MANIFOLD ABSOLUTE PRESSURE SENSOR (NGC) - GRAY 3 WAY
CAV CIRCUIT FUNCTION
1 K1 18VT/BR MAP SIGNAL
2 K900 18DB/DG SENSOR GROUND
2 K900 20DB/DG SENSOR GROUND
3 F856 18YL/PK 5 VOLT SUPPLY
MODE DOOR ACTUATOR 1 (PANEL TO FLOOR)-2WAY
CAV CIRCUIT FUNCTION
1 C34 20DB/LB COMMON DOOR DRIVER
2 C801 20DB/OR MODE DOOR 1 DRIVER
MODE DOOR ACTUATOR 2 (DEFROST TO FLOOR)-2WAY
CAV CIRCUIT FUNCTION
1 C34 20DB/LB COMMON DOOR DRIVER
2 C29 20DB MODE DOOR 2 DRIVER
MULTI-FUNCTION SWITCH - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 G194 20VT/LG WASH/BEAM SELECT SWITCH SIGNAL
2 L900 20WT/YL WIPER/TURN/BEAM SELECT SWITCH RETURN
3 L12 20WT/OR TURN LAMPS SWITCH SIGNAL
4 W52 20BR/YL INTERMITTENT WIPER SWITCH SIGNAL
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 79

NATURAL VACUUM LEAK DETECTION ASSEMBLY (NGC) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 Z910 18BK GROUND
2 K107 18VT/WT NVLD SWITCH SIGNAL
3 K106 18VT/LB NVLD SOLENOID CONTROL
OUTPUT SPEED SENSOR (45RFE) - DK BLUE 2 WAY
CAV CIRCUIT FUNCTION
1 T14 18DG/BR OUTPUT SPEED SENSOR SIGNAL
2 T13 18DG/VT SPEED SENSOR GROUND
OUTPUT SPEED SENSOR (47RE)-2WAY
CAV CIRCUIT FUNCTION
1 T14 18DG/BR OUTPUT SPEED SENSOR SIGNAL
2 T13 18DG/VT SPEED SENSOR GROUND
OVERHEAD MAP/READING LAMP (EXCEPT BASE)-3WAY
CAV CIRCUIT FUNCTION
1 M288 20YL/GY FUSED B(+)
2 Z964 20BK GROUND
3 M22 20YL/OR COURTESY LAMPS DRIVER
8W - 80 - 80 8W-80 CONNECTOR PIN-OUTSDR

OXYGEN SENSOR 1/1 UPSTREAM (NGC) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 K99 18BR/LG O2 1/1 HEATER CONTROL
2 Z42 18BK/LG GROUND
3 K902 18BR/DG O2 RETURN (UP)
4 K41 18DB/LB O2 1/1 SIGNAL
OXYGEN SENSOR 1/2 DOWNSTREAM (NGC)-4WAY
CAV CIRCUIT FUNCTION
1 K299 18BR/WT O2 1/2 HEATER CONTROL
2 Z43 18BK/LB GROUND
3 K904 18DB/DG O2 RETURN (DOWN)
4 K141 18DB/YL O2 1/2 SIGNAL
OXYGEN SENSOR 2/1 UPSTREAM (NGC)-4WAY
CAV CIRCUIT FUNCTION
1 K199 18BR/VT O2 2/1 HEATER CONTROL
2 Z934 18BK GROUND
3 K902 18BR/DG O2 RETURN (UP)
4 K43 18DB/LG O2 2/1 SIGNAL
OXYGEN SENSOR 2/2 DOWNSTREAM (NGC)-4WAY
CAV CIRCUIT FUNCTION
1 K399 18BR/GY O2 2/2 HEATER CONTROL
2 Z992 18BK GROUND
3 K904 18DB/DG O2 RETURN (DOWN)
4 K243 18BR O2 2/2 SIGNAL
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 81

