INTEGRATED POWER MODULE (IPM)
An Integrated Power Module is located in the engine
compartment near the battery. This center contains maxi
fuses, mini fuses and relays. A label that identifies each
component is printed on the inside of the cover. Cavity Maxi Fuse Description
F4 30 Amp
Pink Front Wipers
F9 40 Amp
Green Anti-Lock Brake System
(ABS) Pump
F10 40 Amp
Green Front Blower
F13 40 Amp
Green Electronic Back Light (EBL)
F19 40 Amp
Green Body Control Module
(BCM) Feed 1
F20 30 Amp
Pink Central Amplifier
F22 30 Amp
Pink Seats
F27 40 Amp
Green Radiator FanIntegrated Power module (IPM)412 MAINTAINING YOUR VEHICLE
