DODGE DURANGO SRT 2019 Owners Manual

CNG And LP Fuel System Modifications
Modifications that allow the engine to run on Compressed
Natural Gas (CNG) or Liquid Propane (LP) may result in
damage to the engine, emissions, and fuel system compo-
nents. Problems that result from running CNG or LP are
not the responsibility of the manufacturer and may void or
not be covered under the New Vehicle Limited Warranty.
MMT In Gasoline
Methylcyclopentadienyl Manganese Tricarbonyl (MMT) is
a manganese-containing metallic additive that is blended
into some gasoline to increase octane. Gasoline blended
with MMT provides no performance advantage beyond
gasoline of the same octane number without MMT. Gaso-
line blended with MMT reduces spark plug life and
reduces emissions system performance in some vehicles.
The manufacturer recommends that gasoline without
MMT be used in your vehicle. The MMT content of
gasoline may not be indicated on the gasoline pump;
therefore, you should ask your gasoline retailer whether
the gasoline contains MMT. MMT is prohibited in Federal
and California reformulated gasoline.
Fuel System Cautions
CAUTION!
Follow these guidelines to maintain your vehicle’s
performance:
•The use of leaded gasoline is prohibited by Federal
law. Using leaded gasoline can impair engine perfor-
mance and damage the emissions control system.
• An out-of-tune engine or certain fuel or ignition
malfunctions can cause the catalytic converter to
overheat. If you notice a pungent burning odor or
some light smoke, your engine may be out of tune or
malfunctioning and may require immediate service.
Contact an authorized dealer for service assistance.
• The use of fuel additives, which are now being sold
as octane enhancers, is not recommended. Most of
these products contain high concentrations of metha-
nol. Fuel system damage or vehicle performance
problems resulting from the use of such fuels or
additives is not the responsibility of the manufac-
turer and may void or not be covered under the New
Vehicle Limited Warranty.
9
TECHNICAL SPECIFICATIONS 459

NOTE:Intentional tampering with the emissions control
system can result in civil penalties being assessed against
you.
Carbon Monoxide Warnings
WARNING!
Carbon monoxide (CO) in exhaust gases is deadly.
Follow the precautions below to prevent carbon mon-
oxide poisoning:
• Do not inhale exhaust gases. They contain carbon
monoxide, a colorless and odorless gas, which can
(Continued)
WARNING! (Continued)
kill. Never run the engine in a closed area, such as a
garage, and never sit in a parked vehicle with the
engine running for an extended period. If the vehicle
is stopped in an open area with the engine running
for more than a short period, adjust the ventilation
system to force fresh, outside air into the vehicle.
• Guard against carbon monoxide with proper main-
tenance. Have the exhaust system inspected every
time the vehicle is raised. Have any abnormal condi-
tions repaired promptly. Until repaired, drive with
all side windows fully open.
FLUID CAPACITIES
U.S. Metric
Fuel (Approximate) 24.6 Gallons 93.0 Liters
Engine Oil With Filter
6.4 Liter Engine (SAE 0W-40, Synthetic API Certified, MS-12633) 7 Quarts 6.6 Liters
Cooling System*
6.4 Liter Engine (Mopar Antifreeze/Engine Coolant 10 Year/150,000 Mile Formula
that meets the requirements of FCA Material Standard MS.90032. 16 Quarts 15.5 Liters
* Includes heater and coolant recovery bottle filled to MAX level.
460 TECHNICAL SPECIFICATIONS

FLUIDS AND LUBRICANTS
Engine
ComponentFluid, Lubricant or Genuine Part
Engine Coolant We recommend you use Mopar Antifreeze/Coolant 10
Year/150,000 Mile Formula OAT (Organic Additive Tech-
nology) that meets the requirements of FCA Material
Standard MS.90032.
Engine Oil For best performance and maximum protection under all
types of operating conditions, the manufacturer only rec-
ommends full synthetic engine oils that meet the American
Petroleum Institute (API) categories of SN.
The manufacturer recommends the use of Pennzoil Ultra
Platinum 0W-40 or equivalent Mopar engine oil meeting
the requirements of FCA Material Standard MS-12633 for
use in all operating temperatures.
Engine Oil Filter We recommend you use Mopar Engine Oil Filters.
Spark Plugs We recommend you use Mopar Spark Plugs.
Fuel Selection Premium Unleaded 91 Octane Only or Higher, 0-15%
Ethanol (Do not use E-85).
9
TECHNICAL SPECIFICATIONS 461

