FUEL INJECTOR PACK NO. 2 (DIESEL)-4WAY
CAV CIRCUIT FUNCTION
1 K229 14BR/LB ENG - INJECTOR HIGH SIDE DRIVER - BANK 2
1 K229 14TN/PK ENG - INJECTOR HIGH SIDE DRIVER - BANK 2
2 K14 14BR/TN INJECTOR CONTROL NO. 4
3 K227 14BR/LG ENG - INJECTOR HIGH SIDE DRIVER - BANK 1
4 K13 14BR/LB INJECTOR CONTROL NO. 3
4 K13 14TN INJECTOR CONTROL NO. 3
FUEL INJECTOR PACK NO. 3 (DIESEL)-4WAY
CAV CIRCUIT FUNCTION
1 K229 14BR/LB ENG - INJECTOR HIGH SIDE DRIVER - BANK 2
1 K229 14TN/PK ENG - INJECTOR HIGH SIDE DRIVER - BANK 2
2 K58 14BR/VT INJECTOR CONTROL NO. 6
3 K229 14TN/PK ENG - INJECTOR HIGH SIDE DRIVER - BANK 2
3 K229 14BR/LB ENG - INJECTOR HIGH SIDE DRIVER - BANK 2
4 K38 14BR/OR INJECTOR CONTROL NO. 5
4 K38 14GY INJECTOR CONTROL NO. 5
FUEL PUMP MODULE - LT GRAY 4 WAY
CAV CIRCUIT FUNCTION
1 Z201 12BK/OR GROUND
2 K900 18DB/DG SENSOR GROUND
3 N4 18DB/WT FUEL LEVEL SENSOR SIGNAL
4 A109 14OR/RD FUEL PUMP RELAY OUTPUT
FUEL PUMP MOTOR (DIESEL)-2WAY
CAV CIRCUIT FUNCTION
1 K31 18BR FUEL PUMP RELAY CONTROL
2 K65 18BR/LB FUEL PUMP RELAY RETURN
8W - 80 - 66 8W-80 CONNECTOR PIN-OUTSDR

GENERATOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K20 18BR/GY GEN FIELD CONTROL
2 Z816 18BK (DIESEL) GROUND
2 Z20 18BR/BK (NGC) GROUND
GLOVE BOX LAMP AND SWITCH - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 Z328 20BK/TN GROUND
2 M228 18YL/LB COURTESY LAMP DRIVER
HANDS FREE MODULE (TELEMATICS) - 22 WAY
CAV CIRCUIT FUNCTION
1 A114 18GY/RD FUSED B(+)
2 F983 20PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
3- -
4- -
5 X722 18LB/DG MICROPHONE 2 IN (+)
6- -
7- -
8 X703 18DG/OR LEFT AUDIO OUTPUT
9 X704 18DG/YL RIGHT AUDIO OUTPUT
10 X795 18DG HANDS FREE AUDIO OUTPUT COMMON
11 - -
12 - -
13 - -
14 D25 20WT/VT PCI BUS
15 X730 18GY/YL VOICE RECOGNITION/PHONE SWITCH SIGNAL
16 X712 18DG/LB MICROPHONE 1 IN (+)
17 X792 18LB/DG MICROPHONE IN (-)
18 X735 22NA HANDSFREE MICROPHONE SHIELD
19 - -
20 X793 18DG/YL HANDSFREE MICROPHONE HSD FEED
21 X835 18OR/GY SENSOR GROUND
22 Z970 18BK GROUND
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 67

HEADLAMP SWITCH - BLACK 8 WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3 E19 20OR/BR PANEL LAMPS DIMMER SIGNAL
4 Z407 20BK/OR GROUND
5 L89 20WT/YL (FOG LAMPS) FOG LAMP RELAY OUTPUT
6 E2 20OR/BR PANEL LAMPS DIMMER SIGNAL
7 L115 20WT/YL HEADLAMP SWITCH RETURN
8 L116 20WT/LG HEADLAMP SWITCH SIGNAL
HEADLAMP-LEFT - BLUE 3 WAY
CAV CIRCUIT FUNCTION
A L43 18WT/DB LEFT LOW BEAM OUTPUT
B Z345 18BK/LB GROUND
C L33 18WT/LG LEFT HIGH BEAM OUTPUT
HEADLAMP-RIGHT - BLUE 3 WAY
CAV CIRCUIT FUNCTION
A L44 18WT/TN RIGHT LOW BEAM OUTPUT
B Z346 18BK/LG GROUND
C L34 18WT/GY RIGHT HIGH BEAM OUTPUT
HEATED SEAT CUSHION-DRIVER - BLUE 4 WAY
CAV CIRCUIT FUNCTION
1 P187 18LG/BR DRIVER SEAT TEMPERATURE SENSOR INPUT
2 Z939 20BK GROUND
3 P53 20LG/OR DRIVER SEAT TEMPERATURE 5 VOLT SUPPLY
4 P89 20LG/OR SEAT HEATER DRIVER
8W - 80 - 68 8W-80 CONNECTOR PIN-OUTSDR

