remote start DODGE DURANGO 2008 2.G User Guide

Resetting the Auto-Up Feature
Should the Auto-Up feature stop working the window
probably needs to be reset. To reset Auto-Up:
Pull the window switch up and close the window com-
pletely, then pull and hold the switch for 1 second.
Window Lockout Switch
The window lockout switch on the driver's door allows
you to disable the window control on the other doors. To
disable the window controls on the other doors, press the
window lock button. To enable the window controls,
press the window control button again.
LIFTGATE
The liftgate can be unlocked using the remote keyless
entry transmitter or by activating the power door lock
switches located on the front doors.
Window Lockout Switch
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35
2

NOTE:When the engine is running from a Remote Start
(if equipped), the vehicle must first be unlocked by
pressing the remote transmitter UNLOCK button prior to
activating the Power Liftgate otherwise the engine will
stop automatically.Once unlocked, the liftgate can be opened or closed. To
open the liftgate, pull the exterior handle and open the
liftgate with one fluid motion.
The liftgate will not manually open if the vehicle is in
gear or the vehicle speed is above 0 mph (0 km/h).
NOTE:If the liftgate is locked and is not equipped with
a powered liftgate, pressing the button on the remote
keyless entry transmitter will result in the liftgate becom-
ing unlocked for 30 seconds allowing you to manually
access the liftgate area. The liftgate will re-lock automati-
cally within 10 seconds once the liftgate is closed.
Power Liftgate Ð If Equipped
The power liftgate may be opened manually or by using
the button on the remote keyless entry transmitter. Press
the button on the remote keyless entry transmitter twice
within five seconds, to open the power liftgate. Once the
liftgate is fully open, pressing the button twice within
five seconds a second time will close the liftgate.
Power Liftgate Button
36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

When the remote keyless entry transmitter button is
pressed two times and the ªLamp Flashº feature is
enabled the turn signals will flash twice to signal that the
liftgate is opening or closing.
The power liftgate may also be opened by pressing the
switch located on the overhead console.WARNING!
During power operation, personal injury or cargo
damage may occur. Ensure the liftgate travel path is
clear. Make sure the liftgate is closed and latched
before driving away.
A beeping signal will sound two seconds before the
liftgate starts to open or close.
NOTE:
²If anything obstructs the power liftgate while it is
closing or opening, the liftgate will automatically
reverse to the closed or open position, provided it
meets sufficient resistance.
²There are also pinch sensors attached to the side of the
liftgate. Light pressure anywhere along these strips
will cause the liftgate to return to the open position.
Power Liftgate Switch
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37
2

²The power liftgate must be in the full open position in
order to power close. If the liftgate is not fully open,
press the remote keyless entry transmitter or overhead
console button to fully open the liftgate and then press
again to close.
²If the liftgate handle is pulled while the power liftgate
is closing, the liftgate will reverse to the full open
position.
²If the liftgate handle is pulled while the power liftgate
is opening, the liftgate motor will disengage to allow
manual operation.
²The power liftgate buttons will not operate if the
vehicle is in gear or the vehicle speed is above 0 mph
(0 km/h).
²The power liftgate will not operate in temperatures
below222ÉF(230É C) or temperatures above 150É F
(65É C). Be sure to remove any buildup of snow or ice
from the liftgate before pressing any of the power
liftgate switches.
²If the power liftgate encounters multiple obstructions
within the same cycle, the system will automatically
stop and must be opened or closed manually.
²If your liftgate is power closing and you put the
vehicle in gear, the liftgate will continue to power
close. However, vehicle movement may result in a
detection of an obstruction.
38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WARNING!
²Relying on the airbags alone could lead to more
severe injuries in a collision. The airbags work
with your seat belt to restrain you properly. In
some collisions the airbags won't deploy at all.
Always wear your seat belts even though you have
airbags.
²Being too close to the steering wheel or instrument
panel during airbag deployment could cause seri-
ous injury. Airbags need room to inflate. Sit back,
comfortably extending your arms to reach the
steering wheel or instrument panel.
²If the vehicle has window bags, they also need
room to inflate. Do not lean against the door or
window. Sit upright in the center of the seat.
Air Bag System Components
The airbag system consists of the following:
²Occupant Restraint Controller
²Side Remote Acceleration Sensors
²Airbag Warning Light
²Driver Airbag
²Passenger Airbag
²Window Bags above Side Windows
²Steering Wheel and Column
²Instrument Panel
²Interconnecting Wiring
²Knee Impact Bolsters
²Front Acceleration Sensors
²Driver and Front Passenger Seat Belt Pretensioners
56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

