MAINTAINING YOUR VEHICLE
CONTENTS

2.7L Engine..........................285

3.5L Engine..........................286

5.7L Engine..........................287

Onboard Diagnostic System—OBD II......288

Emissions Inspection And Maintenance
Programs
............................289

Replacement Parts.....................290

Dealer Service........................290

Maintenance Procedures.................291
▫Engine Oil..........................291
▫Engine Oil Filter......................296▫Drive Belts—Check Condition And
Tensioner...........................296
▫Spark Plugs.........................296
▫Engine Air Cleaner Filter................297
▫Fuel Filter..........................297
▫Catalytic Converter....................297
▫Maintenance-Free Battery................299
▫Air Conditioner Maintenance.............300
▫A/C Air Filter—If Equipped............301
▫Power Steering—Fluid Check............302
▫Front & Rear Suspension Ball Joints........302
▫Steering Linkage......................302
7

environment. Contact your dealer, service station, or
governmental agency for advice on how and where used
oil and oil filters can be safely discarded in your area.
Engine Oil Filter
The engine oil filter should be replaced at every engine
oil change.
Engine Oil Filter Selection
This manufacture’s engines have a full-flow type oil filter.
Use a filter of this type for replacement. The quality of
replacement filters varies considerably. Only high quality
filters should be used to assure most efficient service.
MoparEngine Oil Filters are a high quality oil filter and
are recommended.
Drive Belts—Check Condition and Tensioner
Belt tension is controlled by means of an automatic
tensioner. No belt tension adjustments are required.
However, belt and belt tensioner condition should be
inspected at the specified intervals, and replaced if re-
quired. See your authorized dealer for service.At the mileage indicated in the maintenance schedule, all
belts and tensioner should be checked for condition.
Improper belt tension can cause belt slippage and failure.
Belts should be inspected for evidence of cuts, cracks,
glazing, or frayed cords and replaced if there is indication
of damage which could result in belt failure. Low gen-
erator belt tension can cause battery failure.
Also check belt routing to make sure there is no interfer-
ence between the belts and other engine components.
Spark Plugs
Spark plugs must fire properly to assure engine perfor-
mance and emission control. New plugs should be in-
stalled at the specified mileage. The entire set should be
replaced if there is any malfunction due to a faulty spark
plug. Malfunctioning spark plugs can damage the cata-
lytic converter. For proper type of replacement spark
plugs, refer to the“Vehicle Emission Control Informa-
tion”label in the engine compartment.
296 MAINTAINING YOUR VEHICLE

