8W - 80 - 15 PL-RHD 8W-80 CONNECTOR PIN-OUTS
PLR08015
CAV CIRCUIT FUNCTION
1 A142 18DG/OR AUTOMATIC SHUTDOWN RELAY OUTPUT
2 Z1 18BK GROUND
3 K4 20BK/LB SENSOR GROUND
4 K141 20TN/WT DOWNSTREAM HEATED OXYGEN SENSOR SIGNAL
CAV CIRCUIT FUNCTION
1 R45 18DG/LB DRIVER AIRBAG SQUIB LINE 2
2 R43 18BK/LB DRIVER AIRBAG SQUIB LINE 1
YELLOW
DRIVER SIDE
AIRBAG 2 1
CAV CIRCUIT FUNCTION
1 K52 20PK/BK DUTY CYCLE EVAP/PURGE SOLENOID CONTROL
2 F12 20DG/WT FUSED IGNITION SWITCH OUTPUT (RUN/START) BLACK2 1
DUTY CYCLE
EVAP/PURGE
SOLENOID
CAV CIRCUIT FUNCTION
A K4 20BK/LB*SENSOR GROUND
A K4 20BK/RDlSENSOR GROUND
B K2 20TN/DB*ENGINE COOLANT TEMPERATURE SENSOR SIGNAL
B K2 20TN/BKlENGINE COOLANT TEMPERATURE SENSOR SIGNAL
C G20 20VT/YL ENGINE COOLANT TEMPERATURE GAUGE SIGNAL
BLACK
ENGINE COOLANT
TEMPERATURE (ECT)
SENSOR
BA
CB A
C
*2.0L SOHC ENGINEl2.0L DOHC ENGINE
BLACK
2
4
1
3
DOWNSTREAM HEATED
OXYGEN SENSOR
CAV CIRCUIT FUNCTION
1 K35 20GY/YL EXHAUST GAS RECIRCULATION SOLENOID CONTROL
2 F12 18DB/WT FUSED IGNITION SWITCH RELAY OUTPUT BLACK
21
(EGR)
TRANSDUCER
SOLENOID

Downloaded from www.Manualslib.com manuals search engine 978W-1
PL-RHD 8W - 80 - 16 8W-80 CONNECTOR PIN-OUTS
PLR08016
CAV CIRCUIT FUNCTION
1 G6 18GY OIL PRESSURE SWITCH SENSOR
2Ð Ð
1 2
ENGINE OIL
PRESSURE SWITCHGREEN
CAV CIRCUIT FUNCTION
1 L7 20BK/YLHEADLAMP SWITCH FEED TO FRONT FOG LAMP SWITCH
2 L35 20BR/RD FRONT FOG LAMP SWITCH TO RELAY
2L35 20BR/RDFRONT FOG LAMP SWITCH TO REAR FOG LAMP SWITCH
3 Z3 22BK/OR GROUND
FRONT FOG LAMP
SWITCH
CAV CIRCUIT FUNCTION
1 K11 18WT/DB INJECTOR NO. 1 DRIVER
2 A142 18DG/OR AUTOMATIC SHUTDOWN RELAY OUTPUT
FUEL INJECTOR NO. 1
CAV CIRCUIT FUNCTION
1 K12 18TN INJECTOR NO. 2 DRIVER
2 A142 18DG/OR AUTOMATIC SHUTDOWN RELAY OUTPUT
FUEL INJECTOR NO. 2
BLACK
21
BLACK
21
CAV CIRCUIT FUNCTION
1 K13 18YL/WT INJECTOR NO. 3 DRIVER
2 A142 18DG/OR AUTOMATIC SHUTDOWN RELAY OUTPUT
FUEL INJECTOR NO. 3
BLACK
21
FUEL INJECTOR NO. 4
CAV CIRCUIT FUNCTION
1 K14 18LB/BR INJECTOR NO. 4 DRIVER
2 A142 18DG/OR AUTOMATIC SHUTDOWN RELAY OUTPUT
BLACK
21
BLACK
123

