Alignment DODGE RAM 1500 1998 2.G Workshop Manual

NOTE:
All measurements are in mm.
O/F = Over Flush
U/F = Under Flush
DIMENSION DESCRIPTION GAP FLUSH
1 Roof to rear door Ð U/F 6.0   1.5
Parallel within 1.5
2 Quarter to rear door 5.0   1.5
Parallel within 2.00.0   1.5
3 Rear door to quarter character line
alignmentÐ Up/Down 0.0   1.5
4 Rear door to front door character line
alignmentÐ Up/Down 0.0   1.5
5 Rear door to front door 5.0   1.5
Parallel within 2.00.0   1.5
Fig. 2 GAP & FLUSH - QUAD CAB
DRBODY STRUCTURE 23 - 97
GAP AND FLUSH (Continued)

NOTE:
All measurements are in mm.
O/F = Over Flush
U/F = Under Flush
DIMENSION DESCRIPTION GAP FLUSH
1 Tailgate to outer box
(Up/Down surface only)Ð 0.0   1.5
Parallel within 1.0
2 Cab Back to box front 31.0   5.0
Parallel within 3.0Ð
3 Fuel door to outer box 5.0   1.5
Parallel within 1.00.0   1.5
4 Cab to box side 31.0   5.0
Parallel within 3.04.0   2.5 (Standard Cab)
O/F 5.0   2.5 (Quad Cab)
5 Cab to box character line alignment Ð Up/Down 0.0   3.0
6 Tailgate to outer box 5.0   2.0
Parallel within 1.0U/F 1.5   1.5
7 Bumper to outer box 24.75   5.0 (F/A)
23.75   5.0 (C/C)
Parallel within 5.0Ð
8 Tailgate to outer box character line
adjustmentÐ Up/Down 0.0   1.5
9 Bumper to tailgate 30.25   3.0
Parallel within 4.0Ð
Fig. 3 GAP & FLUSH - PICKUP BOX
23 - 98 BODY STRUCTUREDR
GAP AND FLUSH (Continued)

5.7L V-8
The 5.7L V-8 engine is equipped with a closed
crankcase ventilation system and a Positive Crank-
case Ventilation (PCV) valve.
This system consists of:
²a PCV valve mounted into the top of the intake
manifold, located to the right / rear of the throttle
body (Fig. 12). The PCV valve is sealed to the intake
manifold with 2 o-rings (Fig. 13).
²passages in the intake manifold.
²tubes and hoses to connect the system compo-
nents.
5.9L V-8
The 5.9L V-8 engine is equipped with a closed
crankcase ventilation system and a positive crank-
case ventilation (PCV) valve.
This system consists of a PCV valve mounted on
the cylinder head (valve) cover with a hose extending
from the valve to the intake manifold (Fig. 14).
Another hose connects the opposite cylinder head
(valve) cover to the air cleaner housing to provide a
source of clean air for the system. A separate crank-
case breather/filter is not used.
Fig. 11 CRANKCASE BREATHERS (2) - 3.7L V-6 /
4.7L V-8
1 - CRANKCASE BREATHERS (2)
2 - REAR OF ENGINE
Fig. 12 LOCATION 5.7L PCV VALVE
1 - TOP OF INTAKE MANIFOLD
2 - THROTTLE BODY
3 - AIR RESONATOR
4 - P C V VA LV E
Fig. 13 5.7L PCV VALVE
1 - P C V VA LV E
2 - O-RINGS
3 - ALIGNMENT TABS
25 - 18 EVAPORATIVE EMISSIONSDR
PCV VALVE (Continued)