POWERTRAIN CONTROL MODULE C2 (NGC) - ORANGE 38 WAY
CAV CIRCUIT FUNCTION
1 K10 18DB/OR COIL CONTROL NO. 6
2 K16 18DB/YL COIL CONTROL NO. 5
3 K15 18DB/GY COIL CONTROL NO. 4
4 K58 18BR/VT INJECTOR CONTROL NO. 6
5 K38 18BR/OR INJECTOR CONTROL NO. 5
6 K447 18TN/YL (5.7L) ETC MOTOR (+)
7 K18 18DB/OR COIL CONTROL NO. 3
8 K35 18DB/VT (5.7L LIGHT DUTY) EGR SOLENOID CONTROL
9 K17 18DB/TN COIL CONTROL NO. 2
10 K19 18DB/DG COIL CONTROL NO. 1
11 K14 18BR/TN INJECTOR CONTROL NO. 4
12 K13 18BR/LB INJECTOR CONTROL NO. 3
13 K12 18BR/DB INJECTOR CONTROL NO. 2
14 K11 18BR/YL INJECTOR CONTROL NO. 1
15 K922 18BR/DB (5.7L) THROTTLE POSITION SENSOR GROUND
16 - -
17 K199 18BR/VT O2 2/1 HEATER CONTROL
18 K99 18BR/LG O2 1/1 HEATER CONTROL
19 K20 18BR/GY GEN FIELD CONTROL
20 K2 18VT/OR ECT SIGNAL
21 K22 18BR/OR TP NO. 1 SIGNAL
22 K34 18DB/LG (5.7L LIGHT DUTY) EGR SENSOR SIGNAL
23 K1 18VT/BR MAP SIGNAL
24 K942 18BR/LG (EXCEPT 4.7L) KNOCK SENSOR NO. 1 RETURN
25 K42 18DB/YL (EXCEPT 4.7L) KNOCK SENSOR NO. 1 SIGNAL
26 - -
27 K900 18DB/DG SENSOR GROUND
28 K122 18BR/DG (5.7L) TP NO. 2 SIGNAL
28 K961 18BR/VT (EXCEPT 5.7L) IAC RETURN
29 F855 18PK/YL 5 VOLT SUPPLY
30 K21 18DB/LG IAT SIGNAL
31 K41 18DB/LB O2 1/1 SIGNAL
32 K904 18DB/DG O2 RETURN (DOWN)
33 K43 18DB/LG O2 2/1 SIGNAL
34 K44 20DB/GY CMP SIGNAL
35 K24 20BR/LB CKP SIGNAL
36 K242 18BR/WT (EXCEPT 4.7L) KNOCK SENSOR NO. 2 SIGNAL
37 K924 18WT/BR (EXCEPT 4.7L) KNOCK SENSOR NO. 2 RETURN
38 K448 18TN/OR (5.7L) ETC MOTOR (-)
38 K61 18VT/GY (EXCEPT 5.7L) IAC MOTOR CONTROL
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 89

POWERTRAIN CONTROL MODULE C3 (NGC) - WHITE 38 WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3 K51 20BR/WT ASD RELAY CONTROL
4- -
5 V35 20VT/OR (4.7L) S/C VENT CONTROL
6 K173 18BR/VT CONDENSER FAN RELAY CONTROL
7 V32 20VT/YL (4.7L) S/C POWER SUPPLY
8 K106 18VT/LB NVLD SOLENOID CONTROL
9 K299 18BR/WT O2 1/2 HEATER CONTROL
10 K399 18BR/GY O2 2/2 HEATER CONTROL
11 C13 20LB/OR A/C CLUTCH RELAY CONTROL
12 V36 20VT/YL (4.7L) S/C VACUUM CONTROL
13 - -
14 V32 20VT/YL (5.7L) BRAKE SWITCH NO. 2 SIGNAL
15 V937 20VT/BR (5.7L) S/C SWITCH RETURN
16 K167 20BR/YL (5.7L) APPS NO. 1 RETURN
17 K400 20BR/VT (5.7L) APPS NO. 2 RETURN
18 V38 20VT/OR (5.7L) S/C SWITCH NO. 2 SIGNAL
19 K342 16BR/WT ASD RELAY OUTPUT
20 K52 18DB/WT EVAP PURGE CONTROL
21 T41 20YL/DB TRS T41 SENSE
22 G113 18VT PTO SWITCH SENSE
23 B29 20DG/WT BRAKE SWITCH SIGNAL
24 - -
25 K23 20BR/WT (5.7L) APPS NO. 1 SIGNAL
26 - -
27 - -
28 K342 16BR/WT ASD RELAY OUTPUT
29 K70 18DB/BR EVAP PURGE RETURN
30 K66 18DB/WT P/S SWITCH SIGNAL
31 - -
32 K25 18DB/VT BATT TEMP SIGNAL
33 N4 18DB/WT (3.7L/4.7L) FUEL LEVEL SENSOR SIGNAL
33 N4 20DB/WT (5.7L) FUEL LEVEL SENSOR SIGNAL
34 V37 20VT S/C SWITCH NO. 1 SIGNAL
35 K107 18VT/WT NVLD SWITCH SIGNAL
36 K29 20WT/BR (5.7L) APPS NO. 2 SIGNAL
37 K31 20BR FUEL PUMP RELAY CONTROL
38 T752 20DG/OR STARTER RELAY CONTROL
8W - 80 - 90 8W-80 CONNECTOR PIN-OUTSDR