Miles 21,000 24,000 27,000 30,000 33,000 36,000
(Kilometers) (35 000) (40 000) (45 000) (50 000) (55 000) (60 000)
Change engine oil and engine oil filter, if not
replaced at 3 months.XXXXX X
Inspect theair cleaner filterand replace if re-
quired.*XXX X X
Replace theair cleaner filter.X
Replace thespark plugs.5.7L Engine. X
Inspect the front and rear brake linings and
rotors.XX
Check and replace, if necessary, thePCV
valve.*X
Replace the air conditioning filter. X X
Rotate the tires. X X X
SCHEDULE“B”341
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 57,000 60,000 63,000 66,000 69,000 72,000
(Kilometers) (95 000) (100 000) (105 000) (110 000) (115 000) (120 000)
Change engine oil and engine oil filter, if not
replaced at 3 months.XXXXX X
Inspect theair cleaner filterand replace if re-
quired.*X XXX X
Replace theair cleaner filter.X
Replace thespark plugs.5.7L Engine. X
Inspect the front and rear brake linings and
rotors.XX
Check and Inspect the accessory drive belt
and tensioner. Replace if required.X
Check and replace, if necessary, thePCV
valve.*‡X
Change the automatic transmission fluid and
filter.X
Replace the air conditioning filter. X X
Flush and replace engine coolant at 60 months
if not done at 102,000 miles.X
Rotate the tires. X X X
SCHEDULE“B”343
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 75,000 78,000 81,000 84,000 87,000 90,000
(Kilometers) (125 000) (130 000) (135 000) (140 000) (145 000) (150 000)
Change engine oil and engine oil filter, if not
replaced at 3 months.XXXXX X
Inspect theair cleaner filterand replace if re-
quired.*XXXX
Replace theair cleaner filter.XX
Replace thespark plugs.5.7L Engine. X
Inspect the front and rear brake linings and
rotors.X
Check and replace, if necessary, thePCV
valve.*‡X
Replace the air conditioning filter. X
Rotate the tires. X X X
344 SCHEDULE“B”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 93,000 96,000 99,000 102,000 105,000
(Kilometers) (155 000) (160 000) (165 000) (170 000) (175 000)
Change engine oil and engine oil filter, if not re-
placed at 3 months.XXXXX
Inspect theair cleaner filterand replace if re-
quired.*XXXX
Replace theair cleaner filter.X
Inspect the front and rear brake linings and rotors. X
Replace theengine timing belt.3.5L Engine. X
Replace thespark plugs.2.7L, 3.5L Engines. X
Check and Inspect the accessory drive belt and ten-
sioner. Replace if required.X
Change the rear axle fluid. X
Replace the air conditioning filter. X
Change the Transfer Case Fluid - All Wheel Drive
(AWD) only.X
Flush and replace engine coolant at 102,000 miles if
not done at 60 months.X
Rotate the tires. X X
SCHEDULE“B”345
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 108,000 111,000 114,000 117,000 120,000
(Kilometers) (180 000) (185 000) (190 000) (195 000) (200 000)
Change engine oil and engine oil filter, if not re-
placed at 3 months.XXXXX
Inspect theair cleaner filterand replace if re-
quired.*XXXX
Replace theair cleaner filter.X
Inspect the front and rear brake linings and rotors. X X
Replace thespark plugs.5.7L Engine. X
Check and replace, if necessary, thePCV valve.*X
Change the automatic transmission fluid and filter. X
Replace the air conditioning filter. X X
Flush and replace the engine coolant at 120 months,
if not replaced at 102,000 miles.X
Rotate the tires. X X X
* This maintenance is recommended by the manufacture
to the owner but is not required to maintain the emis-
sions warranty.
‡This maintenance is not required if previously replaced.Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.
346 SCHEDULE“B”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

SCHEDULE“A”
Miles 6,000 12,000 18,000 24,000 30,000 36,000
(Kilometers) (10 000) (20 000) (30 000) (40 000) (50 000) (60 000)
[Months] [6] [12] [18] [24] [30] [36]
Change engine oil and engine oil filter. XXXXXX
Inspect theair cleaner filterand replace if re-
quired.*X XXX X
Replace theair cleaner filter.X
Replace thespark plugs.5.7L Engine. X
Inspect the front and rear brake linings and
rotors.XX
Replace the air conditioning filter. X X X
Rotate the tires. XXXXXX
SCHEDULE“A”347
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 42,000 48,000 54,000 60,000 66,000 72,000
(Kilometers) (70 000) (80 000) (90 000) (100 000) (110 000) (120 000)
[Months] [42] [48] [54] [60] [66] [72]
Change engine oil and engine oil filter. X X X X X X
Inspect theair cleaner filterand replace if
required.*XXX XX
Replace theair cleaner filter.X
Inspect the front and rear brake linings and
rotors.XX
Replace thespark plugs.5.7L Engine. X
Check and Inspect the accessory drive belt
and tensioner. Replace if required.X
Flush and replace engine coolant at 60 months
if not done at 102,000 miles.X
Check and replace, if necessary, thePCV
valve.*X
Replace the air conditioning filter. X X X
Rotate the tires. X X X X X X
348 SCHEDULE“A”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 78,000 84,000 90,000 96,000 102,000
(Kilometers) (130 000) (140 000) (150 000) (160 000) (170 000)
[Months] [78] [84] [90] [96] [102]
Change engine oil and engine oil filter. X X X X X
Inspect theair cleaner filterand replace if re-
quired.*XX XX
Replace theair cleaner filter.X
Inspect the front and rear brake linings and rotors. X
Check and Inspect the accessory drive belt and ten-
sioner. Replace if required.X
Replace thespark plugs.2.7L, 3.5L Engines. X
Replace thespark plugs.5.7L Engine. X
Check and replace, if necessary, thePCV valve.*‡X
Replace theengine timing belt.3.5L Engine. X
Flush and replace the engine coolant at 102,000
miles if not done at 60 months.X
Replace the air conditioning filter. X X
Rotate the tires. X X X X X
SCHEDULE“A”349