HEATED SEAT CUSHION-PASSENGER - BLUE 4 WAY
CAV CIRCUIT FUNCTION
1 P188 18LG/VT PASSENGER SEAT TEMPERATURE SENSOR INPUT
2 Z939 20BK GROUND
3 P54 20OR/LG PASSENGER SEAT TEMPERATURE 5 VOLT SUPPLY
4 P89 20LG/OR SEAT HEATER DRIVER
HEATED SEAT SWITCH-DRIVER-6WAY
CAV CIRCUIT FUNCTION
1 P81 20TN/LB DRIVER SEAT LOW HEAT LED DRIVER
2 P301 20LG/OR PANEL LAMPS DRIVER
3 Z301 20TN/BK GROUND
4 P85 20LG/WT HEATED SEAT SWITCH SUPPLY
5 P83 20TN/WT DRIVER SEAT HIGH HEAT LED DRIVER
6 P7 20LG/DG DRIVER SEAT HEATER MUX SWITCH
HEATED SEAT SWITCH-PASSENGER-6WAY
CAV CIRCUIT FUNCTION
1 P82 20TN/DG PASSENGER SEAT LOW HEAT LED DRIVER
2 P301 20LG/OR PANEL LAMPS DRIVER
3 Z302 20LG/BK GROUND
4 P85 20LG/WT HEATED SEAT SWITCH SUPPLY
5 P84 20TN/VT PASSENGER SEAT HIGH HEAT LED DRIVER
6 P8 20LG/WT PASSENGER SEAT HEATER MUX SWITCH
HORN SWITCH - WHITE 2 WAY
CAV CIRCUIT FUNCTION
1 X3 20DG/VT HORN SWITCH SENSE
2- -
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 69

INLET AIR TEMPERATURE SENSOR-4WAY
CAV CIRCUIT FUNCTION
1 K690 18BR/YL (A/T) INLET AIR TEMPERATURE/PRESSURE RETURN
1 K690 18DG/YL (M/T) INLET AIR TEMPERATURE/PRESSURE RETURN
2 K615 18VT/WT (A/T) INLET AIR TEMPERATURE SENSE
2 K615 18BR/WT (M/T) INLET AIR TEMPERATURE SENSE
3 K668 18BR (A/T) SUPPLY VOLTAGE
3 K668 18LG (M/T) SUPPLY VOLTAGE
4 K616 18BR/YL INLET AIR PRESSURE SENSE
INPUT SPEED SENSOR (45RFE) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 T52 18DG/OR INPUT SPEED SENSOR SIGNAL
2 T13 18DG/VT SPEED SENSOR GROUND
INSTRUMENT CLUSTER C1 - WHITE 26 WAY
CAV CIRCUIT FUNCTION
1 P1 18TN/LG (SLT) DOOR UNLOCK DRIVER LEFT FRONT
2 A941 18RD FUSED B(+)
3 K32 18DB/YL BTSI SOLENOID CONTROL
4- -
5- -
6- -
7 E16 20OR/GY PANEL LAMPS DRIVER
8 E14 20OR/TN PANEL LAMPS DRIVER
9 E19 20OR/BR PANEL LAMPS DIMMER SIGNAL
10 P393 18LG (SLT) DOOR LOCK DRIVER LEFT DOORS
11 P392 18LG/DB (SLT) DOOR LOCK DRIVER RIGHT DOORS
12 - -
13 Z921 18BK GROUND
14 Z108 20BK/LG GROUND
15 M288 18YL/GY FUSED B(+)
16 P85 20LG/WT (SLT+) HEATED SEAT SWITCH SUPPLY
17 M228 18YL/LB (SLT) COURTESY LAMP DRIVER
18 L14 20WT/TN CARGO LAMP DRIVER
19 P301 20LG/OR (SLT+) PANEL LAMPS DRIVER
20 E11 20OR/DB (SLT) PANEL LAMPS DRIVER
21 M20 20YL/LB COURTESY LAMPS DRIVER
22 M22 20YL/OR COURTESY LAMPS DRIVER
23 P5 18TN/OR (SLT) DOOR UNLOCK DRIVER LEFT REAR
24 G778 18VT/LB (SLT) DOOR UNLOCK DRIVER RIGHT DOORS
25 A944 20RD FUSED B(+)
26 A944 20RD FUSED B(+)
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 71

