Grab the cover handle and pull it toward you. As the
cover nears the liftgate opening, guide the rear attach-
ment posts (on both ends of the cover) into the notches in
the trim panels. Lower the cover to position the posts into
the bottom of the notches and release the handle.WARNING!
A cargo cover that is unsecured in the vehicle could
cause injury in a collision. It could become airborne
during a sudden stop and strike someone inside the
vehicle. Do not store the cargo cover on the cargo
floor or in the passenger compartment. Remove the
cover from the vehicle when taken from its mount-
ing. Do not store it in the vehicle.
Positioning Retractable Cargo Area Cover
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 289

REAR WINDOW FEATURES
Rear Window Wiper/Washer
The rear window wiper/washer control is located on the
left side of the steering column.Rotate the switch upward to the first detent
position for rear wiper operation.
Rotate the switch upward past the first detent
position to activate the rear washer. The washer
pump will continue to operate as long as the switch is
held. Upon release, the wiper will cycle three times
before returning to the set position.
Rear Wiper/Washer
290 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

If the rear wiper is operating when the ignition is turned
to the LOCK position, the wiper will automatically return
to the “Park” position. When the vehicle is restarted, the
wiper will resume function at whichever position the
switch is set at.
CAUTION!
•Turn the rear wiper off when driving through an
automatic car wash. Damage to the rear wiper may
result if the rear wiper switch is left in the ON
position.
• In cold weather, always turn off the rear wiper
switch and allow the rear wiper to return to the
park position before turning off the engine. If the
rear wiper switch is left on and the rear wiper
freezes to the window, damage to the rear wiper
motor may occur when the vehicle is restarted.
• Always remove any buildup of snow that prevents
the rear wiper blade from returning to the park
position. If the rear wiper control is turned off and
the blade cannot return to the park position, dam-
age to the rear wiper motor may occur.
Rear Wiper/Washer Control
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 291

Rear Window Defroster
The rear window defroster button is located on
the climate control panel. Press this button to turn
on the rear window defroster and the heated outside
mirrors (if equipped). An indicator in the button will
illuminate when the rear window defroster is on. The
rear window defroster automatically turns off after ap-
proximately 10 minutes.
NOTE: To prevent excessive battery drain, use the rear
window defroster only when the engine is operating.
CAUTION!
Failure to follow these cautions can cause damage to
the heating elements:
• Use care when washing the inside of the rear
window. Do not use abrasive window cleaners on
the interior surface of the window. Use a soft cloth
and a mild washing solution, wiping parallel to the
heating elements. Labels can be peeled off after
soaking with warm water.
• Do not use scrapers, sharp instruments, or abrasive
window cleaners on the interior surface of the
window.
• Keep all objects a safe distance from the window.
292 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

ROOF LUGGAGE RACK — IF EQUIPPED
The roof rack cross rails and side rails are designed to
carry cargo weight. The load must not exceed 150 lbs
(68 kg), and it should be distributed uniformly over the
cross rails. In addition, the roof rack does not increase the
total load carrying capacity of the vehicle. Be sure the
total load of cargo inside the vehicle plus that on the roof
rack does not exceed the maximum vehicle load capacity.
NOTE:Metal crossbars are offered by MOPAR® acces-
sories. See your authorized dealer.
To Move The Cross Rails
1. Loosen the knobs on top of each cross rail approxi- mately six turns to disengage the clamp tooth from the
side rail. 2. Relocate the cross rails, aligning the cross rail stan-
chions (end pieces) with one of the vertical marks on
the outboard surface of the side rail for proper posi-
tioning. There are four frontward marks for the front
cross rail and four rearward marks for the rear cross
rail. Make sure the cross rails remain equally spaced or
parallel at any position for proper function.
3. Tighten the knobs on each cross rail to lock it in position. As you tighten the knob, make sure the
clamp tooth engages completely into the side rail slot.
4. Attempt to move the cross rail to ensure that it is locked in position.
NOTE:
• To help control wind noise when installing the cross
rails, make sure the arrows marked on the underside
of the cross rails face the front of the vehicle.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 293

•To help reduce the amount of wind noise when the
cross rails are not in use, fasten the front cross rail in
the fourth position from the front and the rear cross
rail in the eighth position. The tie down holes on the
cross rail ends should always be used to tie down the
load. Check the straps frequently to be sure that the
load remains securely attached.
CAUTION!
•Cross rails should remain equally spaced or paral-
lel at any luggage rack position for proper function.
Noncompliance could result in damage to the roof
rack, cargo, and vehicle.
• To avoid damage to the roof rack and vehicle, do
not exceed the maximum roof rack load capacity of
150 lbs (68 kg). Always distribute loads as evenly as
possible and secure the load appropriately.
(Continued)
CAUTION! (Continued)
•Long loads, which extend over the windshield,
such as wood panels or surfboards, or loads with
large frontal area should be secured to both the
front and rear of the vehicle.
• Place a blanket or other protection between the
surface of the roof and the load.
• Travel at reduced speeds and turn corners carefully
when carrying large or heavy loads on the roof
rack. Wind forces, due to natural causes or nearby
truck traffic, can add sudden upward lift to loads.
This is especially true on large flat loads and may
result in damage to the cargo or your vehicle.
294 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!
Cargo must be securely tied before driving your
vehicle. Improperly secured loads can fly off the
vehicle, particularly at high speeds, resulting in per-
sonal injury or property damage. Follow the roof rack
cautions when carrying cargo on your roof rack.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 295

UNDERSTANDING YOUR INSTRUMENT PANEL
CONTENTS
INSTRUMENT PANEL FEATURES ..........300
 INSTRUMENT CLUSTER .................301
 INSTRUMENT CLUSTER DESCRIPTIONS .....302
 ELECTRONIC VEHICLE INFORMATION
CENTER (EVIC) .......................311
▫ Electronic Vehicle Information Center (EVIC)
Displays ............................313
▫ EVIC White Indicators ..................316
▫ EVIC Amber Indicators .................317
▫ EVIC Red Indicators ...................317 ▫
Oil Change Due ..................... .320
▫ Fuel Economy ........................321
▫ Vehicle Speed ........................322
▫ Trip Info .......................... .323
▫ TirePSI............................ .324
▫ Vehicle Info (Customer Information Features) . .324
▫ Messages .......................... .324
▫ Turn Menu OFF .......................325
4

Uconnect® SETTINGS ...................325
▫ Hard-Keys ..........................325
▫ Soft-Keys .......................... .325
▫ Customer Programmable Features —
Uconnect® 4.3 Settings ..................325
▫ Customer Programmable Features —
Uconnect® System 8.4 Settings ............337
 Uconnect® MULTIMEDIA — VIDEO
ENTERTAINMENT SYSTEM (VES™) —
IF EQUIPPED ........................ .350
▫ Getting Started .......................351
▫ Single Video Screen ....................351
▫ Play Video Games .....................352
▫ Listen To An Audio Source On Channel 2
While A Video Is Playing On Channel 1 ......353▫
Important Notes For Single Video Screen
System ............................ .354
▫ Play A DVD Using The Touchscreen Radio . . .355
▫ VES™ Remote Control — If Equipped .......356
▫ Remote Control Storage .................358
▫ Locking The Remote Control .............359
▫ Replacing The Remote Control Batteries ......360
▫ Headphones Operation .................360
▫ Replacing The Headphone Batteries .........361
▫ Controls ............................361
▫ Unwired® Stereo Headphone Lifetime Limited
Warranty .......................... .362
▫ System Information ....................364