POWERTRAIN CONTROL MODULE C4 (NGC) - GREEN 38 WAY
CAV CIRCUIT FUNCTION
1 T60 18YL/GY OVERDRIVE SOLENOID CONTROL
2 T259 18YL/DG 4C SOLENOID CONTROL
3- -
4 T118 18DG MS SOLENOID CONTROL
5- -
6 T219 18YL/LG 2C SOLENOID CONTROL
7- -
8 T59 18YL/LB UNDERDRIVE SOLENOID CONTROL
9- -
10 T20 18DG/WT L/R SOLENOID CONTROL
11 T140 18YL/GY PRESSURE CONTROL SOLENOID CONTROL
12 Z908 18BK GROUND
13 Z977 18BK GROUND
14 Z904 18BK (A/T) GROUND
15 T1 18DG/LB TRS T1 SENSE
16 T3 18DG/DB TRS T3 SENSE
17 T6 18DG TOW/HAUL OVERDRIVE OFF SWITCH SENSE
18 T515 20YL/DB TRANSMISSION CONTROL RELAY CONTROL
19 T16 18YL/OR TRANSMISSION CONTROL RELAY OUTPUT
20 T48 18BR/YL 4C PRESSURE SWITCH SENSE
21 T29 18YL/WT UNDERDRIVE PRESSURE SWITCH SENSE
22 T9 18DG/TN OVERDRIVE PRESSURE SWITCH SENSE
23 - -
24 - -
25 - -
26 T4 18DG/LB TRS T2 SENSE
27 - -
28 T16 18YL/OR TRANSMISSION CONTROL RELAY OUTPUT
29 T50 18YL/TN LOW/REVERSE PRESSURE SWITCH SENSE
30 T147 18DG/YL 2C PRESSURE SWITCH SENSE
31 T38 18YL/BR LINE PRESSURE SENSOR SIGNAL
32 T14 18DG/BR OUTPUT SPEED SENSOR SIGNAL
33 T52 18DG/OR INPUT SPEED SENSOR SIGNAL
34 T13 18DG/VT SPEED SENSOR GROUND
35 T54 18DG/OR TRANSMISSION TEMPERATURE SENSOR SIGNAL
36 - -
37 T42 18DG/YL TRS T42 SENSE
38 T16 18YL/OR TRANSMISSION CONTROL RELAY OUTPUT
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 91

SEAT BELT SWITCH-DRIVER-2WAY
CAV CIRCUIT FUNCTION
1 Z951 20BK GROUND
2 G10 20VT/LG SEAT BELT SWITCH SENSE
SEAT BELT TENSIONER REDUCER (STANDARD CAB)-2WAY
CAV CIRCUIT FUNCTION
1 F983 20PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
2 G10 20VT/LG SEAT BELT SWITCH SENSE
SEAT BELT TENSIONER-DRIVER-2WAY
CAV CIRCUIT FUNCTION
1 R55 20LG/DG DRIVER SEAT BELT TENSIONER LINE 1
2 R53 20LG/YL DRIVER SEAT BELT TENSIONER LINE 2
SEAT BELT TENSIONER-PASSENGER-2WAY
CAV CIRCUIT FUNCTION
1 R54 20LB/YL PASSENGER SEAT BELT TENSIONER LINE 2
2 R56 20LB/DG PASSENGER SEAT BELT TENSIONER LINE 1
SEAT HEATER INTERFACE MODULE - GREEN 14 WAY
CAV CIRCUIT FUNCTION
1 P7 20LG/DG DRIVER SEAT HEATER MUX SWITCH
2 P89 20LG/OR SEAT HEATER DRIVER
3 P188 18LG/VT PASSENGER SEAT TEMPERATURE SENSOR INPUT
4 A930 18RD FUSED B(+)
5 P187 18LG/BR DRIVER SEAT TEMPERATURE SENSOR INPUT
6 A930 18RD FUSED B(+)
7 P54 20OR/LG PASSENGER SEAT TEMPERATURE 5 VOLT SUPPLY
8 P53 20LG/OR DRIVER SEAT TEMPERATURE 5 VOLT SUPPLY
9 P8 20LG/WT PASSENGER SEAT HEATER MUX SWITCH
10 P82 20TN/DG PASSENGER SEAT LOW HEAT LED DRIVER
11 P84 20TN/VT PASSENGER SEAT HIGH HEAT LED DRIVER
12 P81 20TN/LB DRIVER SEAT LOW HEAT LED DRIVER
13 Z951 20BK GROUND
14 P83 20TN/WT DRIVER SEAT HIGH HEAT LED DRIVER
8W - 80 - 94 8W-80 CONNECTOR PIN-OUTSDR

