FLOOR CONSOLE
Floor Console Features
The Floor Console between the driver's and front pas-
senger's seat, has the following features:
²Miscellaneous storage compartments
²Flexible cup holder inserts
²Portable phone storage bin
²Portable phone cord routing between lid and base on
forward edge
²12 Volt reconfigurable power outlet inside storage
compartment
²Side open armrest lid
²Tissue holder & pen holder
²Coin slots
²Removable CD binThe coin slots are located under the instrument panel
center stack.
Cup Holders
Your vehicle has 8 cupholders. Four are located in the
center console, two are located in the second row armrest,
and two are located in the left hand quarter panel for
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 181
3
Page 182 of 481

third row occupants. The four cupholders located in the
center console may be removed for cleaning.
Power Outlet and Portable Phone Storage
The console is equipped with a power outlet, portable
phone storage bin, and phone cord routing. The phone
storage bin can be used when easy access to the phone is
needed. Also, the power outlet inside the console com-
partment can be used to power up the phone while it is
being stored in the bin. To use, plug in the portable power
recharge cord and place the cord along the opening
under the forward portion of the storage bin. Close the
console armrest lid and plug the power cord into the
phone while resting the phone in the bin. The power
outlet may be used for any portable item with a standard
12 volt power outlet adaptor, requiring up to 20 Amps of
current.
Rear Floor Console Features ± If Equipped
The Rear Floor Console located between the second row
bucket seat, has the following features:
²Miscellaneous storage compartments
²Cup holders
²Portable phone cord routing on the sides of the console
lid and the base.
²12 Volt power outlet inside storage compartment
²Tissue holder & pen holder
²Second row heated seat switches (if equipped).
182 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 183 of 481

To access the storage bin, lift up on the console door latch.
FACTORY INSTALLED ROOF LUGGAGE RACK
The load carried on the roof when equipped with a
luggage rack must not exceed 68 kg (150 lbs.), and should
be uniformly distributed over the cargo area.
Rear Floor Console
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 183
3
Page 184 of 481

The side rails between the stantions should be used to tie
down cargo. Check the straps frequently to be sure that
the load remains securely attached.
NOTE:Crossbars are offered by Mopartaccessories.
External racks do not increase the total load carrying
capacity of the vehicle. Be sure that the total occupant
and luggage load inside the vehicle, plus the load on the
luggage rack, do not exceed the maximum vehicle load
capacity.CAUTION!
To avoid damage to the roof rack and vehicle, do not
exceed the maximum roof rack load capacity. Always
distribute heavy loads as evenly as possible and
secure the load appropriately.
Long loads which extend over the windshield, such
as wood panels or surfboards, should be secured to
both the front and rear of the vehicle.
Place a blanket or other protection between the
surface of the roof and the load.
Travel at reduced speeds and turn corners carefully
when carrying large or heavy loads on the roof rack.
Wind forces, due to natural causes or nearby truck
traffic, can add sudden upward loads. This is espe-
cially true on large flat loads and may result in
damage to the cargo or your vehicle.
184 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 185 of 481

WARNING!
Cargo must be securely tied before driving your
vehicle. Improperly secured loads can fly off the
vehicle, particularly at high speeds, resulting in per-
sonal injury or property damage. Follow the roof rack
Cautions when carrying cargo on your roof rack.
CARGO MANAGEMENT SYSTEMÐIF EQUIPPED
The cargo management system consists of a removable
cargo liner and removable cargo organizer.
1 - Side Cover Latch
2 - Main Cover Latch
3 - Cargo Divider HandlesUNDERSTANDING THE FEATURES OF YOUR VEHICLE 185
3
Page 186 of 481

To open the side cover, pull on the cover latch, and attach
the cord to the upper cargo net hook.
To open the main cover, pull up on the latch, and attach
the cord to the rear seat head restraint post.
To open the Cargo divider, lift up on the cargo divider
handles, raising the doors to the full open position. Raise
the side panels until they engage into the doors.To remove the cargo management system from the ve-
hicle, pull the right hand side of the organizer towards
you so that the right pin slides out of the slot in the
vehicle. Push the organizer to the right and lift out of the
vehicle.
1 - Cargo Divider Door
2 - Cargo Divider Side Panel 186 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