INSTRUMENT CLUSTER C2 - GRAY 16 WAY
CAV CIRCUIT FUNCTION
1 G194 20VT/LG WASH/BEAM SELECT SWITCH SIGNAL
2 G160 20VT/LG (SLT)8PASSENGER DOOR LOCK SWITCH MUX
3 G161 20VT/DG (SLT) DRIVER DOOR LOCK SWITCH MUX
4 E2 20OR/BR PANEL LAMPS DIMMER SIGNAL
5 L116 20WT/LG HEADLAMP SWITCH SIGNAL
6- -
7 G163 20VT/LB (SLT) DRIVER CYLINDER LOCK SWITCH MUX
8 L12 20WT/OR TURN LAMPS SWITCH SIGNAL
9- -
10 W52 20BR/YL INTERMITTENT WIPER SWITCH SIGNAL
11 T117 20DG/YL TRANS RANGE SENSOR ELECTRONIC CLUSTER 5
VOLT SUPPLY
12 X20 20GY/WT (SLT PREMIUM RADIO) RADIO CONTROL MUX
13 - -
14 - -
15 - -
16 - -
INSTRUMENT CLUSTER C3 - GRAY 26 WAY
CAV CIRCUIT FUNCTION
1 G75 20VT DRIVER DOOR AJAR SWITCH SENSE
2 G77 20VT/GY LEFT REAR DOOR AJAR SWITCH SENSE
3 G76 20VT/YL RIGHT REAR DOOR AJAR SWITCH SENSE
4 G74 20VT/WT PASSENGER DOOR AJAR SWITCH SENSE
5- -
6- -
7 K77 18BR/WT TRANSFER CASE POSITION SENSOR INPUT
8 L900 20WT/YL WIPER/TURN/BEAM SELECT SWITCH RETURN
9 L115 20WT/YL HEADLAMP SWITCH RETURN
10 T917 20YL/TN TRANS RANGE SENSOR ELECTRONIC CLUSTER MUX
11 - -
12 - -
13 Z18 20BK/LB GROUND
14 X3 20DG/VT HORN SWITCH SENSE
15 L50 18WT/TN BRAKE LAMP SWITCH OUTPUT
16 G15 20VT/TN KEY IN IGNITION SWITCH SENSE
17 - -
18 - -
19 D25 20WT/VT PCI BUS
20 G10 20VT/LG SEAT BELT SWITCH SENSE
21 - -
22 B25 20DG/WT PARK BRAKE SWITCH SENSE
23 F983 20PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
24 F1 16PK/WT FUSED IGNITION SWITCH OUTPUT (OFF-RUN-START)
25 F21 20PK/DG FUSED IGNITION SWITCH OUTPUT (RUN-START)
26 A114 18GY/RD FUSED B(+)
8W - 80 - 72 8W-80 CONNECTOR PIN-OUTSDR

INTAKE AIR TEMPERATURE SENSOR (GAS) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K900 18DB/DG SENSOR GROUND
2 K21 18DB/LG IAT SIGNAL
INTAKE AIR TEMPERATURE/MANIFOLD ABSOLUTE PRESSURE SENSOR (DIESEL)-4WAY
CAV CIRCUIT FUNCTION
A K916 18BR/OR SENSOR GROUND
B K21 18DB/LG INTAKE AIR TEMPERATURE SENSOR SIGNAL
C F855 18PK/YL 5 VOLT SUPPLY
D K37 18LB (A/T) BOOST PRESSURE SENSOR SIGNAL
D K37 18BR/OR (M/T) BOOST PRESSURE SENSOR SIGNAL
INTEGRATED POWER MODULE C1 - 26 WAY
CAV CIRCUIT FUNCTION
1 A960 14RD (DIESEL) FUSED B(+)
1 A16 16RD/BR (NGC) FUSED B(+)
2 F21 20PK/DG FUSED IGNITION SWITCH OUTPUT (RUN-START)
3- -
4 F500 20DG/PK FUSED IGNITION SWITCH OUTPUT (RUN)
5 L673 18YL TRAILER TOW LEFT TURN RELAY OUTPUT
6- -
7 L674 18LG TRAILER TOW RIGHT TURN RELAY OUTPUT
8 A981 14RD FUSED B(+)
9 A114 18GY/RD FUSED B(+)
10 L70 18WT/GY FUSED PARK LAMP RELAY OUTPUT
11 F951 16PK/LG FUSED IGNITION SWITCH OUTPUT (RUN-START)
12 A941 18RD FUSED B(+)
13 A919 20RD FUSED B(+)
14 X2 18DG/OR HORN RELAY OUTPUT
15 - -
16 A103 18GY/RD FUSED B(+)
17 L678 18BR PARK LAMP RELAY OUTPUT
18 - -
19 L7 18WT/YL FUSED PARK LAMP RELAY OUTPUT
20 - -
21 - -
22 - -
23 - -
24 - -
25 - -
26 - -
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 73