If the rear wiper is operating when the ignition is turned
off, the wiper will automatically return to the ªParkº
position. When the vehicle is restarted, the wiper will
resume operation.
Rear Window Defrosting
A push-button type switch is located in the climate
control panel. Press the switch and the rear win-
dow defroster and electric remote control heated mirrors
(if equipped) will turn On. An amber indicator on the
push-button will light when the defroster is turned On.
An symbol will be displayed when the defroster is turned
on with an ATC control. Push again to turn Off prior to
time-out. The defroster will automatically turn Off after
fifteen minutes. For ten more minutes of operation, push
the button again. To prevent excessive battery drain, use
the defroster only when the engine is operating.
CAUTION!
Use care when washing the inside of the rear window
to prevent damage to heating elements. Use a soft
cloth and a mild washing solution, wiping parallel to
the heating elements. Also, keep all objects a safe
distance from the window to prevent damaging the
heating elements.
INSTRUMENT PANEL AND CONTROLS 267
4

Fuses (Power Distribution Center)
Your vehicle is equipped with an electrical power distri-
bution center located in the left side of the engine
compartment.
This center contains cartridge fuses, mini fuses and
relays. A description of each fuse and component may bestamped on the inside cover otherwise the cavity number
of each fuse is stamped on the inside cover that corre-
sponds to the following chart. These fuses and relays can
be obtained from your dealer.
CavityCartridge
Fuse /
RelayMini
FuseDescription
1 30 Amp
PinkStarter
2 30 Amp
PinkFront Wiper
3 40 Amp
GreenBrake Batt
4 30 Amp
PinkJB Feed Acc # 2
5 40 Amp
GreenPower Seats
6 30 Amp
PinkRun Remote Relay
Feed
Power Distribution Center
424 MAINTAINING YOUR VEHICLE

CavityCartridge
Fuse /
RelayMini
FuseDescription
23 20 Amp
YellowTrailer Tow
24 15 Amp
BlueA/C Clutch
25 15 Amp
BlueStop Lamp Switch
26 Spare
27 20 Amp
YellowRun/Start Relay
Feed
28 Spare
29 Relay Run Start
30 Relay Run Remote
31 SpareCavityCartridge
Fuse /
RelayMini
FuseDescription
32 Relay Starter
33 Relay Electronic Auto-
matic Transaxle
(EATX)
34 Relay AC Clutch
35 Relay Fuel Pump Rly
36 Spare
37 Relay Stop Lamp Switch
38 Spare
39 Relay Blower Motor
40 Relay Auto Shut Down
(ASD) Rly
426 MAINTAINING YOUR VEHICLE

Driving
Through Flowing, Rising, or Shallow Standing
Water.............................. 288
DVD Player (Video Entertainment System)...... 244
E-85 Fuel............................. 339
Electric Remote Mirrors.................... 85
Electrical Power Outlets................... 177
Electronic Brake Control System............. 295
Anti-Lock Brake System................. 295
Brake Assist System.................... 296
Electronic Roll Mitigation................ 298
Electronic Stability Program............... 299
Traction Control System................. 298
Electronic Roll Mitigation (ERM)............. 298
Electronic Speed Control (Cruise Control)...... 149
Electronic Stability Program (ESP).........200,299
Electronic Vehicle Information Center
(EVIC).............................156,159Emergency, In Case of
Freeing Vehicle When Stuck............... 377
Jacking............................. 370
Tow Hooks.......................... 377
Towing............................. 378
Emission Control System Maintenance......... 444
Emission Related Components.............. 409
Engine
Air Cleaner.......................... 395
Block Heater......................... 276
Break-In Recommendations................ 74
Compartment......................385,386
Coolant (Antifreeze).................... 440
Exhaust Gas Caution................39,75,336
Fails to Start.......................... 274
Flooded, Starting...................... 274
Fuel Requirements..................... 439
Jump Starting......................... 375
Multi-Displacement..................... 304
466 INDEX

Recreational Towing...................... 360
Shifting into Transfer Case Neutral (N)....... 361
Shifting out of Transfer Case Neutral (N)..... 363
Reformulated Gasoline.................... 333
Refrigerant............................ 400
Release, Hood.......................... 135
Reminder, Seat Belt....................... 50
Remote Keyless Entry (RKE)................. 20
Remote Sound System (Radio) Controls........ 249
Remote Starting System.................... 27
Replacement Keys........................ 15
Replacement Parts....................... 390
Replacement Tires....................... 320
Reporting Safety Defects................... 456
Resetting Oil Change Indicator...........162,197
Restraints, Child.......................64,70
Restraints, Occupant...................... 39
Rocking Vehicle When Stuck................ 377
Roll Over Warning........................ 4Roof Type Carrier....................... 183
Rotation, Tires.......................... 324
Safety Checks Inside Vehicle................. 76
Safety Checks Outside Vehicle............... 77
Safety Defects, Reporting.................. 456
Safety, Exhaust Gas....................... 39
Safety Information, Tire................... 305
Safety Tips............................. 75
Satellite Radio...............206,207,236,237,244
Satellite Radio Antenna................... 248
Schedule, Maintenance.................... 444
Seat Belt Maintenance.................... 419
Seat Belt Reminder....................... 50
Seat Belts..........................39,40,76
And Pregnant Women................... 52
Child Restraint.......................64,65
Extender............................. 52
Front Seat............................ 40
INDEX 475
