DODGE MAGNUM 2008 1.G Owners Manual

FUSES (POWER DISTRIBUTION CENTERS)
Fuses (Front Power Distribution Center)
A power distribution center is located in the engine
compartment. This center contains fuses and relays.
Cavity Car-
tridge
FuseMini
FuseDescription
1 Ð 15 Amp
BlueWasher Motor
2 Ð 25 Amp
NeutralPowertrain Control
Module (PCM)
3 Ð 25 Amp
NeutralIgnition Run/Start
4 Ð 25 Amp
NeutralAlternator/EGR Sole-
noid
5ÐÐÐ
6 Ð 25 Amp
NeutralIgnition Coils/Injectors/
Short Runner Valve
7ÐÐÐ
8 Ð 25 Amp
NeutralStarter
9ÐÐÐ
Front Power Distribution Center
MAINTAINING YOUR VEHICLE 421
7

Cavity Car-
tridge
FuseMini
FuseDescription
10 30 Amp
PinkÐ Windshield Wiper
11 30 Amp
PinkÐ Anti-lock Brakes System
(ABS) Valves - if
equipped
12 40 Amp
GreenÐ Radiator Fan
13 50 Amp
RedÐ Anti-lock Brakes System
(ABS) Pump Motor - if
equipped
14 60 Amp
YellowÐ Radiator Fan
15 50 Amp
RedÐ Radiator Fan
16ÐÐÐ
17ÐÐÐCavity Car-
tridge
FuseMini
FuseDescription
18ÐÐÐ
19ÐÐÐ
20ÐÐÐ
21ÐÐÐ
22ÐÐÐ
422 MAINTAINING YOUR VEHICLE

CAUTION!
²When installing the Power Distribution Center
cover, it is important to ensure the cover is prop-
erly positioned and fully latched. Failure to do so
may allow water to get into the Power Distribution
Center, and possibly result in an electrical system
failure.
²When replacing a blown fuse, it is important to
use only a fuse having the correct amperage rating.
The use of a fuse with a rating other than indicated
may result in a dangerous electrical system over-
load. If a properly rated fuse continues to blow, it
indicates a problem in the circuit that must be
corrected.
Fuses (Rear Power Distribution Center)
There is also a power distribution center located under a
hinged access cover in the load floor in the cargo area.
This center contains fuses and relays.
Opening The Access Panel
MAINTAINING YOUR VEHICLE 423
7

Cavity Car-
tridge
FuseMini
FuseDescription
1 60 Amp
YellowÐ Ignition Off Draw (IOD)
Cavity Car-
tridge
FuseMini
FuseDescription
2 40 Amp
GreenÐ Integrated Power Mod-
ule (IPM)
3ÐÐÐ
4 40 Amp
GreenÐ Integrated Power Mod-
ule (IPM)
5 30 Amp
PinkÐ Heated Seats - if
equipped
6 Ð 20 Amp
YellowFuel Pump
7ÐÐÐ
8 Ð 15 Amp
BlueDiagnostic Link Connec-
tor (DLC)/Wireless Con-
trol Module (WCM)/
Wireless Ignition Node
(WIN)
Rear Power Distribution Center
424 MAINTAINING YOUR VEHICLE

Cavity Car-
tridge
FuseMini
FuseDescription
9 Ð 20 Amp
YellowPower Outlet
10ÐÐÐ
11*ÐÐÐ
12*ÐÐÐ
13*ÐÐÐ
14 Ð 10 Amp
RedAC Heater Control/
Cluster/Security Mod-
ule - if equipped
15 Ð 20 Amp
YellowTrailer Tow Brake Mod-
ule - if equipped
16 Ð 20 Amp
YellowRear Power Outlet
17 Ð 20 Amp
YellowClusterCavity Car-
tridge
FuseMini
FuseDescription
18 Ð 20 Amp
YellowSelectable Power Outlet
19 Ð 10 Amp
RedStop Lights
20 Ð 20 Amp
YellowRear Wiper Motor
21ÐÐÐ
22ÐÐÐ
23ÐÐÐ
24ÐÐÐ
25ÐÐÐ
26ÐÐÐ
27 Ð 10 Amp
RedOccupant Restraint Con-
troller (ORC)
MAINTAINING YOUR VEHICLE 425
7

