Once the driver ’s side crossbar is in place, tighten the
thumb screws completely.
Repeat the procedure to stow the second crossbar on the
opposite side.NOTE:
•
To help control wind noise, stow the crossbars in the side
rails when they are not in use.
• If any metallic object is placed over the satellite radio
antenna (if equipped), you may experience interruption
of satellite radio reception.
Tightening Crossbar
Stowed Crossbars
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 229

WARNING!
Cargo must be securely tied before driving your ve-
hicle. Improperly secured loads can fly off the vehicle,
particularly at high speeds, resulting in personal injury
or property damage. Follow the roof rack cautions
when carrying cargo on your roof rack.
CAUTION!
•To prevent damage to the roof of your vehicle, DO
NOT carry any loads on the roof rack without the
crossbars deployed. The load should be secured and
placed on top of the crossbars, not directly on the
roof. If it is necessary to place the load on the roof,
place a blanket or other protective layer between the
load and the roof surface.
• To avoid damage to the roof rack and vehicle, do not
exceed the maximum roof rack load capacity of 150 lb
(68 kg). Always distribute heavy loads as evenly as
possible and secure the load appropriately.
(Continued)
CAUTION! (Continued)
•Load should always be secured to cross bars first,
with tie down loops used as additional securing
points if needed. Tie loops are intended as supple-
mentary tie down points only. Do not use ratcheting
mechanisms with the tie loops. Check the straps and
thumb wheels frequently to be sure that the load
remains securely attached.
• Long loads that extend over the windshield, such as
wood panels or surfboards, or loads with large
frontal area should be secured to both the front and
rear of the vehicle.
• Travel at reduced speeds and turn corners carefully
when carrying large or heavy loads on the roof rack.
Wind forces, due to natural causes or nearby truck
traffic, can add sudden upward lift to a load. This is
especially true on large flat loads and may result in
damage to the cargo or your vehicle.
230 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

UNDERSTANDING YOUR INSTRUMENT PANEL
CONTENTS
INSTRUMENT PANEL FEATURES ...........234
 INSTRUMENT CLUSTER ..................235
 WARNING AND INDICATOR LIGHTS ........237
▫ Red Telltale Indicator Lights ...............238
▫ Yellow Telltale Indicator Lights .............245
▫ Green Telltale Indicator Lights ..............254
▫ White Telltale Indicator Lights ..............257
▫ Blue Telltale Indicator Lights ...............258
 INSTRUMENT CLUSTER DISPLAY ...........259
▫ Instrument Cluster Display Location
And Controls ........................ .259
▫ Engine Oil Life Reset ....................262
▫ Instrument Cluster Display Messages ........263
▫ Instrument Cluster Display Selectable
Menu Items .......................... .264▫
Screen Setup Driver Selectable Items .........268
▫ Battery Saver On/Battery Saver Mode
Message — Electrical Load Reduction Actions —
If Equipped ......................... .269
 CYBERSECURITY ....................... .271
 UCONNECT SETTINGS ...................273
▫ Buttons On The Faceplate .................273
▫ Buttons On The Touchscreen ...............274
▫ Customer Programmable Features —
Uconnect 5.0 Personal Settings ..............274
▫ Customer Programmable Features —
Uconnect 8.4 Personal Settings ..............293
 UCONNECT RADIOS — IF EQUIPPED ........314
 IPOD/USB/MP3 CONTROL — IF EQUIPPED . . .314
▫ Connecting The iPod Or External USB Device . . .3144

▫Using This Feature ..................... .315
▫ Second Row USB Charging Port ............315
 UCONNECT REAR SEAT ENTERTAINMENT (RSE)
SYSTEM — IF EQUIPPED .................316
▫ Getting Started ....................... .316
▫ Dual Video Screen ..................... .318
▫ Blu-ray Disc Player ..................... .318
▫ Play Video Games ..................... .320
▫ Play A DVD/Blu-ray Disc Using The
Touchscreen Radio ..................... .321
▫ Important Notes For Dual Video Screen
System ............................. .323
▫ Blu-ray Disc Player Remote Control —
If Equipped .......................... .323
▫ Replacing The Remote Control Batteries .......325
▫ Headphones Operation ...................325
▫ Controls ............................ .325
▫ Replacing The Headphone Batteries ..........326▫
Unwired Stereo Headphone Lifetime Limited
Warranty ............................ .326
 STEERING WHEEL AUDIO CONTROLS —
IF EQUIPPED ......................... .332
▫ Radio Operation ....................... .333
▫ CD Player ........................... .333
 CD/DVD/BLU-RAY DISC MAINTENANCE . . . .333
 RADIO OPERATION AND MOBILE PHONES . . .334
▫ Regulatory And Safety Information ..........334
 CLIMATE CONTROLS ...................336
▫ Overview ........................... .336
▫ Automatic Temperature Control (ATC) —
If Equipped ......................... .346
▫ Operating Tips ....................... .350
 PERSONALIZED

