspect auto tension drive belt and replace if
required.X
354 SCHEDULE ªAº
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 72,000 78,000 84,000 90,000 96,000 100,000
(Kilometers) (115 000) (125 000) (134 000) (144 000) (154 000) (160 000)
[Months] [72] [78] [84] [90] [96]
Change engine oil and engine oil filter. X X X X X
Rotate tires. X X X X X X
Check transfer case fluid level (4X4). X
Inspect brake linings. X X
Replace engine air cleaner filter.X
Replace spark plugs.X
Inspect PCV valve, replace as necessary.*X
Inspect auto tension drive belt and replace if
required.³X
Drain and refill automatic transmission fluid
and change sump and cooler return filter (if
equipped) (4.7L/5.7L only).X
SCHEDULE ªAº 355
