Miles 57,000 60,000 63,000 66,000 69,000 72,000
(Kilometers) (95 000) (100 000) (105 000) (110 000) (115 000) (120 000)
Change engine oil and engine oil filter, if not
replaced at 3 months.XXXXX X
Inspect theair cleaner filterand replace if re-
quired.*X XXX X
Replace theair cleaner filter.X
Replace thespark plugs.5.7L Engine. X
Inspect the front and rear brake linings and
rotors.XX
Check and Inspect the accessory drive belt
and tensioner. Replace if required.X
Check and replace, if necessary, thePCV
valve.*‡X
Change the automatic transmission fluid and
filter.X
Replace the air conditioning filter. X X
Flush and replace engine coolant at 60 months
if not done at 102,000 miles.X
Rotate the tires. X X X
SCHEDULE“B”343
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 75,000 78,000 81,000 84,000 87,000 90,000
(Kilometers) (125 000) (130 000) (135 000) (140 000) (145 000) (150 000)
Change engine oil and engine oil filter, if not
replaced at 3 months.XXXXX X
Inspect theair cleaner filterand replace if re-
quired.*XXXX
Replace theair cleaner filter.XX
Replace thespark plugs.5.7L Engine. X
Inspect the front and rear brake linings and
rotors.X
Check and replace, if necessary, thePCV
valve.*‡X
Replace the air conditioning filter. X
Rotate the tires. X X X
344 SCHEDULE“B”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 93,000 96,000 99,000 102,000 105,000
(Kilometers) (155 000) (160 000) (165 000) (170 000) (175 000)
Change engine oil and engine oil filter, if not re-
placed at 3 months.XXXXX
Inspect theair cleaner filterand replace if re-
quired.*XXXX
Replace theair cleaner filter.X
Inspect the front and rear brake linings and rotors. X
Replace theengine timing belt.3.5L Engine. X
Replace thespark plugs.2.7L, 3.5L Engines. X
Check and Inspect the accessory drive belt and ten-
sioner. Replace if required.X
Change the rear axle fluid. X
Replace the air conditioning filter. X
Change the Transfer Case Fluid - All Wheel Drive
(AWD) only.X
Flush and replace engine coolant at 102,000 miles if
not done at 60 months.X
Rotate the tires. X X
SCHEDULE“B”345
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 108,000 111,000 114,000 117,000 120,000
(Kilometers) (180 000) (185 000) (190 000) (195 000) (200 000)
Change engine oil and engine oil filter, if not re-
placed at 3 months.XXXXX
Inspect theair cleaner filterand replace if re-
quired.*XXXX
Replace theair cleaner filter.X
Inspect the front and rear brake linings and rotors. X X
Replace thespark plugs.5.7L Engine. X
Check and replace, if necessary, thePCV valve.*X
Change the automatic transmission fluid and filter. X
Replace the air conditioning filter. X X
Flush and replace the engine coolant at 120 months,
if not replaced at 102,000 miles.X
Rotate the tires. X X X
* This maintenance is recommended by the manufacture
to the owner but is not required to maintain the emis-
sions warranty.
‡This maintenance is not required if previously replaced.Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.
346 SCHEDULE“B”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 42,000 48,000 54,000 60,000 66,000 72,000
(Kilometers) (70 000) (80 000) (90 000) (100 000) (110 000) (120 000)
[Months] [42] [48] [54] [60] [66] [72]
Change engine oil and engine oil filter. X X X X X X
Inspect theair cleaner filterand replace if
required.*XXX XX
Replace theair cleaner filter.X
Inspect the front and rear brake linings and
rotors.XX
Replace thespark plugs.5.7L Engine. X
Check and Inspect the accessory drive belt
and tensioner. Replace if required.X
Flush and replace engine coolant at 60 months
if not done at 102,000 miles.X
Check and replace, if necessary, thePCV
valve.*X
Replace the air conditioning filter. X X X
Rotate the tires. X X X X X X
348 SCHEDULE“A”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 78,000 84,000 90,000 96,000 102,000
(Kilometers) (130 000) (140 000) (150 000) (160 000) (170 000)
[Months] [78] [84] [90] [96] [102]
Change engine oil and engine oil filter. X X X X X
Inspect theair cleaner filterand replace if re-
quired.*XX XX
Replace theair cleaner filter.X
Inspect the front and rear brake linings and rotors. X
Check and Inspect the accessory drive belt and ten-
sioner. Replace if required.X
Replace thespark plugs.2.7L, 3.5L Engines. X
Replace thespark plugs.5.7L Engine. X
Check and replace, if necessary, thePCV valve.*‡X
Replace theengine timing belt.3.5L Engine. X
Flush and replace the engine coolant at 102,000
miles if not done at 60 months.X
Replace the air conditioning filter. X X
Rotate the tires. X X X X X
SCHEDULE“A”349
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 108,000 114,000 120,000
(Kilometers) (180 000) (190 000) (200 000)
[Months] [108] [114] [120]
Change engine oil and engine oil filter. X X X
Inspect theair cleaner filterand replace if required.* X X
Replace theair cleaner filter.X
Inspect the front and rear brake linings and rotors. X
Replace thespark plugs.5.7L Engine. X
Check and replace, if necessary, thePCV valve.*X
Replace the air conditioning filter. X X
Flush and replace the engine coolant at 120 months, if not re-
placed at 102,000 miles.X
Rotate the tires. X X X
* This maintenance is recommended by the manufacturer
to the owner but is not required to maintain the emis-
sions warranty.
‡This maintenance is not required if previously replaced.
Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.
WARNING!
You can be badly injured working on or around a
motor vehicle. Do only that service work for which
you have the knowledge and the right equipment. If
you have any doubt about your ability to perform a
service job, take your vehicle to a competent mechanic.
350 SCHEDULE“A”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