MENU BAR...............353
 UCONNECT VOICE RECOGNITION
QUICK TIPS .......................... .354
▫ Introducing Uconnect ....................354
232 UNDERSTANDING YOUR INSTRUMENT PANEL

▫Get Started .......................... .355
▫ Basic Voice Commands ...................356
▫ Radio .............................. .356
▫ Media .............................. .357
▫ Phone .............................. .358
▫ Voice Text Reply ...................... .359
▫ Climate (8.4/8.4 NAV) ...................361
▫ Navigation (8.4 /8.4 NAV) ................362
▫ Uconnect Access (8.4/8.4 NAV) .............363
▫ Register (8.4/8.4 NAV) ...................364 ▫
Vehicle Health Alert ....................364
▫ Mobile App (8.4/8.4 NAV) ................365
▫ Voice Texting (8.4/8.4 NAV) ...............366
▫ Yelp (8.4/8.4 NAV) ..................... .367
▫ SiriusXM Travel Link (8.4/8.4 NAV) ..........368
▫ Siri Eyes Free — If Equipped ..............369
▫ Do Not Disturb ....................... .372
▫ General Information .....................373
▫ Additional Information ...................373
4
UNDERSTANDING YOUR INSTRUMENT PANEL 233

INSTRUMENT PANEL FEATURES
Instrument Panel
1 — Air Outlet6 — Lower Switch Bank
2 — Instrument Cluster 7 — Hazard Switch
3 — Radio 8 — Ignition Start/Stop Button
4 — Glove Compartment 9 — Dimmer Switch
5 — Climate Controls 10 — Headlight Switch
234 UNDERSTANDING YOUR INSTRUMENT PANEL

INSTRUMENT CLUSTER
Instrument Cluster
4
UNDERSTANDING YOUR INSTRUMENT PANEL 235

1. Tachometer•Indicates the engine speed in revolutions per minute
(RPM x 1000).
2. Speedometer •Indicates vehicle speed.
3. Temperature Gauge •
The temperature gauge shows engine coolant tempera-
ture. Any reading within the normal range indicates that
the engine cooling system is operating satisfactorily.
• The gauge pointer will likely indicate a higher tem-
perature when driving in hot weather, up mountain
grades, or when towing a trailer. It should not be
allowed to exceed the upper limits of the normal
operating range.
CAUTION!
Driving with a hot engine cooling system could damage
your vehicle. If the temperature gauge reads “H” pull over
and stop the vehicle. Idle the vehicle with the air condi-
tioner turned off until the pointer drops back into the
normal range. If the pointer remains on the “H”, turn the
engine off immediately and call an authorized dealer for
service.
WARNING!
A hot engine cooling system is dangerous. You or
others could be badly burned by steam or boiling
coolant. You may want to call an authorized dealer for
service if your vehicle overheats. If you decide to look
under the hood yourself, see “Maintaining Your Ve-
hicle”. Follow the warnings under the Cooling System
Pressure Cap paragraph.
4. Fuel Gauge •The pointer shows the level of fuel in the fuel tank
when the Keyless Push Button Ignition is in the
ON/RUN position.
•
The fuel pump symbol points to the side of the
vehicle where the fuel door is located.
5. Instrument Cluster Display
•The Instrument Cluster Display features a driver-
interactive display. Refer to “Instrument Cluster Dis-
play” in “Understanding Your Instrument Panel” for
further information.
236 UNDERSTANDING YOUR INSTRUMENT PANEL

WARNING AND INDICATOR LIGHTS
IMPORTANT:The warning / indicator lights switch on in the
instrument panel together with a dedicated message and/or
acoustic signal when applicable. These indications are indica-
tive and precautionary and as such must not be considered as
exhaustive and/or alternative to the information contained in
the Owner ’s Manual, which you are advised to read carefully
in all cases. Always refer to the information in this chapter in
the event of a failure indication.
All active telltales will display first if applicable. The system
check menu may appear different based upon equipment
options and current vehicle status. Some telltales are optional
and may not appear.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 237

Red Telltale Indicator Lights
Seat Belt Reminder Warning Light
Red TelltaleLight What It Means
Seat Belt Reminder Warning Light
When the ignition is first placed in the ON/RUN position, if the driver ’s seat belt is unbuckled, a
chime will sound and the light will turn on. When driving, if the driver or front passenger seat
belt remains unbuckled, the Seat Belt Reminder Light will flash or remain on continuously and a
chime will sound. Refer to “Occupant Restraints” in “Things To Know Before Starting Your Ve-
hicle” for further information.
Air Bag Warning Light
Red Telltale
Light What It Means
Air Bag Warning Light
This light will turn on for four to eight seconds as a bulb check when the ignition is placed in the
ON/RUN position. If the light is either not on during startup, stays on, or turns on while driv-
ing, have the system inspected at an authorized dealer as soon as possible. This light will illumi-
nate with a single chime when a fault with the Air Bag Warning Light has been detected, it will
stay on until the fault is cleared. If the light comes on intermittently or remains on while driving,
have an authorized dealer service the vehicle immediately.
238 UNDERSTANDING YOUR INSTRUMENT PANEL
