DODGE MAGNUM 2008 1.G Owners Manual

CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with an oily surface, clean the
bulb with rubbing alcohol.
3 Ð Park/Turn Light BulbMAINTAINING YOUR VEHICLE 4317

Tail/Stop, Turn Signal Light, and Backup Light
1. Open the liftgate.
2. Remove tail light access cover.
3. Push the electrical connector locking tab to the side.
4. Disconnect the electrical connector.5. Remove 1 wing nut from the back of the tail light
assembly.
6. Remove 2 push pin fasteners under the liftgate with a
flat blade tool.
7. Pull tail light assembly clear from vehicle to access
bulbs.
432 MAINTAINING YOUR VEHICLE

8. Turn the appropriate bulb and socket assembly
counter-clockwise to remove it from the tail light assem-
bly.
1 Ð Tail/Stop Light Bulb
2 Ð Turn Signal Light BulbMAINTAINING YOUR VEHICLE 4337

9. Disconnect the bulb from the socket assembly and
install the replacement bulb.
10. Reinstall the bulb and socket assembly into the tail
light assembly, and then turn it clockwise.
11. Reinstall the tail light assembly, fasteners, and elec-
trical connector.
12. Close the liftgate.
3 Ð Backup Light Bulb 434 MAINTAINING YOUR VEHICLE

License Light
1. Remove the screws securing the light to the rear fascia.
2. Remove the bulb and socket assembly.
3. Disconnect the bulb from the socket assembly and
install the replacement bulb.
4. Reinstall the bulb and socket assembly.
5. Reattach the light to the rear fascia, and then install the
screws.
1 Ð License Light Bulb
2 Ð SocketMAINTAINING YOUR VEHICLE 4357

FLUIDS AND CAPACITIES
U.S. Metric
Fuel (approximate)
2.7 Liter Engine 18 gallons 68 liters
3.5 Liter Engine without All Wheel Drive 18 gallons 68 liters
3.5 Liter Engine with All Wheel Drive 19 gallons 72 liters
5.7 Liter Engine 19 gallons 72 liters
Engine Oil-With Filter
2.7 Liter Engine (SAE 5W-20, API Certified) 6.0 qts. 5.7 liters
3.5 Liter Engine (SAE 10W-30, API Certified) 6.0 qts. 5.7 liters
5.7 Liter Engine (SAE 5W-20, API Certified) 7.0 qts. 6.6 liters
436 MAINTAINING YOUR VEHICLE

Cooling System *
2.7 Liter Engine (MopartAntifreeze/Coolant 5 Year/100,000 Mile For-
mula) or equivalent.9.9 qts 9.4 liters
3.5 Liter Engine without All Wheel Drive (MopartAntifreeze/Coolant
5 Year/100,000 Mile Formula) or equivalent.11.1 qts 10.5 liters
3.5 Liter Engine with All Wheel Drive (MopartAntifreeze/Coolant 5
Year/100,000 Mile Formula) or equivalent.11.4 qts 10.8 liters
5.7 Liter Engine without Severe Duty II Cooling System (Mopart
Antifreeze/Coolant 5 Year/100,000 Mile Formula) or equivalent.14.7 qts 13.9 liters
5.7 Liter Engine with Severe Duty II Cooling System (Mopart
Antifreeze/Coolant 5 Year/100,000 Mile Formula) or equivalent.15.1 qts 14.3 liters
* Includes heater and coolant recovery bottle filled to MAX level.
MAINTAINING YOUR VEHICLE 437
7

FLUIDS, LUBRICANTS, AND GENUINE PARTS
Engine
Component Fluids, Lubricants, and Genuine Parts
Engine Coolant MopartAntifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Or-
ganic Additive Technology) or equivalent
Engine Oil (2.7 Liter) Use API Certified SAE 5W-20 Engine Oil meeting the requirements of
DaimlerChrysler Material Standard MS-6395. Refer to the engine oil fill cap
for correct SAE grade.
Engine Oil (3.5 Liter) Use API Certified SAE 10W-30 Engine Oil meeting the requirements of
DaimlerChrysler Material Standard MS-6395. Refer to the engine oil fill cap
for correct SAE grade.
Engine Oil (5.7 Liter) Use API Certified SAE 5W-20 Engine Oil meeting the requirements of
DaimlerChrysler Material Standard MS-6395. Refer to the engine oil fill cap
for correct SAE grade.
Spark Plugs (2.7L) RE14PMC5 (Gap.050 in [1.27 mm])
Spark Plugs (3.5L) ZFR5LP-13G (Gap.050 in [1.27 mm])
Spark Plugs (5.7L) REC14MCC4 (Gap.043 in [1.1 mm])
Oil Filter (2.7 Liter) Mopart05281090 or equivalent.
438 MAINTAINING YOUR VEHICLE

Component Fluids, Lubricants, and Genuine Parts
Oil Filter (3.5 Liter) Mopart05281090 or equivalent.
Oil Filter (5.7 Liter) Mopart05281090 or equivalent.
Fuel Selection (2.7 Liter) 87 Octane
Fuel Selection (3.5 Liter) 87 to 89 Octane
Fuel Selection (5.7 Liter) 87 to 89 Octane
MAINTAINING YOUR VEHICLE 439
7

Chassis
Component Fluids, Lubricants, and Genuine Parts
Automatic Transmission MopartATF+4 Automatic Transmission Fluid.
Brake Master Cylinder MopartDOT 3, SAE J1703 or equivalent should be used. If DOT 3 brake
fluid is not available, then DOT 4 is acceptable. Use only recommended
brake fluids.
Front Axle API GL-5 SAE 75W90 Synthetic Gear Lubricant or equivalent.
Power Steering Reservoir MopartPower Steering Fluid + 4, MopartATF+4 Automatic Transmission
Fluid.
Rear Axle API GL-5 SAE 75W140 Synthetic Gear Lubricant or equivalent.
Transfer Case MopartTransfer Case Lubricant LX, P/N 05170055AA, or equivalent.
440 MAINTAINING YOUR VEHICLE