Chassis
ComponentFluid, Lubricant, or Genuine Part
Automatic Transmission Use only Mopar ZF 8&9 Speed ATF Automatic Transmis-
sion Fluid or equivalent. Failure to use the correct fluid
may affect the function or performance of your transmis-
sion.
Transfer Case – Single-Speed We recommend you use Mopar ATF+4 Automatic Trans-
mission Fluid.
Axle Differential (Front) We recommend you use Mopar GL-5 Synthetic Axle Lubri-
cant SAE 75W-85.
Axle Differential (Rear) – With Electronic Limited-Slip
Differential (ELSD) We recommend you use Mopar GL-5 Synthetic Axle Lubri-
cant SAE 75W-85 with integrated friction modifier.
Brake Master Cylinder We recommend you use Mopar DOT 3 Brake Fluid, SAE
J1703 should be used. If DOT 3, SAE J1703 brake fluid is not
available, then DOT 4 is acceptable.
462 TECHNICAL SPECIFICATIONS

MULTIMEDIA
CONTENTS
UCONNECT SYSTEMS ...................466
 DRAG & DROP MENU BAR ................466
 CYBERSECURITY ...................... .467
 UCONNECT SETTINGS ...................468
▫ Customer Programmable Features — Uconnect
4C/4C NAV Settings ....................469
 PERFORMANCE PAGES — IF EQUIPPED ......489
▫ Home .............................. .490
▫ Timers ............................. .492
▫ Gauges ............................. .494
▫ G-Force ............................. .496
▫ Engine ............................. .497
▫ Dynamometer (Dyno) ....................498
 SRT DRIVE MODES ..................... .499▫
Track Mode .......................... .500
▫ Sport Mode .......................... .501
▫ Tow Mode ........................... .501
▫ Snow Mode .......................... .502
▫ Auto Mode .......................... .503
▫ Custom Mode ........................ .504
 RACE OPTIONS ........................ .505
▫ Launch Control ....................... .505
▫ Shift Light ........................... .507
▫ Race Cooldown — If Equipped .............508
 VALET MODE ......................... .509
 ECO MODE ............................511
 STEERING WHEEL AUDIO CONTROLS —
IF
EQUIPPED ......................... .512
10

▫Radio Operation ....................... .512
▫ Media Mode ......................... .513
 IPOD/USB/MP3 CONTROL — IF EQUIPPED . . .513
▫ Connecting The iPod Or External USB Device . . .513
▫ Using This Feature ..................... .514
▫ Second Row USB Charging Port ............514
 UCONNECT REAR SEAT ENTERTAINMENT
(RSE) SYSTEM — IF EQUIPPED .............515
▫ Getting Started ....................... .515
▫ Dual Video Screen ..................... .517
▫ Blu-ray Disc Player ..................... .517
▫ Play Video Games ..................... .519
▫ Play A DVD/Blu-ray Disc Using The
Touchscreen Radio ..................... .520
▫ Important Notes For Dual Video Screen
System ............................. .521
▫ Blu-ray Disc Player Remote Control —
If Equipped .......................... .522▫
Headphones Operation ...................523
▫ Controls ............................ .524
▫ Replacing The Headphone Batteries ..........524
▫ Accessibility — If Equipped ...............525
▫ Stereo Headphone Lifetime Limited Warranty . . .525
 RADIO OPERATION AND MOBILE PHONES . . .530
▫ Regulatory And Safety Information ..........530
 UCONNECT VOICE RECOGNITION QUICK
TIPS ................................ .531
▫ Introducing Uconnect ....................531
▫ Get Started .......................... .532
▫ Basic Voice Commands ...................532
▫ Radio .............................. .533
▫ Media .............................. .534
▫ Phone .............................. .535
▫ V

oice Text Reply — If Equipped ............535
▫ Climate ............................. .537
464 MULTIMEDIA

