Remove the spare tire before attempting to jack the truck.
1. Remove the rubber plug from the floor in the cargo
area.2. Engage the jack wrench extension to the spare tire
winch through the hole in the floor.
3. Turn the wrench counterclockwise to lower the spare
tire. Continue to turn the wrench until the spare tire can
be pulled out from under the vehicle.
It is recommended that you stow the flat or spare to
avoid tangling the loose cable.
CAUTION!
The winch mechanism is designed for use with the
jack extension tube only. Use of an air wrench or
other power tools is not recommended and can dam-
age the winch.
WHAT TO DO IN EMERGENCIES 369
6

²Block both the front and rear
of the wheel diagonally oppo-
site the jacking position. For
example, if the right front
wheel is being changed, block
the left rear wheel.
²Passengers should not remain in the vehicle when the
vehicle is being jacked.
Instructions
1. Remove the spare wheel, jack, and tools from storage.
2. Using the wheel wrench, loosen, but do not remove,
the wheel nuts by turning them counterclockwise one
turn while the wheel is still on the ground.
3. When changing a front wheel, place the jack under the
frame rail behind the wheel. Locate the jack as farforward as possible on the straight part of the frame
(prior to inboard transition. Operate the jack using the
jack drive tube and the wheel wrench - the tube exten-
sion, may be used but is not required.
Front Jacking Location
WHAT TO DO IN EMERGENCIES 371
6

When changing a rear wheel, assemble the jack drive
tube to the jack and connect the drive tube to the
extension tube. Place the jack under the axle as close to
the tire as posssible with the drive tubes extending to the
rear. Connect the jack tube extension and wheel wrench.
Before raising the wheel off the ground, make sure that
the jack will not damage surrounding truck parts and
adjust the jack position as required.
4. By rotating the wheel wrench clockwise, raise the
vehicle until the wheel just clears the surface.
Rear Left Jacking Location
Rear Right Jacking Location
372 WHAT TO DO IN EMERGENCIES

License Lights
1. Remove the two screws securing the lens to the
liftgate.2. Rotate the socket 1/4 turn counterclockwise.
3. Pull bulb from socket.
436 MAINTAINING YOUR VEHICLE

Center High-Mounted Stoplight
1. Remove two screws securing stoplight housing assem-
bly to the liftgate.2. Turn socket 1/4 counterclockwise and free from hous-
ing.
3. Pull bulb straight from socket to remove.
MAINTAINING YOUR VEHICLE 437
7

Fog Lights
To replace the left foglamp bulb:
1. Remove the three wheel liner screws.2. Remove the remove the far left air dam screw at the
bottom of the fascia.
3. Peel back the liner and access the foglamp.
4. Rotate the socket and connector 1/4 turn counter-
clockwise and pull straight reward to disengage from the
lamp.
5. Remove the bulb from the socket and replace.
The right foglamp can be accessed from below the
vehicle. Follow the previous steps 4 and 5 of the left
foglamp to replace the bulb.
NOTE:These are Halogen bulbs. Take care not to touch
the bulb with your fingers. Body oils from your fingers
could cause excessive heat build-up, which reduces bulb
life.
438 MAINTAINING YOUR VEHICLE
