DODGE POWER WAGON 2005 2.G Owners Manual

Miles 93,000 96,000 99,000 100,000 102,000
(Kilometers) (149 000) (154 000) (158 000) (160 000) (163 000)
Change engine oil and engine oil filter, or at 3
months, whichever comes first.XXX X
Lubricate Drive Shaft Fitting. X X X X X
Rotate tires. X X
Lubricate tie rod end links. X X X X X
Flush and replace engine coolant, if not done at 60
months.X
Flush and replace Power Steering Fluid. X
Inspect brake linings. X
SCHEDULE“B”421
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 105,000 108,000 111,000 114,000 117,000 120,000
(Kilometers) (168 000) (173 000) (178 000) (182 000) (187 000) (192 000)
Change engine oil and engine oil filter, or at 3
months, whichever comes first.X X XXXX
Lubricate Drive Shaft Fitting. X XXXXX
Rotate tires. X X X
Lubricate tie rod end links. X XXXXX
Drain and refill transfer case fluid.X
Change rear axle fluid. X X
Change front axle fluid. X X
Change 6-spd manual transmission (G-56)
fluid.X
Inspect brake linings. X X
Inspect engine air cleaner filter, replace if
necessary.XX
Replace spark plugs.X
Replace ignition cables.X
422 SCHEDULE“B”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 105,000 108,000 111,000 114,000 117,000 120,000
(Kilometers) (168 000) (173 000) (178 000) (182 000) (187 000) (192 000)
Inspect PCV valve, replace as necessary.**X
Inspect auto tension drive belt and replace if
required.XX
Drain and refill automatic tranmission fluid
and change main sump and spin-on cooler
return filter (if equipped) [545RFE only].X
* This applies only if the vehicle is used for frequent
trailer towing, snowplowing, fleet vehicle or commercial
service.
**This maintenance is recommend, but not required.Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.
SCHEDULE“B”423
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Schedule“A”
Miles 6,000 12,000 18,000 24,000 30,000
(Kilometers) (10 000) (19 000) (29 000) (38 000) (48 000)
[Months] [6] [12] [18] [24] [30]
Change engine oil and engine oil filter. X X X X X
Lubricate Front Prop Shaft fitting. X X X X v
Rotate tires. X X X X X
Check transfer case fluid level.X
Lubricate tie rod end links. X X X X X
Inspect brake linings. X
Inspect engine air cleaner filter, replace if neces-
sary.X
Replace spark plugs.X
424 SCHEDULE“A”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 36,000 42,000 48,000 54,000 60,000 66,000
(Kilometers) (58 000) (67 000) (77 000) (84 000) (96 000) (106 000)
[Months] [36] [42] [48] [54] [60] [66]
Change engine oil and engine oil filter. X XXXXX
Lubricate Front Prop Shaft fitting. X XXXXX
Rotate tires. X XXXXX
Check transfer case fluid level. X
Lubricate tie rod end links. X XXXXX
Flush and replace engine coolant at 60
months, regardless of mileage.X
Inspect brake linings. X X
Inspect engine air cleaner filter, replace if
necessary.X
Replace spark plugs.X
Inspect PCV valve, replace as necessary.**X
Replace ignition cables.X
SCHEDULE“A”425
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 72,000 78,000 84,000 90,000 96,000 100,000
(Kilometers) (115000) (125 000) (134 000) (144 000) (154 000) 160 000
[Months] [72] [78] [84] [90] [96]
Change engine oil and engine oil filter. X X X X X
Lubricate Front Prop Shaft fitting. X X X X X
Rotate tires. X X X X X
Lubricate tie rod end links. X X X X X
Check transfer case fluid level. X
Flush and replace Power Steering Fluid. X
Inspect brake linings. X X
Inspect engine air cleaner filter, replace if
necessary.X
Replace spark plugs.X
Inspect PCV valve, replace as necessary.**X
Inspect auto tension drive belt and replace if
required.X
426 SCHEDULE“A”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 102,000 108,000 114,000 120,000
(Kilometers) (163 000) (173 000) (182 000) (192 000)
[Months] [102] [108] [114] [120]
Change engine oil and engine oil filter. X X X X
Lubricate Front Prop Shaft fitting. X X X X
Rotate tires. X X X X
Drain and refill transfer case fluid.X
Flush and replace engine coolant, if not done at 60 mos. X
Lubricate tie rod end links. X X X X
Inspect brake linings. X
Inspect auto tension drive belt and replace if required. X X
Replace ignition cables.X
Inspect engine air cleaner filter, replace if necessary.X
Replace spark plugs.X
Inspect PCV Valve, replace as necessary.** X
SCHEDULE“A”427
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.
**This maintenance is recommend, but not required.
WARNING!
You can be badly injured working on or around a
motor vehicle. Do only that service work for which
you have the knowledge and the right equipment. If
you have any doubt about your ability to perform a
service job, take your vehicle to a competent me-
chanic.
428 SCHEDULE“A”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

IF YOU NEED CONSUMER ASSISTANCE
CONTENTS

Suggestions For Obtaining Service For Your
Vehicle..............................430
▫Prepare For The Appointment............430
▫Prepare A List........................430
▫Be Reasonable With Requests.............430

If You Need Assistance...................430
Warranty Information....................433

MoparParts.........................435

Reporting Safety Defects..................435
▫In Canada..........................435

Publication Order Forms..................436
9

SUGGESTIONS FOR OBTAINING SERVICE FOR
YOUR VEHICLE
Prepare For The Appointment
If you’re having warranty work done, be sure to have the
right papers with you. Take your warranty folder. All
work to be performed may not be covered by the
warranty, discuss additional charges with the service
manager. Keep a maintenance log of your vehicle’s
service history. This can often provide a clue to the
current problem.
Prepare A List
Make a written list of your vehicle’s problems or the
specific work you want done. If you’ve had an accident,
or work done that is not on your maintenance log, let the
service advisor know.
Be Reasonable With Requests
If you list a number of items, and you must have your
vehicle by the end of the day, discuss the situation with
the service advisor and list the items in order of priority.
At many dealers you may obtain a rental vehicle at a
minimal daily charge. If you need a rental, it is advisable
to make these arrangements when you call for an ap-
pointment.
IF YOU NEED ASSISTANCE
The manufacturer and its dealers are vitally interested in
your satisfaction. We want you to be happy with our
products and services.
430 IF YOU NEED CONSUMER ASSISTANCE