Cavity Car-
tridge
FuseMini
FuseDescription
28 Ð 10 Amp
RedIgnition Run
29 Ð 5 Amp
OrangeCluster/Electronic Sta-
bility Program (ESP) - if
equipped/Powertrain
Control Module (PCM)/
Stop Light Switch
30 Ð 10 Amp
RedDoor Modules/Power
Mirrors/Steering Con-
trol Module (SCM)
31ÐÐÐ
32ÐÐÐ
33ÐÐÐ
34ÐÐÐCavity Car-
tridge
FuseMini
FuseDescription
35 Ð 5 Amp
OrangeAntenna Module - if
equipped/Power Mir-
rors
36 Ð 20 Amp
YellowHands Free Phone - if
equipped/Video Moni-
tor - if equipped/Radio
37 Ð 15 Amp
BlueTransmission
38 Ð 10 Amp
RedCargo Light/Satellite
Receiver (SDARS) Video
- if equipped/Vehicle
Information Module - if
equipped
39 Ð 10 Amp
RedHeated Mirrors - if
equipped
426 MAINTAINING YOUR VEHICLE

Cavity Car-
tridge
FuseMini
FuseDescription
40 Ð 5 Amp
OrangeAuto Inside Rearview
Mirror - if equipped/
Heated Seats - if
equipped/Switch Bank
41 Ð 10 Amp
RedAC Heater Control/
Headlights/Tire Pres-
sure Monitoring - if
equipped
42 30 Amp
PinkÐ Front Blower Motor
43 30 Amp
PinkÐ Rear Window Defroster
44 20 Amp
BlueÐ Amplifier - if equipped/
Sunroof - if equipped*Cavities 11, 12, and 13 contain self-resetting fuses
(circuit breakers) that are only serviceable by an autho-
rized dealer. The Cluster and the Driver Seat Switch (if
equipped) are fused by the 25 amp circuit breaker in
Cavity 11. The Passenger Seat Switch (if equipped) is
fused by the 25 amp circuit breaker in Cavity 12. The
Door Modules, the Driver Power Window Switch, and
the Passenger Power Window Switch are fused by the 25
amp circuit breaker in Cavity 13. If you experience
temporary or permanent loss of these systems, see your
authorized dealer for service.
MAINTAINING YOUR VEHICLE 427
7

CAUTION!
²When installing the Power Distribution Center
cover, it is important to ensure the cover is prop-
erly positioned and fully latched. Failure to do so
may allow water to get into the Power Distribution
Center, and possibly result in an electrical system
failure.
²When replacing a blown fuse, it is important to
use only a fuse having the correct amperage rating.
The use of a fuse with a rating other than indicated
may result in a dangerous electrical system over-
load. If a properly rated fuse continues to blow, it
indicates a problem in the circuit that must be
corrected.
VEHICLE STORAGE
If you are leaving your vehicle dormant for more than 21
days, you may want to take steps to protect your battery.
You may:
²Disconnect the negative cable from the battery.
²Anytime you store your vehicle, or keep it out of
service (i.e. vacation) for two weeks or more, run the
air conditioning system at idle for about five minutes
in the fresh air and high blower setting. This will
insure adequate system lubrication to minimize the
possibility of compressor damage when the system is
started again.
428 MAINTAINING YOUR VEHICLE

REPLACEMENT LIGHT BULBS
LIGHT BULBS Ð Interior Bulb Number
Rear Courtesy/Reading Lights.............. W5W
Rear Compartment (Liftgate) Light............ 578
Overhead Console Reading Lights............. 578
Visor Vanity Lights.....................A6220
Glove Box Light......................... 194
Door Courtesy.......................... 562
Shift Indicator Light.................JKLE14140
Optional Door Map Pocket /
Cup Holder Lighting....... LED(Serviced at Dealer)
NOTE:For lighted switches, see your dealer for replace-
ment instructions.
All of the interior bulbs are glass wedge base or glass
cartridge types. Aluminum base bulbs are not approved
and should not be used for replacement.LIGHT BULBS Ð Exterior Bulb Number
Low Beam Headlight.....................9006
High Beam Headlight.....................9005
Front Park/Turn Light..................3457AK
Front Fog LightÐIf Equipped............9145/H10
(Serviced at Dealer)
Front Side Marker........194NA (Serviced at Dealer)
Tail/Stop......................3157KP27/7WK
Turn Light.....................3757AP27/7WK
Rear Side Marker................3757APY27/7W
Backup Light......................921/W16W
Center High Mount Stop Light
(CHMSL)............................. LED
(Serviced at Dealer)
License.............................. W5W
MAINTAINING YOUR VEHICLE 429
7

BULB REPLACEMENT
Low Beam Headlight, High Beam Headlight, and
Park/Turn Light
1. Open the hood.
NOTE:Removal of the air cleaner filter housing may be
necessary prior to replacing bulbs in the headlight assem-
bly on the driver side of the vehicle.
2. Twist the appropriate bulb and socket assembly
counter-clockwise and then pull it out of the headlight
assembly.
3. Disconnect the bulb from the socket assembly and
install the replacement bulb.
4. Reinstall the bulb and socket assembly into the head-
light assembly, and then turn it clockwise.
1 Ð Low Beam Headlight Bulb
2 Ð High Beam Headlight Bulb 430 MAINTAINING YOUR VEHICLE
