check transmission fluid DODGE RAM 1500 GAS 2004 3.G Owners Manual
[x] Cancel search | Manufacturer: DODGE, Model Year: 2004, Model line: RAM 1500 GAS, Model: DODGE RAM 1500 GAS 2004 3.GPages: 429, PDF Size: 7.52 MB
Page 320 of 429
NMaintenance Free Battery................337
NAir Conditioner Maintenance.............338
NPower Steering Ð Fluid Check............339
NFront Suspension Ball Joints..............340
NSteering Linkage Ð Inspection............341
NHalf-Shaft Constant Velocity Joints.........341
NBody Lubrication.....................341
NWindshield Wiper Blades................342
NWindshield Washers...................342
NExhaust System......................343
NCooling System.......................344
NHoses And Vacuum/Vapor Harnesses.......347
NBrake System........................348NClutch Hydraulic System................349
NClutch Linkage.......................350
NPropeller Shaft Universal Joints...........350
NRear Axle And 4X4 Front Driving Axle
Fluid Level..........................350
NTransfer Case........................351
NManual Transmission..................351
NAutomatic Transmission................352
NFront Wheel Bearings..................355
NSelection Of Lubricating Grease...........356
NNoise Control System Required Maintenance &
Warranty For 3500 2-Wheel Drive And 4-Wheel
Drive Models Over 10,000 Lbs. (4 535 Kg) Gross
Vehicle Weight Rating...................356
320 MAINTAINING YOUR VEHICLE
Page 351 of 429
NOTE:The presence of water in the gear lubricant will
result in corrosion and possible failure of differential
components. Operation of the vehicle in water, as may be
encountered in some off-highway types of service, will
require draining and refilling the axle to avoid damage.
Limited-Slip Differentialsin 1500 Model vehicles re-
quire that 4 oz. (118 ml) Mopartlimited slip additive be
added to the gear lubricant. Refer to Recommended
Fluids, Lubricants and Genuine Parts for correct fluid
type. The Mopartlimited slip additive should be added
to the gear lubricant whenever a fluid change is made.
Ram 2500/3500 Model AxlesDO NOT REQUIREany
limited slip oil additive (friction modifiers).Transfer Case
Fluid Level Check
This fluid level can be checked by removing the filler
plug. The fluid level should be to the bottom edge of the
filler plug hole with the vehicle in a level position.
Lubricant Selection
Refer to Recommended Fluids, Lubricants and Genuine
Parts for correct fluid type.
Manual Transmission
Fluid Level Check
This fluid level can be checked by removing the filler
plug. If the level of the lubricant is more than 1/4º (6.4
mm) below the bottom of the filler hole while the vehicle
is on level ground, enough lubricant should be added to
bring the level to the bottom of the filler hole.
MAINTAINING YOUR VEHICLE 351
7
Page 352 of 429
Lubricant Selection NV-3500 (5-Speed Manual
Transmission Ð If Equipped)
This transmission is filled with manual transmission
fluid at the factory. This fluid does not require periodic
changing. If it is necessary to add or change fluid in this
transmission refer to Recommended Fluids, Lubricants
and Genuine Parts for correct fluid type. This is the only
lubricant recommended for use in the NV-3500 transmis-
sion.
Lubricant Selection NV-4500 (5-Speed Manual
Transmission Ð If Equipped)
This transmission does not require periodic changing. If
it becomes necessary to add or change the fluid in this
transmission, refer to Recommended Fluids, Lubricants
and Genuine Parts for correct fluid type.
Automatic Transmission
Fluid Level Check
The fluid level should be checked when the engine is
fully warmed up and the fluid in the transmission is at
normal operating temperature. Operation of the trans-
mission with an improper fluid level will greatly reduce
the life of the transmission and of the fluid. Check the
fluid level whenever the vehicle is serviced.
Fluid Level Check ± 45RFE/545RFE
Check the fluid level while the transmission is at normal
operating temperature 82ÉC (180ÉF). This occurs after at
least 15 miles (25 km) of driving. At normal operating
temperature the fluid cannot be held comfortably be-
tween the fingertips.
352 MAINTAINING YOUR VEHICLE
Page 353 of 429
To check the automatic transmission fluid level properly,
the following procedure must be used:
1. Operate the engine at idle speed and normal operating
temperature.
2. The vehicle must be on level ground.
3. Fully apply the parking brake and press the brake
pedal.
4. Place the gear selector momentarily in each gear
position ending with the lever in P (Park).
5. Remove the dipstick, wipe it clean and reinsert it until
seated.
6. Remove the dipstick again and note the fluid level on
both sides. The fluid level should be between the ªHOTº
(upper) reference holes on the dipstick at normal operat-
ing temperature. Verify that solid coating of oil is seen on
both sides of the dipstick. If the fluid is low, add asrequired into the dipstick tube.Do not overfill.After
adding any quantity of oil through the oil fill tube, wait
a minimum of two (2) minutes for the oil to fully drain
into the transmission before rechecking the fluid level.
NOTE:If it is necessary to check the transmissionbelow
the operating temperature, the fluid level should be
between the two ªCOLDº (lower) holes on the dipstick
with the fluid at approximately 70ÉF (21ÉC) (room tem-
perature). If the fluid level is correctly established at
room temperature, it should be between the ªHOTº
(upper) reference holes when the transmission reaches
180ÉF (82ÉC). Remember it is best to check the level at the
normal operating temperature.
MAINTAINING YOUR VEHICLE 353
7
Page 354 of 429
CAUTION!
Be aware that if the fluid temperature is below 50ÉF
(10ÉC) it may not register on the dipstick. Do not add
fluid until the temperature is elevated enough to
produce an accurate reading.
