DODGE JOURNEY 2014 1.G Owners Manual

For vehicles equipped with the EVIC
The power sunroof switch will remain active for up to 10
minutes after the ignition switch is turned to the LOCK
position. Opening either front door will cancel this
feature.
NOTE:The delay time if programmable using the
Uconnect® system. Refer to “Uconnect® System” in
“Understanding Your Instrument Panel” for further in-
formation.
ELECTRICAL POWER OUTLETS
A 12 Volt (13 Amp) power outlet is located in the center
console below the radio. The power outlet has power
available when the ignition in the ON/RUN or ACC
position. This power outlet will also operate a conventional cigar
lighter unit.
To preserve the heating element, do not
hold the lighter in the heating position.Front 12 Volt Power Outlet
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 269

A second 12 Volt (13 Amp) power outlet is located inside
the center console storage area. Power is available with the
ignition is in the ON/RUN, ACC or LOCK position.A third fused 12 Volt power outlet is located on the back
of the center console. This power outlet has power
available when the ignition is in the LOCK, ON or ACC
position.
Center Console 12 Volt Power Outlet
Rear Seat 12 Volt Power Outlet
270 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

A fourth fused 12 Volt power outlet is located on the left
quarter trim panel in the cargo area. This power outlet
has power available when the ignition is in the ON or
ACC position.NOTE:
To ensure proper operation a MOPAR® knob
and element must be used.
CAUTION!
• Do not exceed the maximum power of 160 Watts
(13 Amps) at 12 Volts. If the 160 Watt (13 Amp)
power rating is exceeded the fuse protecting the
system will need to be replaced.
• The power outlet on the bottom of the center
console shares the fuse with the power outlet on
the back of the console. The combined usage must
not exceed 160 Watts (13 Amps) at 12 Volts.
•
Power outlets are designed for accessory plugs only.
Do not insert any other object in the power outlets as
this will damage the outlet and blow the fuse.
Improper use of the power outlet can cause damage
not covered by your New Vehicle Limited Warranty.
Rear Cargo Area Power Outlet
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 271

WARNING!
To avoid serious injury or death:
•Only devices designed for use in this type of outlet
should be inserted into any 12 Volt outlet.
• Do not touch with wet hands.
• Close the lid when not in use and while driving the
vehicle.
• If this outlet is mishandled, it may cause an electric
shock and failure.
Power Outlet Fuses
1 — F103 20 A Yellow Power Outlet Console Bin & Power Outlet
Console Rear
2 — F102 20 A Yellow Cigar Lighter Instrument Panel & Power
Outlet Left Rear Cargo Area 272 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

CAUTION!
•Many accessories that can be plugged in draw
power from the vehicle’s battery, even when not in
use (i.e., cellular phones, etc.). Eventually, if
plugged in long enough, the vehicle’s battery will
discharge sufficiently to degrade battery life and/or
prevent the engine from starting.
• Accessories that draw higher power (i.e., coolers,
vacuum cleaners, lights, etc.) will degrade the bat-
tery even more quickly. Only use these intermit-
tently and with greater caution.
• After the use of high power draw accessories, or
long periods of the vehicle not being started (with
accessories still plugged in), the vehicle must be
driven a sufficient length of time to allow the
alternator to recharge the vehicle’s battery.
(Continued)
CAUTION! (Continued)
•Power outlets are designed for accessory plugs
only. Do not hang any type of accessory or acces-
sory bracket from the plug.
POWER INVERTER — IF EQUIPPED
Your vehicle may be equipped with a 115 Volt AC
(150 Watt maximum) power outlet located on the back of
the center console. This outlet can power mobile phones,
electronics and other low power devices requiring power
up to 150 Watts. Certain high-end video games, such as
Playstation3 and XBox360 will exceed this power limit, as
will most power tools.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 273

The power inverter is designed with built-in overload
protection. If the power rating of 150 Watts is exceeded,
the power inverter will automatically shut down. Once
the electrical device has been removed from the outlet the
inverter should automatically reset. If the power rating
exceeds approximately 170 Watts, the power invertermay have to be reset manually. To reset the inverter
manually press the power inverter button OFF and ON.
To avoid overloading the circuit, check the power ratings
on electrical devices prior to using the inverter.
NOTE:
Due to built-in overload protection, the power
outlet will shut down if the 115 Volt AC (150 Watt
maximum) power rating is exceeded.
WARNING!
To avoid serious injury or death:
• Do not use a three-prong adaptor.
• Do not insert any objects into the receptacles.
• Do not touch with wet hands.
• Close the lid when not in use.
• If this outlet is mishandled, it may cause an electric
shock and failure.
Power Inverter
274 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Power Inverter Operation
The power inverter is turned on and off using the
Uconnect® System.
Vehicles Equipped With Uconnect® 4.3
To turn the power inverter on or off perform the following:
1. Press the “More” hard-key (located next to theUconnect® display).
2. Press the “Outlet” soft-key (located on the Uconnect® display) to turn the power inverter On or Off.
Vehicles Equipped With Uconnect® 8.4 And 8.4 Nav
To enable or disable the power inverter perform the
following:
1. Press the “Controls” soft-key.
2. Press the “Outlet” soft-key to turn the power inverter On or Off.
CUPHOLDERS
There are two cupholders, located in the center floor
console, for the front passengers.
For passengers in the second row there are two cuphold-
ers, located in the center armrest between the two seats.
Floor Console Cupholders
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 275

When the armrest is folded flat the cupholders are in the
back of the Head Restraint. The Head Restraint can be
adjusted to better position the cupholders.
For vehicles equipped with third row seating, there are
additional cupholders located in the trim panels.In addition to cupholders, vehicles may also be equipped
with bottle holders. The bottle holders are located on the
door trim panels.
Armrest CupholdersDoor Bottle Holder
276 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!
If containers of hot liquid are placed in the bottle
holder, they can spill when the door is closed, burn-
ing the occupants. Be careful when closing the doors
to avoid injury.
STORAGE
Glove Compartment
The glove compartment is located on the passenger side
of the instrument panel. Pull on the release handle to
open the glove compartment.
Glove Compartment
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 277

Floor Console Storage
An open storage area, or cubby bin, is located in the floor
console.
Center Console Storage
There is a storage tray and storage compartment located
under the center console armrest.
Pull upward on the release handle, located on the front of
the lid, to gain access to the storage tray and storage
compartment.
Floor Console Cubby BinCenter Console