INTEGRATED POWER MODULE C2 - WHITE 15 WAY
CAV CIRCUIT FUNCTION
1 A991 10RD FUSED B(+)
2 A34 16RD/WT (ELECTRONIC TRANS-
FERCASE))FUSED B(+)
3 A405 18RD/DB FUSED B(+)
4- -
5 A210 12OR/RD FUSED B(+)
6 A970 10RD FUSED B(+)
7 A100 14RD/VT FUSED B(+)
8 A111 14DG/RD FUSED B(+)
9 A205 18RD/OR FUSED B(+)
10 A921 16RD FUSED B(+)
11 - -
12 F984 18PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
13 A116 18YL/RD FUSED B(+)
14 A951 16RD FUSED B(+)
15 - -
INTEGRATED POWER MODULE C3 - 16 WAY
CAV CIRCUIT FUNCTION
1 W10 20BR WASHER PUMP MOTOR CONTROL
2 L62 18WT/YL RIGHT REAR TURN LAMP DRIVER
3 Z117 18BK/WT GROUND
4 G31 20VT/LG (DIESEL) AAT SIGNAL
5 Z118 18BK/YL GROUND
6 L1 18WT/LG BACKUP LAMP FEED
7- -
8- -
9- -
10 D25 20VT/PK PCI BUS
11 - -
12 L61 18WT/LG LEFT FRONT TURN LAMP DRIVER
13 L53 18DG/WT LEFT STOP LAMP FEED
14 L63 18WT/DG LEFT REAR TURN LAMP DRIVER
15 L60 18WT/TN RIGHT FRONT TURN LAMP DRIVER
16 G180 20VT/YL (DIESEL) SENSOR GROUND
8W - 80 - 74 8W-80 CONNECTOR PIN-OUTSDR

KNOCK SENSOR (3.7L) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 K42 18DB/YL KNOCK SENSOR NO. 1 SIGNAL
2 K942 18BR/LG KNOCK SENSOR NO. 1 RETURN
3 K242 18BR/WT KNOCK SENSOR NO. 2 SIGNAL
4 K924 18WT/BR KNOCK SENSOR NO. 2 RETURN
KNOCK SENSOR-LEFT (5.7L)-2WAY
CAV CIRCUIT FUNCTION
1 K42 18DB/YL KNOCK SENSOR NO. 1 SIGNAL
2 K942 18BR/LG KNOCK SENSOR NO. 1 RETURN
KNOCK SENSOR-RIGHT (5.7L)-2WAY
CAV CIRCUIT FUNCTION
1 K242 18BR/WT KNOCK SENSOR NO. 2 SIGNAL
2 K924 18WT/BR KNOCK SENSOR NO. 2 RETURN
LICENSE LAMP-LEFT-2WAY
CAV CIRCUIT FUNCTION
1 L7 18WT/YL FUSED PARK LAMP RELAY OUTPUT
2 Z367 18BK/BR GROUND
LICENSE LAMP-RIGHT-2WAY
CAV CIRCUIT FUNCTION
1 L7 18WT/YL FUSED PARK LAMP RELAY OUTPUT
2 Z367 18BK/BR GROUND
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 77

LIFT PUMP MOTOR (DIESEL)-2WAY
CAV CIRCUIT FUNCTION
1 N2 18DB/YL LIFT PUMP FEED
2 Z816 18BK GROUND
LINE PRESSURE SENSOR (NGC)-4WAY
CAV CIRCUIT FUNCTION
1 K900 18DB/DG SENSOR GROUND
2 F856 18YL/PK 5 VOLT SUPPLY
3 T38 18YL/BR LINE PRESSURE SENSOR SIGNAL
4- -
LUMBAR MOTOR-DRIVER-2WAY
CAV CIRCUIT FUNCTION
1 P105 12LG LUMBAR MOTOR FORWARD
2 P107 12LG/WT LUMBAR MOTOR REARWARD
LUMBAR MOTOR-PASSENGER-2WAY
CAV CIRCUIT FUNCTION
1 P104 12LG LUMBAR MOTOR FORWARD
2 P106 12LG/WT RIGHT SEAT REAR UP
8W - 80 - 78 8W-80 CONNECTOR PIN-OUTSDR