7. Check for leaks. Release parking brake.
To prevent dirt and water from entering the transmission
after checking or replenishing fluid, make certain that the
dipstick cap is properly reseated. It is normal for the
dipstick cap to spring back slightly from its fully seated
position, as long as its seal remains engaged in the
dipstick tube.
Selection Of Lubricant
Refer to Recommended Fluids, Lubricants and Genuine
Parts for correct fluid type. It is important that the
transmission fluid be maintained at the prescribed level
using the recommended fluid.
CAUTION!
Using a transmission fluid other than the manufac-
turers recommended fluid may cause deterioration
in transmission shift quality and/or torque converter
shudder. Using a transmission fluid other than the
manufacturers recommended fluid will result in
more frequent fluid and filter changes. Refer to
Recommended Fluids, Lubricants and Genuine Parts
for correct fluid type.
354 MAINTAINING YOUR VEHICLE
Page 386 of 429
At Each Stop for Fuel
²Check the engine oil level about 5 minutes after a fully
warmed engine is shut off. Checking the oil level while
the vehicle is on level ground will improve the accu-
racy of the oil level reading. Add oil only when the
level is at or below the ADD or MIN mark.
²Check the windshield washer solvent and add if
required.
Once a Month
²Check tire pressure and look for unusual wear or
damage.
²Inspect the battery and clean and tighten the terminals
as required.
²Check the fluid levels of coolant bottle, brake master
cylinder, and transmission and add as needed.
²Check all lights and all other electrical items for correct
operation.
At Each Oil Change
²Change the engine oil filter.
²Inspect the exhaust system.
²Inspect the brake hoses.
²Inspect the CV joints (if equipped) and front suspen-
sion components.
²Check the automatic transmission fluid level.
²Check the manual transmission fluid level.
²Check the coolant level, hoses, and clamps.
Tire Rotation
²Rotate the tires at 6,000 miles (10 000 km).
386 MAINTENANCE SCHEDULES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
Page 414 of 429
Adding Fuel........................259,295
Air Cleaner, Engine...................334,357
Air Conditioner Maintenance............327,338
Air Conditioning Refrigerant.......327,328,338,339
Air Conditioning System.............187,327,338
Air Conditioning System, Zone Control........ 191
Air Pressure, Tires....................244,251
Airbag..............................45,50
Airbag Light.........................70,144
Airbag On/Off Switch..................... 50
Airbag, Side............................ 53
Alarm..............................29,147
Alignment and Balance................... 250
Alterations/Modifications, Vehicle............. 7
Antifreeze (Engine Coolant)..............346,379
Anti-Lock Brake System................... 231
Anti-Lock Warning Light...............148,232
Anti-Theft System.....................29,147
Appearance Care........................ 361Ashtray............................... 127
Automatic Transmission
Adding Fluid......................... 353
Fluid and Filter Changes................. 355
Fluid Level Check...................... 352
Fluid Type........................354,382
Shift Indicator........................ 147
Shifting............................. 208
Special Additives...................... 355
Axle Fluid.......................272,350,382
Axle Lubrication.....................272,350
Ball Joints............................. 340
Battery............................... 337
Emergency Starting..................... 312
Bearings.............................. 355
Belts, Drive............................ 333
Belts, Seat.............................. 34
Body Mechanism Lubrication............... 341
414 INDEX
Page 418 of 429
Exhaust System.......................69,343
Exterior Lighting........................ 101
Filters
Air Cleaner........................334,357
Engine Fuel.......................... 334
Engine Oil........................333,381
Engine Oil Disposal.................... 332
Flashers
Turn Signal.......................... 103
Flat Tire Stowage.....................301,311
Flexible Fuel Vehicles
Cruising Range........................ 265
Engine Oil........................... 264
Fuel Requirements..................262,263
Maintenance.......................... 265
Replacement Parts..................... 265
Starting............................. 265
Flooded Engine Starting................... 206Fluid, Brake........................... 382
Fluid Capacities......................... 379
Fluid Level Checks
Automatic Transmission................. 352
Power Steering........................ 339
Fog Lights..........................102,378
Fold Flat Load Floor..................... 130
Four Wheel Drive....................... 216
Four-Way Hazard Flasher.................. 294
Freeing A Stuck Vehicle................... 316
Front Axle............................. 350
Front Wheel Bearings..................... 355
Fuel................................. 256
Adding............................. 259
Filter............................... 334
Gauge.............................. 150
Octane Rating......................256,381
Requirements......................256,379
Tank Capacity........................ 379
418 INDEX
Page 422 of 429
Lumbar Support......................... 94
Maintenance........................... 327
Maintenance Free Battery.................. 337
Maintenance Procedures................... 327
Maintenance Schedule.................... 384
Schedule9A9......................... 397
Schedule9B9.......................... 387
Malfunction Indicator Light................ 325
Manual, Service......................... 410
Manual Transmission..................213,351
Fluid Level Check...................... 351
Lubricant Selection..................352,382
Shift Speeds.......................214,216
Mirrors................................ 75
Automatic Dimming..................... 76
Electric Powered....................... 77
Outside.............................. 76
Rearview............................. 75Trailer Towing......................79,278
Modifications/Alterations, Vehicle............. 7
Mopar Parts.........................327,409
Multi-Function Control Lever............... 103
Noise Control
Maintenance.......................... 356
Tampering Prohibited................356,357
Noise Emission Warranty.................. 358
Occupant Restraints....................... 33
Octane Rating, Gasoline................... 256
Odometer..........................148,150
Trip .............................148,150
Off-Pavement Driving.................... 291
Off-Road Driving........................ 291
Oil, Engine.........................329,381
Capacity............................ 379
Change Interval....................... 330
422 INDEX
