traction control DODGE DURANGO 2007 2.G User Guide

conditions and more wheel spin than ESP would nor-
mally allow is required to gain traction. TSC (Trailer
Sway Control) is not available when the system is in the
Partial Offmode. To turn ESP on again, momentarily
depress the “ESP-Control OFF” Control Switch. This will
restore the normal “ON” mode of operation. ESP always
operates under braking, even with the switch in the
OFF-position.
WARNING!
In the Partial Off mode, the engine torque reduction
and stability features are desensitized. Therefore,
the enhanced vehicle stability offered by ESP is
unavailable.
NOTE:To improve the vehicle’s traction when driving
with snow chains, or starting off in deep snow, sand or
gravel, it may be desirable to switch to the “Partial Off”mode by pressing the ESP Control Switch. Once the
situation requiring ESP to be switched to the “Partial Off”
mode is overcome, turn ESP on by momentarily depress-
ing the “ESP Control Switch”. This may be done with the
vehicle is in motion.
4WD LOW Range
Partial Off
This is the normal operating mode for ESP in 4WD LOW.
Whenever the vehicle is started in 4WD LOW or the
transfer case (if equipped) is shifted from 4WD LOCK or
neutral to 4WD LOW, the ESP system will be in this
mode. In 4WD LOW, ESP function is desensitized until
the vehicle reaches a speed of 30 mph (48 km/h). At 30
mph (48 km/h) the normal ESP stability function returns
and the ESP/TCS Indicator Light” turns off. When the
vehicle speed drops below 25 mph (40 km/h) the ESP
system goes back to Partial Off. ESP is desensitized at low
vehicle speeds in 4WD LOW so that it will not interfere
STARTING AND OPERATING 281
5

DEPARTMENT OF TRANSPORTATION UNIFORM
TIRE QUALITY GRADES
The following describes the tire grading categories estab-
lished by the National highway Traffic Safety Adminis-
tration. The specific grade rating assigned by the tire’s
manufacturer in each category is shown on the sidewall
of the tires on your car.
All Passenger Car Tires Must Conform to Federal Safety
Requirements in Addition to These Grades.
Treadwear
The treadwear grade is a comparative rating based on the
wear rate of the tire when tested under controlled con-
ditions on a specified government test course. For ex-
ample, a tire graded 150 would wear one and a half (1
1/2) times as well on the government course as a tire
graded 100. The relative performance of tires depends
upon the actual conditions of their use, however, andmay depart significantly from the norm due to variations
in driving habits, service practices and differences in road
characteristics and climate.
Traction Grades
The traction grades, from highest to lowest, are AA, A, B,
and C. Those grades represent the tire’s ability to stop on
wet pavement as measured under controlled conditions
on specified government test surfaces of asphalt and
concrete. A tire marked C may have poor traction perfor-
mance.
WARNING!
The traction grade assigned to this tire is based on
straight-ahead braking traction tests, and does not
include acceleration, cornering, hydroplaning, or
peak traction characteristics.
454 IF YOU NEED CONSUMER ASSISTANCE

Traction Control....................... 279
Turn Signal........................135,409
Warning (Instrument Cluster Description)..... 185
Loading Vehicle......................... 320
Tires ............................... 289
Locks................................. 27
Automatic Door........................ 28
Child Protection........................ 30
Door................................ 27
Ignition.............................. 13
Keys................................ 12
Power Door........................... 28
Steering Wheel......................... 13
Lower Anchors and Tether for CHildren
(LATCH).............................. 65
Lubricating Oil......................... 392
Lubrication, Body....................... 378
Lug Nuts............................. 350
Luggage Carrier......................... 175Lumbar Support........................ 110
Maintenance Free Battery.................. 374
Maintenance Procedures................... 366
Maintenance Schedule.................... 422
Schedule “A”......................... 440
Schedule “B”......................... 425
Malfunction Indicator Light (Check Engine) . . 192,364
Manual, Service......................... 452
Manual Transmission
Lubricant Selection..................... 419
Map/Reading Lights..................... 151
Memory Seat........................... 124
Mirrors ................................ 79
Automatic Dimming................... 80,83
Electric Powered....................... 81
Heated.............................. 83
Memory............................. 124
Outside.............................. 81
INDEX 467
10

Tire Safety Information.................... 284
Tires ............................ 73,293,454
Aging(LifeofTires) .................... 300
Air Pressure.......................... 293
Alignment........................... 302
Chains.............................. 303
Changing............................ 346
Compact Spare........................ 297
General Information.................... 293
High Speed.......................... 296
Inflation Pressures..................... 294
Jacking............................. 347
LifeofTires .......................... 300
Load Capacity.....................289,290
Pressure Monitor System (TPMS)........... 306
Pressure Warning Light.................. 193
Quality Grading....................... 454
Radial.............................. 297
Replacement......................... 301Rotation............................. 305
Safety...........................284,293
Sizes ............................... 286
Snow Tires........................... 304
Spare Tire........................... 346
Spinning ............................ 299
Tread Wear Indicators................... 300
Wheel Mounting....................... 347
Wheel Nut Torque..................... 350
Tongue Weight/Trailer Weight.............. 329
Torque Converter Clutch.................. 258
Tow Hooks, Emergency................... 355
Towing ............................... 323
Disabled Vehicle....................... 356
Guide .............................. 329
Recreational.......................... 337
Weight .............................. 329
Traction .............................. 268
Traction Control......................190,277
INDEX 473
10