SENTRY KEY IMMOBILIZER MODULE (SKIM) - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1- -
2 D25 20WT/VT PCI BUS
3- -
4 F202 20PK/GY FUSED IGNITION SWITCH OUTPUT (RUN-START)
5 Z120 20BK/WT GROUND
6 A919 20RD FUSED B(+)
SIDE IMPACT SENSOR-LEFT-4WAY
CAV CIRCUIT FUNCTION
1 R13 20LG/TN LEFT SIDE IMPACT SENSOR 1 SIGNAL
2 R15 20LG/BR LEFT SIDE IMPACT SENSOR 1 GROUND
3- -
4- -
SIDE IMPACT SENSOR-RIGHT-4WAY
CAV CIRCUIT FUNCTION
1 R14 20TN/LG RIGHT SIDE IMPACT SENSOR 1 SIGNAL
2 R16 20BR/LG RIGHT SIDE IMPACT SENSOR 1 GROUND
3- -
4- -
SPEAKER-CENTER INSTRUMENT PANEL-2WAY
CAV CIRCUIT FUNCTION
1 X299 18GY/YL LEFT INSTRUMENT PANEL SPEAKER (-)
2 X208 18GY/DG RIGHT INSTRUMENT PANEL SPEAKER (+)
SPEAKER-LEFT FRONT DOOR - WHITE 3 WAY
CAV CIRCUIT FUNCTION
1 X155 18DG/LB LEFT FRONT DOOR SPEAKER (-)
2- -
3 X153 18DG/YL LEFT FRONT DOOR SPEAKER (+)
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 95

TAIL/STOP/TURN SIGNAL LAMP-LEFT-6WAY
CAV CIRCUIT FUNCTION
1 L7 18WT/YL FUSED PARK LAMP RELAY OUTPUT
2- -
3 Z928 18BK GROUND
4 L53 18DG/WT LEFT STOP LAMP FEED
5 L63 18WT/DG LEFT REAR TURN LAMP DRIVER
6 L1 18WT/LG BACKUP LAMP FEED
TAIL/STOP/TURN SIGNAL LAMP-RIGHT - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1 L70 18WT/GY FUSED PARK LAMP RELAY OUTPUT
1 L70 18WT/YL FUSED PARK LAMP RELAY OUTPUT
2- -
3 Z928 18BK GROUND
4 L54 18DG/WT RIGHT STOP LAMP FEED
4 L54 18WT/LG RIGHT STOP LAMP FEED
5 L62 18WT/YL RIGHT REAR TURN LAMP DRIVER
5 L62 18WT/DG RIGHT REAR TURN LAMP DRIVER
6 L1 18WT/LG BACKUP LAMP FEED
TAILGATE LAMP-2WAY
CAV CIRCUIT FUNCTION
1 L7 18WT/YL FUSED PARK LAMP RELAY OUTPUT
2 Z942 20BK GROUND
THROTTLE POSITION SENSOR (3.7L)-3WAY
CAV CIRCUIT FUNCTION
1 F855 18PK/YL 5 VOLT SUPPLY
2 K900 18DB/DG SENSOR GROUND
3 K22 18BR/OR TP NO. 1 SIGNAL
8W - 80 - 98 8W-80 CONNECTOR PIN-OUTSDR

THROTTLE POSITION SENSOR (4.7L)-3WAY
CAV CIRCUIT FUNCTION
1 F855 18PK/YL 5 VOLT SUPPLY
2 K22 18BR/OR TP NO. 1 SIGNAL
3 K900 18DB/DG SENSOR GROUND
TOW/HAUL OVERDRIVE SWITCH - WHITE 2 WAY
CAV CIRCUIT FUNCTION
1 T6 20DG TOW/HAUL OVERDRIVE OFF SWITCH SENSE
2 Z71 20LB/BK GROUND
TRAILER TOW CONNECTOR-4WAY
CAV CIRCUIT FUNCTION
1 Z999 14BK GROUND
2 L678 18BR PARK LAMP RELAY OUTPUT
3 L673 18YL TRAILER TOW LEFT TURN RELAY OUTPUT
4 L674 18LG TRAILER TOW RIGHT TURN RELAY OUTPUT
TRAILER TOW CONNECTOR-ADD ON - 10 WAY
CAV CIRCUIT FUNCTION
1- -
2 L674 18LG TRAILER TOW RIGHT TURN RELAY OUTPUT
3 L1 18WT/LG BACKUP LAMP FEED
4 A100 14RD/VT FUSED B(+)
5 L678 18BR PARK LAMP RELAY OUTPUT
6- -
7 B40 14DG TRAILER TOW BRAKE B(+)
8 Z999 14BK GROUND
9 Z999 14BK GROUND
10 L673 18YL TRAILER TOW LEFT TURN RELAY OUTPUT
