DODGE POWER WAGON 2005 2.G Owners Manual

•Heavy Loading.
•Taxi, police, or delivery service (commercial service).
•Off-road or desert operation.
•If equipped for and operating with E-85 (ethanol)
fuel.
NOTE:IfANYof these apply to you then change your
engine oil every 3,000 miles (5 000 km) or 3 months,
whichever comes first and follow schedule“B”of the
Maintenance Schedulessection of this manual.
NOTE:IfANYof these apply to you then flush and
replace your engine coolant every 102,000 miles (163 000
km) or 60 months, whichever comes first and follow
schedule“B”of theMaintenance Schedulessection of
this manual.
NOTE:Most vehicles are operated under the conditions
listed for ScheduleB.Second is Schedule“A”. It is for vehicles that are not
operated under any of the conditions listed under Sched-
uleB.
Use the schedule that best describes your driving condi-
tions. Where time and mileage are listed, follow the
interval that occurs first.
NOTE:Under no circumstances should oil change in-
tervals exceed 6000 miles (10 000 km) or 6 months
whichever comes first.
CAUTION!
Failure to perform the required maintenance items
may result in damage to the vehicle.
MAINTENANCE SCHEDULES 411
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

At Each Stop for Fuel
•Check the engine oil level about 5 minutes after a fully
warmed engine is shut off. Checking the oil level while
the vehicle is on level ground will improve the accu-
racy of the oil level reading. Add oil only when the
level is at or below the ADD or MIN mark.
•Check the windshield washer solvent and add if
required.
Once a Month
•Check tire pressure and look for unusual wear or
damage.
•Inspect the battery and clean and tighten the terminals
as required.
•Check the fluid levels of coolant bottle, brake master
cylinder, and transmission and add as needed.
•Check all lights and all other electrical items for correct
operation.
At Each Oil Change
•Change the engine oil filter.
•Lubricate the driveshaft grease fitting and tie rod end
links.
•Inspect the exhaust system.
•Inspect the brake hoses.
•Inspect the CV joints (if equipped) and front suspen-
sion components.
•Check the automatic transmission fluid level.
•Check the manual transmission fluid level.
•Check the coolant level, hoses, and clamps.
412 MAINTENANCE SCHEDULES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Schedule“B”
Follow schedule“B”if you usually operate your vehicle
under one or more of the following conditions.
•Day or night temperatures are below 32°F(0°C).
•Stop and go driving.
•Extensive engine idling.
•Driving in dusty conditions.
•Short trips of less than 10 miles (16 km).
•More than 50% of your driving is at sustained high
speeds during hot weather, above 90°F C (32°).
•Trailer towing.
•Snowplowing.
•Heavy Loading.
•Taxi, police, or delivery service (commercial service).
•Off-road or desert operation.
•If equipped for and operating with E-85 (ethanol)
fuel.
NOTE:IfANYof these apply to you then change your
engine oil every 3,000 miles (5 000 km) or 3 months,
whichever comes first and follow schedule“B”of the
Maintenance Schedulessection of this manual.
NOTE:IfANYof these apply to you then flush and
replace your engine coolant every 102,000 miles (163 000
km) or 60 months, whichever comes first and follow
schedule“B”of theMaintenance Schedulessection of
this manual.
If none of these apply to you, then change your engine oil
at every interval shown on scheduleAof theMainte-
nance Schedulessection of this manual.
SCHEDULE“B”413
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 3,000 6,000 9,000 12,000 15,000
(Kilometers) (5 000) (10 000) (14 000) (19 000) (24 000)
Change engine oil and engine oil filter, or at 3
months, whichever comes first.X X XXX
Lubricate Drive Shaft Fitting. X X X X X
Rotate tires. X X
Lubricate tie rod end links. X X X X X
Change rear axle fluid.X
Change front axle fluid.X
Inspect brake linings.X
Inspect engine air cleaner filter, replace if neces-
sary.X
414 SCHEDULE“B”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 18,000 21,000 24,000 27,000 30,000
(Kilometers) (29 000) (34 000) (38 000) (43 000) (48 000)
Change engine oil and engine oil filter, or at 3
months, whichever comes first.X XXX
Lubricate Drive Shaft Fitting. X X X X X
Rotate tires. X X X
Lubricate tie rod end links. X X X X X
Change rear axle fluid.X
Change front axle fluid.X
Check transfer case fluid level.X
Inspect brake linings. X
Inspect engine air cleaner filter, replace if neces-
sary.X
Replace spark plugs.X
Inspect PCV valve, replace as necessary.**X
SCHEDULE“B”415
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 33,000 36,000 39,000 42,000 45,000
(Kilometers) (53 000) (58 000) (62 000) (67 000) (72 000)
Change engine oil and engine oil filter, or at 3
months, whichever comes first.X X XXX
Lubricate Drive Shaft Fitting. X X X X X
Rotate tires. X X
Lubricate tie rod end links. X X X X X
Change rear axle fluid.X
Change front axle fluid.X
Inspect brake linings. X
Inspect engine air cleaner filter, replace if neces-
sary.X
416 SCHEDULE“B”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 48,000 51,000 54,000 57,000 60,000
(Kilometers) (77 000) (82 000) (86 000) (91 000) (96 000)
Change engine oil and engine oil filter, or at 3
months, whichever comes first.X X XXX
Lubricate Drive Shaft Fitting. X X X X X
Rotate tires. X X X
Lubricate tie rod end links. X X X X X
Drain and refill transfer case fluid.X
Change rear axle fluid.X
Change front axle fluid.X
Change 6-spd manual transmission (G-56) fluid. X
Inspect brake linings. X X
Inspect engine air cleaner filter, replace if neces-
sary.X
Replace spark plugs.X
Replace ignition cables.X
Inspect PCV valve, replace as necessary.**X
SCHEDULE“B”417
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 48,000 51,000 54,000 57,000 60,000
(Kilometers) (77 000) (82 000) (86 000) (91 000) (96 000)
Drain and refill automatic tranmission fluid and
change main sump filter (545RFE only).X
418 SCHEDULE“B”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 63,000 66,000 69,000 72,000 75,000
(Kilometers) (101 000) (106 000) (110 000) (115 000) (120 000)
Change engine oil and engine oil filter, or at 3
months, whichever comes first.X X XXX
Lubricate Drive Shaft Fitting. X X X X X
Rotate tires. X X
Lubricate tie rod end links. X X X X X
Inspect engine air cleaner filter.X
Change rear axle fluid.X
Change front axle fluid.X
Inspect brake linings.X
Inspect auto tension drive belt and replace if re-
quired.X
Flush and replace engine coolant at 60 months, if
not done at 102, 000 miles (163 000 km).X
SCHEDULE“B”419
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 78,000 81,000 84,000 87,000 90,000
(Kilometers) (125 000) (130 000) (134 000) (139 000) (144 000)
Change engine oil and engine oil filter, or at 3
months, whichever comes first.X X XXX
Lubricate Drive Shaft Fitting. X X X X X
Rotate tires. X X X
Lubricate tie rod end links. X X X X X
Change rear axle fluid.X
Change front axle fluid.X
Check transfer case fluid level.X
Inspect brake linings. X
Inspect engine air cleaner filter, replace if neces-
sary.X
Replace spark plugs.X
Inspect PCV valve, replace as necessary.**X
Inspect auto tension drive belt and replace if re-
quired.X