▫Navigation (4C NAV) ....................537
▫ SiriusXM Guardian (4C/4C NAV) —
If Equipped .......................... .538
▫ Register (4C/4C NAV) ...................539
▫ Vehicle Health Report/Alert (4C/4C NAV) .....539
▫ Mobile App (4C/4C NAV) ................539
▫ SiriusXM Travel Link (4C NAV) .............540
▫ Siri Eyes Free — If Equipped ..............541▫
Do Not Disturb ....................... .542
▫ Android Auto — If Equipped ..............542
▫ Apple CarPlay — If Equipped ..............543
▫ General Information .....................544
▫ Additional Information ...................545
 CD/DVD DISC MAINTENANCE ............545
10
MULTIMEDIA 465

UCONNECT SYSTEMS
For detailed information about your Uconnect system,
refer to your Uconnect Owner ’s Manual Supplement.
NOTE:Uconnect screen images are for illustration pur-
poses only and may not reflect exact software for your
vehicle.
DRAG & DROP MENU BAR
The Uconnect features and services in the main menu bar
are easily changed for your convenience. Simply follow
these steps:
1. Press the “Apps
” button to open the App screen.
2. Press and hold, then drag the selected App to replace anexisting shortcut in the main menu bar.
The new app shortcut, that was dragged down onto the
main menu bar, will now be an active App/shortcut.
NOTE: This feature is only available if the vehicle is in
PARK.
Uconnect 4C/4C NAV Main Menu
466 MULTIMEDIA

CYBERSECURITY
Your vehicle may be a connected vehicle and may be
equipped with both wired and wireless networks. These
networks allow your vehicle to send and receive informa-
tion. This information allows systems and features in your
vehicle to function properly.
Your vehicle may be equipped with certain security fea-
tures to reduce the risk of unauthorized and unlawful
access to vehicle systems and wireless communications.
Vehicle software technology continues to evolve over time
and FCA US LLC, working with its suppliers, evaluates
and takes appropriate steps as needed. Similar to a com-
puter or other devices, your vehicle may require software
updates to improve the usability and performance of your
systems or to reduce the potential risk of unauthorized and
unlawful access to your vehicle systems.
The risk of unauthorized and unlawful access to your
vehicle systems may still exist, even if the most recent
version of vehicle software (such as Uconnect software) is
installed.
WARNING!
•It is not possible to know or to predict all of the
possible outcomes if your vehicle’s systems are
breached. It may be possible that vehicle systems,
including safety related systems, could be impaired
or a loss of vehicle control could occur that may
result in an accident involving serious injury or
death.
• ONLY insert media (e.g., USB, SD card, or CD) into
your vehicle if it came from a trusted source. Media
of unknown origin could possibly contain malicious
software, and if installed in your vehicle, it may
increase the possibility for vehicle systems to be
breached.
• As always, if you experience unusual vehicle behav-
ior, take your vehicle to your nearest authorized
dealer immediately.
10
MULTIMEDIA 467

NOTE:
•FCA US LLC or your dealer may contact you directly
regarding software updates.
• To help further improve vehicle security and minimize
the potential risk of a security breach, vehicle owners
should:
• Routinely check www.driveuconnect.com (U.S. Resi-
dents) or www.driveuconnect.ca (Canadian Residents)
to learn about available Uconnect software updates.
• Only connect and use trusted media devices (e.g.
personal mobile phones, USBs, CDs).
Privacy of any wireless and wired communications cannot
be assured. Third parties may unlawfully intercept infor-
mation and private communications without your consent.
For further information, refer to “Data Collection & Pri-
vacy” in your Uconnect Owner ’s Manual Supplement or
“Onboard Diagnostic System (OBD II) Cybersecurity” in
“Getting To Know Your Instrument Panel”.UCONNECT SETTINGS
The Uconnect system uses a combination of buttons on the
touchscreen and buttons on the faceplate located on the
center of the instrument panel that allow you to access and
change the customer programmable features. Many fea-
tures can vary by vehicle.
Uconnect 4C/4C NAV Buttons On Faceplate And Buttons On Touchscreen
1 — Uconnect Buttons On The Touchscreen
2 — Uconnect Buttons On The Faceplate
468 MULTIMEDIA
