DODGE JOURNEY 2017 1.G Owners Manual

Wind Buffeting
Wind buffeting can be described as the perception of
pressure on the ears or a helicopter-type sound in the ears.
Your vehicle may exhibit wind buffeting with the windows
down, or the sunroof (if equipped) in certain open or
partially open positions. This is a normal occurrence and
can be minimized. If the buffeting occurs with the rear
windows open, open the front and rear windows together
to minimize the buffeting. If the buffeting occurs with the
sunroof open, adjust the sunroof opening to minimize the
buffeting or open any window.
Sunroof Maintenance
Use only a nonabrasive cleaner and a soft cloth to clean the
glass panel.
Ignition Off Operation
The power sunroof switch will remain active for up to
approximately ten minutes after the ignition switch is
turned to the LOCK position. Opening either front door
will cancel this feature.
NOTE:Ignition Off time is programmable through the
Uconnect System. Refer to “Uconnect Settings/Customer
Programmable Features” in “Understanding Your Instru-
ment Panel” for further information.
POWER OUTLETS
A 12 Volt (13 Amp) power outlet is located in the center
console below the radio. The power outlet has power
available when the ignition in the ON/RUN or ACC
position.
This power outlet will also operate a conventional cigar
lighter unit. To preserve the heating element, do not hold
the lighter in the heating position.
Front 12 Volt Power Outlet
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 199

A second 12 Volt (13 Amp) power outlet is located inside
the center console storage area. Power is available with the
ignition is in the ON/RUN, ACC or LOCK position.A third fused 12 Volt power outlet is located on the back of
the center console. This power outlet has power available
when the ignition is in the LOCK, ON or ACC position.
Center Console 12 Volt Power OutletRear Seat 12 Volt Power Outlet
200 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

A fourth fused 12 Volt power outlet is located on the left
quarter trim panel in the cargo area. This power outlet has
power available when the ignition is in the ON or ACC
position.
NOTE:To ensure proper operation a MOPAR knob and
element must be used.CAUTION!
• Do not exceed the maximum power of 160 Watts (13
Amps) at 12 Volts. If the 160 Watt (13 Amp) power
rating is exceeded the fuse protecting the system will
need to be replaced.
• The power outlet on the bottom of the center console
shares the fuse with the power outlet on the back of
the console. The combined usage must not exceed
160 Watts (13 Amps) at 12 Volts.
• Power outlets are designed for accessory plugs only.
Do not insert any other object in the power outlets as
this will damage the outlet and blow the fuse.
Improper use of the power outlet can cause damage
not covered by your New Vehicle Limited Warranty.
Rear Cargo Area Power Outlet
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 201

WARNING!
To avoid serious injury or death:
•Only devices designed for use in this type of outlet
should be inserted into any 12 Volt outlet.
• Do not touch with wet hands.
(Continued)
WARNING! (Continued)
•Close the lid when not in use and while driving the
vehicle.
• If this outlet is mishandled, it may cause an electric
shock and failure.
CAUTION!
• Many accessories that can be plugged in draw power
from the vehicle’s battery, even when not in use (i.e.,
cellular phones, etc.). Eventually, if plugged in long
enough, the vehicle’s battery will discharge suffi-
ciently to degrade battery life and/or prevent the
engine from starting.
• Accessories that draw higher power (i.e., coolers,
vacuum cleaners, lights, etc.) will degrade the battery
even more quickly. Only use these intermittently and
with greater caution.
• After the use of high power draw accessories, or long
periods of the vehicle not being started (with acces-
sories still plugged in), the vehicle must be driven a
sufficient length of time to allow the alternator to
recharge the vehicle’s battery.
(Continued)
Power Outlet Fuses
1 — F103 20 A Yellow Power Outlet Console Bin & Power Outlet
Console Rear
2 — F102 20 A Yellow Cigar Lighter Instrument Panel & Power
Outlet Left Rear Cargo Area 202 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

CAUTION!(Continued)
•Power outlets are designed for accessory plugs only.
Do not hang any type of accessory or accessory
bracket from the plug.
POWER INVERTER — IF EQUIPPED
Your vehicle may be equipped with a 115 Volt AC (150 Watt
maximum) power outlet located on the back of the center
console. This outlet can power mobile phones, electronics
and other low power devices requiring power up to 150
Watts. Certain high-end video game consoles will exceed
this power limit, as will most power tools.
The power inverter is designed with built-in overload
protection. If the power rating of 150 Watts is exceeded, the
power inverter will automatically shut down. Once the
electrical device has been removed from the outlet the
inverter should automatically reset. If the power rating
exceeds approximately 170 Watts, the power inverter may
have to be reset manually. To reset the inverter manually
press the power inverter button OFF and ON. To avoid
overloading the circuit, check the power ratings on electri-
cal devices prior to using the inverter.
Power Inverter
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 203

NOTE:Due to built-in overload protection, the power
outlet will shut down if the 115 Volt AC (150 Watt maxi-
mum) power rating is exceeded.
WARNING!
To avoid serious injury or death:
• Do not use a three-prong adaptor.
• Do not insert any objects into the receptacles.
• Do not touch with wet hands.
• Close the lid when not in use.
• If this outlet is mishandled, it may cause an electric
shock and failure.
Power Inverter Operation
The power inverter is turned On and Off using the
Uconnect System.
Vehicles Equipped With Radio 4.3
To turn the power inverter on or off perform the following:
1. Press the “More” button on the faceplate (located next to the Uconnect display).
2. Press the “Outlet” button on the touchscreen (located on the Uconnect display) to turn the power inverter On or
Off.
Vehicles Equipped With Radio 8.4/8.4 NAV
To turn the power inverter on or off perform the following:
1. Press the “Controls” button on the touchscreen.
2. Press the “Outlet” button on the touchscreen to turn thepower inverter On or Off.
CUPHOLDERS
There are two cupholders, located in the center floor
console, for the front passengers.
Floor Console Cupholders
204 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

For passengers in the second row there are two cupholders,
located in the center armrest between the two seats.
When the armrest is folded flat the cupholders are in the
back of the Head Restraint. The Head Restraint can be
adjusted to better position the cupholders.
For vehicles equipped with third row seating, there are
additional cupholders located in the trim panels.
In addition to cupholders, vehicles may also be equipped
with bottle holders. The bottle holders are located on the
door trim panels.
WARNING!
If containers of hot liquid are placed in the bottle
holder, they can spill when the door is closed, burning
the occupants. Be careful when closing the doors to
avoid injury.
Armrest Cupholders
Door Bottle Holder
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 205

STORAGE
Glove Compartment
The glove compartment is located on the passenger side of
the instrument panel. Pull on the release handle to open the
glove compartment.
Floor Console Storage
An open storage area, or cubby bin, is located in the floor
console.
Glove Compartment
Floor Console Cubby Bin
206 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Center Console Storage
There is a storage tray and storage compartment located
under the center console armrest.
Pull upward on the release handle, located on the front of
the lid, to gain access to the storage tray and storage
compartment.The storage tray can be slid forward and rearward or
removed to access the center console storage compartment.
Center Console
Center Console Storage Tray
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 207

WARNING!
Do not operate this vehicle with a console compart-
ment lid in the open position. Driving with the console
compartment lid open may result in injury in a colli-
sion.
Sliding Armrest
The center console armrest can also slide rearward for easy
access to the storage area.
WARNING!
Do not operate this vehicle with a console compartment
lid in the open position. Driving with the console
compartment lid open may result in injury in a collision.
Center Console Storage Compartment
Sliding Armrest
208 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