ABS (Anti-Lock Brake System)............. 219
Adding Engine Coolant (Antifreeze)......... 306
Adding Fuel.......................... 250
Adding Washer Fluid.................103,303
Additives, Fuel........................ 248
Adjustable Pedals....................... 93
Air Conditioner Maintenance.............. 300
Air Conditioning....................... 187
Air Conditioning Filter................196,301
Air Conditioning, Operating Tips........... 197
Air Conditioning Refrigerant.............. 301
Air Conditioning System................. 187
Air Pressure, Tires...................... 232
Airbag................................ 38
Airbag Deployment....................41,42
Airbag Light....................42,49,59,142
Airbag Maintenance...................... 44
Airbag, Side........................... 44
Airbag, Window (Side Curtain)...........38,44
Alarm System (Security Alarm)............. 24
Alignment and Balance.................. 238
All Wheel Drive (AWD)...............239,313
Alterations/Modifications, Vehicle............ 7Antenna, Satellite Radio.................. 180
Antifreeze (Engine Coolant)............306,331
Disposal............................ 308
Anti-Lock Brake System (ABS)............. 219
Anti-Lock Warning Light................. 147
Anti-Theft Security Alarm (Theft Alarm)...... 24
Appearance Care....................... 314
Auto Down Power Windows............... 28
Auto Up Power Windows................. 28
Automatic Dimming Mirror................ 65
Automatic Door Locks..................17,18
Automatic Headlights.................... 98
Automatic Temperature Control (ATC)....... 190
Automatic Transmission.........204,209,312,313
Adding Fluid.....................313,333
Fluid and Filter Changes................ 313
Fluid Change........................ 313
Fluid Level Check..................... 312
Fluid Type.......................... 333
Gear Ranges......................... 205
Torque Converter..................... 207
Automatic Transmission Limp Home Mode . . . 208
Autostick.......................... 211,216
360 INDEX

Electric Remote Mirrors................... 67
Electrical Power Outlets.................. 121
Electronic Speed Control (Cruise Control)..... 109
Electronic Stability Program (ESP).......... 107
Electronic Vehicle Information Center (EVIC) . . 148
Emergency, In Case of
Freeing Vehicle When Stuck............. 280
Hazard Warning Flasher................ 268
Jacking............................. 269
Jump Starting........................ 277
Overheating......................... 268
Towing............................. 281
Emission Control System Maintenance....289,336
Engine.........................285,286,287
Air Cleaner.......................... 297
Air Cleaner Filter..................... 297
Block Heater......................... 204
Break-In Recommendations............... 58
Checking Oil Level.................291,292
Compartment..................285,286,287
Coolant (Antifreeze)................305,332
Cooling............................ 305
Exhaust Gas Caution..............27,59,249Fails to Start......................... 203
Fuel Requirements.................246,331
Oil ..........................291,331,332
Oil Change Interval................... 293
Oil Selection......................293,331
Oil Synthetic......................... 295
Overheating......................... 268
Temperature Gauge................... 141
Enhanced Accident Response Feature......... 43
Event Data Recorder..................... 49
Exhaust Gas Caution.............27,59,249,304
Exhaust System........................ 304
Exterior Folding Mirrors.................. 66
Filters
Air Cleaner.......................... 297
Air Conditioning..................196,301
Engine Fuel......................... 297
Engine Oil.......................296,332
Engine Oil Disposal................... 295
Flashers
Hazard Warning...................... 268
Turn Signal.......................... 142
INDEX 363
10

Flash-To-Pass.......................... 100
Flat Tire Changing...................... 269
Floor Console.......................... 125
Fluid Capacities........................ 331
Fluid Leaks............................ 60
Fluid Level Checks
Brake.............................. 311
Cooling System....................... 305
Engine Oil.......................291,292
Power Steering....................... 302
Fluids............................... 332
Fluids, Lubricants and Genuine Parts........ 332
Fog Lights.........................100,144
Folding Rear Seat....................... 92
Freeing A Stuck Vehicle.................. 280
Fuel................................. 246
Adding............................. 250
Additives........................... 248
Clean Air........................... 247
Filler Cap (Gas Cap)................... 250
Filter.............................. 297
Gasoline............................ 246
Gauge............................. 141Hoses.............................. 312
Octane Rating.....................246,332
Requirements.....................246,331
Tank Capacity........................ 331
Fueling.............................. 250
Fuses................................ 318
Garage Door Opener (HomeLink) .......... 113
Gas Cap (Fuel Filler Cap)................. 250
Gasoline, Clean Air..................... 247
Gasoline (Fuel)........................ 246
Gasoline, Reformulated.................. 247
Gauges
Coolant Temperature.................. 141
Fuel............................... 141
Speedometer......................... 141
Tachometer.......................... 141
Gear Ranges.......................... 205
General Information.................15,23,243
Glass Cleaning......................... 317
Gross Axle Weight Rating..............252,254
Gross Vehicle Weight Rating............252,254
364 INDEX