Downloaded from www.Manualslib.com manuals search engine 978W-1
8W - 80 - 17 PL-RHD 8W-80 CONNECTOR PIN-OUTS
PLR08017
CAV CIRCUIT FUNCTION
1 Z1 18BK GROUND
2 Z2 18BK GROUND
3 G4 18DB FUEL LEVEL SENSOR SIGNAL
4 A141 18DG/WT FUEL PUMP RELAY OUTPUT
LT GRAY
FUEL PUMP
MODULE 41
BLACK
CAV CIRCUIT FUNCTION
1 A142 18DG/OR AUTOMATIC SHUTDOWN RELAY OUTPUT
2 K20 18DG GENERATOR FIELD DRIVER
GENERATOR 21
CAV CIRCUIT FUNCTION
1 M1 22PK FUSED B(+)
2 Z3 20BK/OR GROUND12
GLOVE BOX
LAMP AND SWITCHGRAY
HEADLAMP DIMMER
AND OPTICAL HORN
SWITCH 41BLACK
CAV CIRCUIT FUNCTION
1 L4 14VT/WT DIMMER SWITCH LOW BEAM OUTPUT
2 L2 14LG HEADLAMP SWITCH OUTPUT
3 L3 14RD/OR DIMMER SWITCH HIGH BEAM OUTPUT
4 L20 14LG/WT FUSED B(+)
BLACK
HEADLAMP
SWITCH 1
2
9
73
4
5
6 8
CAV CIRCUIT FUNCTION
1 E1 20TN PANEL LAMPS DIMMER SWITCH SIGNAL
2 L2 14LG HEADLAMP SWITCH OUTPUT
3 M2 22YL TIME OUT RELAY
4 F33 20PK/RD FUSED B(+)
5G26 20LB KEY-IN IGNITION SWITCH SENSEG26 20LB KEY-IN IGNITION SWITCH SENSE
6G16 20BK/LB LEFT FRONT DOOR JAMB SWITCH SENSEG16 20BK/LB LEFT FRONT DOOR JAMB SWITCH SENSE
7 L20 14LG/WT FUSED B(+)
8 A3 12RD/WT FUSED B(+)
9L7 20BK/YL PARK LAMP SWITCH OUTPUT
L7 20BK/YL PARK LAMP SWITCH OUTPUT
CAV CIRCUIT FUNCTION
1Ð Ð
2 L43 20VT LEFT HEADLAMP FEED
3 Z1 20BK GROUND
4 E2 20OR ILLUMINATION FEED
5 L13 20BR/YL HEADLAMP LEVELING SIGNAL TO MOTORSHEADLAMP LEVELING
SWITCH
12 345
BLACK

Downloaded from www.Manualslib.com manuals search engine 978W-1
PL-RHD 8W - 80 - 18 8W-80 CONNECTOR PIN-OUTS
PLR08018
CAV CIRCUIT FUNCTION
A X2 18DG/RD HORN RELAY OUTPUT
B Z1 20BK GROUND
BLACK
BA
HORN NO. 1
CAV CIRCUIT FUNCTION
A X2 18DG/RD HORN RELAY OUTPUT
B Z1 20BK GROUND
BLACK
BA
HORN NO.2
CAV CIRCUIT FUNCTION
A K4 18BK/LB SENSOR GROUND
B K21 18BK/RD INTAKE AIR TEMPERATURE SENSOR SIGNAL
C K6 18VT/WT 5 VOLT SUPPLY
D K1 18DG/RD MAP SENSOR SIGNAL
BLACK
AD
(IAT/MAP) SENSOR
CAV CIRCUIT FUNCTION
1 K59 18VT IDLE AIR CONTROL MOTOR NO. 4 DRIVER
2 K40 18BR/WT IDLE AIR CONTROL MOTOR NO. 1 DRIVER
3 K60 18YL/BK IDLE AIR CONTROL MOTOR NO. 2 DRIVER
4 K39 18GY/RD IDLE AIR CONTROL MOTOR NO. 3 DRIVERIDLE AIR
CONTROL (IAC)
MOTOR
CAV CIRCUIT FUNCTION
1 K17 18DB/TN IGNITION COIL NO. 2 DRIVER
2 A142 18DG/OR AUTOMATIC SHUTDOWN RELAY OUTPUT
3 K19 18BK/GY IGNITION COIL NO. 1 DRIVER
IGNITION
COIL PACK
14
BLACK
31
BLACK

Downloaded from www.Manualslib.com manuals search engine 978W-1
8W - 80 - 35 PL-RHD 8W-80 CONNECTOR PIN-OUTS
PLR08035
CAV CIRCUIT FUNCTION
1 L60 22TN RIGHT TURN SIGNAL
2Ð Ð
3 L62 20BR/RD RIGHT REAR STOP/TURN SIGNAL LAMP OUTPUT
4 L32 20PK COMBINATION FLASHER OUTPUT
5 L5 20BK FUSED IGNITION SWITCH OUTPUT (RUN)
6 L9 22BK/WT FUSED B(+)
7Ð Ð
8Ð Ð
9 L63 20DG/RD LEFT REAR STOP/TURN SIGNAL LAMP OUTPUT
10 L61 22LG LEFT TURN SIGNAL
11 L55 20BK/YL COMBINATION FLASHER INPUT
BLACK
TURN
SIGNAL/HAZARD
SWITCH 61
11 7
CAV CIRCUIT FUNCTION
1Ð Ð
2 F12 18DG/WT FUSED IGNITION SWITCH OUTPUT (RUN/START)
3 K106 18WT/LG VAPOR CANISTER SOLENOID DRIVER
4 K107 18OR VAPOR CANISTER PUMP SWITCH DRIVER
BLACK
VAPOR CANISTER
LEAK DETECTOR 4 1
CAV CIRCUIT FUNCTION
1 K7 18OR 8 VOLT SUPPLY
2 K4 18BK/LB SENSOR GROUND
3 G7 18WT/OR VEHICLE SPEED SENSOR SIGNAL
VEHICLE SPEED
SENSORBLACK
31
CAV CIRCUIT FUNCTION
1 A142 18DG/OR AUTOMATIC SHUTDOWN RELAY OUTPUT
2 Z1 18BK GROUND
3 K4 20BK/LB SENSOR GROUND
4 K41 20BK/DG UPSTREAM HEATED OXYGEN SENSOR SIGNAL
UPSTREAM HEATED
OXYGEN SENSOR
GRAY
2
4
1
3
